CHAPTER 1: WHEN TO USE ALAN EXPANSION MODULE
Packeteer’s PacketShaper, PacketSeeker and AppVantage
offer visibility into network application performance and the
ability to control it when needed. They monitor and manage
traffic at WAN access links, ensuring a smooth flow that
maximizes throughput and speeds critical traffic. A
LEM2-1000M-T and LEM2G-1000M-T LAN Expansion
Module extends these benefits to topologies that incorporate
multiple LANs.
The following scenarios are examples of situations that
require a Lan Expansion Module:
• You want to manage a single WAN link and your
network includes a firewall/router that splits your
network into two separate LANs: a protected segment
and a DMZ segment.
• You want to manage a single WAN link and your
network includes a router with multiple LAN
segments.
• You have a single WAN link and your network
includes a router with two LANs; one segment may
connect to the LAN through a firewall and the other to
a VPN tunnel management device.
• Your network includes branch offices with two or
three separate LANs that you manage, and only one
WAN link.

Chapter 1: Introduction
1-2
Gigabit LAN Expansion Module Requirements
The software for the LEM2-1000M-T Gigabit LAN Expansion
Module is included in PacketWise version 6.1.0 and all later
versions. The RoHs-compliant LEM2G-1000M-T requires
PacketWise 7.x or later.
✍Note: The PacketShaper 10000, PacketSeeker 10000 and
PacketShaper/ISP 10000 are only compatible with LEM2G-
1000M-T and later-generation LEM2-1000M-T LAN
Expansion Modules. These newer LEM2-1000M-T LEMs
can be identified by their serial numbers, which have values
of 006-10010001 or higher. For details, see “Problems?” on
page 3-12.
LANs connected to this copper-connector LEM module must use
10BaseT, 100BaseT, or 1000BaseT RJ-45 Ethernet ports or use
fiber optic conversion units for fiber optic networks.
LED
Indicators
The front panel of the LEM has the following LED indicators
beside each port.
LED
Indicator Description
Link Illuminated when the network cable is
properly connected
Tx/Rx Illuminated when network cable is properly
connected; flickers when the unit is
transmitting and receiving data
Speed When properly installed, the speed LED
color on the LEM module indicates that the
LEM is operating at the following speeds:
• amber = 1GB
• green = 100MB
•off=10MB

Chapter 1: Introduction
1-3
Installing a Gigabit LAN Expansion Module
The connectors on your Packeteer unit look like one of the four
illustrations below. Follow the instructions that match your unit.
If your unit looks like this, follow the installation directions in
Chapter 2, "Install into a 6500 Model."
If your unit looks either one of these, follow the installation
directions in Chapter 3, "Install into a 8500/9500/10000 Model."
FAULT
POWER
STATUS Tx/Rx
100
LINK
Tx/Rx
100
OUTSIDEINSIDE LINK
CONSOLE
FAULT
POWER
STATUS
CONSOLE
INSIDE OUTSIDE
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
FAULT
POWER
STATUS
CONSOLE
OUTSIDE
INSIDE OUTSIDE
LINK
Tx
Rx
LINK
Tx
Rx
FAULT
POWER
STATUS
CONSOLE
OUTSIDE
INSIDE OUTSIDE
LINK
Tx
Rx
LINK
Tx
Rx
BYPASS CTRL
INSIDE OUTSIDE
SX/LX
Tx/Rx
Link
SX/LX
Tx/Rx
Link

Chapter 1: Introduction
1-4

Chapter 2: Install into a 6500 Model
2-1
CHAPTER 2: INSTALL INTO A6500 MODEL
This chapter describes how to install a LEM2G-1000M-T or LEM2-
1000M-T Gigabit LAN Expansion Module (LEM) into
PacketShaper 6500, PacketShaper 6500/ISP, or
PacketSeeker 6500. The directions in this chapter apply only to
these models, which are hereafter collectively referred to as a
“6500 model.”
The following illustration shows a unit with two LEMs installed,
for a total of three LANs using one 6500 model. This is a maximum
configuration; you can install only one module if you wish.
Directions begin on the next page.
FAULT
POWER
STATUS Tx/Rx
100
LINK
Tx/Rx
100
OUTSIDE
INSIDE LINK
CONSOLE
WAN Router
INPUT 100-240 MAX 50-60Hz
INSIDE OUTSIDE
INSIDE OUTSIDE
LAN B
LAN C
LAN A
WAN
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED

Chapter 2: Install into a 6500 Model
2-2
Installing
the LEM
To install the LEM into a 6500 model:
1. Disconnect the system from any telecommunication links,
networks, or modems, and then turn off the system power
source. WARNING: Failure to do so before you open the
system or do any procedures can result in personal injury or
equipment damage.
2. Ground yourself. WARNING: Electrostatic discharge
(ESD) can damage system components. If an ESD station is
not available, wear a wrist strap attached to a metal part of
the system. If you don’t have a strap, touch some metal part
of the box to ground yourself.
3. Remove the rackmount ears (if present) from the 6500
model, then remove the screws from the back of the unit.

Chapter 2: Install into a 6500 Model
2-3
4. Remove the unit cover.
5. Remove the screw that holds one of the slot covers in place.
To install two modules, remove both slot covers.
INSIDE OUTSIDE

Chapter 2: Install into a 6500 Model
2-4
6. Remove the screws holding the C-shaped mounting bracket
from the module, then remove the bracket.
7. Attach the other bracket supplied with the LEM by aligning
the screw holes on the bracket tabs directly above the screw
holes on the module, then inserting the screws from below.
WARNING: Using an incorrect bracket can damage the
module or the 6500 model.
SPEED
Tx/Rx
LINK
SPEED
Tx/Rx
LINK
OUTSIDE
10/100/1000MB
Ethernet
INSIDE
SPEED
Tx/Rx
LINK
OUTSIDE
INSIDE
SPEED
Tx/Rx
LINK

Chapter 2: Install into a 6500 Model
2-5
8. If the unit is or will be using the standby function, remove
the jumpers from the module as shown below.
✍Note: Do not discard the jumpers; you will have to replace
them if you later wish to disable the standby function. For
additional information on enabling or disabling standby, refer
to the latest Getting Started Guide for your Packeteer unit,
available at http://support.packeteer.com/documentation.
9. Locate the expansion slots on the riser card in the interior of
the 6500 model.
LINK
Tx/Rx
SPEED
Tx/Rx
LINK
OUTSIDE
10/100/1000MB
Ethernet
INSIDE
SPEED
Tx/Rx
LINK
OUTSIDE

Chapter 2: Install into a 6500 Model
2-6
10.Insert the LEM completely into the opening, then push it
toward the expansion slots on the riser card until it snaps
into the slots. Be careful not to push the riser card so hard
that it disconnects from the motherboard. Note that there are
extra pins on the LEM that are not used on a 6500 model.
These extra pins will not attach to the riser card.
11. If you are installing two LEMs, repeat steps 6-10 for the
other module.
12.Replace the screw(s) that holds the expansion card(s) in
place, then replace the cover and cover screws.
SPEED
Tx/Rx
LINK
SPEED
Tx/Rx
LINK
OUTSIDE
INSIDE

Chapter 2: Install into a 6500 Model
2-7
Verify the Installation
Access the unit’s browser interface and check the setup tab to be
sure your card has been recognized by the system. It should look
something like the one below.
From the setup page, select one of the following NIC modes for
each LEM interface: 10BaseT half-duplex, 10BaseT full-duplex,
100BaseT half-duplex, 100BaseT full-duplex, 1000BaseT full-
duplex. Auto-negotiate is the default network communication
selection.
✍Note: Selecting 1000BaseT full-duplex causes the unit to
auto-negotiate per IEEE standard.
The screen above indicates that the built-in LEM card for this unit
is 100 Megabits, the lower slot contains a 100 Megabit LEM, and
the upper slot contains a Gigabit LEM.

Chapter 2: Install into a 6500 Model
2-8
Configure the LEM module
1. From the web browser interface, click the setup tab, then
choose the basic setup page. Set Site Router to none. If this
is set incorrectly, you may not be able to use the LEM.
2. To check security on this unit, select the setup tab, then
choose security from the drop-down box. The Outside and
Inside interface settings also apply to the LEM interfaces.
3. You can change security settings for all Inside and Outside
interface communication, if desired. Click the
Inside Interfaces: and Outside Interfaces: drop-down lists
to set access to all, none, or specified devices.
Setting Access Level
unsecure
(default)
Enables unlimited access over the specified
interface
secure Blocks all access from the specified interface
list Enables access to up to eight listed IP addresses,
separated by spaces and/or commas. To specify a
subnet, use the format: ipaddress:subnet_mask

Chapter 2: Install into a 6500 Model
2-9
Connect the Unit to a Router
Connect the Built-in Port
Use the following steps to cable the built-in port to a router:
1. On the router, disconnect the straight-through cable
connected to LAN A.
2. Reconnect this cable to the built-in port on the unit labeled
INSIDE.
3. Connect the unit's OUTSIDE port the router using the
orange cross-over cable.
FAULT
POWER
STATUS Tx/Rx
100
LINK
Tx/Rx
100
OUTSIDE
INSIDE LINK
CONSOLE
WAN Router
INPUT 100-240 MAX 50-60Hz
INSIDE OUTSIDE
INSIDE OUTSIDE
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LAN A
WAN

Chapter 2: Install into a 6500 Model
2-10
Connect the First LEM
Use the following steps to cable the first LEM module to a router:
1. On the router’s second LAN port, disconnect the straight-
through cable connected to LAN B.
2. Reconnect this cable to the INSIDE port of the LEM.
3. Using the orange cross-over cable, connect the OUTSIDE
port to the router.
FAULT
POWER
STATUS Tx/Rx
100
LINK
Tx/Rx
100
OUTSIDE
INSIDE LINK
CONSOLE
WAN Router
INPUT 100-240 MAX 50-60Hz
INSIDE OUTSIDE
WAN
LAN A
LAN B
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED

Chapter 2: Install into a 6500 Model
2-11
Connect the Second LEM
Use the following steps to cable the second LEM to a router:
1. On the router’s third LAN port, disconnect the straight-
through cable connected to LAN C.
2. Reconnect this cable to the INSIDE port of the second LEM.
3. Using the orange cross-over cable, connect the OUTSIDE
port to the router.
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
FAULT
POWER
STATUS Tx/Rx
100
LINK
Tx/Rx
100
OUTSIDE
INSIDE LINK
CONSOLE
WAN Router
INPUT 100-240 MAX 50-60Hz
INSIDE OUTSIDE
OUTSIDE
LAN C
LAN A
LAN B
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
LINK
Tx/Rx
SPEED
WAN

Chapter 2: Install into a 6500 Model
2-12
Managing Traffic with Three LANs
Traffic from all three LANs is now being tracked by one unit. The
traffic classes will reflect the combined traffic from all three LANs.
For example, POP3 will include POP3 traffic from LAN A, LAN
B, and LAN C.
If you wanted to manage the individual LAN traffic to/from the
WAN, you would create a class for each subnet and put classes
such as POP3 under each subnet class.
✍Note: Even though traffic classes are combined, each LAN’s
traffic is an individual flow; 6500 models cannot route traffic
between LANs. For example, if one LAN has public servers
and the other does not, the security of the non-public LAN
will not be compromised.
Traffic between LANs (LAN A to LAN B for example) should not
be shaped by a 6500 model, as it may slow the WAN speed. By
default, units auto-discover such traffic as “sameside” and apply an
ignore policy.
