Painless Performance 50340 User manual

Off-Road Switch Panel
Installation Instructions
50340: 6 Switch Extreme Off-Road Switch Panel
w/ Push Button Start
Painless Performance Products recommends you, the installer, read this installation
manual from front to back before installing this harness.

1
Painless Performance Products, LLC
2501 Ludelle Street
Fort Worth, TX 76105-1036
800-423-9696 phone –817-244-4024 fax
Web Site: www.painlessperformance.com
E-Mail: [email protected]
If you have any questions concerning the installation of this product,
feel free to call Painless Performance Products' tech line at 1-800-423-
9696. Calls are answered from 8am to 5pm central time, Monday thru
Thursday, 8am-4:30pm Friday, except holidays.
Here we have provided you with accurate instructions for the
installation of this product. However, if you have comments/suggestions
concerning these instructions, please call or email us (our contact
information can be found at the top of this page or online at
www.painlessperformance.com). We sincerely appreciate your business.
Painless Performance Products, LLC shall in no event be liable in
contract or tort (including negligence) for special, indirect, incidental, or
consequential damages, such as but not limited to, loss of property, or any
other damages, costs or expenses which might be claimed as the result of
the use or failure of the goods sold hereby, except only the cost of repair or
replacement.
Should you damage or lose part of your manual, a full-color copy of
these instructions can be found online at www.painlessperformance.com
2nd Edition: Jan 2019
Copyright 2019 by Perfect Performance Products, LLC

2
CONTENTS OF THE PAINLESS KIT
Refer to the Contents Figure (below) to take inventory. See that you have
everything you’re intended to have in this kit. If you find that anything is missing or
damaged, please contact the dealer where you obtained the kit or Painless Performance
at [phone].
The Painless Off-Road toggle Switch Kit should contain the following:
(1) 6-Switch Customizable Switch Panel w/ (1) label sheet
(1) Mounting Box w/ (3) 7∕8” plastic plugs & (1) rubber grommet
(1) Foam Liner
(9) Toggle Switches
o(5) On-Off
o(2) On-Off-On
o(2) Off- Momentary On
(6) Toggle Switch Boots
(1) Push-Button Starter Switch
(8) Indicator Lights
o(3) Amber
o(3) Red
o(1) Blue
o(1) Green
Hardware: (15) 10-12 ga. Ring Terminal, (12) 14-16 ga. #10 ring
Terminals, (8) 18-20 ga. Ring Terminals, 14-16 ga. butt connectors, &
(6) 8x12 screws

3
INSTALLATION
First, decide what switches will be used for your
application and install them into the panel. Start by
adjusting the hex shaped backing nut on each of the
switches ¾ of the way back toward the body of the switch.
Insert the switch through the switch hole opening
with the slot on the threads facing down and screw the black
toggle switch boot onto the front of switch by hand until
snug.
Next, using either a 5∕8”or a 16mm deep wall
socket hold the switch boot in place while tightening
the hex shaped backing nut to fully secure the switch
to the panel. Tightening the switch using the nut
inside the switch boot could damage the shoulders
around the boot.
In order to allow the maximum amount
of room for the switch labels, line the switch
boots up with the flat sides of the hex-shaped
nut running parallel with the top and bottom
sides of the switch panel.
Install the Push Button Start Switch
into the switch panel. Install and tighten the
weather-resistant retaining nut by hand. Next tighten the switch backing nut to fully
secure the switch to the panel. NOTE: A thread locker may be used to assist in
keeping the ignition switch nut from vibrating loose. The start switch has 2
connections, power into the switch, and power out of the switch to the starter solenoid. It
does not matter which position carries which function.
Illustration A,
illustrates the proper
hookup of wires to an
on/off switch, which
will control a single
device.
Illustration A

4
Illustration B, illustrates the proper hookup of wires to an on/off/on switch, which
will control 2 separate devices.
Illustration B
The power wire to the Indicator can only be connected to one of the Output wires.
Connecting it to both Outputs will only tie the Outputs together causing power to be routed
to both devices no matter which “on” position the switch is switched to. Illustration C
shows the correct way to connect the Indicator to both Outputs using diodes.
Illustration C

5
Illustration D illustrates the proper hookup of wires using an on/off/on switch
when two devices are to be operated and one of the devices is to be on in both positions.
An example might be headlights and taillights. With the switch in the upper position only
the taillights are on and in the lower position the headlights and taillights are on. The
diode, in the illustration, allows this function to take place.
Illustration D
Once all of the wires have been connected to the switches, the polyethylene liner
can be installed. Decide which hole of the roll bar mounting box the wires will be exiting
and make a small hole in the liner. Then, pass the wires through the opening. Next, slide
the liner over the switches and flush up to the panel.
Install the rubber grommet in the corresponding hole of the roll-bar mounting box
and route the wires out that hole. Use the plastic plugs to fill the remaining holes. Secure
the switch panel with the liner installed down onto the box with the six screws provided in
this kit.
For dash mounted panels, you must cut a 9 ¾” x 2 ¼” opening for the six switch
panel to allow room for the polyethylene liner.

6
The plastic wire ties are for looming and securing the wires to the vehicle.
The label sheet included is to identify each switch of its function. Simply peel off the
label needed and place it under the switch wired for that function. The "R" and "L"
labels are for right and left in the event an on/off/on switch is turned sideways for turn
signals
