Palfinger RSQ 450 Series User manual

BHP Billiton Iron Ore Pty Ltd
A.B.N. 46 008 700 981
City Square
125 St Georges Terrace
PERTH WA 6000
FRM-000-G-00011
VENDOR DOCUMENT PAGE 1 of 208
NUMBER 8946-C-83093-VD-00192/0
DESCRIPTION TUGS & TUG HARBOUR
RASTAR85 TUG
MANUAL
RESCUE BOAT & DAVIT
OFFICE OF ORIGIN ASL Shipyard Pte Ltd CONTRACT: 8946-C-83093
WRITTEN BY Palfinger DATE: -ASL Hull No: H1104-09
CHECKED BY Winfield Zheng DATE: 17/11/16
TITLE OF CHECKER Engineering Manager (Asst)
STATUS APPROVAL BY BHPBIO RESPONSIBLE MANAGER/ENGINEER
SIGNED DATE REV.
ACCEPTED
(Alpha or Numeric)
.......................... .................... .............
ACCEPTED EXCEPT AS NOTED
(Alpha)
.......................... .................... .............
REVISE AND RESUBMIT
(Alpha or Numeric)
.......................... .................... .............
APPROVAL BY BHPBIO RESPONSIBLE MANAGER
(Numeric)
.................................................................................. DATE: ................................
Rev. Date Description By Checked BHPBIO
0 17/11/16 For Construction PALFINGER
Iron Ore Projects
Review Outcome:
(Apply final outcome review stamp)
…………………………………………………
AUTHORISATION TO PROCEED DOES NOT
RELIEVE THE SELLER/CONTRACTOR OF ANY RESPONSIBILITY OR
LIABILITY UNDER THE PURCHASE ORDER / CONTRACT
Document No.:
Submission No.:
8946-C-83093-VD-00192
2
APPROVED
APPROVED
APPROVED
CONTRACT:
8946-C-83093
ASL Hull No: H1107
Vessel Name: IRON
BROLGA
Naval Architect's Name: RAL
Naval Architect's No.: 213-082

HARBOUR FACILITIES
TUGS – RASTAR 85 01
MANUAL
RESCUE BOAT & DAVIT
Doc
No.:
Page:
8946-C-83093-
VD-00192/A
2 of 208
Contents
RESCUE BOAT - RSQ 450 G
Operation and Maintenance Manual .................................................................. 3
OUTBOARD ENGINE - 40 SEA PRO/MARATHON – 30/40 HP
Operation and Maintenance Manual ................................................................ 40
HYDRAULIC SLEWING DAVIT SYSTEM – SCH 10 5.2 R
Operation and Maintenance Manual .............................................................. 123
AUTOMATIC RELEASE HOOK – CAR35
Operation and Maintenance Manual .............................................................. 191

Operation and Maintenance Manual
RSQ 450 Series
Rescue Boat
Revision 2015-07-14

TECHNICAL MANUAL
OPERATION MANUAL
INSTALLATION MANUAL
PALFINGER BOATS
INSTALLATION
SPAREPARTS
INSTALLATION MANUAL
ORIGINAL ENGLISH MANUAL
TRANSLATION BY PALFINGER BOATS
PROVISIONAL EDITION
FINAL EDITION
REVISIT EDITION
Boat RSQ 450 SERIES
Made for customer: Standard manual
Customer order number:
Palfinger boats project number:
Manual number: OM-450 AG-02 RSQ 450 series
Revision: 2015-07-14 First release 2011-09-08

2015-07-14 2 RSQ 450 series
PALFINGER BOATS B.V.
Pasteurdijk 8
3846 BS Harderwijk
The Netherlands
[phone]
[e-mail]
www.palfingerboats.com
P
ALFINGER BOATS
B.V. Service
& spare parts
[e-mail]
www.palfingerboats.com

2015-07-14 3 RSQ 450 series
Important information
Copyright © PALFINGER BOATS 2014
The copyright on this manual and any other information supplied remains the property of
PALFINGER BOATS.
The information may only be used for installation, training and servicing according to the
function it was originally intended.
Re-use, re-engineering, reproduction or transmission, other than as mentioned here, in
any form, in whole or in part, by electronic or mechanical means, without the prior
written approval of PALFINGER BOATS, is prohibited.
Copyright © or trademar
Third party trademarks and / or copyright material are property of their owners.
Warranty
Warranty on products of PALFINGER BOATS
Terms and Conditions of Contract of Holland Marine Equipment Association filed
with the Clerk of Rotterdam District Court on May 31st 2002, File number 71/2002.
Liability
Marine Equipment Association filed with the Clerk of Rotterdam District Court on
May 31st 2002, File number 71/2002.
Statutory regulations
The information in this manual is generally valid information applicable to the rescue
boat. The eventual installation will have to comply with the statutory rules and
regulations as prevailing locally in the country where the rescue boat is being used.
PALFINGER BOATS will not accept any claims from third parties caused by non-
compliance with these statutory rules and regulations.
Execution of Work
PALFINGER BOATS is not responsible for execution of the work with or on the rescue
boat. This work should be carried out by properly trained persons.
Liability for the Contents of this manual
Our manuals are constantly updated we reserve the right to change the contents without
notice. Although the greatest care has been taken to arrive at a correct and complete
description of the connection of the rescue boat, PALFINGER BOATS and its re sellers do
not accept any liability for damage resulting from any inaccuracies and / or omissions in
this manual.
Deficiencies
If you encounter any deficiencies in this manual, however, we would very much
appreciate being notified of them. This helps us to further optimize our documentation.
General
Personnel must be trained for safety, operations and general maintenance on a regular
base. Technical specifications and the descriptions are subject to change without notice.

2015-07-14 4 RSQ 450 series
Table of contents
Important information ............................................................................................ 3
Table of contents ................................................................................................... 4
1. Introduction .................................................................................................... 7
1.1. General .................................................................................................... 7
1.2. Introduction ............................................................................................. 7
1.2.1. Construction RSQ 450 A ....................................................................... 7
1.2.2. Construction RSQ 450 G ...................................................................... 7
1.2.3. General description RSQ 450 series ....................................................... 7
1.3. Target group............................................................................................. 9
1.4. Conventions ............................................................................................. 9
1.5. He / she form ........................................................................................... 9
2. Technical description .......................................................................................10
2.1. General ...................................................................................................10
2.1.1. Layout of the rescue boat ....................................................................10
2.2. Technical specifications .............................................................................11
2.3. RSQ 450 series rescue boat limitations .......................................................11
2.4. Technical description RSQ 450 series rescue boat .........................................11
2.4.1. Hull construction ................................................................................11
2.4.2. Outboard engine ................................................................................11
2.5. Rescue boat fittings (permanently fitted) .....................................................12
2.5.1. Stowage facilities ...............................................................................12
2.5.2. Hoisting facilities ................................................................................12
2.5.3. Painter facilities .................................................................................12
2.5.4. Retro-reflective materials ....................................................................12
2.5.5. Rescue boat markings/lettering ............................................................12
2.5.6. Towing facilities .................................................................................12
2.5.7. Handholds .........................................................................................13
2.6. Rescue boat equipment, (loose items) ........................................................13
2.7. Optional accessories and equipment ...........................................................13
3. Preparation arrival unloading and installing ........................................................15
3.1. General ...................................................................................................15
3.2. Arrival storage and unloading ....................................................................15
3.2.1. Arrival ..............................................................................................15

2015-07-14 5 RSQ 450 series
3.2.2. Storage .............................................................................................15
3.3. Receiving a Rescue boat ............................................................................15
3.4. Take out a rescue boat from a container .....................................................17
3.5. Preparing the rescue boat .........................................................................18
4. Controls and instruments description ................................................................19
4.1. Forward, neutral or reversing .....................................................................19
4.2. Steering ..................................................................................................19
4.3. Speed .....................................................................................................19
4.4. Hoisting release hook................................................................................19
4.5. Painter release .........................................................................................19
5. Safety ...........................................................................................................20
5.1. General ...................................................................................................20
5.2. Responsibilities ........................................................................................20
5.3. Operator requirements ..............................................................................20
5.3.1. Physical ............................................................................................20
5.3.2. Mental ..............................................................................................20
5.3.3. Emotional ..........................................................................................21
5.3.4. Training ............................................................................................21
5.3.5. Operator duties and responsibilities ......................................................21
5.3.6. Responsibilities ..................................................................................21
5.3.7. Clean surroundings .............................................................................21
5.4. Controls and instruments ..........................................................................21
5.4.1. ................................................................................21
5.4.2. Fire extinguisher ................................................................................22
5.4.3. Position indication light .......................................................................22
5.4.4. Search light .......................................................................................22
5.4.5. Fuel pump .........................................................................................22
6. Operation description ......................................................................................23
6.1. General ...................................................................................................23
6.1.1. Forward or reversing ..........................................................................23
6.1.2. Steering ............................................................................................23
6.1.3. Speed ...............................................................................................23
6.1.4. Hoisting release hook .........................................................................23
6.1.5. Painter release ...................................................................................23

2015-07-14 6 RSQ 450 series
6.1.6. Launch & recovery of the rescue boat ...................................................23
6.1.7. Preparations before launching ..............................................................23
6.2. Launching instructions ..............................................................................24
6.3. Recovery instructions ................................................................................25
6.4. Other situations .......................................................................................26
6.4.1. Up-righting of capsized boat ................................................................26
6.4.2. Rescue of floating persons ...................................................................26
6.4.3. Towing ..............................................................................................27
7. Trouble shooting ............................................................................................28
8. Maintenance of the RSQ 450 series ...................................................................29
8.1. Several items to check ..............................................................................29
8.2. Maintenance & control ..............................................................................30
8.2.1. Maintenance schedule .........................................................................30
8.2.2. RSQ 450 series MAINTENANCE LOG ......................................................33
9. Recommend ship spares ..................................................................................34
10. Drawings and listings ...................................................................................35
11. Appendix ....................................................................................................36

2015-07-14 7 RSQ 450 series
1. Introduction
1.1. General
All systems that are delivered to the costumer are fully tested according the rules and
regulations applicable. During these tests, all components are set for optimal
performance of the rescue boat.
For a safe operation of the Rescue boat, the operator(s) need to be fully aware of the
equipment controls and how to operate these. Therefore we will insist to read this
manual and the supplemental manuals before un-packing, installing and starting up the
rescue boat.
Follow every instruction in this handbook. This will prevent for possible accidents and the
periodic maintenance will assure a long working life. Incorrect maintenance results in
warranty loss. For maintenance purposes we recommended the customers to have a 1
year service package present. For details, please refer to chapter 9.
1.2. Introduction
All PALFINGER BOATS rescue and fast rescue boats are designed according to the
standards which have been recorded by the different classification bureaus. This means
that all our boats meet the requirements which are necessary for recovery of persons
who have accidently fallen overboard.
A rescue boat is carried for the protection of everyone on board. However it can only
fulfill its task, if the assigned persons on board are acquainted with the whole rescue
boat, its functions and operations. Only permanent practice gives confidence to the
rescue boat and prevents mistakes of handling in case of danger.
1.2.1. Construction RSQ 450 A
The RSQ 450 A rescue boat is a rigid rescue boat, made 5083H111 grade aluminium. The
hull of the RSQ 450 A rescue boat is a so-
divided into several compartments. It has been built-up of an upper hull and lower hull
stiffened by several bulkheads. All compartments are pressure tested to make sure all
compartments are watertight.
The hull has been executed with a stern inlet to accommodate the outboard engine. Its
V-shaped hull construction guarantees an optimum planing and subsequent sailing speed
with excellent stability characteristics.
1.2.2. Construction RSQ 450 G
The RSQ 450 G rescue boat is a rigid rescue boat, made of E-glass glass fibre. The hull of
the RSQ 450 G rescue boat is a so-
into several compartments. It has been built-up of an upper hull and lower hull stiffened
by several bulkheads. All compartments are filled with approved polyurethane foam.
The hull has been executed with a stern inlet to accommodate the outboard engine. Its
V-shaped hull construction guarantees an optimum planing and subsequent sailing speed
with excellent stability characteristics.
1.2.3. General description RSQ 450 series
The RSQ rescue boat, 450 series are being designed for long time operations.
It has been designed especially to rescue people in distress as well as to marshal life
rafts. The rescue boat is capable of carrying at least 5 seated persons and 1 person
laying on a stretcher.

2015-07-14 8 RSQ 450 series
The RSQ 450 series are capable of manoeuvring at a speed of 6 knots as a minimum and
to maintain that speed for a period of at least 4 hours. It is optional to have bigger
engines up to 40HP which will increase the top speed and bollard pull.
Marshalling or towing of life rafts can be done by using the two bollards which are
permanently fitted at the stern of the rescue boat.
It shall be clear that the capacity of the outboard engine depends on the size of the
largest life raft.
In the unfortunate event of capsizing, the RSQ 450 series rescue boat can be up righted
by two persons.
To make this possible, the rescue boat has been provided with a righting rope and
various handgrips on gunwale and bottom. Moreover the rescue boat is fitted with grab
lines at starboard and portside.
The RSQ 450 series rescue boat has been executed with one aft bench and two seats in
the front.
Between the front seats there is a safe and easily accessible area for a person lying on a
stretcher. The aft bench is permanently fitted and fully integrated into the hull
construction. The aft bench offers 2 seats.
Although the rescue boat has adequate sheer, it has been provided with a bow cover to
protect the crew from water spray. Nevertheless, the deck has been provided with a non-
skid surface and the boat is automatically self-bailing.
The RSQ 450 series rescue boat are designed, built and equipped to comply with the
following requirements:
RSQ 450 A
SOLAS 74 Convention as amended, Regulations III/4, X/3, III/21, III/31 and III/34
IMO Res. MSC.48(66) amended by MSC.207(81), MSC.218(82), MSC.272(85),
MSC.293(87) and MSC.320(89)
IMO Res. MSC.36(63)-(1994 HSC Code) 8
IMO Res. MSC.97(73)-(2000 HSC code) 8
IMO Res. MSC.81(70) amended by MSC.200(80), MSC.226(82) MSC.274(85),
MSC.295(87) and MSC.321(89)
IMO MSC/Circ.1006
IMO MSC/Circ.980
RSQ 450 G
SOLAS 74 Convention as amended, Regulations III/4, X/3, III/21, III/31 and III/34
IMO Res. MSC.48(66) amended by MSC.207(81), MSC.218(82), MSC.272(85)
MSC.293(87) and MSC.320(89)
IMO Res. MSC.36(63)-(1994 HSC Code) 8
IMO Res. MSC.97(73)-(2000 HSC Code) 8
IMO Res. MSC.81(70) amended by MSC.200(80), MSC.226(82), MSC.274(85),
MSC.295(87) and MSC.321(89)
IMO MSC/Circ.1006
IMO MSC/Circ.980
It is also approved according the latest amendments with a person weight of 82.5 kg
each person.
The RSQ 450 series rescue boat meets the latest IMO/SOLAS requirements and LSA Code
(Chapter V, regulation 5.1 Rescue boat
96/98 EC on Marine Equipment (M.E.D.) and U.S. coast guard (U.S.C.G.).

2015-07-14 9 RSQ 450 series
All tests have been carried out with a person weight of 82,5 kg according to the latest
amendments.
Only properly trained personnel should operate the rescue boat and davit.
1.3. Target group
This manual is made to assist the personnel responsible for:
Installation
Operation
Maintenance
It is the owners responsibility:
All personnel, working with or on the installation, described in this manual, must
be familiar with the contents of this manual.
If you receive any supplements to this manual from the supplier, these should be added
to the manual immediately.
1.4. Conventions
In this manual the following signs are
special importance.
Danger
Identifies possible dangers in operation and maintenance. Ignoring the
information can result in death, serious injury or equipment damage.
Warning
Identifies possible dangers in operation and maintenance. Ignoring the
information can result in serious injury or equipment damage.
Caution
Identifies conditions that can disturb the normal process and can damage the
equipment or product.
Instruction
Important instructions will be indicated with this sign.
Warning
Danger for injury by electrical power.
Warning
Crush hazard. Keep hands clear.
Environmental advice
Advice to exonerate the environment or to stimulate recycling.
1.5. He / she form
In this manual persons are referred

2015-07-14 10 RSQ 450 series
2. Technical description
2.1. General
This chapter covers the technical specifications of the RSQ 450 series rescue boat.
2.1.1. Layout of the rescue boat
Figure: layout of the rescue boat
Figure: layout of the rescue boat
No Description
1 Painter line hook
2 Light
3 Lifting eye (4pcs in total)
4 Storage location for two paddles
5 Fuel tank compartment
6 Storage compartment, with equipment
(ref. DWG, 3FS-100003 and 3FS-100009)
7 Bollard (2 pcs in total)
8 Bailing pipe
9 Outboard engine
10 Drain plug
1
5
3
2
6
3
7
8
10
9
4

2015-07-14 11 RSQ 450 series
2.2. Technical specifications
Type RSQ 450 A FRSQ 450 G
Manufacturer PALFINGER BOATS PALFINGER BOATS
Length overall Max. 4875 mm
(dep. of engine type)
Max. 4875 mm
(dep. of engine type)
Length hull 4320 mm 4320 mm
Beam overall 1750 1750
Height, keel to lifting
point
Max. 1633 mm
(dep. of engine type)
Max. 1633 mm
(dep. of engine type)
Max. weight Max. 960 kg
(dep. of engine type)
Max. 966 kg
(dep. of engine type)
Bollard pull 1060 N till 2200 N
(dep. of engine type)
1060 N till 2200 N
(dep. of engine type)
Engine 15 HP till 40 HP 15 HP till 40 HP
2.3. RSQ 450 series rescue boat limitations
Launching and recovery: max 6 persons (check davit SWL and boat type plate in some
cases SWL is downgraded.
2.4. Technical description RSQ 450 series rescue boat
The following describes the technical description and technical data summarized
2.4.1. Hull construction
V-shaped double hull construction executed with stern inlet and bow cover. Stowage
compartments for small equipment are located underneath the bow cover and the aft
bench.
RSQ 450 A rescue boat
The rescue boat is built with the colour: orange (RAL2004) or yellow (1016).
RSQ 450 G rescue boat
All fiberglass is E-glass quality and approved by a class certification society.
The RSQ 450 G Rescue boat is built with gel coat, colour: orange (RAL2004).
2.4.2. Outboard engine
The RSQ 450 series rescue boat is supplied with a SOLAS approved long tail outboard
engine with single propeller propulsion.
Starting the engine is done manually by means of a starter rope.
Steering is done by the helmsman by moving the tiller handle to the left or to the right.
The tiller handle has been provided with a throttle grip which can be turned clockwise or
anti-clockwise in order to increase or decrease the sailing speed.
For safety reasons the outboard engine is supplied with a safety stop switch and lanyard.
This lanyard is a coiled cord which can be stretched out to a certain length. One end of
this lanyard is connected to the safety stop switch whilst the other end is attached to the
helmsman by wrapping it around his wrist or leg.
In the unfortunate event of the helmsman falling overboard, the safety stop switch will
be activated automatically and the engine stops immediately.
To protect people in the water from getting injured by the rotating propeller, and foreign
objects getting entangled with the propeller, the engine is equipped with a propeller
guard.

2015-07-14 12 RSQ 450 series
The fuel tank(s) are stowed underneath the aft bench of the rescue boat and are lashed
down securely by means of straps.
A fuel hose with integrated hand pump is included in the scope of supply.
The RSQ 450 series rescue boat can be equipped with outboard engines of different
brand names and outputs up to 40 horsepower (hp).
In most common cases the RSQ 450 series rescue boat is supplied with a 2-stroke engine
of 25 hp.
PALFINGER BOATS has exclusive rights for supplying Selva Marine SOLAS approved
outboard engines however, other outboard manufacturers can be supplied as well.
2.5. Rescue boat fittings (permanently fitted)
2.5.1. Stowage facilities
A stowage compartment is located underneath the bow cover of the rescue boat. In this
compartment all loose rescue boat equipment can be stowed.
A second stowage facility can be found underneath the aft bench. This is used for
stowage of the fuel tank.
2.5.2. Hoisting facilities
The rescue boat is equipped with a certified 4-point lifting sling suspension. The slings
are made from high quality nylon straps.
The lifting lugs are made of stainless steel 316 and are electric polished.
2.5.3. Painter facilities
The RSQ 450 series rescue boat is fitted with a painter device on top of its bow cover.
This painter device is of sufficient strength to withstand the towing forces when the
rescue boat is being towed by the mother ship making headway at speeds up to 5 knots
in calm water.
The painter device consists of a stainless steel painter hook which can be released at all
times from inside the rescue boat by means of a pull cord.
2.5.4. Retro-reflective materials
The RSQ 450 series rescue boats are fitted with self-adhesive seawater resistant retro-
reflective materials in order to detect the rescue boat from all directions, even if it has
been capsized.
2.5.5. Rescue boat markings/lettering
The rescue boat is provided with the following markings/lettering:
Number of persons for which the rescue boat is approved
Port of registry
Call sign
Due to logistic reasons, the above mentioned markings/lettering will be applied only in
case they have been confirmed to us in writing not later than three weeks before the
agreed delivery date. Information received after this date shall not be processed
anymore.
2.5.6. Towing facilities
Two bollards of sufficient strength to marshal or to tow life rafts are fitted permanently at
the stern of the rescue boat. The bollards from the 450 A are made of aluminium. The
bollards form the 450 G are made of electric polished stainless steel 316.

2015-07-14 13 RSQ 450 series
2.5.7. Handholds
The rescue boat is fitted with 4 handholds. The handholds from the 450 A are made of
aluminium. The handholds from the 450 G are made of stainless steel 316.
2.6. Rescue boat equipment, (loose items)
The RSQ 450 series rescue boat will be out-fitted with several loose items of rescue
equipment.
For part numbers, please refer to chapter 10, drawings and listings.
Quantity Description Comments
1 Boarding ladder
1 Bucket
1 Electric watertight torch incl. spare batteries
1 First Aid Kit
1 Floating rope L = 50m
1 Floating whistle
1 Floating knife
1 Paddle
1 Paddle incl. hook
1 Painter line L = 30m
1 Rescue equipment bag
2 Rope with Buoyant ring L = 30m
1 Sea anchor L = 10m
1 Water bailer
1 Position indicating light (A.1/1.2)
1 Battery for Position indicating light (A.1/1.2)
1 Radar reflector (A.1/1.33)
1 Searchlight (A.1/1.38)
1 Search light battery
2 Thermal Protective Aid (A.1/1.7)
1 Portable fire extinguisher (A.1/3.38)
1 Portable compass (A.1/4.23)
1 Sponge USGC only
Remarks
With the exception of the paddles, the above mentioned items are properly stowed away
in a weather tight stowage bag that can be found in the stowage compartment
underneath the rescue boat
All items that are marked with have been type approved in accordance with the
European Council Directive 96/98 EC on Marine Equipment (M.E.D.) and applicable
amendments.
2.7. Optional accessories and equipment
The items listed below are available as option.
Rescue net
The RSQ 450 series rescue boat can be equipped with an RSQ-net as an option.
This RSQ-net is a rescue net that has been designed for safe and quick recovery

2015-07-14 14 RSQ 450 series
of a drowning person from the sea. It will be delivered in a weather tight stowage
bag and can be fitted permanently into the rescue boat.
Boat cover
Upon request the RSQ 450 series rescue boat can be supplied with a boat cover in
order to keep the cockpit clean and tidy.
Boat cradle
Unless integrated into its launching device, the RSQ 450 series rescue boat can be
supplied with a boat cradle for safe and adequate installation on deck.
There are two different cradles available, a fixed type and a releasable type. In
case the rescue boat is launched by means of stored power, the cradle must be a
releasable one.
Non-standard outboard motors
Upon request.
Steering Console
Upon request.
Navigation systems such as VHF, SART or EPIRB
Upon request.
separately from this manual.
The above mentioned options are just randomly picked from the various possibilities. We
wish to draw your attention to the fact that all items that have not been mentioned
explicitly will be considered as non-standard and subsequently excluded from our scope
of supply.

2015-07-14 15 RSQ 450 series
3. Preparation arrival unloading and installing
3.1. General
Thoroughly reed and understand these instructions.
This operation and maintenance manual must be read before operating the RSQ 450
series rescue boat engine supplier
(Engine Instruction Manual), release hook supplier and if used in combination with a
use the complete system both boat, release hook and davit!
Misuse of the total system can cause serious injuries or death!
The first paragraphs describes the preparations that must be made before the rescue
boat is put in service.
Caution.
When in doubt, contact PALFINGER BOATS before undertaking any activity.
3.2. Arrival storage and unloading
3.2.1. Arrival
Check supplied goods with the packing/shipping list.
Check for possible damage in the presence of the transporter or his representative.
Any damage must be noted on the freight bill and signed by the transporter or his
representative. A detailed description of the damage (including photographs) must be
immediately communicated in writing to:
The shipping agent
Insurance agent
PALFINGER BOATS
Caution
Do not change or repair anything before agreement of all parties involved.
In addition, refer to PALFINGER BOATS conditions of sale.
3.2.2. Storage
Caution
Preferably, store the rescue boat in a dry and frost free aria. Put a tarpaulin
cover over the rescue boat, make sure that the boat has a little trim to the stern
so that water /condensate can drain trough the drain pipes at the stern of the
rescue boat.
When the engine is new / unused, the engine is conserved by the manufacturer, no
further storage requirements are necessary. If the engine is used or tested, please refer
to the engine manufacturer manual for storage requirements.
If the engine is used make sure that the cooling water is drained to prevent frost
damage. Also change the oil inside the reversing gearbox is advised.
Instruction
Protection against corrosion
responsibility.
PALFINGER BOATS cannot accept any guarantee claims for damage caused by
incorrect storage.
3.3. Receiving a Rescue boat
Before sending the RSQ 450 series rescue boat to our clients the rescue boat have to
undergo several quality checks. One of the quality checks is if the boat is completely
delivered as ordered by our client. If this is found to be compliant with the order,

2015-07-14 16 RSQ 450 series
PALFINGER BOATS seals the hatches to prevent losses of equipment. Also every delivery
is clearly documented to be confident of a correct delivery.
Normally a rescue boat is shipped inside a container, below an illustration showing a
typical delivery of a RSQ 450 series after being removed from the container.
Figure: Typical delivery RSQ 450 series
If equipment is missing please contact our service department at service-
[e-mail]. Please mention the serial number of the rescue boat. The serial
number can be found on the type plate at the starboard side of the aft bench, see also
the illustration above and below.
Typical example type plate
Type plate
Safety equipment as per
drawing
Hosting sling /
2pc paddles
Wooden transport
cradle
Fuel tank & fuel hose
underneath the bench

2015-07-14 17 RSQ 450 series
3.4. Take out a rescue boat from a container
Note: illustrations below may not show correct boat type, removal from container goes
via the same principal.
1. Jack up the cradle and place
four rollers underneath the
cradle.
2. Roll the cradle outwards as far
as possible.
3. Lift the back end of the cradle
up with a forklift truck.
4. Drive backwards until lifting
hook is out of the container.
Without overhead crane:
5. Place a block under the rear of
the cradle.
6. Lift the cradle with the boat up
on the lifting hook with a forklift
until it is free from the rollers.
7. Ask the truck driver to move
the truck forward until entire boat
is clear of the container.
With overhead crane:
5. Lift the boat up on the lifting
lug with an overhead crane until
it is free from the rollers.
6. Move the boat further out of
the container or ask the truck
driver to move forward.
Reference drawing 3FTR-100005
