PA F5K User manual

USER GUIDE
English
PROTECTOR ALARMS (UK) Ltd.
TEL No. 020 8761 3771
FAX No. 020 8670 9441
Distributed By
20/22 GIPSY HILL
CRYSTAL PALACE
LONDON. SE19 1NL
email: [email protected]
Website: www.ProtectorAlarms.com

IMPORTANT
PLEASE NOTE: The infrared beam path MUST be kept
clear of obstructions at all times!
Failure to comply may result in the Detector initiating a
Fire or Fault signal.

Contents
Installation
4 General Information
5 Wiring Diagrams
6 Fitting the Product
Commissioning
7 Apply Power and Enter Pass Code
8 Finding Detectors and Selecting Power Mode
9 Select Detector and Distance
10 LASER Targeting
11 ‘Auto’ Alignment and ‘Set’ 0/100 (Calibrate)
12 Alignment Status
In Use
13 Settings and Final Tests
15 Cleaning the System
16 Re-Finding a System - After Adding or
Removing Detectors
Troubleshooting
17 System in Fault/Trouble
18 Error Codes
20 LASER Not Visible
21 Home Position
Display and Indicators
22 LCD Icon Layout
23 Detector and System Controller Status
Indicators
24 User Menu
25 User Menu - Descriptions
26 Engineering Menu
27 Detector Settings
28 System Controller Settings
29 Operating Parameters and Dimensions
Approval Information
30 Territory-Specific Approval Information

General Information
Installation
• Check the beam spacing against local regulations
• Position beam as high as possible, but with a minimum
distance of 0.5m from Detector to ceiling
• Mount Detector and Reflector directly opposite each
other
• Do NOT position Detector where personnel or objects
can enter the beam path
• Do NOT position 2 Detectors facing each other
• LED indicator must face downward
18—50m = 1
50—100m = 4
8—18m = 1
Use Short Range
Mask
50cm
8-100m
50cm
Ensure clear line of sight
from Detector to Reflector
Mount on solid surfaces (structural wall or girder)
50cm
50cm
8-100m
4

Wiring Diagrams
Installation
Wiring for all other System Controllers (where more than one System
Controller is on one zone)
(Not to be used for UL region installations. Please refer to supplied CD
for UL region installation multiple-System Controller wiring)
Wiring for a single System Controller or last System
Controller on one zone
ZONE -
ZONE +
SUPPLY -
SUPPLY +
EARTH/SCREEN
Components not supplied (Check Fire Control Panel
manufacturer for values):
• Fire Resistor (Some Zone and Switch Interface
Modules do not need a Fire Resistor - replace Resistor
with a short circuit.)
• Detector Continuity Diode
• End Of Line (‘EOL’) component
• Check operation of Fire and Fault connection on Fire
Panel
• ALWAYS use a separate screened 2-core cable for
each detector head
• CAUTION: For system monitoring – Do not use
looped wire under any terminals. Break wire run to
provide monitoring of connections
Apply a
voltage of
5V to 40V
to ‘Ext
Reset’
contact for
at least 2
seconds to
clear a
Latched
Fire
condition
DET 1 DET 2 DET 3 DET 1 DET 2 DET 3 DET 4
14V - 28V DC
DET 4
14V - 28V DC
FIRE
ConA
123
N/O
Fire
Resistor
Fire
Resistor
Ext
Reset
Ext
Reset
EOL
COM N/C N/O COM N/C
FAULT
ConB
123
FIRE
ConA
123
N/O COM N/C N/O COM N/C
FAULT
ConB
123
5
Contact Protector Alarms for wiring to
MX4000 addressable panels, or 2 wire
connection to 909 panels.

Fitting the Product
Installation
LED indicator must face downward
6

Apply Power and Enter Pass Code
Commissioning
1. Apply power
•‘E-02’ at this stage is
normal
2. Enter Pass Code to Access Engineering Menu
Press for Pass Code screen:
2 seconds
15 seconds
40 seconds
•Default Pass Code: 1234
•Change digit
•Move between digits
•Accept
•An incorrect Pass Code will return the display to the
Pass Code entry screen
•Three incorrect attempts will lock access for three
minutes
One System Controller can be used to control
and monitor up to four Detector heads.
The ‘#’ symbol in this guide is used to
represent the number of the Detector currently
selected (1, 2, 3 or 4).
7

Finding Detectors and Selecting Power Mode
Commissioning
3. Find Detectors
60 seconds
•Press tick to enable ‘Found’ Detectors
•Any unused Detector channels are switched
off
•Press to re-scan if number is incorrect
Menu Navigation
•All functions can be performed in ‘Lo A’ mode (default)
(10, 12, 14 or 16 mA for 1, 2 ,3 or 4 Detectors found)
•The system will default to ‘Lo A’ mode when power is
applied
•Select ‘Hi A’ (50mA) to enable faster beam movement
during Auto-Align, Hand Align and Laser Targeting
•After installation, set the system back to ‘Lo A’
4. Select Power Mode
1. Use to move between
icons in the Engineering Menu, to
highlight the icon shown
3. Use to move to
required item
2. Press to select
This will be the number of
Detectors found
4. Use to
change selection
5. Press to accept
Press to cancel
•‘Find’ is
automatically
displayed the first
time this process
is run. ‘Find’ can
also be accessed
in the System
Controller settings
menu
8

Select Detector and Distance
Commissioning
•Select 8-50m (default) or 100m
•It is possible to set the range of each
individual Detector
6. Select Distance between Detector and Reflector
•Select Detector to be accessed
•All Detectors need to be aligned separately
•Steps 6 to 9 explain how to align individual Detectors
5. Select Detector
1
2
3
4
9

The system will signal Fault while in this mode
The LASER is used to align the Detector with the Reflector. It
is an approximate alignment tool only. After Auto-Align the
LASER will not necessarily be pointing on the Reflector
• Use to move the LASER as close to the
Reflector as possible
• One press of an arrow key results in one movement of the
Detector head
• Press or to turn off the LASER and return to the
Settings menu
• Refer to User Guide page 20 for troubleshooting if LASER
is not visible
LASER Targeting
Commissioning
LASER RADIATION - AVOID
DIRECT EYE EXPOSURE
POWER OUTPUT < 5mW
CLASS IIIa LASER
Wavelength 630 - 680 nm
DANGER
7. LASER Targeting
10

Commissioning ‘Auto’ Alignment and ‘Set’ 0/100 (Calibrate)
9. ‘Set’ 0/100 (Calibrate)
• Select ‘Auto’ to automatically
align the infrared beam
• Signal Strength will be shown
during Alignment
• If the LASER is turned on it
will not necessarily be
pointing on the Reflector
after ‘Auto’ is run - this is
normal
8. ‘Auto’ Alignment
•When ‘Set’ is displayed press
•When ‘S-00’ is displayed, cover the Reflector with a non-
reflective material and leave covered, then press
•When ‘S-01’ is displayed, uncover the Reflector and
leave uncovered, then press
•Repeat Steps 5 to 9 for any other Detectors found during
the ‘Find’ process
11
LoA: 7 minutes
HiA: 4 minutes

Commissioning Alignment Status
10. System is Aligned
•It is recommended to set the system back to ‘Lo A’ mode
•Green LED on Detector will flash every 10 seconds, and
Signal Strength should be between 99% and 101%
•Default values: 35% Fire Threshold, 10 second delay to
Fire and Fault, Non-Latching mode
•Refer to User Guide page 13-14 to change settings and
for Fire and Fault Test
11. Check Alignment Status Displays
A commissioned
system will display:
When Detectors have
been found but the
selected Detector is not
aligned the system will
display:
When a Detector is
connected but not
‘Found’ the system will
display:
12

In Use Settings and Final Tests
Fire Threshold
How to change the
threshold at which the
Detector will detect a Fire
Delay 1 (Fire)
Fire / Fault Delay
How to change the delay
the System Controller
uses before signalling a
Fire or Fault to the Fire
Control Panel
Delay to Fire
(Delay 1) cannot
be less than Delay
to Fault (Delay 2)
Delay 2 (Fault)
Latching/Non-Latching
Mode
How to select either
Latching Mode (system will
stay in Fire condition after
the fire clears) or Non-
Latching Mode (system will
automatically return to
normal condition after the
fire clears) Use to move between icons in the
Detector Menu, until the graph and bell icons
are shown
Non-Latching Latching
13
(Set for each Detector)
(Set for each Detector)
(Set for the system not each individual Detector)

In Use Settings and Final Tests
Detector Fire LED Test
Detector will signal Fire,
System Controller will stay
Normal.
Press to exit
without performing the test
Relay/Controller Wiring Test
System Controller signals
‘Fire’ to Fire Control Panel
Press or to
exit
Software Fire Test
How to perform a Fire Test
from the System Controller,
to test the wiring to the Fire
Control Panel
NOTE: The Software Fire
Test is acceptable for Fire
Authority Acceptance and
Routine Maintenance per
UL268-5
Manual Fire and Fault Tests
After installation or cleaning, it is recommended that a manual Fire and Fault test is performed:
Fire Test: Cover the Reflector slowly so that it takes longer than
5 seconds to cover. The System Controller will signal Fire to the
Fire Control Panel
Fault Test: Cover the Reflector completely within 2 seconds. The
System Controller will signal Fault back to the Fire Control Panel.
14

In Use Cleaning the System
Cleaning the System
The system will automatically compensate for dust
build-up by changing the Compensation Level.
However, it is recommended that the Detector lenses
and the Reflector are cleaned periodically with a soft
lint-free cloth.
If the Compensation Level for a particular Detector
remains above 130 for several days, this indicates
that cleaning should take place on that Detector.
The system should be isolated from the Fire Control
Panel before cleaning takes place.
After cleaning, verify that the system is operating
normally:
If the Signal Strength is between 92% and 108%
- leave the system to compensate back to 100% (this
should take no more than 12 hours)
If the Signal Strength is above 108%
- reduce Compensation Level until Signal Strength is
92—108%, and wait for system to compensate back
to 100%
If the Signal Strength is below 90%
- perform LASER Targeting, Auto-Align, and Set.
How to change Compensation Level:
Use to move between icons
in the Detector Menu, until this icon is
shown
15

Re-Finding a System - After Adding or Removing Detectors
In Use
60 seconds
•Press tick to enable found Detectors
•Any unused Detector channels are switched
off
•Press to re-scan if number is incorrect
•Repeat Alignment (Steps 5 to 9) for any
other Detectors found during the ‘Find’
process
This will be the number of
Detectors found
•Power Down the system
•Connect new Detector(s) or disconnect
unwanted Detector(s)
•Power the system back up, then follow
procedure:
Use to move between icons in the
System Controller Settings, until the ‘Find’
screen is shown
16

Troubleshooting System in Fault/Trouble
17
•If a Fault/Trouble is indicated at the System Controller:
•Refer to manufacturer for further technical assistance
Does the LCD come on if a key is pressed?
Do any LEDs on the System Controller flash? Check power to System Controller
Have the Detector(s) been ‘Found’ and aligned?
(Refer to page 12 of User Guide for indication
screens)
Does the compensation level = 205 or - 49?
(Refer to pages 15, 24 and 25 of User Guide for
compensation level screens)
Is the signal strength less than 13%?
Is the signal strength greater than 110%?
NO
Perform ‘Find’, and align / ‘Set’ the
Detector(s). Refer to pages 8-14 of User
Guide
NO
Clean and re-align Detector(s).
YES
Check that the beam path is not blocked
Check that Reflector and Detector are still in
position and have not moved
YES
Check that there is not a reflective object in
the beam path
YES
YES
YES
NO
NO

Troubleshooting Error Codes
Detector Not Found
System Controller could not find
Detector. Also displayed during
power up.
• Wait 45 seconds for system to
power up
• Check wiring between System
Controller and Detector (Voltage
to Detector should be 11—13V)
Detector is connected but not
‘Found’
A Detector is connected but not
‘Found’
• Follow ‘Find’ process and
align if necessary
Compensation Level Not Zero
Compensation must equal zero
when ‘Set’ is selected.
• Re-align Detector using Auto-
Align
Signal Strength Out of Range
Signal Strength is too low or too high
after Auto-Align.
• Ensure correct distance has been
set
• Ensure correct Reflector type has
been used
• Ensure clear line of sight to
Reflector
• Re-align Detector using LASER
and Auto-Align
Reflector Not Found
Detector could not align with
Reflector
• Ensure correct distance has been
set
• Ensure correct Reflector type has
been used
• Ensure clear line of sight to
Reflector
• Re-align Detector using LASER
and Auto-Align
18
Auto-Align Failed
• Ensure correct distance between
Reflector and roof structures
• Ensure clear line of sight to
Reflector
• Re-align Detector using Auto-
Align

Troubleshooting Error Codes
Cannot Zero During ‘S-00’
in ‘Set’
The Reflector was not
covered or the Detector was
not aligned onto the Reflector.
• Ensure Reflector was
completely covered with a
non-reflective material
• Re-align Detector using
Auto-Align
No Signal During ‘S-01’ in ‘Set’
The Reflector was not uncovered
during ‘S-01’.
• Ensure Reflector was
uncovered when ‘S-01’ was
selected
‘Centre’ Stage of Alignment
Failed
Detector has aligned on
something other than the
Reflector
• Ensure clear line of sight from
Detector to Reflector for a
radius of 0.5m
19

If it is not possible to see the LASER because of
the installation environment (for example, if you
cannot see the Reflector from the System
Controller or there is high ambient light) then use
‘Hand’ Alignment. This option displays the signal
strength value returned by the Detector, and
allows the user to move the beam
1. Start ‘Auto’ Alignment and press after two
seconds to exit. (this will maximise infrared
power)
2. Select ‘Hand’ alignment
3. Use to steer the beam until the
signal strength is above 800. There is no
auto-repeat function on any key. To move the
motor in any given direction more than once,
press the key multiple times
4. Cover the Reflector. If the Signal Strength
does not drop by more than half, the beam is
not aligned to the Reflector, so repeat Step 3
5. Perform ‘Auto’ alignment, followed by ‘Set’
Troubleshooting LASER Not Visible
20
