OVIS 33531B User manual

33531B King Bed
REV 02
1

CAUTION:
PLEASE CONTACT US FOR QUESTIONS
Email our support team: [email protected]o
2
Do not a empt to slide the bed once it is fully
assembled. To avoid structural damage while moving
your assembled bed, any ma ress and bedding should
be removed from the bedframe. Then the bedframe
should be lied and carried (not slid) to your desired
locaon.
When placing furniture on non-carpeted flooring, we
recommend the use of floor protecon such as an area
rug or furniture pads. Area rugs and padding not
included with purchase.

3
LB
Estimated Time for Assembly
Weight Limitation
25:00 - 35:00
Additional Tools Needed – Phillips Screwdrive.
600 lbs

Remove parts from headboard
compartment
PLEASE CONTACT US FOR QUESTIONS
Email our support team: [email protected]o
4

( L )
( R )
Hardware
Components
1 pc
1 set
1 pc
2 pcs
2 sets
2 pcs
8 pcs
4 pcs
8 pcs
M8X20
J
8 pcs
M6X35
K
6 pcs
M6X50
L
8 pcs
M6X60
M
24 pcs
M4X32
N
8 pcs
M6
O
6 pcs
M6
P
1 pc
M4
Q
1 pc
M5
R
KING BED
2 rolls
( L )
( R )
PACKAGE CONTENT
DO NOT SLIDE BED AFTER
ASSEMBLY. LIFT THE BED FRAME
INTO ITS FINAL POSITION.
CAUTION:
5

1.
6 pcsM6X50
+P
L
P
L
Q
A ach “P” washers to “L” bolt.
Connect the leg “B” to back of headboard “A”.
Use the bolts to a ach.
( L )
( R )
6

2.
7

J
R
8 pcs
M8X20
Thread “J” bolts into the holes
in the headboard and footboard.
Do not ghten. These will be
ghtened in later steps.
J
( L )
( R )
3.
8

K
O
Q
8 pcs
M6X35
+
A ach “O” washers to “K” bolt.
Connect the top and bo om of
each side rail with a “D” side leg.
Use the bolts to a ach.
KO
D
E
E
4.
9
Repeat steps to assemble right side rail.

R
J( L )
( R )
Hang the hooks at the ends of the side rails
onto the “J” bolts in the headboard leg and the
footboard. Do not fully ghten the “J” bolts.
The bolts will be ghtened in a later step.
5.
10
Do not a empt to slide the bed once it is fully
assembled. Sliding the bed could result in
damage to the rails, headboard, or footboard.
Assembled bed should be lied and carried
when being moved. (not slid)
NOTE:

8 pcs
M6X60
M
M
6.
Aer the slat system is assembled, place the slats
into the frame of the bed as shown next page.
11
Repeat steps to assemble the second roll slat.
Assemble the slat system by a aching the slats “G”
to the “I” supports and “H” legs. First, extend the
slats. Then, line up the holes in the slats with the
holes in the “I” supports and the holes in the tops
of the “H” legs. Use an “M” bolt through the holes
to a ach them together.

24 pcs
M4X32
N
Then, use screwdriver to
install“N” screws into
side rail cleat
N
Finally, ghten all “J” bolts.
R
J
7.
12
NEED ADDITIONAL HELP?
Email our support team: [email protected]o
Floor line
Floor Glide
NOTE:
The center support leg glide sits
approximately 1/4" off of the floor. The glide
will touch the floor aer a ma ress is placed
on the bedframe.
Do not place a ma ress on bedframe unl it is
fully assembled and the bedframe located in
your desired locaon. Sliding the bed with
weight upon it can compromise the integrity
of the center support legs.
