I
ixtremeM5850
Service Guide
PRINTED INTAIWAN

II
RevisionHistory
Please refertothe tablebelowfor theupdates made onixtremeM5850seriesguide.
Date Chapter Updated

III
Copyright
Copyright 2010byAcerIncorporated.Allrightsreserved.Nopartofthispublicationmaybe
reproduced,transmitted,transcribed,storedinaretrievalsystem,ortranslated intoanylanguageor
computerlanguage,inanyformorbyanymeans,electronic,mechanical,magnetic,optical,chemical,
manual orotherwise, withoutthe priorwritten permissionof AcerIncorporated.
Disclaimer
Theinformationinthisguideissubject tochangewithoutnotice.
AcerIncorporatedmakes no representationsorwarranties,eitherexpressedorimplied,withrespectto
the contentshereofandspecificallydisclaimsanywarrantiesofmerchantabilityorfitnessforany
particularpurpose.AnyAcerIncorporatedsoftwaredescribedinthismanualissoldorlicensed"as is".
Shouldtheprogramsprovedefectivefollowingtheirpurchase,the buyer (andnotAcerIncorporated,its
distributor,oritsdealer)assumestheentirecost ofall necessaryservicing, repair, andanyincidentalor
consequential damagesresulting fromanydefect inthesoftware.

IV
Conventions
Thefollowing conventionsareused inthismanual:
SCREEN
MESSAGES Denotes actual messages that appear
on screen.
NOTE Givesbitsandpieces of additional
informationrelated tothecurrent
topic.
WARNING Alertsyourtoanydamage that might
result fromdoing ornot doingspecific
actions.
CAUTION Givesprecautionarymeasures to
avoidpossiblehardwareorsoftware
problem.
IMPORTANT Remindsyoutodo specificactions
relevant totheaccomplishmentof
procedures.

V
Preface
Beforeusing thisinformation andthe product it supports, pleasereadthe followinggeneralinformation.
1. ThisServiceGuide providesyouwithalltechnicalinformationrelatingtothe BASIC
CONFIGURATIONdecidedforAcer's"global" productoffering.To betterfitlocalmarket
requirementsandenhanceproductcompetitiveness,yourregionalofficeMAYhavedecidedto
extendthefunctionalityofamachine(e.g.add-on card,modem,orextramemorycapability).
TheseLOCALIZEDFEATURES willNOTbe coveredinthisgenericservice guide. Insuch cases,
please contactyourregionaloffices orthe responsiblepersonnel/channeltoprovideyouwith
furthertechnicaldetails.
2. Please noteWHEN ORDERING FRUPARTS,thatyoushouldcheckthe mostup-to-date
informationavailableon yourregionalweborchannel. If,forwhateverreason,apart number
changeismade,itwill notbenotedintheprintedService Guide.ForACER-AUTHORIZED
SERVICEPROVIDERS,yourAceroffice mayhaveaDIFFERENTpart numbercodetothose
given intheFRU listof thisprinted Service Guide. YouMUSTusethe listprovidedbyyourregional
Acer office toorder FRUpartsforrepairandserviceofcustomer machines.

VI
Introducing theMotherboard................................................ 誤! 尚未定義書籤。
Features...................................................................................................2
MainboardComponents........................................................................4
BlockDiagram........................................................ 誤! 尚未定義書籤。
ixtremeM5850......................................................................................5
I/OPortIntroduction..............................................................................9
HardwareSpecificationsandConfigurations....... 誤! 尚未定義書籤。
Using BIOS...............................................................................................................16
Setup UtilityMenus............................................... 誤! 尚未定義書籤。
ProductInformation.............................................. 誤! 尚未定義書籤。
Standard CMOSFeatures....................................... 誤! 尚未定義書籤。
AdvancedBIOSFeatures........................................ 誤! 尚未定義書籤。
AdvancedChipsetFeatures................................... 誤! 尚未定義書籤。
IntegratedPeripherals........................................... 誤! 尚未定義書籤。
PowerManagementSetup................................... 誤! 尚未定義書籤。
PCHealth Status..................................................... 誤! 尚未定義書籤。
Frequency/VoltageControl................................... 誤! 尚未定義書籤。
BIOSSecurityFeatures........................................... 誤! 尚未定義書籤。
LoadDefaultSettings............................................ 誤! 尚未定義書籤。
MachineDisassemblyandReplacement................................................................30
GeneralInformation.............................................................................31
Standard AssemblyProcess..................................................................32
Standard DisassemblyProcess............................... 誤! 尚未定義書籤。
Troubleshooting.....................................................................................................66
Power-OnSelf-Test(POST)...................................................................67
POSTErrorMessagesList......................................................................71
Error SymptomsList..............................................................................73
UndeterminedProblems......................................................................77
JumperandConnector Information......................................................................78
FRU(FieldReplaceableUnit)List.........................................................................92
ExplodedDiagram................................................................................92
FRUList..................................................................................................98

1
Introducing the Motherboard
Introduction
Thankyou forchoosingthe H67motherboard.Thismotherboardisahigh performance, enhanced
function motherboarddesignedtosupport theLGA1155 socket for2ndGeneration IntelRCoreTM
Family/PentiumR/CeleronRprocessorsfor high-endbusinessorpersonaldesktopmarkets.
ThismotherboardisbasedonIntelRH67Chipset forbest desktopplatformsolution.H67 isasingle-chip,
highlyintegrated,highperformanceHyper-Threading peripheral controller, unmatchedbyanyother single
chip-device controller. Thismotherboardsupportsup to16 GBofsystemmemorywithdual channel DDR3
1333/1066SDRAM.TwoPCIaresupported,fullycompliantwithPCIrev2.2specificationat33MHz. High
resolutiongraphicsviaPCIExpress x16slot, intendedforGraphicsInterface, isfullycompliant tothePCI
Express BaseSpecificationrevision2.0.Inaddition,one PCIExpressslotissupported. Itimplementsan
EHCI(EnhancedHost ControllerInterface)compliantinterfacethat providesfourteen USB2.0ports(six
USB2.0portsat the back panel andfourUSB2.0headerssupport additional eight USB2.0ports).
The motherboardisequippedwithadvancedfull set of I/Oportsinthe rear panel, includingPS/2mouse
and PS/2keyboardconnectors,one DVI(co-layHDMI)port,oneD_sub (VGA)port, oneLanport, sixUSB
2.0/3.0ports, andaudiojacksfor microphone,line-inandline-out. Inaddition,thismotherboardsupports
twoSATA 6Gb/sconnectorsand fourSATA3Gb/sconnectors.
Chapter1

2
Features
Operatingsystem
Windows®7HomePremiumx86/x64,Windows®7HomeBasicx86,Windows®7Starter x86
Processor
Themotherboarduses anLGA1155 type of socketthatcarriesthe following
Features:
lAccommodates2nd Generation IntelRCoreTMFamily/ PentiumR/ CeleronRprocessors
lSupports “Hyper-Threading”technologyCPU
lOnePCIExpressx16 Gen2port supportingupto5GB/sdirectionpeakbandwidth
“Hyper-Threading”technologyenables theoperatingsystemintothinkingit’shookedup totwoprocessors,
allowingtwothreadstoberuninparallel,bothon separate “logical”processorswithinthe samephysical
processor.
Chipset
TheIntelH67 ExpressChipsetisasingle-chipwithproven reliabilityandperformance.
lSupport onePCI Express slot
lIntegratedtwoSATA6.0Gb/sHostController
lIntegratedtwoSATA3.0Gb/sHostController
lFourteenUSB2.0portssupported
lSerialPeripheralInterface(SPI)support
lIntegratedGraphicsSupportwithPAVP1.5
l•Intel®High DefinitionAudioController
Memory
lSupportsDDR31333/1066 DDR3SDRAMwithDual-channelarchitecture
lAccommodatesfour unbufferedDIMMs
lUpto4GBperDIMMwithmaximummemorysizeupto16GB
OnboardLAN
TheonboardLANprovidesthefollowing features:
lSupportsPCIExpressTM1.1
lIntegrated10/100 /1000transceiver
lWake-on-LANandremotewake-up support
Audiol5.1ChannelHigh DefinitionAudioCodec
lADCssupport44.1k/48k/96kHzsamplerate
lMeetsMicrosoft WLP3.10 Vistapremiumand mobilePCsaudiorequirements
lDirect Sound 3DTM compatible
ExpansionOptions
Themotherboardcomeswiththefollowing expansion options:
lOnePCIExpressx16 slotfor GraphicsInterface
lThree PCI Express x1slot
lSixSATAconnectors

3
IntegratedI/O
Themotherboardcomeswiththefollowing expansion options:
lTwoPS/2portsformouse andkeyboard
lOneVGAport
lOneHDMIport
lSixUSBports
lOneLAN port
lAudiojacksformicrophone,line-inandline-out
BIOSFirmware
Themotherboarduses AMIBIOSthatenables userstoconfiguremanysystemfeaturesincluding the
following:
lPower management
lWake-up alarms
lCPU parameters
lCPU and memorytiming
lGraphicparameters
Thefirmwarecanalsobe used tosetparametersfor different processorclockspeeds.
1.Somehardwarespecifications and softwareitemsaresubject tochange
withoutprior notice.
2. Due tochipsetlimitation, werecommendthat motherboardbeoperated
intheambiancebetween0and 50 C.
Dimensionsandweight
l355 (H)x382.5(D) x180(W)mm(withoutbezel)
l11.4Kg

4
MainboardComponents
No Label Component
1 CPU SocketAMDsocket
2 ATX_12VAuxiliary4-pinpower connector
3 SYS_FANSystemcooling fan connector
4 CPU_FAN CPUcooling fanconnector
5 DIMM1~4 240-pinDDR3SDRAMslots
6 ATX1Standard24-pinATXpowerconnector
7 CLR_CMOSClearCMOSjumper
8 ME_DISABLEMEdisableheader
9 LEDH1 Frontpanelswitch/LEDheader
10 SATA1~6SerialATA connectors
11 F_USB1~4 Frontpanel USBheaders
12 SPDIF_OUT SPDIFoutheader
13 F_AUDIO1Frontpanel audioheader
14 PCIE1Х-1~3 PCI Expressx1slot
15 PCIE16ХPCIExpress x16slot
ThisconcludesChapter1. Thenext chapterexplainshowtoinstallthemotherboard.

5
BlockDiagram

6
ixtremeM5850
Thecomputer’sfront panelconsistsof thefollowing
Frontview
No Icon Component Description
1 USB ports. ConnectstoUSB2.0devices
(e.g.,USBmouse, USBcamera).
2 xD
3 CF Compact flash.
4 MS/MSPro
MS:MemoryStick
MSPro:MemoryStick PRO
5 MicroSD MicroSecureDigital.
6 SD/MMC
SDPlus: UltraII SD PLUSMemory
Card
MMCPlus: MultiMediaCardPLUS
7 Headphone/Speaker-out/line-outport. Connectstoaudioline-indevices
(e.g.,speakers,headphones).
8 Microphone-injack. Acceptsinput fromexternalmicrophones.
9 USB ports. ConnectstoUSB2.0devices
(e.g.,USBmouse, USBcamera).

7
Rearview
No Icon Component Description
1 PS/2keyboardconnector
2 HDMI HDMIPort HighDefinition MultimediaInterface
3 USB2.0ports ConnectstoUSB2.0devices
(e.g., USBmouse,USBcamera).
4 Microphonejack Acceptsinput fromexternal
microphones.
5
PS/2mouse connector
6 Networkport Lightstoindicatethe statusof wireless
LAN communications.
7 Line-injack Acceptsaudioline-out devices
(e.g.,audioCDplayer,)
8 Line-out jack Acceptsaudioline-indevices
(e.g.,audioCDplayer,)

8
AudioJackFunctionTable
Color/Use Headphone 2CH 4CH 5.1CH
Blue Line-in Line-in RearSpeaker RearSpeaker
Green Headphone Frontspeaker Frontspeaker Front speaker
Pink Mic-in Mic-in Mic-in Center&bass

9
I/O Port Introduction
Thebackplaneofthe motherboardhas thefollowing I/Oports:
No Component Description
1 PS2Mouse Usetheupper PS/2port toconnectaPS/2pointing
device.
2 USBPorts UsetheUSBportstoconnect USBdevices.
3 LANPort Connectan RJ-45 jacktothe LANporttoconnectyour
computertotheNetwork.
4 Line-in/ Line-out /Microphone
Usethe threeaudioportstoconnectaudiodevices.The
firstjackisforstereo line-insignal.The second jack isfor
stereoline-out signal. Thethirdjackisformicrophone.
5 PS2Keyboard UsethelowerPS/2port toconnectaPS/2keyboard.
6 HDMIPort ConnecttheHDMIport totheHDMI devices.
7 VGAPort Connect yourmonitor totheVGAport.

10
System Peripherals
The IXTREME M5850 seriescomputerconsistofthe systemitself,andsystemperipherals,likea
mouse,keyboard,cardreaderandasetofspeakers(optional). Thissectionprovidesabrief description
of thebasicsystemperipherals.
Mouse(PS/2orUSB,manufacturing option)
Theincludedmouse isastandardtwo-button wheelmouse.Connectthe mousetothePS/2mouse port
or USBport onthe back panel ofthe system.
Keyboard(PS/2orUSB,manufacturingoption)
Connectthe keyboardtothePS/2keyboardport orUSB port onthebackpanelof thesystem.
Speakers
Forsystemsbundledwithspeakers, beforepoweringon the system, connect thespeakercabletothe
audioout (externalspeaker) port on theback panelofthe system.
Formoredetailed informationabout thespeakers, pleaserefertothe includedoperating instructions.
NOTE: speakersareoptionalandtheappearance might be different depending onthe actualproduct.

11
Card Reader(Option)
Memorycardsareusedinawideselectionof digital cameras,PDAs,MP3playersandmobilephones.
Selectedcomputersinclude an “all-in-one”memorycardreaderthatallowsyou readand writethemost
common types, suchas SD (SecureDigital)™/MMC(Multi MediaCard™), CF(CompactFlash®), xD
(XD-PICTURECARD), MicroSDandMS/MSPro(MemoryStick®).
NOTE: Cardreaderareoptionaland theappearance mightbedifferent dependingontheactualproduct.

12
HardwareSpecificationsandConfigurations
Processor Item Specification
Type LGA1155 socket for2ndGeneration IntelRCoreTM
Family/ PentiumR/CeleronRprocessors
Socket socketLGA1155
Speed DependsonCPUwhichisconfigured
FSB DependsonCPUwhichisconfigured
BIOS Item Specification
BIOScode programmer Afudos
BIOSversion P01-A0(ornewer version)
BIOSROMtypeFlashROM
BIOSROMsize 32MB
BIOSROMpackage32-pinDIPpackage(SST)
Support protocolACPI2.0, APM1.2,SMBIOS2.3,WFMsupport,
ASD
BootfromCD-ROMfeatureYes
Support toLS-120 FDD driveYes
NOTE: The BIOScanbe overwritten/upgradedbyusing the flashutility.
BIOSHotkeyList
Item Specification Specification
DEL EnterBIOSSetup Utility
Presswhilethesystemisbooting toenterBIOS
setup Utility.
F12 EnterBootMenu Presswhilethesystemisbooting toenterBoot
Menu.
MainBoardMajorChips
Item Specification
Chipset Intel H67
AGPcontroller Intel H67
SuperI/Ocontroller ITE8728F
Audiocontroller RealtekALC662
LANcontroller Intel 82579V
HDDcontroller Intel H67
Keyboardcontroller ITE8728F

13
System Memory
Item Specification
Memoryslot number 4slots
Support memorysizeper socket 1GBto4GB
Support maximummemorysize 16 GB
Support memorytype DDR3DRAM
Support memoryinterface DDR31066/1333
Support memorymodulepackage 240-pinDIMM
Support paritycheck feature Yes
Support toErrorCorrection Code(ECC)feature ECCchecking withdouble-bitdetectand single-bit
correct
Memorymodulecombinations Youcaninstallmemorymodules inany combination as longastheymatch the
specifications.
NOTE: Dual channelshouldbeenabled alwayswhenplug-in2samememorysizeDDRIImemorymodule.
CacheMemory Item Specification
First-Level Cache Configurations
Cache functioncontrol Alwaysenabled
Second-LevelCacheConfigurations
L2 CacheRAMsize Upto2MBper core(exclusive)
L2 CacheRAMspeed One-half the processorcoreclock frequency
L2 Cachefunction control Enable/DisablebyBIOSSetup
VideoInterface Item Specification
Videocontroller Intel H67
Videocontrollerresidentbus PCIE
VideoInterface X16
AudioInterface Item Specification
Audiocontroller Realtek
AudiocontrollerType ALC662
AudioChannel 5.1ch
Audiofunctioncontrol Enable/disablebyBIOSSetup
Monoorstereo 5.1channel
Samplingrate DACs:44.1k/48k/96k/192kHz
MPU-401UARTsupport Yes
Microphonejack Supported
Headphonejack Supported

14
IDEInterface Item Specification
IDEcontroller Intel H67
Number ofSATAconnector 4
Support bootableCD-ROM Yes
USBPort Item Specification
Universal HCI USB 2.0/3.0
USB Class Support legacykeyboardforlegacymode
USB Number support upto12 ports
PowerManagement
Devices S1 (Idle)
S3
(Suspendto
RAM)
S4
(Suspendto
DIsk)
S5
(ShutDown)
PowerButton Enabled Enabled Enabled Disabled
USBKeyboard Enabled Enabled Enabled N/A
LAN Disabled Disabled Disabled Disabled
RTC Disabled Enabled Disabled Disabled
Modem(Ring) Disabled Disabled Disabled N/A
