The SNP-6200RH is a Full HD PTZ dome camera with 20x optical
zoom and focused IR illumintaion. The IR function illuminates
objects at a distance of up to 100m by focusing the beam as the
camera zooms, resulting in clear imaging in total darkness. The
SNP-6200RH is also IP66 environment protected, IK10 vandal
resistant and can withstand high temperature variations of -50°C to
+55°C.
SNP-6200RH
SNP-6200RH
• Max. 2MP (1920x1080) resolution
• 16 : 9 Full HD (1080p) resolution support
• Built-in 20x optical zoom lens (4.45 ~ 89mm)
• WDR, UPnP and face detection support
• IP66/IK10, IR LED (IR distance 100m, LED 2ea)
2MP 1080p Full HD 20x Network IR Dome Camera
Clearly Captured with
Full HD and 20x Zoom
in Complete Darkness

I.E-1306
DISTRIBUTED BY
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : [phone] Direct : [phone]
Fax : [phone]
Design and specifications are subject to change without notice.
Specifications
2MP 1080p Full HD 20x Network IR Dome
SNP-6200RH
SNP-6200RHN SNP-6200RHP
VIDEO
Imaging Device 1/3" 2M PS CMOS
Total Pixels 2,010(H) x 1,108(V)
Effective Pixels 1,944(H) x 1,092(V)
Scanning System Progressive
Min. Illumination Color : 1.5Lux (F1.6, 50IRE), B/W : 0Lux (IR LED on)
S / N Ratio 50dB
Video Output CVBS : 1.0 Vp-p / 75Ωcomposite, 704 x 480(N), 704 x 576(P), for installation
LENS
Focal Length (Zoom Ratio)
4.45 ~ 89mm (20x)
Max. Aperture Ratio F1.6(Wide) / F2.9(Tele)
Angular Field of View H : 62.9˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
Min. Object Distance 1m (3.28ft)
Focus Control Auto / Manual / One shot
Lens Type DC auto iris
Mount Type Board-in type
PAN / TILT / ROTATE
Pan Range 360˚ Endless
Pan Speed Preset : 250˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Tilt Range 190˚(-5˚ ~185˚ )
Tilt Speed Preset : 250˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Preset 255ea
Preset Accuracy ±0.1˚
OPERATIONAL
IR LED 2ea
Viewable Length 100m (328.08ft)
Camera Title Off / On (Displayed up to 15 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC / WDR
Wide Dynamic Range 60dB
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization Off / On
Motion Detection Off / On (1 programmable zones)
Privacy Masking Off / On (8 Rectangle programmable zones)
Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / Outdoor / Indoor / Manual / AWC (2,400°K ~ 10,500°K)
Electronic Shutter Speed Auto / FLK / Manual (1/30 ~ 33,000sec) Auto / FLK / Manual (1/25 ~ 33,000sec)
Digital Zoom Off / On (1x ~ 8x)
Flip / Mirror Off / On
Intelligent Video Analytics Tampering (Scene change), Virtual line, Enter / Exit, Appear / Disappear, Audio detection, Face detection (5ea)
Alarm I/O Input 4ea / Output 3ea
Remote Control Interface
RS-485/422
RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Vicon, Bosch, GE
Alarm Triggers Alarm input, Motion detection, Intelligent video analytics, Network disconnect
Alarm Events File upload via FTP and E-mail, Notification via E-mail, TCP,
Local storage (SD/SDHC/SDXC) recording at Network disconnected, External output, PTZ preset
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264 (MPEG-4 part 10/AVC), MJPEG
Resolution 1920 x 1080P (Full HD), SXGA (1280 x 1024), 1280 x 960, HD (16 : 9, 1280 x 720p),
1024 x 768, SVGA (800 x 600), VGA (640 x 480), QVGA (320 x 240)
Max. Framerate 30fps (When WDR on, Max. framerate is Max 15fps.) 25fps (When WDR on, Max. framerate is Max 15fps.)
Video Quality Adjustment H.264 : Compression level, Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 6 profiles)
Audio I/O Mic(Line)-in selectable via UI, Line-out (Mono, 1Vrms)
Audio Compression Format G.711 u-law, G.726
Audio Communication Bi-directional audio
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP,
IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP
Security HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 10 users at unicast mode
Memory Slot SD/SDHC memory slot
ONVIF Conformance Yes
Webpage Language English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese,
Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Web Viewer
Supported OS : Windows XP / VISTA / 7, MAC OS
Supported Browser : Internet Explorer 7.0 or Higher, Firefox, Google Chrome, Apple Safari
*Apple Safari, Windows Internet Explorer 9.0(32bit) / 8.0(32bit) / 7.0(32bit)
*For Mac OS X, only the Safari browser is supported.
Central Management Software SmartViewer 4.0
ENVIRONMENTAL
Operating Temperature / Humidity -50°C ~ +55°C (-58°F ~ +131°F) / Less than 100% RH
Ingress Protection IP66 grade
Vandal Resistance IK10
ELECTRICAL
Input Voltage / Current 24V AC only
Power Consumption Max. 30W (Heater Off) / 35W (Heater Off, IR on), 90W (Heater On, IR on)
MECHANICAL
Color / Material Ivory / Aluminum
Dimensions (WxH) Ø248.0 x 399.5mm (Ø9.76" x 15.73")
Weight 6.6Kg (14.95 lb)
2M
D&N ICR
IR LED
WDR
Full
1080p
Dimensions
Accessory (Optional)
Unit : mm (inch)
SBP-300LMSBP-300CM
SBP-300WM1 SBP-300WM
SBP-300B SBP-300PM SBP-300KM
20x
Ø248
20
202.5177
399.5
Ø248.0 (9.76")
399.5 (15.73")
177.0 (6.97") 202.5 (7.97") 20.0 (0.79")
