OV Solutions IPC-600P User manual

1
IPC-600P
Installation guide
Hardware Overview
Network Side
Interface:
Ethernet: RJ45
Coax: BNC
DC Input: DC Jack
Green LED: Ethernet communication status
range LED: Coax communication status
Camera Side
Interface:
Ethernet: RJ45
Coax: BNC
DC Input: DC Jack
Green LED: Ethernet communication status
range LED: Coax communication status

2
Configuration xamples
PoE Powered solution:
Install steps:
1. First, insert one end of an Ethernet cable to IP Camera and insert the other
end into Ethernet port of IPC-600PR.
2. Connect a coaxial cable between the IPC-600PT and the IPC-600PR.
3. Insert one end of an Ethernet cable to into Ethernet port of IPC-600PT and
insert the other end into your P E Ethernet Switch or P E Injector.
External power supply with non-PoE switch solution:
Install steps:
1. First, insert one end of an Ethernet cable to IP Camera and insert the other
end into Ethernet port of IPC-600PR.
2. Connect a coaxial cable between the IPC-600PT and the IPC-600PR.
3. Insert one end of an Ethernet cable to into Ethernet port of IPC-600PT and
insert the other end into your NVR (or computer).
4. Finally, connect the power adapter’s cord into the DC input of the IPC-600PT
and plug AC plug to power source (such as a wall socket or power strip).

3
Multi IPC-600PR application solution:
Install steps:
1. First, insert one end of an Ethernet cable to IP Camera and insert the other
end into Ethernet port of IPC-600PR.
2. Connect a coaxial cable between a Splitter output and the IPC-600PR.
3. Install others IP Camera and IPC-600PR such setp1 and step2.
4. Connect a coaxial cable between the Splitter input and the IPC-600PT
5. Insert one end of an Ethernet cable to into Ethernet port of IPC-600PT and
insert the other end into your NVR (or computer).
6. Finally, connect the power adapter’s cord into the DC input of the IPC-600PT
and plug AC plug to power source (such as a wall socket or power strip).
Camera side local power solution:
Install steps:
1. First, insert one end of an Ethernet cable to IP Camera and insert the other
end into Ethernet port of IPC-600PR.
2. Connect a coaxial cable between the IPC-600PT and the IPC-600PR.
3. Insert one end of an Ethernet cable to into Ethernet port of IPC-600PT and
insert the other end into your NVR (or computer).
4. Connect the power adapter’s cord into the DC input of the IPC-600PT and
plug AC plug to power source (such as a wall socket or power strip).
5. Finally, connect the power adapter’s cord into the DC input of the IPC-600PR
and plug AC plug to power source (such as a wall socket or power strip).

4
3. Optional Accessories
1. 56V DC Power adapter (IPC-600P-PW)
2. Rack mount (IPC-600PK)
3. Mounting Tabs 4. 4Way Power passing splitter
(IPC-600P-MT) (IPC-600P-SP)
IPC-600PK not includes IPC-600P
