Outsider FHTA80082A User manual

Questions, problems, or missing parts?
Before returning to the store, call Customer Service.
8am - 5pm, PST Monday - Friday
Model No. FHTA80082A
B A R B E C U E S
FHTA80082A OUTSIDERBARBECUES . C O M
866-292-8800
RETAIN THIS MANUAL FOR FUTURE USE.
A S S E M B L Y I N S T R U C T I O N S
I N S T R U C T I O N S D E M O N T A G E
G U Í A D E L P R O D U C T O
BAR COUNTER

IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
P L E A S E D O NOT RE T U R N T O T H E R E T A I L E R / S T O R E
from where you purchased the product.
Please call our Toll-Free Customer Service Hotline at:
1-866-292-8800
To expedite any future warranty claims, please retain the instruction sheet and
receipt for future use.
SAFETY INSTRUCTION S
SAFETY SYMBOLS
IMP O RTANT: RETAIN FO R F U T U R E REF E RENCE, AND R E A D C A R E F ULL Y .
THIS PR O DUCT IS FOR OUTDO O R U S E O N L Y .
C A U T I O N DANGE R
Indicates a potentially
hazardous situation or
unsafe practice which, if not
avoided, may result in minor
or moderate injury.
Indicates a imminently
hazardous situation which, if
not avoided, will result in
death or serious injury.
WARNIN G
Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
OUTSIDERBARBECUES.COM866-292-8800
FHTA80082A

PARTS LIST
Key Qty Description
AA 10 M6*15
BB 8 M6*35
FF 1 Leveler
GG 1 Allen Wrench
1 1 Countertop
OUTSIDERBARBECUES. CO M866-292-8800
CC 7 Washer
DD 7 Nut
EE 3 Adjusting Knob
1
2
3
4
5
67
Washer
x 10AA
BB x 8
CC x 7
DD x 7
EE x 3
M6*15
M6*35
FF x 1
GG x 1
Wrench
Allen wrench
Nut
Adjusting knob
FHTA80082A
2 1 Side Panel A
3 1 Back Panel
4 1 Side Panel C
5 1 Tube-1
6 1 Footrest
71 Footrest Support

LEVELING THE CABIN E T S
I M P O RTANT:
Leveling the cabinets is the most important part of installation, to ensure doors align properly and
countertop sets evenly. Cabinets need to be level and square. Each cabinet features levelers at
the corners that can be adjusted to acheive a perfectly level countertop. Turn levelers clockwise
to raise the height of the cabinet, and counter-clockwise to reduce the height.
L E V E L I N G Y O U R CABINETS
Be sure to level your cabinets in all three directions:
1. Front to Back
2. Vertically
3. Horizontally
OUTSIDERBARBECUES.COM866-292-8800FHTA80082A
1
2
3

ASSEMBLY
S T E P 1
Requires: EE, 2
OUTSIDERBARBECUES.COM866-292-8800
EE
FHTA80082A
2
AD D L E V E L E R S T 0 B 0 T T O M O F B A C K P A N E L
Add levelers (EE) to the bottom of the back panel (2). Repeat 3 times.

ASSEMBLY
S T E P 2
Requires: CC, DD, 1, 2
OUTSIDERBARBECUES.COM866-292-8800
DD
CC
FHTA80082A
2
1
ATTACH T H E BAC K P A N E L T O T H E C O U N T E R T O P
Place countertop upside down on soft surface, such as cardboard or a blanket.
Ask someone to help you hold the back panel (2) in place as you connect it to the countertop.
Connect the back panel (2) to the countertop (1) using washers (CC) and nuts (DD).

ASSEMBLY
S T E P 3
Requires:
Attach side panel B (3) and side panel C (4) to the countertop (1) and back panel (2)
using bolts (BB), washers (CC), and nuts (DD).
BB
DD
CC
OUTSIDERBARBECUES.COM866-292-8800
FHTA80082A
3
1
4
2
A T T A C H T H E S I D E P A N E L S
BB, CC, DD, 1, 2, 3, 4

ASSEMBLY
S T E P 4
Requires: AA, CC, DD, 1, 3, 4, 5
Attach tube-1 (5) to the countertop (1) using bolts (AA), washers (CC), and nuts (DD)...
AA
DD
CC
OUTSIDERBARBECUES.COM
866-292-8800
FHTA80082A
3
4
1
5
A T T A C H T H E R T T O T H E C O U N T E R T O PS U P P O

ASSEMBLY
S T E P 5
Requires:AA, 3, 4, 6
Attach the footrest (6) to side panel B (3) and side panel C (4) using bolts (AA)..
AA
AA
OUTSIDERBARBECUES.COM
866-292-8800
FHTA80082A
6
4
3
A T T A C H T H E R E S T T O T H E S I D E P A N E L SF O OT

ASSEMBLY
S T E P 6
Requires:AA, 6, 7
Attach the footrest support (7) to the footrest (6) using bolts (AA)..
AA
AA AA
AA
OUTSIDERBARBECUES.COM
866-292-8800
FHTA80082A
76
A T T A C H T H E S T S U P P O R T T O T H E F O O T R E S TF O OT R E

ASSEMBLY
S T E P 7
Requires: 1, BB
Connect three cabinets together
using
bolts (BB).
BB
OUTSIDERBARBECUES.COM866-292-8800
FHTA80082A
Bar Counter MUST be properly secured to two additional leveled Outsider
cabinets or bar counter will tip over, which could cause serious injury or death.
DANGER

CARE AND MAINTENANCE
CLEANING & MAINTENANCE
FHTA80082 A OUTSIDERBARBECUES.COM 866-292-8800

WARRANTY
LIMITE D WARRANTY P R O G R A M
FHTA80082 A O UTSIDERBARBECUES.COM866-292-8 8 0 0
The Manufacturer will either repair or replace defective components in accordance with this Limited
Warranty, according the scope and period below:
SCOPE OF COVERAGE PERIOD OF COVERAGE TYPE OF FAILURE COVERAGE
dna,gnirutcafunam,noitarofrePsraey)net(01srenruBsselniatS
material defects only.
Firebox, Hood, Cooking Grates 3 (three) years
Cabinet Frames (not including
countertops and hardware)
5 (five) years
Chair Frames and Fabric 5 (five) years
All other parts 1 (one) year
This warranty is between the Manufacturer and the original purchaser and is valid only when
accompanied by the original purchaser’s sales receipt showing original date of purchase and location of
purchase. Replacementsunder this warranty revert back to the date of original purchase for future
warranty.
The Manufacturer or its authorized dealer can accept or reject warranty claims based on its findings.
This warranty applies in normal residential use only and is not intended for commercial use. The
Manufacturer can make substitutions as required of materials, components, and sub-components of
comparable value and utility. This warranty is limited to product repair or replacement (to be
determined solely by the Manufacturer). Warranty return is limited to only the single affected
component.
This limited warranty covers only manufacturing defects and does not cover normal wear and tear,
damage due to acts of nature (such as, but not limited to freezing or high winds), abuse or misuse,
including chemical damage from suntan oil or other chemicals, exposure to extreme heat or cold,
abrasion or excessive weight. This product is intended to be used in standard installations only. This
warranty is void if the product is not used for itsintended purpose. The Manufacturer disclaims liability
for any aspect of installation and any inconvenience caused by a defective part of a component.
Certain items are not covered by this warranty. These include, but are not limited to the following:
1. Components subjected to abuse, including abuse intended to simulate failure.
2. Damages caused by retailer, shipper or installation crew (such as scratches, dents, tears, chips, etc.).
3. Any part which merely exhibits normal wear yet functions essentially as new, including chips,
scratches or stretching of materials and stitching.
4. Tears, punctures, scratches or any damage caused by improper installation or use.
5. Damage to frames/welds resulting from improper assembly or exposure to water and/or sub-freezing
temperatures is not covered. General frame rusting is not covered.
6. Fading and/or discoloration of fabrics/cushions/straps/wicker resulting from exposure to the
elements, chemicals, oils, fluids or any other cause are not covered.
7. Umbrella bases are not covered under any circumstances.
8. Items sold ‘‘as is’’ or floor models.
To make a claim, call the toll-free number below. Please have available a copy of the original sales
receipt along with a brief description of the problem. Please also provide your email address and
daytime telephone or cell phone number. All items may be charged actual freight costs plus $15 for
handling. Repairs or replacement will be made at the Manufacturer’s option. Sales and use taxes, plus
shipping and handling charges are the responsibility of the consumer.
THIS IS THE ENTIRE EXCLUSIVE EXPRESS LIMITED LIABILITY. THE MANUFACTURER NEITHER MAKES NOR
IS RESPONSIBLE FOR ANY OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING THOSE OF
RETAILING DEALERS. THIS EXCLUSIVE REMEDY IS LIMITED TO RECEIPT OF A CREDIT IN CONNECTION
WITH THE REPAIR OR REPLACEMENT OF ANY PRODUCT OR COMPONENT DEEMED TO BE DEFECTIVE
UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER THE PRODUCT
MANUFACTURER NOR ITS AGENTS SHALL BE LIABLE IN ANY CASE FOR INCIDENTAL, INDIRECT, SPECIAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING OUT OF ANY
BREACH OF THIS
WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES,
EXCEPT AS OTHERWISE MAY BE REQUIRED BY LAW, THERE ARE NO OTHER EXPRESS OR IMPLIED
WARRANTIES OTHER THAN THE WARRANTY DESCRIBED HEREIN, AND ALL OTHER WARRANTIES,
INCLUDING IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE
EXPRESSLY DISCLAIMED.
