PAIFANG HQD-314 User manual

kitchen waste disposer
Product manuals
The version number：V1.0.0

For users
Thank you very much for your kind of products! This manual is designed to give you
a quick grasp of how to use this product.
This manual applies to the following models:
Name: Kitchen waste disposer
Model: HQD-314
●Please read this product manual carefully before using the product and keep it safe
for easy reference at any time. If the equipment is damaged due to failure to follow
the requirements used in this manual, the warranty will not be covered.
● The pictures in this manual are for illustrative purposes only and are subject to
physical objects.

Directory
One ：Product overview................................................................................................................. 4
Two ：Product specifications.........................................................................................................4
Three ： Operating instructions.................................................................................................. 5
3.1 Button action...........................................................................................................................5
3.1 App usage instructions....................................................................................................... 9
Four ：Precautions.......................................................................................................................... 10
Five ：Questions and answers.................................................................................................... 11

One 、Product overview
This product is used for the treatment of kitchen waste equipment, through the "drying and
grinding" to decompose kitchen waste and form a dry and convenient natural fertilizer, with
a short decomposition cycle, large amount of garbage reduction, high temperature sanitize,
recyclable, low input costs and other characteristics. Under normal use, the amount of
organic waste can be decomposed and reduced by more than 85%, which greatly reduces
the burden on the environment, and the unique air purification system of the equipment
uses high-efficiency activated carbon to filter and UV lamp sterilization. The high-grade
board contains microbial degradation, through the "microorganism" to decompose the
kitchen waste and form organic fertilizer, reducing the amount by more than 90%.
Two 、Product specifications
Product model
HQD-314
HQD-314-Plus
HQD-314-PRO
Device baseThis
Information
Whether supports
microorganisms
Not
Not
Backing
Safety standards
GB4706.1/GB4706.
10
GB4706.1/GB4706.10
GB4706.1/GB4706.10
Whether or not to hav a display
Not
size
314*314*314
314*314*314
314*314*314
Whether child locks are
supported
Not
Not
Backing

Three 、Operating instructions
3.1 .Button action
Machine operating surface
Note: Under the corresponding button is the indicator light, which is the working
Opening method
Touch the button
Action tips
buzzer
buzzer
buzzer
Device status is displayed
Light
Whether UV sterilization is
supported
Support (Auto &
Manual)
Support (auto-on)
Support (auto-on)
Power supply mode
220v &110V
220v &110V
220v &110V
Barrel capacity
3.3L
3.3L
3.3L

indicator, the UV sterilization/strain decomposition indicator, and the child lock indicator.
The dot is an alarm indicator, and the alarm light is lit in the event of a stall or abnormal
high temperature.
Grinding and drying work button:
In the state of no open child lock, after a long press for 3 seconds to open, a "drip"
sound is emitted, and the device enters the grinding and drying working mode.
1、A "Dribble" prompt sound is emitted, and the machine enters working mode. The
working LED is on.
2、The first step is drying, the motor drives the metal blade to rotate slowly (35 seconds
positive -" 50 seconds stop -" 35 seconds reverse) metal blade 2.5r/min cycle, heating
control heating plate temperature to 110 degrees, exhaust fan began to work. The air
outlet temperature is constant at 65 degrees and the humidity is lower than 60 to enter
the next process;
3、The second part is crushed, and the motor drives the metal blade to rotate rapidly
(45 seconds forward rotation -" 35 seconds stop -" 45 seconds reverse) metal blade
about 3.5r/min cycle cycle, heating control heating plate temperature 110 degrees,
exhaust fan has been working, control the temperature in the barrel, air outlet
temperature is constant at 70 degrees and humidity is less than 10% to enter the next
process;
4、The third step is cooling, heating off, fan on, UV lamp cycle start and stop (30min per
hour, stop 30min), while the motor drives the metal blade to rotate slowly (60 seconds
positive -" 10 seconds stop -" 60 seconds reverse) metal blade 3.5r/min cycle, the air

outlet temperature is constant at 60 degrees and the heating plate is 70 degrees to end
the work.
UV sterilization/culture mode:
In the state of no open child lock, after a long press for 3 seconds to open, a "drip" sound
is emitted, and the low-end version of the device enters the UV sterilization mode, and
the high-end version enters the strain mode.
UV sterilization mode:
1、A "drip" sound is emitted and the machine enters UV mode.
The sterilization indicator light is on, the other indicator lights are off, and the UV lamp
cycle starts and stops (working 10min-"stop 10min-"working 10min).The exhaust fan
starts working. Heating controls the heating plate temperature to 80 degrees. At the
same time, the motor drives the metal blade to rotate slowly when the UV lamp stops
(35 seconds positive -" 35 seconds stop -" 35 seconds reverse) Metal blade 2.5r/min
cycle.
3、After 30 minutes into the cooling, heating off, fan on, UV lamp cycle start and stop (30
min per hour, stop 30 min), while the motor drives the metal blade to rotate slowly (60
seconds positive -" 10 seconds stop -》 60 seconds reverse) Metal blade about 3.5r / min
cycle, the air outlet temperature is constant at 45 degrees when the end of the work, all
control stops.
4、At the end of the cleaning mode, a "drip" sound is emitted for 5 times, and the
indicator light is also flashed 5 times at the same time when sterilizing. The system enters

sleep mode
Species decomposition mode:
1、A "drip" sound is emitted and the machine enters UV mode.
The sterilization indicator light is on, the other indicator lights are off, the UV light cycle
starts and stops (working for 35 seconds -" stop for 35 seconds -" working for 35
seconds). Heating controls the heating plate temperature to 85 degrees. At the same
time, the motor rotates rapidly (45 seconds positive -" 35 seconds stop -" 45 seconds
reverse) metal blade 3.5r/min cycle.
3、Wait for the humidity to be constant below 30 to finish the work, and make a "drip"
sound to prompt the end of the 5 times.
Open cover button：In the state of no opening child lock, after a
long press for 3 seconds to open, a "drip" sound is emitted, the
magnetic suction is closed, and the cover bullet reaches 60 degrees.
童锁按钮：
1 、 Long press UV +
After 3 seconds of opening, a "drip" sound is
emitted, the child lock
lamp is lit, and the machine opens the child
lock.
2、Long press UV+
3 seconds to release, make a "drip" sound, the
machine turns off
the child lock.
Sleep mode:
1、UV disinfection indicator 1 second flashing, the motor drives the metal blade to rotate

slowly (35 seconds positive -" 30min stop -" 35 seconds reverse) metal blade about 2.5r/min
cycle, while the fan follows the motor start and stop, the interval period is 30 minutes, the
temperature in the barrel is controlled to 30 degrees.
3.1App usage instructions
For the time being, only support Android system, after installing the APP, open
Bluetooth and enter the APP.
1、Click on the image location to enter the Bluetooth scan page
2、Click on the image location to turn on Bluetooth scanning
3、Find Beeco in the list and click Connect.

4、The APP can monitor data and operate the equipment
Four 、Precautions
1、Do not release hard objects or large bones, which may cause the stirring tip to break.
2、Be careful not to put too much water in the garbage.
3、During the working hours of the equipment, open the lid and do not touch the metal

drum to avoid burns
Five 、Questions and answers
1、How much power is consumed?
A: The maximum power is 650W, and the single process consumes about 1.1 kWh of
electricity.
2、How noisy is the operation?
A: Less than 48 dB.
3、How long does it take to turn food waste into drying and grinding?
A: It generally takes 4-6 hours, and the moisture is longer.
4、Activated carbon filter:
A: Durability time; 4 months (but also depending on the frequency of use, the service
life of the filter needs to be adjusted).
