ACTi E33 User manual

* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
www.acti.com
121101
ACCESSORY OPTIONS
PHOTO INDICATION DIMENSION DIAGRAM
Bullet Camera
E33 5MP Bullet with D/N, IR, Basic WDR, Fixed lens
•Progressive Scan CMOS
•DayandnightfunctionwithmechanicalIRcutlter
•Minimum illumination 0 lux with IR LED on
•Built-inf4.2mm/F1.8Megapixelxedlens
•15 fps at 2592x1944 resolution
•Selectable H.264 HP, MJPEG compressions with dual
streaming
•Video motion detection
•Weatherproof IP66 rated casing
•Powered by PoE Class 2
* The bracket is included.
Camera Bracket
PMAX-1103 Aluminum, max. load 10 kg (22.05
lb), tilt angle 90°, swivel angle 360°
Popular Mounting Solutions
Corner PMAX-1103
PMAX-0402
Pole PMAX-1103
PMAX-0502
* For more mounting solutions, please refer to Mounting Accessory section of Buyer’s
Guide or Project Planner on www.acti.com
+
+
Unit: mm [inch]Unit: mm [inch]
1Reset Button
2Power LED
3Ethernet Port
2
1
Internal External
3

IP VIDEO SOLUTION PRODUCT
*Allspecicationsaresubjecttochangewithoutnotice.
* All brand names and registered trademarks are the property of their respective owners. www.acti.com
121101
Bullet Camera
PRODUCT SPECIFICATION
Hemispheric Bullet Cube Speed DomeDome Box PTZ Video Encoder Video Decoder
E33
E33
• Device
Device Type Bullet Camera
Image Sensor Progressive Scan CMOS
Day / Night Yes
Minimum Illumination Color: 0.1 lux at F1.8 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W switch ISPsensorbasedswitch;Congurable
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700 - 1100 nm
IR LED IR LED x 20 (850 nm)
IR Working Distance 15m (0 lux, 30 IRE, Max Exposure Gain)
Electronic Shutter 1/5 - 1/2,000 sec (Manual / Auto mode)
• Lens
Focal Length / Aperture Fixed focal, f4.2 mm / F1.8
Iris Fixed iris
Focus Fixed Focus
Lens Mount Board Mount
Horizontal Viewing Angle 64.1°
• Video
Compression H.264 HP, MJPEG
Maximum Frame Rate
vs. Resolution
15 fps at 2592 x 1944; 15fps at 2048 x 1536;
30 fps at 1920 x 1080 (Full HD 1080p); 30 fps at 1280 x 720 (HD 720p); 30 fps at 640 x 480 (VGA)
Multi-Streaming Simultaneousdualstreamsbasedontwocongurations
Bit Rate 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode Constant, Variable
Image Enhancement Basic WDR; White balance: automatic, hold, and manual; Brightness;
Contrast; Automatic gain control; Digital noise reduction; Flickerless
Privacy Mask 4congurableregions
Text Overlay Userdenedtextonvideo
Image Orientation Imageipandmirror
• Network
Protocol & Service TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS,
DDNS, NTP, ICMP, ARP,IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IPaddressltering;HTTPSencryption;Passwordprotecteduserlevels;IEEE802.1Xnetworkaccesscontrol
• Alarm
Alarm Trigger Video motion detection (3 regions)
Alarm Response Notify control center; Change camera settings; Command other devices;
E-mailnoticationwithsnapshots;Uploadvideo,snapshottoFTPserver
• General
Power Source /
Consumption PoE Class 2 (IEEE802.3af) / 6.29W (IR on)
Weight 584 g (1.29 lb)
Dimensions (Ø x L) 77 mm x 196.74 mm (3.04" x 7.7'')
Bundled Accessories Bracket
Environmental Casing Weatherproof (IP66 rated)
Mount Type Wall, Ceiling, Corner, Pole
Operating Temperature -20 °C ~ 50 °C (-4 °F ~ 122 °F)
Operating Humidity 10% ~ 85% RH
Approvals CE, FCC, IP66
• Integration
UniedSolution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available; ONVIF compliant
Firmware Access Browser Microsoft Internet Explorer 6.0 or newer
