Oypla GARDEN 3553 User manual

Page 1
Manual Version: v1.0
Model Code: 3553
Oypla.com LLP / www.oypla.com
User Manual
Model Code: 3553
Contents
1Front Cover
-
2Safety
Instructions
-
3Assembly
Instructions
-
4Assembly
Instructions
-
5Assembly
Instructions
-
6Back Cover
End
-
16 Litre Knapsack
Sprayer

Page 2
Manual Version: v1.0
Model Code: 3553
Oypla.com LLP / www.oypla.com
DO NOT ATTEMPT TO FILL THE KNAPSACK
SPRAYER ABOVE THE 16 LITRE LIMIT.
Contents
1Front Cover
-
2Safety
Instructions
-
3Assembly
Instructions
-
4Assembly
Instructions
-
5Assembly
Instructions
-
6Back Cover
End
Safety Instructions
Notice: Ensure you read and fully understand instructions before use
While every attempt is made to ensure the highest degree of protection in all equipment, we cannot
guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold
on this condition, which no representative of the company can waive or change.
The sprayer is designed for the
application of agricultural
chemicals, disinfectants, cleaning
agents etc. Do not spray caustic or
corrosive solutions as these will
damage the sprayer.
Wash the inside of the spray tank
with clean water after usage.
Always wear the correct personal
protective equipment whilst
using, cleaning and servicing the
sprayer.
Do not spray towards people,
animals or food.
Lubricate the felt sealing washer
at the top of the air chamber with
light oil at regular intervals. This
ensures smooth operation of the
air pump and prevents leakage of
spray liquid.
Do not expose the sprayer to
strong sunlight when storing as to
prevent deterioration of the tank.
Store the 16 Litre Knapsack
Sprayer in a well ventilated area,
out of the reach of children and
animals.
Always direct the spray downwind
of the operator. Spraying into the
wind will result in operator
contamination.
Do not use on windy days.
Do not eat, drink or smoke whilst
using the sprayer.
Wash hands and face after use.
If the product is damaged or has
any defects, please contact
[email protected].

Page 3
Manual Version: v1.0
Model Code: 3553
Oypla.com LLP / www.oypla.com
Parts List:
-If you are missing any of the below parts, please contact [email protected]
-Please be aware that you will be referring to this parts list throughout the assembly
process.
Tank –
Including
straps and
pump
X1
Lever
Handle
X1
Hose and
Spraying
Lever
X1
Pump
Lever
Holder
X1
Pump
Connecting
Rod
X1
Pump
Fastener
X1
Spraying
Lance
X1
Filling
Filter
X1
Pump Lever
Pole
X1
Safety
Pin
X2
Spraying
Nozzles
X3
Washer
X1
Contents
1Front Cover
-
2Safety
Instructions
-
3Assembly
Instructions
-
4Assembly
Instructions
-
5Assembly
Instructions
-
6Back Cover
End
Assembly Instructions

Page 4
Manual Version: v1.0
Model Code: 3553
Oypla.com LLP / www.oypla.com
1
2
Contents
1Front Cover
-
2Safety
Instructions
-
3Assembly
Instructions
-
4Assembly
Instructions
-
5Assembly
Instructions
-
6Back Cover
End
3
4
To start, attach the
hose and spraying
lever to the top of the
pump at the top of
the tank. Simply screw
the two parts together
until secure. Please
see image to the right
for guidance.
Next, simply screw the spraying lance onto the other end of the
hose and spraying lever. Ensure it is tightly secured. Use the photo
below for guidance. Choose which nozzle you would like and
screw to the other end of the spraying lance.
Now, it’s time to
assemble the pump
lever. Start by pushing
it through the holes at
the base of the tank.
Secure in place using
the attachment clip
provided. Once done,
slide the lever handle
onto the other end of
the pump lever pole.
The next step is it connect the
connecting rod to the pump
lever by sliding through the
little hole as seen in the photo.
Secure in place using a safety
pin and washer. Ensure that this
is with the smaller end of the
connecting rod.

Page 5
Manual Version: v1.0
Model Code: 3553
Oypla.com LLP / www.oypla.com
Contents
1Front Cover
-
2Safety
Instructions
-
3Assembly
Instructions
-
4Assembly
Instructions
-
5Assembly
Instructions
-
6Back Cover
End
5
The next step is to
secure the other end of
the connecting rod to
the top of the pump.
Firstly, insert the pump’s
lever holder into its
position at the top of the
pump. Whilst doing this
slide through the
connecting rod so that it
passes through the lever
holder as well as the
holes on top of the
pump. These are
secured using the
second safety pin. Use
the photos to help.
6
Lastly, just place the filter into
the filling point. This prevents
anything other than liquid
entering the tank. Don’t forget to
add the pump fastener to the
groove in the base of the pump
inside the tank. This helps keep it
secure.
Make sure to follow the instructions on the packaging of the agricultural
chemicals, disinfectants, cleaning agents etc. when pouring them into the
Knapsack Sprayer as to avoid damaging the product and/or causing harm to
yourself or those around you.
If you find one of the nozzles becomes blocked during use or doesn’t spray
in the nozzle’s pattern, unscrew the nozzle tip and clean it under running
water. Do not try to unblock the nozzle using an object as this may damage
the nozzle, rendering it ineffective.
To operate sprayer, unscrew the tank lid and fill it through the filter before
screwing the lid back on. Attach the sprayer to your back using the straps and
pump the pump lever to build the pressure in the air chamber before
spraying. Once you’ve finished using the sprayer, remove both the Lid and
the filter and wash the tank with warm water.
