HE-161A
Commercial Air Purifier
OWNER’S MANUAL
Please read all of the information provided in this owner’s manual
before operating your new Commercial Air purifier.

1
CAUTION
RISK OF ELECTRICAL
SHOCK DO NOT
OPEN
ATTENTION
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO
NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVCE PERSONNEL.
This “bolt of lightning” indicates that uninsulated material
within your unit may cause an electrical shock. For the safety
of everyone, do not remove product covering.

2
INTRODUCTION
This commercial air purifier is an advanced and convenient contaminant
remediation product. High-powered oxidation in a compact, light weight,
rugged and simple design. Utilizing controlled corona discharge ozone
technology developed specifically to reduce odors, viruses and bacteria
in unoccupied spaces. Recommended for treatment for HORECA, food
processing, offices and more!
Model:
HE-161A
Rated Voltage:
Europe AC 220-240V/50-60Hz
USA/Japan AC 100-120V/50-60Hz
Power Consumption:
240W
Ceramic Plate Size
(6 pieces):
104 X50mm
Air Volume:
Max 150 CFM(4.20 M3/min)
Active Oxygen：
30000 mg/h
Sound Level:
45 dB
Product size:
L260Xw205xH180mm
Net Weight:
4.5 Kgs(9.9Lbs)

3
Operating the Ozone Generator Air Purifier
(Front View)
Timer Control Knob Turn clockwise to set the timer for timed
operation up to 3 hours.
High& Low Switch High for 30G, Low for 15G
Indicator Light Illuminates when unit is in operation.

4
(Back View)
Ozone Plate
Fuse Holder
Insertion in plate receiver slots.
Houses removable fuse.
(Spare fuse included, 2 amp, 0.79
inch in length)
Power Cord
220~240 Volt grounded cord for
Europe, 100-120 Volt for USA.

5
The ozone generator is designed to remove odors in
unoccupied spaces. The unit has a timer that will enable it to
run for a maximum duration of 3 hours. The timer will then shut
the commercial air purifier off. You should allow 40 minutes
before returning to the treated area.
To operate the Ozone Generator Air Purifier:
Close off the desired area to be treated.
Remove all occupants and pets.
Position the unit as close as possible to the odor source.
In such environments as motels that have individual
heating and cooling systems, turn the fan on and set on
re-circulate.
Set timer to desired time and leave the room.
Allow 40 minutes before re-entering the treated space.
Return to space & ventilation area.

6
If you suspect a problem with your unit check the following:
•Unit is plugged in properly.
•Ceramic plates are clean and dry.
•There are no cracks in plates and each plate is flush with back of
unit.
•It’s important that the Clean Air ozone generator be properly
grounded to avoid potential shock.
•Fuse is installed properly and in good condition. To replace fuse,
pull out the plastic fuse holder, remove old fuse and insert new fuse.
Replacement fuse must be 2 amp (0.79 inch). Refer to picture at
follows:
Caution: No attempt should be made to remove a panel of the
cabinet, as there are no user serviceable parts. Opening the unit will
void all warranties.

7
When the air purifier no longer produces enough ozone to be effective,
the ozone plates should be cleaned. Usually it should be cleaned
every 2,000 hours.
To clean a plate, first turn off the power and remove the plug from the
socket. Remove the top cover unit. Next, loosen the screw that is fixed
to the power module and spread out the three ceramic plates (note: do
not break the connecting line fixed to the ceramic plates).
Use a spray cleaner or cleaner to remove stains from ceramic and
stainless steel plates. A spray liquid cleaner with ammonia or chlorine
can also be used to remove stains.
After cleaning, dry cloth is used to dry out the moisture of the ceramic
and stainless steel plates and completely dry before reinstallation. The
hairdryer dries faster.

8
The ozone generator commercial air purifier comes with a 1 Year Limited
Warranty.
To activate warranty you must return this card within 30 day.
----------------------------------------------------------------------------------------
FOR YOUR RECORDS
Please record the model and serial number below, for easy reference,
in case of loss or theft. These numbers are located on the back panel
of your air purification unit. Space is also provided for other relevant
information.
Name: Phone:
Address:
Model Number:
Serial Number:
Date of Purchase:
Distributor Name:
