MBT 201A, MBT 101A SYSTEMS
MAINTENANCE
MANUAL
OPERATION &
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

i
MANUAL NO. 5050-0381
REV. B
SYSTEM QUICK START
The MBT 201A and MBT 101A systems are very easy to operate and can
be quickly set up for use in standard soldering/desoldering operations. To
beginoperationofyournewsystemquickly,performthe"Set-Up"and
"Quick Start - Basic Operation" procedures detailed on pages 12 - 17
of this manual. When performing other operations which require use of
large or specialized tips, PACE recommends that the user read and fully
understand the "Operation" portion of this manual in order to utilize the
features of this system.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ii
PACE Incorporated retains the right to make changes to specifications contained herein at any time, without
notice.
Contact your local authorized PACE Distributor or PACE Incorporated to obtain the latest specifications.
The following are registered trademarks and/or servicemarks of PACE Incorporated, Laurel Maryland U.S.A. and
may only be used to identify genuine PACE products or services:
AdapTip, Arm-Evac, Cir-Kit, ComForm I, ConducTweez, CRAFT,
Dual Path, Flo-D-Sodr, FuseSet, HandiPik, HotSpot, LapFlo, MBT,
Micro Portable, MicroChine, MiniChine, Mini-Wave, PACE, Pacenter,
Ped-A-Vac, PETS, Pik-Vac, PRC, PRINT, Pro-Evac, Redi-Rak,
ResisTweez, SensaTemp, SMR, Snap-Vac, Sodr-Pen, Sodr-X-Tractor,
SR-3, SR-4, ST, StripTweez, SwaPlater, ThermoBand, Thermo-Drive,
ThermoJet,ThermoPart,ThermoPik,ThermoTweez,Tip-Evac,VisiFilter.
The following are trademarks and/or servicemarks of PACE Incorporated, Laurel Maryland U.S.A. and may only
be used to identify genuine PACE products or services:
Auto Off, Cubby-Vac, Datastore, Dust Evac, EKO, Lab Evac,PaceLink,
PaceNet, Pik & Paste, Prep-Set, Pulse Plate, Spa-Kleen, ThermoBond,
TweezPik, Uni-Frame, V-A-N Ventur-Evac.
Since 1958, PACE Incorporated has provided advanced technology training in all aspects
of hand soldering, rework and repair.
Additional copies of this manual or other PACE literature may be obtained from:
PACE Incorporated (301) 490 - 9860
Sales Administration (301) 498 - 3252 Fax
9893 Brewers Court
Laurel MD 20723-1990
©1995 PACE Incorporated, Laurel MD. All rights reserved. Printed in the U.S.A.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iii
TABLE OF CONTENTS
TITLE PAGE
General Information ............................................................................................................................................... 2
Introduction ................................................................................................................................................. 2
Specifications............................................................................................................................................... 4
Capabilities .................................................................................................................................................. 6
Product Application ..................................................................................................................................... 7
Parts Identification ....................................................................................................................................... 8
Safety .................................................................................................................................................................... 10
Set-up .................................................................................................................................................................... 12
System ....................................................................................................................................................... 12
Handpiece Vacuum/Pressure ..................................................................................................................... 14
Quick Start - Basic Operation .............................................................................................................................. 17
Operation .............................................................................................................................................................. 18
Tip & Temperature Selection..................................................................................................................... 18
Channel Led Operation.............................................................................................................................. 18
Corrective Maintenance ....................................................................................................................................... 19
VisiFilter Element Replacement ................................................................................................................ 19
Handpieces................................................................................................................................................. 20
Power Source ............................................................................................................................................. 21
Replacement Parts ................................................................................................................................................ 22
Power Source ............................................................................................................................................. 22
Accessory Tray, MBT 201A/J/E ................................................................................................................ 23
Accessory Tray, MBT 101A/J/E ................................................................................................................ 24
Accessory Kit, MBT 201A/J/E.................................................................................................................. 25
Accessory Kit, MBT 101A/J/E.................................................................................................................. 26
Manual Improvement & Comment Form ............................................................................................................ 27
TABLE PAGE
Table I Heater Assembly Checkout Procedures.......................................................................................... 20
Table II Power Source Corrective Maintenance .......................................................................................... 21
Table III Power Source Replacement Parts ................................................................................................... 22
Table IV MBT 201A/J/E Accessory Tray .....................................................................................................23
Table V MBT 101A/J/E Accessory Tray .....................................................................................................24
Table VI MBT 201A/J/E Accessory Kit ........................................................................................................ 25
Table VII MBT 101A/J/E Accessory Kit ........................................................................................................ 26
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
GENERAL INFORMATION
INTRODUCTION
The MBT 201A and MBT 101A Universal Soldering/Desoldering Systems provide the user with the power
and versatility to remove and install SMD and Thru-Hole devices. The power source incorporates a highly
responsive SensaTemp (closed-loop) temperature control system which provides power to the two output
channels on the MBT 201A systems and to a single output channel on the MBT 101A systems. Accessory
handpieces (standard & optional) and special use tips allow the user to remove and replace a wide variety
of surface mount components.
The self-contained AUTO SNAP-VAC pump provides an automatic minimum on-time of 1.2 seconds to
virtually eliminate re-sweat joints, tip clogging and maintenance while dramatically increasing tip life.
Virtually all of todays specialized handpieces with large SMD tips suffer from a problem in which the
actual tip temperature that the work sees can be more than 100°F cooler than the Set Tip Temperature on
the Variable Temperature Control. MBT 201A/101A systems feature PACEs unique Tip & Temperature
Selection System which allows the user to set the true temperature desired for any size and type of tip or
handpiece.
The MBT 101A and MBT 201A systems are available in either the 115 VAC version, 100 VAC version or
230 VAC version. The 230 VAC version system bears the CE Conformity Marking which assures the user
that it conforms to all the requirements of council directive EMC 89/336/EEC. The systems package the
power source with a selection of accessories and functional aids. These systems are as follows.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
GENERAL INFORMATION
MBT 101A SYSTEM - Consists of PPS 75A (115 VAC, 60 Hz Version) Power Source, SX-70 Sodr-X-Tractor,
SX Tip & Tool Stand, Tip & Temperature Selection System Charts and Accessory Kit.
MBT 101AJ SYSTEM - Consists of PPS 75AJ (100 VAC, 50/60 Hz Version) Power Source, SX-70 Sodr-X-
Tractor, SX Tip & Tool Stand, Tip & Temperature Selection System Charts and
Accessory Kit.
MBT 101AE SYSTEM - Consists of PPS 75AE (230 VAC, 50 Hz Version) Power Source, SX-70 Sodr-X-
Tractor, SX Tip & Tool Stand, Tip & Temperature Selection System Charts and
Accessory Kit.
MBT 201A SYSTEM - Consists of PPS 80A (115 VAC, 60 Hz Version) Power Source, SP-2A Sodr-Pen
Soldering Iron, SX-70 Sodr-X-Tractor, SX & SP Tip & Tool Stands, Tip &
Temperature Selection System Charts and Accessory Kit.
MBT 201AJ SYSTEM - Consists of PPS 80AJ (100 VAC, 50/60 Hz Version) Power Source, SP-2A Sodr-Pen
Soldering Iron, SX-70 Sodr-X-Tractor, SX & SP Tip & Tool Stands, Tip &
Temperature Selection System Charts and Accessory Kit.
MBT 201AE SYSTEM - Consists of PPS 80AE (230 VAC, 50 Hz Version) Power Source, SP-2A Sodr-Pen
Soldering Iron, SX-70 Sodr-X-Tractor, SX & SP Tip & Tool Stands, Tip &
Temperature Selection System Charts and Accessory Kit.
PETS 5A, 5AE SYSTEMS - PACE Educational Systems containing everything required for step-by-step
training in high reliability soldering & desoldering. Consists of MBT 201A or
MBT 201AE systems plus instructional Videos, Manuals & Skills Kits.
The SR-3 Safety Rated designation on the front panel is your assurance that the MBT 101A/J/E and
MBT 201A/J/E systems: Meet all applicable EOS/ESD, temperature stability and other government and
industry specification requirements (including MIL-STD-2000A); contain PACEs unique SensaTemp
temperature management system for high performance and safety, plus a Tip Offset Compensation
feature for superior thermal process control.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
GENERAL INFORMATION
SPECIFICATIONS
POWER REQUIREMENTS
PPS 75A (MBT 101A System) - Version operates on 97-127 VAC, 50/60 Hz.
86 Watts, 0.75 Amp typical; 120 Watts, 1.0 Amp maximum
PPS 75AJ (MBT 101AJ System) - Version operates on 90-115 VAC, 50/60 Hz.
86 Watts, 0.86 Amp typical; 120 Watts, 1.2 Amp maximum
PPS 75AE (MBT 101AE System)- Version operates on 196-264 VAC, 50 Hz.
86 Watts, 0.44 Amp typical; 100 Watts, 0.55 Amp maximum
PPS 80A (MBT 201A System) - Version operates on 97-127 VAC, 50/60 Hz.
138 Watts, 1.2 Amp typical; 184 Watts, 1.6 Amp maximum
PPS 80AJ (MBT 201AJ System) - Version operates on 90-115 VAC, 50/60 Hz.
138 Watts, 1.4 Amp typical; 184 Watts, 1.8 Amp maximum
PPS 80AE (MBT 201AE System)- Version operates on 196-264 VAC, 50 Hz.
138 Watts, 0.6 Amp typical; 199 Watts, 0.9 Amp maximum
VACUUM AND AIR
Measurements at front panel AUTO SNAP-VAC and Controllable PRESSURE Ports of power source.
Vacuum Rise Time: Evacuates 33 cc (2 cubic inch) volume
to 25 cm Hg. (10 in. Hg.) in 200 ms.
Vacuum: 51 cm Hg. (20 in. Hg.) (nominal).
Pressure: .48 Bar (7 P.S.I.) (nominal, "MAX" setting).
Air Flow: 9 SLPM (0.32 SCFM) maximum.
ENVIRONMENTAL REQUIREMENTS
Ambient Operating Temperature: 0°C to 50°C (32°F to 120°F).
Storage Temperature: -40°C to 100°C (-40°F to 212°F).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
GENERAL INFORMATION
PHYSICAL PARAMETERS
Size (all systems): 13.5 cm H X 16.5 cm W X 20.3 cm D
(5.3 in. H X 6.5 in. W X 8.0 in. D)
Weight (all systems): PPS 75A/J/E - 3.7 kg. (8.1 lbs.)
PPS 80A/J/E - 3.7 kg. (8.1 lbs.)
TEMPERATURE SPECIFICATIONS
Tip Temperature Range: 232°C to 482°C (450°F to 900°F), nominal.
Accuracy: ±5% of control setting
Tip Temperature Stability: ±1.1°C (2°F) at idle from Set Tip Temperature.
NOTE
True minimum and maximum Operating Tip Temperatures may vary
depending on handpiece & tip selection.
EOS/ESD
Tip-To-Ground
Resistance: Less than 2 ohms.
AC Leakage: Less then 2 millivolts RMS from 50Hz to 500Hz, min.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
GENERAL INFORMATION
CAPABILITIES
All capabilities are dependent upon the use of the appropriate Functional Accessories or Work Aids.
Available SensaTemp handpieces and their associated assembly and repair functions are listed below (a
manual is provided separately with each handpiece which describes the applications and recommended
procedures for that particular tool).
SP-2A Sodr-Pen Soldering Iron - Standard handpiece on MBT 201A, MBT 201AJ & MBT 201AE systems.
Provides a wide range of SMD and thru-hole installation and removal capability as well as unsurpassed thermal
performance on heavy, multilayer thru-hole assemblies at safe, lower working temperatures. A wide variety of
3/16" shank, quick change thru-hole and SMD tips (for chip components, SOTs, SOICs and other components)
are available.
SP-1A Sodr-Pen Soldering Iron - Uses 1/8" shank tips and features a slimmer, more compact heater than the
SP-2A Sodr-Pen for easier access on densely populated assemblies.
SX-70 Sodr-X-Tractor Handpiece - Standard handpiece on MBT 201A, MBT 201AJ, MBT 201AE, MBT
101A, MBT 101AJ & MBT 101AE systems. Provides thermally enhanced thru-hole desoldering on heavy
multilayer assemblies, especially during continuous use. With the unique Flo-D-Sodr tip, the Sodr-X-Tractor
performs safe, continuous SMT land cleaning and preparation. The slim-line, pencil-grip design and finger-
actuated vacuum switch allow easy use and manipulation in tight places.
TT-65 ThermoTweez Handpiece - Provides safe, one-handed reflow and removal of PLCCs, LCCCs, chip
components and other surface mount devices. Its high thermal capacity and targeted heat quickly removes large
SMDs without damage to the board or adjacent components, even on heavy, multilayer assemblies. The unique,
vertically oriented design and a wide variety of quick change tips easily reach into tight work areas for safe
SMD removal.
TP-65 ThermoPik Handpiece - Provides safe, one-handed reflow and removal of a wide variety of PQFPs and
FlatPacks in just seconds. The high thermal efficiency design targets controlled SensaTemp heat directly at the
solder joints, away from sensitive substrate areas and adjacent components. The ThermoPiks self-adjusting
integral vacuum pick and unique design provide easy, one-handed operation.
TJ-70 Mini ThermoJet Handpiece - Provides safe, rapid installation of SMDs including chip components,
SOTs, SOICs, PLCCs, LCCCs and FlatPacks. The slim-line design and precision focused air flow lets you
easily target controlled heat right at the solder joints without damaging the board or adjacent components. A
finger-actuated air switch and SensaTemp control provide safe, on-demand capability without constant
running of the air pump.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
GENERAL INFORMATION
NOTE
The MBT 101A/J/E and MBT 201A/J/E products feature PACE’s unique
SensaTemp closed loop temperature management system which will
functiononlywiththeSenaTemphandpieceslistedabove. Donotattempt
to use any other handpiece. Likewise, use SensaTemp handpieces on
onlythosesystems withanSR-3 or SR-4rating(marked on frontpanelof
powersource). TheseincludeotherMBTsystems(MBT101A,MBT201A
and higher) and all ST series systems.
PRODUCT APPLICATION
These products are very versatile and may be used to satisfy a variety of application requirements. If you require
assistance in the use of this product for your particular application, contact your local authorized PACE
distributor or call PACE Applications Engineering at Tel. # [phone], Fax # [phone].
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
GENERAL INFORMATION
PARTS IDENTIFICATION
1. POWER SWITCH - Turns system ON (1) and OFF (0); controls input power to system.
2. CH 1 VARIABLE TEMPERATURE CONTROL - Allows the operator to adjust the tip temperature
for handpiece/tip combination connected to channel 1.
3. CH 2 VARIABLE TEMPERATURE CONTROL (MBT 201A/J/E Systems Only) - Allows the
operator to adjust the tip temperature for handpiece/tip combination connected to channel 2.
4. CH 1 POWER RECEPTACLE - Provides power, tip ground, sensing circuitry and finger switch
connection from MBT system to the handpiece connected to channel 1.
5. CH 2 POWER RECEPTACLE (MBT 201A/J/E Systems Only) - Provides power, tip ground,
sensing circuitry and finger switch connection from MBT system to the handpiece connected to
channel 2.
6. CH 1 LED - Green LED provides visual indication of duty cycle control of channel 1. Indicator lights
as power is applied to the connected handpiece.
7. CH 2 LED (MBT 201/J/E Systems Only) - Green LED provides visual indication of duty cycle
control of channel 2. Indicator lights as power is applied to the connected handpiece.
8. AUTO SNAP-VAC PORT - Quick connect fitting which provides quick-rise vacuum for Sodr-X-
Tractor or ThermoPik handpieces. Vacuum is present when handpiece finger switch or optional foot
pedal is actuated. Vacuum continues a minimum of 1.2 seconds after switch (or foot pedal) actuation.
9. CONTROLLABLE PRESSURE PORT - Quick connect fitting with adjustable valve which
provides variable air flow for the Mini ThermoJet handpiece. Air pressure is present when handpiece
finger switch or optional foot pedal is actuated. Air pressure ceases 1.2 seconds after switch (or foot
pedal) is released.
10. EARTH GROUND RECEPTACLE - Provides positive earth ground to which a ground cable can be
connected from the workpiece or work surface as part of a static control program.
11. POWER CORD - Provides main power to system from AC outlet to AC Power Receptacle.
12. AC POWER RECEPTACLE/FUSE HOLDER - Receptacle for providing power to the system from
AC outlet through Power Cord, and location of fuse which protects system from overcurrent
conditions.
13. FUSE - Provides overload protection for MBT system.
14. FOOT PEDAL RECEPTACLE - Input for foot pedal (optional) which actuates vacuum or pressure
to the air-operated handpieces.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
GENERAL INFORMATION
Figure 1. Parts Identification
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10
SAFETY
NOTE
Used to indicate a statement of company recommendation or policy. The message may relate directly or
indirectly to the safety of personnel or protection of property. NOTE is not associated directly with a hazard or
hazardous situation and is not used in place of "CAUTION", "WARNING" or "DANGER".
CAUTION
Used to indicate a hazardous situation which may result in minor or moderate injury. May also be used to alert
personnel to conditions, procedures and practices which, if not observed, could result in damage to or destruction
of the product or other equipment.
WARNING
Used to define additional information that if not closely followed might result in serious damage to equipment
and represent a potential for serious personnel injury.
DANGER
Defines additional information that if not closely followed might result in severe personnel injury or death.
Danger is not used for property damage unless personal injury risk is present.
The purpose of this "SAFETY" section is to inform users of the heading guidelines used in this manual to indicate
special Notes, Cautions, Warnings or Dangers. Also included are recommended precautions which must be
observed when operating or servicing this product.
HEADING GUIDELINES
PACE adheres to the following Heading Guidelines (based on OSHA guidelines) when listing special information
or precautions to be taken. Especially important are all procedures and practices which, if not strictly observed,
could result in injury or loss of life.
These "NOTES", "CAUTIONS","WARNINGS" and "DANGERS" are inserted in this manual whenever deemed
necessary. They appear in a blocked off form with double outline and a shaded background to highlight the
information as shown below.
NOTE
XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

11
SAFETY
PRECAUTIONS
The following are general safety precautions which personnel must understand and follow when using or
servicing this product. These precautions may or may not be included elsewhere in this manual.
USEAGE PRECAUTIONS
CAUTIONS
1. SensaTemp handpiece heaters and installed tips are hot when handpiece is powered on. DO NOT touch
either the heater or tip. Severe burns may result! Always store handpiece in the appropriate cubby when
not in use.
2. Always use this system in a well ventilated area. A fume extraction system such as those marketed by
PACE are highly recommended to protect personnel from solder flux fumes.
3. Exercise proper precautions when using chemicals (e.g., solder paste). Refer to the Material Safety Data
Sheet (MSDS) supplied with each chemical and adhere to all safety precautions recommended by the
manufacturer.
NOTES
1. The solder collection chamber in the PACE Sodr-X-Tractor is made of glass. Never remove this
chamber using pliers. Breakage of the chamber may result. Always remove using the procedures
recommended by PACE in the associated handpiece manual.
2. The front end (heater end) of the glass solder collection chamber in the PACE Sodr-X-Tractor is hot
when the handpiece is in use. When removing the chamber for cleaning, grip the chamber at the rear
seal. Never touch the front end of the glass chamber with bare hands. Allow the chamber to cool
before cleaning.
3. Always store any connected handpiece in the appropriate Tip & Tool Stand.
SERVICING PRECAUTIONS
DANGERS
POTENTIAL SHOCK HAZARD - Repair procedures performed on this product should be performed
by qualified service personnel only. Line voltage parts will be exposed when equipment is disassembled.
Service personnel must avoid contact with these parts when troubleshooting the power source.
NOTES
Refer to the MBT 201, MBT 101, ST 50 Service Manual (P/N 5050-0340) whenever service is required.
To insure continued peak performance, use genuine PACE replacement parts.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12
SET-UP
SYSTEM
Using Figures 1 thru 4 as a guide, set up the MBT 201A or MBT 101A system using the following steps.
1. Store the shipping container(s) in a convenient location. Reuse of these containers will prevent
damage if you store or ship the system.
2. Place Power Switch in the “Off” or “0” position.
3. Position the system on a convenient bench.
4. Plug the Power Cord into AC Power Receptacle/Fuse Holder at the rear panel of the system.
IMPORTANT
The AC supply receptacle must be checked to insure proper grounding
before initial system operation.
5. Assemble the Tip & Tool Stand(s)
and, if desired, attach to the power
source. Assembly instructions are
enclosed with each stand.
6. If you have purchased the optional
Tip & Temperature Selection
System Chart Holder, attach to the
top of the power source using the
supplied instructions.
7. Install the Tip & Temperature
Selection System Charts booklet
onto Chart Holder (if present).
This booklet is supplied with each
system.
Figure 2. Tip & Temperature Chart Holder (Optional)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
8. Place handpiece(s) into the Tip & Tool Stand(s).
9. Using Figure 3 as a guide, connect handpiece
connector(s) to the power source Power
Receptacle(s) in the following manner:
a) With the Connector Key end facing the power
source, turn the Locking Ring fully
counterclockwise.
b) Align the Connector Key with the Receptacle
Keyway.
c) Insert the connector into the Power Receptacle.
d) Turn the Locking Ring fully clockwise to lock
in place.
10. To avoid confusion among handpieces on MBT
201A systems, PACE recommends the use of
colored markers (P/N 6993-0136 Cable Marker
Kit) to identify the particular handpiece power
cable and/or air hose. Attach any two like colored
markers, one to each end of the handpiece power
cable or air hose. Select and use a different color
marker for each handpiece.
11. If you have purchased the optional foot pedal,
insert the foot pedal connector plug into the Foot
Pedal Receptacle on the rear panel of the power
source.
12. Plug the prong end of the Power Cord into a
convenient three wire grounded outlet.
13. Place the POWER Switch in the “On” or “1”
position. The system is now ready for operation.
SET-UP
Figure 3. Handpiece Connection
Figure 4. Foot Pedal Connection
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

14
SET-UP
HANDPIECE VACUUM/PRESSURE
AIR HOSE CONNECTION
There are two methods of attaching the Air Hose from the PACE power source to an air handpiece. Select the
method which best suits your needs. The Quick Connect Method is best suited for configurations where multiple
air handpieces may be in use. The Traditional Method is best suited for single air handpiece configurations.
CAUTION
Regardless of connection method, ensure that only one Air Hose is
connectedtotheVisiFilterassembly(connectedtotheAUTOSNAP-VAC
Port) or Controllable PRESSURE Port at one time. Attachment to both
ports simultaneously will cause a deterioration of performance.
QUICK CONNECT METHOD
To set up each air handpiece for the quick connect
operation, perform the following steps.
1. Attach a 1 inch length (2.5cm) of clear pvc Air
Hose (P/N 1325-0003-07) to the metal tube in the
back of each handpiece.
2. To the other end of the 1 inch (2.5cm) clear pvc
Air Hose attach a female quick connect hose
mount Fitting (P/N 1259-0086). Secure this short
Air Hose to the handpiece power cable with one
cable clip (P/N 1321-0085-01).
Figure 5. Handpiece Quick Connect Hose
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
3. Prepare a quick connect Air Hose by inserting a
metal hose clamp (P/N 1211-0036, standard on
MBT 201A systems) & a male quick connect hose
mount Fitting (P/N 1259-0087) into each end of a
54 inch (137cm) length of Air Hose. Push the
ridged ends of the Fittings into the hose; slide &
twist the metal hose clamps over the connections
to secure. You may already have this piece if you
have other quick disconnect handpieces
configured.
4. Prepare a VisiFilter in the following manner.
a) Connect a 1 inch (2.5cm) length of clear pvc
Air Hose to each side of the VisiFilter; push and
turn hose onto VisiFilter nipple to seat.
b) To the free end of the Air Hose connected to the
FLOW IN side of the VisiFilter, insert the ridged
end of a female quick connect hose mount Fitting
(P/N 1259-0086).
c) Insert the ridged end of a male quick connect
hose mount Fitting (P/N 1259-0087) in the free
end of theAir Hose connected to the FLOW
OUT side of the VisiFilter.
d) Connect the VisiFilter Air Hose (with attached
male quick connect hose mount Fitting) to the
power source AUTO SNAP-VAC Port.
SET-UP
Figure 6. VisiFilter Set-Up
5. For vacuum, insert the male quick connect hose mount Fitting connected to the long Air Hose into the
female Fitting on the 1 inch (2.5cm) Air Hose (connected toVisiFilter). For pressure, insert the male
quick connect hose mount Fitting directly into the Controllable PRESSURE Port.
CAUTION
When removing any Air Hose, turn and pull. DO NOT attempt to pull Air
Hose directly off. Damage to or breakage ofVacuum Fitting or VisiFilter
may occur.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16
TRADITIONAL METHOD
1. Connect the 54 inch (137cm) length of Air Hose to the metal
tube in the back of each air handpiece.
2. Insert a male quick connect hose mount Fitting (P/N 1259-
0087) to the free end of the 54 inch (137cm) length of Air
Hose. Secure the Air Hose to the handpiece power cable with
cable clips (P/N 1321-0085-01).
3. Prepare a VisiFilter in the following manner.
a) Connect a 1 inch (2.5cm) length of clear pvc Air Hose to
each side of the VisiFilter; push and turn hose onto
VisiFilter nipple to seat.
b) To the free end of the Air Hose connected to the FLOW IN
side of the VisiFilter, insert the ridged end of a female quick
connect hose mount Fitting (P/N 1259-0086).
c) Insert the ridged end of a male quick connect hose mount
Fitting (P/N 1259-0087) in the free end of the Air Hose
connected to the FLOW OUT side of the VisiFilter.
d) Connect the VisiFilter Air Hose (with attached male quick
connect hose mount Fitting) to the power source AUTO
SNAP-VAC Port.
SET-UP
Figure 7. Air Hose Connection
Figure 8. VisiFilter Set-Up
4. For vacuum, insert the male quick connect hose mount Fitting connected to the long Air Hose into the
female Fitting on the 1 inch (2.5cm) Air Hose (connected to VisiFilter). For pressure, insert the male
quick connect hose mount Fitting directly into the Controllable PRESSURE Port.
CAUTION
When removing any Air Hose, turn and pull. DO NOT attempt to pull Air
Hose directly off. Damage to or breakage of Vacuum Fitting orVisiFilter
may occur.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
