Pace TDC776D User manual

www.pace.com

1
CONTENTS
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and
other limited pay-per-view uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
This manual describes some on-screen displays such as menus.
These may change in the future, if the set-top’s software is
updated over the cable. However, the way that you use the
menus will remain similar to the way described in this manual.
SAFETY INFORMATION .............................................................................................2
REAR PANEL ...................................................................................................................8
CONNECTING THE EQUIPMENT........................................................................ 10
Connecting your TV to the AC power supply................................................ 14
Connecting the power cord to your set-top ................................................. 14
Connecting equipment to the wall AC outlets............................................... 14
OPERATING YOUR SET-TOP................................................................................... 15
Turning your set-top on and off......................................................................... 15
Using your remote control................................................................................. 16
Lightning storms.................................................................................................... 16
Using the front-panel buttons............................................................................ 17
Using your set-top’s DVR functions.................................................................. 18
Using an external hard disk ................................................................................ 19
Using RF Bypass..................................................................................................... 20
MAKING USER SETTINGS....................................................................................... 21
About User Settings ............................................................................................. 21
About the TV Aspect Ratio................................................................................. 22
About TV Display Capability (resolution settings)......................................... 23
Setting Auto Pillarbox........................................................................................... 26
Making Closed Captions Settings...................................................................... 28
Setting Front Panel Brightness ........................................................................... 29
Setting Hard Disk Sleep Mode........................................................................... 30
Changing HDMI Settings ..................................................................................... 31
Removing the User Settings menus.................................................................. 31
Restoring the factory default settings .............................................................. 32
USING ZOOM............................................................................................................. 34
USING THE SETUP MENUS ..................................................................................... 35
SOLVING PROBLEMS ................................................................................................ 36
TERMS AND CONDITIONS FOR USE OF SOFTWARE (“TERMS”) ........... 40
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC.
Other trademarks listed herein are the property of their respective owners.
© 2008 Pace plc.
All rights reserved.
Pace and are trademarks and/or registered trademarks of Pace plc

2
SAFETY INFORMATION
This digital set-top has been manufactured and tested with your
safety in mind. However, improper use can result in potential
electric shock or fire hazards.To avoid defeating the safeguards that
have been built into your set-top, please observe the precautions
discussed in this document.
To reduce the risk of fire or electric shock, do not expose this set-
top to rain or moisture.
On the rear panel of your set-top there is a tamper-evident label
that states ‘Warranty void if broken or removed’.
To avoid possible damage to the internal hard disk, do not pick up
or move your set-top while it is connected to the wall AC outlet. If
you want to move your set-top, first stop any recording, then turn off
your set-top and wait 60 seconds before disconnecting it.You should
handle your set-top carefully, as any damage you cause to the internal
hard disk (or any other component) will invalidate your warranty.
Installation
The installation of your set-top should be carried out by a qualified
installer and should conform to local codes.
Note to the installer
This reminder is provided to call the attention of the cable-TV-system
installer to Section 820 of the National Electrical Code (USA), which
provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as is practical.
Service address:
Pace Americas Inc.
3701 FAU Boulevard, Suite 200, Boca Raton
Florida 33431 U.S.A.
The lightning flash with arrowhead symbol, within a
triangle, is intended to alert you to the presence of
uninsulated “dangerous” voltages within your set-top’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within a triangle is intended to
alert you to the presence of important instructions in
the literature accompanying your set-top.
Other warnings
To reduce the risk of electric shock, do not remove the cover of
your set-top. There are no user-serviceable parts inside it.
Do not perform any servicing unless you are qualified to do so.
Refer all servicing to qualified service personnel. Servicing the set-
top yourself will invalidate the warranty.
Warnings on your set-top
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
ATTENTION

3
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read
and understand these Important Safety Instructions.
At all times when using the apparatus you must follow
these Important Safety Instructions to reduce the risk of
fire, electrical shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into the outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.

4
SAFETY INFORMATION (cont.)
In addition to the Important Safety Instructions, please read the
Safety Information below.
Power sources
The model number, serial number and electrical rating of this set-
top are on a label on its base.
You must operate your set-top only from the type of power
source indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your dealer or local
power company. If you move your set-top between locations at
different temperatures, allow it to reach room temperature before
you apply power to it.
Water and moisture
Do not expose your set-top to dripping or splashing and ensure
that no objects filled with liquids, such as vases, are placed on your
set-top. See also item 5 in the Important Safety Instructions.
Lightning
For added protection for your set-top during a lightning storm,
or when it is left unattended and unused for long periods of time,
disconnect the cable system from your set-top. See also item 13 in
the Important Safety Instructions.
Placement and mounting
Do not place your set-top on an unstable or uneven surface.
Your set-top may fall, causing serious injury to a child or adult and
serious damage to your set-top. If you mount your set-top, for
example to a wall or ceiling, follow the manufacturer’s instructions
and use a mounting accessory recommended by the manufacturer.
See also item 12 in the Important Safety Instructions.
Ventilation
Slots and openings in the casing of your set-top are provided for
ventilation, to ensure reliable operation of your set-top and to
protect it from overheating.
• Neverblocktheventilation
openings by placing your
set-top on a bed, sofa, rug or
other similar surface.
• Nevercovertheventilation
openings with items such as
newspapers, table-cloths or
curtains.
• Donotplaceyourset-top
in a built-in installation such
as a bookcase or rack unless
proper ventilation is provided
or you have adhered to the
manufacturer’s instructions.
• Itisrecommendedthatyoumaintainaminimumdistanceof
1 inch around your set-top for sufficient ventilation.
See also item 7 in the Important Safety Instructions.
1 inch 1 inch1 inch

5
SAFETY INFORMATION (cont.)
Entry of objects and liquids
Never push objects of any kind into your set-top through openings
as they may touch dangerous voltage points or short-out parts that
could result in fire or electric shock. Never spill liquid of any kind
on your set-top.
Transporting
Move the combination of set-top and cart with care. Quick stops,
excessive force and uneven surfaces may cause the combination
of set-top and cart to overturn. See also item 12 in the Important
Safety Instructions.
Risk of fire or scorching
Never place naked flame sources, such as lighted candles, on or
adjacent to your set-top.
Ambient temperature
The operating temperature range of your set-top is 32-104°F. If the
ambient temperature around your set-top falls outside this range,
you must correct this in order for your set-top to work correctly
and safely. For example, if the temperature is too high, switch on
the air conditioning.
Overloading
Do not overload wall outlets, extension cords or other power
outlets as this can result in a risk of fire or electric shock.
Replacement parts
When replacement parts are required, be sure that the
service technician has used replacement parts specified by the
manufacturer or that have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock or
other hazards. See also item 14 in the Important Safety Instructions.
Safety check
Upon completion of any servicing or repairs to your set-top, ask
the service technician to perform safety checks to determine that
your set-top is in its proper operating condition. See also item 14
in the Important Safety Instructions.
SAVE THIS INFORMATION FOR FUTURE REFERENCE

6
SAFETY INFORMATION (cont.)
Safety aspects of connections
Full details of the rear panel are on page 8.
Connecting
Do not connect your set-top (or any other equipment such as a TV
or VCR) to the power supply until you have properly connected all
the other cables.
Your set-top operates with a 120 V AC, 60 Hz power supply.
Do not connect your set-top to any supply other than this.
This set-top is equipped with a two-wire power cord, with a
polarized plug at one end.The other end of the cord is fitted with a
polarized connector, which is shaped such that it can be fitted only
one way into the power input jack of your set-top. Connect this
end first, before inserting the polarized plug into the wall socket-
outlet.
Disconnecting
Disconnect your set-top from the power supply before you
disconnect any other equipment from its rear panel.
The only way to disconnect your set-top from the power supply
is to remove the power cord from the wall socket-outlet.Your
set-top must therefore be installed near to the wall socket-outlet,
which should be easily accessible.
The POWER OUTLET plug is designed only for connection to the AC
power cord for a TV.The maximum power it can supply is 500 watts.
Do not connect any equipment that uses more than 500 watts, or
any non-TV equipment such as a toaster or hair dryer.
The CABLE IN connector is designed for
connection to a cable network only.
You must not connect any other equipment,
such as a VCR, to this input.
POWER INPUT
The model number, serial
number and electrical
rating of this set-top are
on a label on its base.

7
SAFETY INFORMATION (cont.)
Epilepsy and on-screen images
Certain people are susceptible to epileptic seizures or losing
consciousness when faced with certain types of flashing lights in
our daily environment.
These people are exposed to the risk of seizures if they watch
certain television images or if they view certain images while they
are browsing the Web.These phenomena may appear even when
the subject has no previous history of this problem or has never
suffered an epileptic seizure.
If you, or a member of your family, has already suffered symptoms
linked to epilepsy (seizure or loss of consciousness) in the presence
of stimulation by light, please consult your doctor before using this
product.
If you or any person using the equipment experiences dizziness,
involuntary movements or convulsion, please immediately stop
viewing and consult a doctor.
When you are browsing the Web or playing a Web-based game,
take the following precautions.
• Usetheequipmentinawell-litroom,andturndownthe
brightness of your television screen.
• Sitatareasonabledistancefromyourtelevisionscreen.
• Takeabreakfortenminuteseveryhour.
You should avoid using the Web if you are tired or have lost some sleep.
Regulatory information
CAUTION: Do not attempt to modify your set-top without
written authorization from the manufacturer. Unauthorized
modification could void your authority to operate your set-top.
NOTE
Your set-top has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules.These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.Your set-top generates, uses
and can radiate radio-frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If your set-top does cause harmful interference
to radio or television reception, which can be determined by turning
your set-top off and on, you are encouraged to try to correct the
interference by one or more of the following measures.
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweenyourset-topandthereceiver.
•Connectyourset-toptoanoutletonacircuitdifferentfromthatto
which the receiver is connected.
•Consultyourdealeroranexperiencedradio/TVtechnicianforhelp.

8
REAR PANEL
COMPONENT VIDEO
Component video output for
analog HDTV
AUDIO OUT
Audio outputs
(stereo, L and R)
CABLE IN
From cable
service-provider
TO TV
RF output to the
TV or VCR
S-VIDEO
S-video output
VIDEO OUT
Composite video output
SATA
For connection to an
optional external
hard disk
DIGITAL AUDIO OUT
Electrical S/PDIF audio output
POWER OUTLET
(500 W max.)
POWER INPUT
(Make this
connection
last of all)
OPTICAL AUDIO OUT
Optical S/PDIF audio output
ETHERNET
To connect to
optional PC
HDMITM
Video and audio
output for digital
HDTV
Universal Serial Bus
(USB) port
To connect USB devices
IR TRANSMIT
Infra-red output to control
a VCR (future use)
IR RECEIVE
Infra-red input from
a remote “eye”
TV PASS MODULE
Connector for a TV pass®
module (for installers’ use only)
