EverFocus EDN Series User manual

EDN Series
Mini Indoor IP Dome Camera
User’s Manual
Copyright © EverFocus Electronics Corp,
Release Date: May, 2013

Copyright 2013 EverFocus Electronics Corp.
All rights reserved. No part of the contents of this manual may be reproduced or transmitted in any form or by
any means without written permission of the EverFocus Electronics Corporation.
EverFocus
12F, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, Taipei, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
May, 2013

i
About this document
All the safety and operating instructions should be read and followed before the unit is operated. This
manual should be retained for future reference. The information in this manual was current when
published. The manufacturer reserves the right to revise and improve its products. All specifications are
therefore subject to change without notice.
Regulatory Notices
FCC Notice "Declaration of Conformity Information"
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this equipment, not expressly approved by EverFocus or
parties authorized by EverFocus could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
EverFocus Electronics Corp.
12F, No. 79, Sec. 1, Shin-Tai Wu Rd., Hsi-Chi,
Taipei Hsien, Taiwan, R.O.C.
EDN Series cameras comply with CE and FCC.

ii
Precautions
1. Do not install the camera near electric or magnetic fields.
Install the camera away from TV/radio transmitters, magnets, electric motors, transformers and
audio speakers since the electromagnetic fields generated from these devices may distort the video
image or otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein.
Improper disassembly or introduction of corrosive materials may result in equipment failure or other
damage.
3. Try to avoid facing the camera toward the sun.
In some circumstances, direct sunlight may cause permanent damage to the sensor and/or internal
circuits, as well as creating unbalanced illumination beyond the capability of the camera to
compensate.
4. Keep the power cord away from water and other liquids and never touch the power cord with wet
hands.
Touching a wet power cord with your hands or touching the power cord with wet hands may result in
electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents.
Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning
For cameras with interchangeable lenses, do not touch the surface of the sensor directly with the
hands. Use lens tissue or a cotton tipped applicator and ethanol to clean the sensor and the camera
lens. Use a damp soft cloth to remove any dirt from the camera body. Please do not use complex
solvents, corrosive or abrasive agents for cleaning of any part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source ratings.
This camera is suitable for indoor operation only. Use the camera at temperatures within -10℃~
50℃(14℉~ 122℉) and humidity between 20% and 85%]; this device is not rated as submersible.
The input power source is 12 VDC / PoE. Be sure to connect the proper + / - polarity and voltage, as
incorrect polarity or too high a voltage will likely cause the camera to fail, and such damage is not
covered by the warranty. The use of properly fused or Class 2 power limited type supplies is highly
recommended.
8. Mounting
Use care in selecting a solid mounting surface which will support the weight of the camera plus any
wind, snow, ice or other loading, and securely attach the camera to the mounting surface using
screws and anchors which will properly support the camera. If necessary (e.g. when mounting to
drop ceilings) use a safety wire to provide additional support for the camera.

iii
CONTENTS
1. Introduction .......................................................................................................................... 1
2. Physical Description ............................................................................................................. 2
3. Features ................................................................................................................................. 3
4. Installation ............................................................................................................................ 4
4.1 Packing List ...............................................................................................................................4
4.2 Basic Installation.......................................................................................................................4
5. Accessing the User Interface............................................................................................... 7
5.1 Checking the Dynamic IP Address ............................................................................................7
5.2 Settings for Microsoft Internet Explorer ..................................................................................9
5.3 Connecting the Camera to the Network ................................................................................11
5.4 Live View Window ..................................................................................................................13
6. Playback ............................................................................................................................... 16
6.1 Remote Playback Using Playback Page...................................................................................16
6.2 Setting Up the Playback Function...........................................................................................18
6.2.1 Inserting / Removing the SD Card ..............................................................................18
6.2.2 Testing the Playback Function ....................................................................................19
6.3 Playing Back Using ARV Viewer ..............................................................................................21
7. Settings ................................................................................................................................ 22
7.1 System Settings.......................................................................................................................23
7.1.1 Network......................................................................................................................23
7.1.2 Date / Time.................................................................................................................30
7.1.3 Storage........................................................................................................................31
7.1.4 Display and Overlay ....................................................................................................33
7.1.5 System Maintenance ..................................................................................................34
7.1.6 System Information ....................................................................................................37
7.1.7 User ............................................................................................................................38
7.1.8 Black/White List..........................................................................................................40
7.2 Camera Settings......................................................................................................................41
7.2.1 Streaming and Audio..................................................................................................41
7.2.2 Camera .......................................................................................................................44
7.2.3 Schedule .....................................................................................................................47
7.2.4 Image..........................................................................................................................48

iv
7.3 Event Settings .........................................................................................................................49
7.3.1 Event Wizard...............................................................................................................49
7.3.2 Event...........................................................................................................................50
7.3.3 Notification.................................................................................................................54
7.4 Link to Smart Phone App........................................................................................................57
8. Upgrading Firmware Using IP Utility ............................................................................... 58
9. Specifications ...................................................................................................................... 60
10. Troubleshooting.................................................................................................................. 62

EDN Series Mini Indoor IP Dome
1
1. Introduction
The small form-factor EDN series mini IP dome comes with three models, 1.3 MP, 2 MP and 3 MP, providing
up to 15 fps at 2048 x 1536 viewing resolution. Video compression formats including H.264, MPEG4 and
MJPEG are all supported. Equipped with selectable fixed lens and designed in small form-factor, the cameras
meet a wide variety of needs for indoor surveillance.
The EDN series mini IP dome features the Wide Dynamic Range (WDR) function, which can provide clear
images even under back light circumstances where intensity of illumination can vary excessively. The DNR
(Digital Noise Reduction) function is designed for reducing the noises in the images, allowing the camera to
better distinguish between real motion and image noise, and thus results in a possibility to store more video
evidence on the connected storage devices.
A built-in micro SDHC card slot and Power over Ethernet (IEEE802.3af) features are also provided. You can
power the camera over the network or by connecting the camera to a 12 VDC power supply. Since the EDN
series mini IP dome conforms to ONVIF / PSIA for compatibility with other network video devices, it
interoperates with a wide variety of hardware and software systems. You can also use EverFocus Mobile
Applications to remotely view the live views of the cameras through your handheld devices; or use
EverFocus CMS to remotely manage multiple IP devices connected on the network. The EDN series mini IP
dome is the ideal solution for your surveillance needs.
The EDN Series Mini Indoor IP Dome Models
Model Name Megapixel Fixed Lens (Selectable)
EDN1120
1.3 MP
2.8mm, 3.6mm, 6mm, 8mm
EDN1220
2 MP
EDN1320
3 MP
System Requirement
Before installing, please check that your computer meets the following system requirements.
Operating System: Microsoft Windows XP / Vista (32-bit) / 7 (32-bit)
Microsoft Internet Explorer 7 or above
Note: For using the Internet Explorer, some settings are required. Please refer to 5.2 Settings for
Microsoft Internet Explorer.

EDN Series Mini Indoor IP Dome
2
2. Physical Description
24
13
5
6
7
No. Item Name Descriptions
1 Microphone One built-in microphone.
2 Micro SD / SDHC Slot For inserting a micro SD / SDHC card.
3 Reset Button Resets all configurations to the factory default settings.
4 Test-Out Connector Connects to a handheld monitor for adjusting camera focus and zoom
using the supplied Test-Out Cable.
5 Power Cable Connects to a 12 VDC power.
6 Audio Cable A Line-in cable for connecting to the audio input device.
7 LAN / PoE Cable Connects to a 10/100 Ethernet or PoE.

EDN Series Mini Indoor IP Dome
3
3. Features
1/2.7” progressive scan CMOS (for EDN1120 / 1220)
1/3” progressive scan CMOS (for EDN1320)
Quad streams from H.264, MPEG4 or MJPEG*
Up to 30 fps at 1920 × 1080
Supports 15 fps at 2048 x 1536 (only for EDN1320)
Hallway Display (9:16)
Built-in micro SD / SDHC card slot
Electronic Day / Night
3-axis mechanism (pan / tilt / rotate)
Built-in microphone
TV-out
Wide Dynamic Range (WDR)
Digital Slow Shutter (DSS)
2D / 3D Dynamic Noise Reduction (DNR)
Motion Detection
10x Digital Zoom
Privacy Mask
12 VDC / PoE
Multi-languages on Web interface
ONVIF / PSIA compliant
Supports EverFocus’ CMS and Mobile Applications
* Only EDN1220/1320 models support MPEG4. EDN1120 do not support MPEG4.

EDN Series Mini Indoor IP Dome
4
4. Installation
4.1 Packing List
Please check that there is no missing item in the package before installing.
•Camera x 1 •Power Pigtail Cable x 1
•Long Screw x 2 (with 2 Anchors) •RJ-45 Connector x 1
- for thick surface installation •Mounting Template x 1
•Set Screw x 2 (with 2 Nuts) •Software CD x 1
- for thin surface installation •Quick Installation Guide x 1
•Test-Out Cable (RCA) x 1
Note:
1. Equipment configurations and supplied accessories vary by country. Please consult your local
EverFocus office or agents for more information. Please also keep the shipping carton for
possible future use.
2. Contact the shipper if any items appear to have been damaged in the shipping process.
4.2 Basic Installation
Please follow the steps below to mount the camera to the wall / ceiling.
1. Paste the supplied mounting template onto a desired location on the wall / ceiling. Drill the two
cross marks and insert the supplied two Screw Anchors into the holes. Note that the camera lens
should point to the arrow direction.
Note: Drill another hole on the upper side of the template only if you want to run the cables
into the wall / ceiling.

EDN Series Mini Indoor IP Dome
5
2. Unscrew the two screws to remove the cover.
3. Attach and then screw the camera to the wall / ceiling using the supplied two Long Screws.
Tip: Before tightly screwing the camera to the
wall / ceiling, you can pan the camera base by
±25° to the desired angle.
±25°
4. Thread the cables.
a. From the side cut of the camera case: remove the plug from the camera case first.
Remove the Plug
b. Through the wall / ceiling: run the cables through the hole on the wall / ceiling.

EDN Series Mini Indoor IP Dome
6
5. Connect the network, power and audio cables to the camera.
6. Optionally insert a micro SD / SDHC card to the card slot. See No.2in 2. Physical Description.
7. Access the camera live view. See 5.1 Assigning an IP Address. Or using the supplied Test-Out cable
to connect a monitor to the Test-Out connector (see No.4in 2. Physical Description) of the camera
for adjusting camera angles. You need to loosen the screw before adjusting the angles.
Note: Do Not adjust camera focus yourself as it has already been adjusted (with the dome
cover on) in the factory. It is normal to see the blurry image on the live view when the camera is
connected to a monitor without the dome cover on. The live view image will be focused once
the dome cover has been put back to the camera.
Rotational Adjustment: Loosen the screw and rotate the lens by ± 90°.
± 90°
Screw
Tilt Adjustment: Loosen the screw and tilt the lens by 90°.
90°
Screw
8. Secure the cover back to the camera.

EDN Series Mini Indoor IP Dome
7
5. Accessing the User Interface
This section explains how to access the Web interface of the camera for configuration.
5.1 Checking the Dynamic IP Address
You can look up the IP address and access the Web interface of the camera using the IP Utility (IPU)
software included in the software CD. Please connect the IP camera in the same LAN of your computer.
1. Install and then start the IPU program . The following dialog box appears.
2. IPU will automatically search the cameras connected in the LAN. The default network values of the
cameras will be displayed. By default, the network protocol of the camera is D H C P.
3. To configure the network settings, select a camera and then click Login/Multi Login to log in.
4. Type the user ID and password. Click OK.
Note:
1. The default user ID is user1 and the default password is 11111111.
2. If you select more than one camera that has the same user ID / password, you will be able
to log in several cameras at once.

EDNSeriesMiniIndoorIPDome
8
5. TochangetheIPsettings,double‐clickthevaluesinthecolumnandtypethenumbersorselectan
option.ClickSetIPAddresstosavethesettings.

Note:MostnetworkssupportDHCPprotocol,butifyouareunsureofyournetworkprotocol,
pleaseconsultyourIPadministratorfornetworkconfigurationdetails.

6. Toaccessthecamera,highlightthecameraandclickConnecttoSelectedIP.TheInternetExplorer
windowpopsup.
7. TypetheuserIDandpasswordtologin.TheLiveViewwindowofthecameraappears.
Note:YoumightberequiredtodownloadActiveX,whichisrequiredtoviewthecamerafeed.
Ifasked,click"Yes".FormoredetailsonsettinguptheMicrosoftInternetExplorer,please
referto5.2SettingsforMicrosoftInternetExplorer.
















EDN Series Mini Indoor IP Dome
9
5.2 Settings for Microsoft Internet Explorer
To enable Remove Live View, Firmware Upgrade and ActiveX Prompt on Internet Explorer, some
settings have to be complete. Please follow the steps below:
1. On the computer, click Start > Control Panel > System and Security > Action Center (click Change
User Account Control Settings), the User Account Control Settings window appears. Adjust the
slide bar to Never Notify and then click OK. Restart your computer if requested.
2. Open the Internet Explore, click Tools > Internet Options > Security Tab > Custom Level, the
Security Settings windows appears.

EDN Series Mini Indoor IP Dome
10
3. In the Download unsigned ActiveX controls field, select Prompt. In the Include local directory
path when uploading files to a server field, select Enable. Click OK.
4. In the Internet Options window, click the Advanced tab and then disable Enable memory
protection to help mitigate online attacks. Click OK.

EDN Series Mini Indoor IP Dome
11
5.3 Connecting the Camera to the Network
There are three methods to connect the IP camera to the network: Router or LAN Connection, Direct
High-Speed Connection and One-to-One Connection.
Router or LAN connection
This is the most common connection in which the IP camera is connected to a router and allows
multiple users on and off site to see the IP camera on a LAN/WAN (Internet). The camera must be
assigned an IP address that is compatible with its LAN. By setting up port forwarding on the router, you
can remotely access the cameras from outside of the LAN via the Internet. To remotely access the Web
interface of the IP camera, please refer to 7.1.1 Network (DDNS Settings). To set up port forwarding,
please consult the manual of the router.
Straight-through LAN patch cable
Right: Pinout of a straight-through cable.

EDN Series Mini Indoor IP Dome
12
Direct High-Speed Connection
In a Direct High-Speed Connection, the camera connects directly to a modem without the need for a
router. You need to set the static or dynamic WAN IP address assigned by your ISP (Internet Service
Provider) in the camera’s configuration web pages. To access the camera, just type
“http://xxx.xxx.xxx.xxx”, where xxx.xxx.xxx.xxx is the IP address given by your ISP. If you have a dynamic
IP address, this connection may require that you use DDNS for a reliable connection. Please refer to
7.1.1 Network (DDNS Settings).
One-to-One Connection (Directly from PC to IP Camera)
You can connect directly without using a switch, router or modem. However, only the PC connected to
the camera will be able to view the IP camera. You will also have to manually assign a compatible IP
address to both the computer and the IP camera. Unless the PC has another network connection, the
IP camera will be the only network device visible to the PC. See the diagram below:
Pinout of straight patch cable
Right: Pinout of a crossed-over cable.

EDN Series Mini Indoor IP Dome
13
5.4 Live View Window
1. Click the button to display the Live View window. If you experience video feed lag time
(if connected via Internet), you can reduce the resolution or limit the number of streams. See 7.2.1
Streaming and Audio.
2. Click the button to play back the recorded data directly from the on-camera Micro SD /
SDHC card (for this function to become active, you have to insert a Micro SD / SDHC card in the Micro
SD / SDHC card slot on the camera. See 6.2 Setting up the Playback Function).
3. Snapshot
Click the Snapshot button to take a snapshot. By default, the snapshot will be saved at C:\EverFocus\.
To change the location, see Record to Local in 7.1.3 Storage.
4. Record
Click the Record button to start / stop recording. By default, the video recordings will be saved at
C:\EverFocus\. To change the location, see Record to Local in 7.1.3 Storage. To change the source
video stream and recording format, see Recording and Snapshot Settings in 7.1.3 Storage. To
configure the Schedule Record setting, see Schedule Settings in 7.3.2 Schedule Settings.

EDN Series Mini Indoor IP Dome
14
5. Speaker / Microphone
Click the Speaker and Microphone buttons to switch the sound on/off for the speaker and
microphone respectively (if such external devices have been connected to the camera directly or via
the network). To activate the Audio function, the Enable Audio must be selected. See Audio Settings
in 7.2.1 Streaming and Audio. Note that the Speaker function is not available for this camera.
6. Click the Setting button to enter the Settings page (see 7. Settings).
7. Click the Wizard button to enter the Setup Wizard.
8. Hallway Display (9:16): Click the Rotate button to rotate the live image. This function allows
users to monitor vertically-oriented areas such as hallway, corridors and aisles. It’s recommended to
select a 16:9 View Size (e.g. 1920x1080 / 1024x768) to achieve the best display effect.
9. Video Stream
Select the Video Stream (Stream 1, Stream 2 or Stream 3) that will be displayed in the video box on
the bottom. Stream 2 and Stream 3 are only selectable if you have enabled the stream. The default
setting is Stream 1 only. See 7.2.1 Streaming and Audio.
10. View Size
Use this to select the appropriate view size and shape of the video box on the bottom. A smaller size
might increase transmission speed and video quality.
11. Language
Click the Language drop-down list to select the desired language.
12. Digital Zoom
Click to zoom in / out the camera view up to 10x. Clicking on a magnified image will
re-center the image around that point.
