Pakedge RT-3100 User manual

RT-3100
5-Port Single-WAN Gigabit Router
User Guide

Contents
Introduction 4
Technical Support 4
Installing 4
Getting to know your product 5
Front panel 5
Back panel 6
Accessing the router 7
First-time login 8
Saving changes 8
Configure 9
Overview 11
Connections 12
Interfaces 13
Edit interface settings 13
Completing the dialog 14
Edit WAN Settings 14
Select a mode 14
Configure DNS Settings 15
DHCP 16
Static 17
PPPoE 17
Dual-Stack Lite 18
L2TP 19
Edit LAN/VLAN Settings 19
Backup/Restore 23
Logs 24
Reset to factory default settings 25
Reset using the interface 25
Reset using the physical RESET button 25
Advanced 26
BakPak 27
Registration 27
Maintenance 27
Unregister from BakPak 27
Device Settings 28
Enable settings 28
Settings 29
Diagnostic Tools 29
Factory Defaults 31
DHCP Reservation 32
Add a new reservation 32

Manage DHCP entries 33
Remove reservations 33
Dual WAN 35
Dynamic DNS 36
Pakedge Dynamic DNS 36
Non-Pakedge DDNS 38
Complete the dialog 40
Add a secondary DDNS profile 41
Edit or delete a Dynamic DNS entry 41
Firewall 42
Global Settings 42
Forwards 43
Add new policy 44
Add Firewall Policies 44
Firmware 47
Multicast Routing 48
Complete the Multicast rule dialog 49
NAT (Port Forwarding) 50
Complete the NAT Policy dialog 51
Parental Controls 54
Block websites 54
Schedule Internet 56
Complete the Intenet Schedule dialog 57
QoS 59
Restrict WAN upload and download speeds 59
Add a QoS priority setting 60
Complete the Add Priority dialog 61
Static Routes 62
VLAN Port Settings 64
VPN 65
Configure OpenVPN 65
Enable the OpenVPN Server 65
Create OpenVPN user profiles 66
Set up the OpenVPN user profile 67
OpenVPN client setup for Windows, iOS, Android 67
Windows 67
iOS 68
Android 71
Configure PPTP 77

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Introduction
The popularity and affordability of IP networking has driven audio/video and control networks
to share the same physical wiring with computer networks. However, computer data can
tolerate unpredictable latency in ways that audio/video streaming and control systems cannot.
Sophisticated systems require the same robustness as an enterprise network to ensure that IP-
based controls occur instantly and audio/video packets arrive in time.
Note: If this is your first time installing this product, please read this manual in its entirety.
Technical Support
Pakedge is committed to providing you with exceptional support on all of our products. If you
wish to speak with one of our representatives, contact us at:
lEmail: [e-mail]
lPhone: 650-385-8703
Visit our website for up-to-date support information at www.pakedge.com.
Be prepared to provide your product's model and serial number. Your model and serial
numbers are printed on a label located on the electronic housing.
Installing
For installation procedures, refer to the Quick Start Guide that came with the router or go to
pkdge.co/rt-3100-ug. You can also visit the Dealer Portal for all the current manuals and
Quick Start Guides.
For rack installation, make sure that the amount of air flow required for safe operation of the
equipment is not compromised.
Caution: If you install the router in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room temperature.
Make sure you install the equipment somewhere within the recommended temperature
range.
For free-standing installation, make sure that the router has at least 1.5 in. (3.75 cm) of
clearance on each side to allow for adequate air flow and cooling.
4

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Getting to know your product
Package contents:
lRT-3100 router
lMounting brackets
lPower cable
l2-meter (about 6 feet) CAT5E cable
lQuick Start Guide
Front panel
LED Status Operation
USB 1 LINK/ACT Blue USB is connected
Flashing
blue
Activity
Off No device connected
WAN 1 LINK/ACT Blue Port is online (link established)
Flashing
blue
Activity
Off No device connected
LAN 1-4 LINK/ACT Blue Port is online (link established)
Flashing
blue
Activity
Off No device connected
Power Blue The router is
powered on
Off The router is
turned off
5

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Back panel
Interface Type Speed Protocol Description
RESET button N/A N/A N/A Hold RESET
button for
10 seconds
while the
power is on
to factory
default the
settings
USB 1 USB-A Up to 5 Gbps USB 3.0 USB port
used for
debugging
and future
use
WAN 1 RJ- 45 10/100/1000
Mbps
Ethernet WAN port
used for the
internet
connection
from the ISP
LAN 1 - 4 RJ- 45 10/100/1000
Mbps
Ethernet 4-port
switch
connections
on the
internal
network
AC
Power input
AC N/A N/A Power Input
Power switch N/A N/A N/A On/Off
power
switch
6

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Accessing the router
To access the router’s interface:
1. Connect an Ethernet cable to the router and a computer.
2. Make sure your network card is set to obtain an IP address automatically, then open any
internet browser and go to http://192.168.1.1 or pakedgerouter.com.
Note: For best results, we recommend using Mozilla Firefox as your web browser.
3. Enter the default username admin and the password password, then click Sign in.
Important: You must change this default password. For instructions, see
Username/Password.
7

RT-3100 5-Port Single-WAN Gigabit Router User Guide
First-time login
The first time you log in, you are brought to the Configure tab. Here you can change your
username and password (required), and specify the device’s network information and network
protocol.
For BakPak Lite setup instructions, see the RT-3100 Quick Start Guide.
Saving changes
After logging in, you can edit your settings on many tabs.
Important! You must click Apply to save your changes. Changes will not be saved to the
router until you click Apply at the top of the tab.
8

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Configure
The Configure tab allows you to change the most common router settings in one screen. This
is the default tab that displays after logging in.
lEdit Login Credentials:
lUsername and Password: The first time you log in, you must change these from the
defaults (“admin” and “password”) to new credentials.
lGeneral Device Information:
lFriendly Device Name: Give the router a descriptive name to identify it on its web
interface screen and in BakPak.
lDevice Location: Describe the physical location of the router here.
lDevice Settings:
lTime Zone: Select the time zone used for the router’s event logs.
lWAN1:
Mode: Select a network protocol (DHCP, Static, PPPoE, L2TP) and then complete the
required fields. (Examples below).
lDHCP:
lFor DHCP networks, the IP Address,Subnet Mask, and Gateway fields are
read-only.
lStatic:
9

RT-3100 5-Port Single-WAN Gigabit Router User Guide
lIP Address: Enter the router’s IP address.
lSubnet Mask: Enter the router’s subnet mask.
lGateway: Enter the router’s Gateway address.
lPPPoE:
lEnter the PPPoE Username and Password.
lL2TP:
lL2TP Server: Enter the remote server IP address of the L2TP server you’re
connecting to.
lL2TP Username/Password: Enter the L2TP Username and Password.
lDNS Settings:
lDNS Server [n] (server’s IP address): For a static IP network, enter up to two DNS
server IP addresses here. For a DHCP network, these fields are read-only.
lLAN:
lIP Address: Enter the IP address for the router’s local network.
(For a DHCP network, this field is read-only).
lSubnet Mask: Enter the router’s subnet mask.
(For a DHCP network, this field is read-only).
lDHCP Start/End: Assign the first and last IP address you would like to use in the
DHCP range. You can have up to four DHCP ranges per interface.
10

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Overview
The Overview tab gives you a quick view of the router’s status and critical settings.
On this page, you will find information on the current Firmware version, number of active
sessions on the router, CPU and memory usage, uptime, serial number and the number of
devices on the network.
If there is new firmware available for the router, you will see a message alerting you with an
option to download it.
lNotifications: System notifications display at the very top of the tab. This example shows
a firmware update is available.
lDevice Name: The device name (assigned in the Configure tab) appears here.
lIP Address and MAC Address: The device’s assigned IP address and unique MAC
address is shown here.
lLocation: Displays the configured "Location" of the device.
lCurrent Status: Shows the router’s Up/Down status.
lUpdate Firmware: Click to open the Update Firmware screen (also accessible under the
Advanced tab). The screen also displays the firmware’s release notes.
lRestart Device: Click to restart (power cycle) the router. It happens immediately, with no
confirmation dialog.
lServices: Displays the status of current services and settings and indicates with an icon
whether the service or setting is optimally configured.
11

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Connections
The Connections tab displays a list of connected devices.
Click any column head to sort the list by that field. Available fields are:
lHostname
lIPType
lIP Address
lMAC Address
lLease Time
lTX/RX
To Reserve or Clear a DHCP Lease on a device, click the … More icon.
lReserve: Click Reserve to have DHCP to always assign the same IP address to the
selected machine.
lClear DHCP Lease: Click Clear DHCP Lease to have the server immediately assign a
new IP address to the selected machine.
12

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Interfaces
The Interfaces tab gives you easy access to the router’s physical and virtual interfaces.
Enable/disable an interface, check port status, and view/edit interface configurations.
Edit interface settings
To edit an Interface’s assigned IP Address, Subnet Mask, Gateway, or DHCP Settings:
1. Click the … More icon and select Edit.
2. Type any adjustments (see below)
3. Click Continue.
4. Click Apply (at the top of the page) to save and apply your changes.
13

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Important! Your changes will not be saved until you hit Apply.
Completing the dialog
Depending on the selected device, you will see an Edit WAN or Edit VLAN dialog.
For help with each dialog, see below.
(Continued...)
Edit WAN Settings
Select a mode
In the Edit WAN dialog, choose a Mode (DHCP, Static, PPPoE, L2TP) for your WAN settings.
The Mode specifies how the WAN interface will connect with the Internet Service Provider.
14

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Depending on the Mode you selected, the settings in the dialog change.
See below for help completing the Edit WAN dialog.
Configure DNS Settings
Many WAN modes ask you to enter DNS settings.
See the table below for help configuring the DNS settings.
15

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Field Explanation
DNS Server 1, 2 Enter up to two WAN DNS server addresses.
MTU Enter the WAN MTU value.
PMTU Enable/disable.
Override MAC
Address
Specify which MAC address to use for the WAN interface.
VLAN Tag on
WAN
Enable/disable.
VLAN ID Enter the VLAN ID.
Rely on ICMP Enable/disable.
Allow the WAN interface to reply to PINGrequests coming
from the internet.
For instructions on completing the rest of the dialog, see below.
DHCP
If you are using DHCP, configure these settings:
Field Description
DNS Server Enter the WAN DNS server address.
DNS Settings: Add New Add a custom DNS entry.
Override MAC Address Specify which MAC address to use for the WAN interface.
Other settings See DNS Settings (above).
16

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Static
If you are using Static, configure these settings:
Field Description Comments
IP
Address
Enter the WAN IP address. Tip: Cannot be in IP ranges of
another WAN Interface, for
example:
lDMZ Interface
lVLAN Interfaces
lPPTP Range
lOpenVPN Subnet
Gateway Enter the WAN Gateway address
from the Internet Service Provider.
IP
Subnet
Mask
Enter the WAN subnet mask.
Other
settings
See DNS Settings (above).
PPPoE
If you are using PPPoE, configure these settings:
17

RT-3100 5-Port Single-WAN Gigabit Router User Guide
Field Description
PPPoE Username/Password Enter the PPPoE Username and Password.
Other settings See DNS Settings (above).
Dual-Stack Lite
If you are using DSLite, configure these settings:
Field Description Comments
DS-Lite AFTP
Address
Enter the IP address of the Address
Family Transition Router.
Use any valid IPv4 or
IPv6 IP address.
18

RT-3100 5-Port Single-WAN Gigabit Router User Guide
L2TP
If you are using L2TP mode, configure these settings:
Field Description
L2TP Server Enter the remote server IP address of the L2TP server you’re
connecting to.
PAP/CHAP
Username
PAP/CHAP
Password
Enter the L2TP Username and Password.
Edit LAN/VLAN Settings
In the Edit LAN/VLAN dialog, specify how devices will connect to the local network(s) of the
router.
19

RT-3100 5-Port Single-WAN Gigabit Router User Guide
20
