SUN ODYSSEY 42DS
OWNER'S MANUAL
CROISIERE
134928
Index D

-1/124
WELCOME ABOARD
Madam, Sir,
You have just taken delivery of your new JEANNEAU boat and we thank you for the
confidence you have shown us in ordering a vessel of our brand. The whole JEANNEAUteam
welcomes you aboard.
A JEANNEAU is made to last, in order to bring you all the pleasure you expect from a vessel
over a period of many years. Each boat is subject to the utmost attention to detail from the
design stage right through to launching.
This manual is meant to help you to enjoy your boat comfortably and safely. It includes the boat
specifications, the equipment provided or installed, the systems and tips on her operation and
maintenance. Some of the equipment described in this manual may be optional.
Your JEANNEAU dealer will be able to help and advise you in the use and maintenance of
your boat.
Read this user's guide/owner's manual carefully and get to know your boat before using it.
The better you know your vessel the more pleasure you will get from being at the helm.
The sea is a source for learning. Caution based on a knowledge of one's own limits and those
of the boat is the pre-requisite for an accomplished sailor.
Even when your boat has been adapted for them, the sea and wind conditions corresponding
to the design categories A, B, C and D may vary, ranging from severe conditions to strong
storms subject to the risks of exceptional waves and gusts of wind, this meaning they are
dangerous conditions in which only an experienced, fit and well trained crew manoeuvring a
well maintained boat can sail in a satisfactory manner.
This user's guide/owner's manual is not a course in safety at sea or about sailing sense. If this
is your first boat or if you change to a new type of boat which you are not used to, get some
training in boat control and sailing to ensure your safety and comfort. Your dealer, your
international sailing association or your yacht club will be very happy to recommend local
sailing schools or professional instructors.
Make sure the sea and wind conditions will correspond to the category of your boat and you
and your crew are able to handle the boat in these conditions.
Always listen to the weather forecast before you put out to sea.
Keep this user's guide/owner's manual in a safe place and hand it over to the new owner if
you sell your boat.
You are advised to keep all the instructions and manuals provided by the boat equipment
manufacturers (accessories...) in the same place as this manual

1/124
INTRODUCTION
THE USERS OF THE BOAT ARE INFORMED OF THE FOLLOWING:
This user guide/owner's manual is not a maintenance or repair guide. In case of difficulty
do not hesitate to call on the services of your concessionaire JEANNEAU.
Any alterations which may affect the safety specifications of the boat must be assessed,
carried out and recorded by persons qualified to do so. Any change in the distribution of the
vessel's mass (adding a radar, altering the mast, changing an engine, etc) may affect the
stability, trim and performance of your boat.
The SPBI shipyards may not be held responsible for any alterations which they have not
approved.
The complete crew must be equipped appropriately.
In numerous countries, a licence, an authorization or a training course is requested. Make
sure you have this legal authorization before you use your boat.
Adapt the use of your boat to her condition that wears out with time and use.
Any boat, however solid she may be, may be severely damaged if badly used. This is not
compatible with safe navigation. Always adapt the speed and direction of your boat to the
conditions of the sea.
The boat shall not be loaded more with than the maximum load recommended by the
builder, in particular the total weight of the food supplies, of the different equipment that are not
supplied by the builder and of the persons on board.
The weight of the boat shall be properly distributed.
The stability is reduced when you add weight in the upper parts.
In case of heavy weather, the hatches, lockers and doors shall be closed in order to
minimize the risk of water coming in.
Breaking waves are a serious threat to stability.
The water in the bilge shall be kept at its minimum.
The stability may be reduced when you tow a boat or when you lift heavy weights with the
davits or the boom.
If your boat is equipped with a liferaft, carefully read the instructions. The boat must have
on board all the proper safety equipment (lifejackets, buoys, harness, flares, liferafts, etc.)
depending on the type of vessel, its certification, the country, the weather conditions
encountered, etc.
The crew must be familiar with the use of all the safety equipment and the emergency
safety procedures (MOB, towing etc.). Sailing schools organise regular training sessions.

2/124
Anyone on the deck shall wear a life jacket or a buoyancy aid.
The safety regulations as defined by the sailing code and enforced by the ’’COLREG’’ should
be observed.
NAME PLATE:
Some of the data is shown on the manufacturer'splate fixed to the boat. The explanation of the
data is given in the appropriate chapters of this manual.
IDENTIFICATION OF VESSEL:
The vessel's identification is found on the builder's certificate delivered with the boat and is
engraved on the starboard aft side.
So as to be able to continuously improve their product the SPBI shipyards reserve the right to
make any alterations in design, layout or equipment which they judge necessary.
That is the reason why the specifications and information given are not contractual, they may
be modified without prior notice or up dates.
This owner's manual is designed in accordance with the ISO 10240 standard requirements, it
has a general purpose and it may sometimes list some equipment or accessories or deal with
some points or questions that are not relevant to your own boat.
The different warnings used throughout this guide are broken down as follows.
DANGER
Indicates the existence of a serious inherent danger with a high risk of death
or serious injury if the appropriate precautions are not taken.
WARNING
Indicates the existence of a danger which could lead to injury or death if the
appropriate precautions are not taken.
PRECAUTION
Indicatesareminderofsafetypracticeor draws attentiontodangerouspracticeswhichcould
cause injury to persons or damage to the vessel or to its components.
ADVICE - RECOMMENDATION
Indicates a recommendation or advice for carrying out manoeuvres appropriate for the
planned manoeuvres.

3/124
HISTORY OF UPDATES
•Index A ........................................................................................................................12/2009
•Index B ........................................................................................................................09/2010
•Index C........................................................................................................................02/2011
•Index D........................................................................................................................08/2012

5/124
CONTENTS
INTRODUCTION
Chapter 1 ...... SPECIFICATIONS AND WARRANTY............................................Page 7
Chapter 2 ...... SAFETY ........................................................................................Page 13
Chapter 3 ...... HULL.............................................................................................Page 31
Chapter 4 ...... DECK ............................................................................................Page 35
Chapter 5 ...... STEERING SYSTEM ....................................................................Page 45
Chapter 6 ...... RIGGING AND SAILS...................................................................Page 49
Chapter 7 ...... INTERIOR .....................................................................................Page 69
Chapter 8 ...... WATER AND SEWAGE WATER .................................................Page 75
Chapter 9 ....... ELECTRICAL EQUIPMENT .........................................................Page 85
Chapter 10 .... ENGINE.......................................................................................Page 103
Chapter 11 .... LAUNCHING...............................................................................Page 115
Chapter 12 .... WINTER STORAGE....................................................................Page 119
PERSONAL NOTES
SUN ODYSSEY 42DS Anglais
Update 08/2012
Index D
Code: 134928 Total number of pages: 124

7/124
SPECIFICATIONS AND WARRANTY
TECHNICAL SPECIFICATIONS
CERTIFICATION
DESIGN CATEGORY
YOUR BOAT
1

8/124
TECHNICAL SPECIFICATIONS
L.O.A .............................................................................................................................12,93 m
Hull length......................................................................................................................12,59 m
L.W.L..............................................................................................................................11,60 m
Overall width....................................................................................................................4,13 m
Beam................................................................................................................................4,13 m
Waterline beam................................................................................................................3,33 m
Air draught (Classical mast)...........................................................................................18,70 m
Air draught (Mast with in-mast furling)...........................................................................19,21 m
Air draught (Mast Performance).....................................................................................19,28 m
Keeled version - Deep draught keel
Draught............................................................................................................................2,10 m
Ballast weight................................................................................................................2 550 kg
Light displacement........................................................................................................8 925 kg
Displacement with maximum load ..............................................................................11 152 kg
Maximum load recommended by the builder................................................................2 382 kg
Keeled version - Shallow draught keel
Draught............................................................................................................................1,60 m
Ballast weight................................................................................................................2 780 kg
Light displacement........................................................................................................9 122 kg
Displacement with maximum load ..............................................................................11 349 kg
Maximum load recommended by the builder................................................................2 382 kg
Including the mass of the persons who are authorized on board (75 kg/165 lbs per adult), the
supplies, the liquids that can be used (fresh water and fuel) in fixed completely full tanks, the
additional loads, the optional equipments, the liferaft and the scope for load.
Total mass of liquids (all tanks full)..................................................................................749 kg
Freshwater capacity................................................................................................200 l + 155 l
Extra tank............................................................................................................................160 l
Fuel capacity.......................................................................................................................130 l
Refrigeration unit capacity ..................................................................................................190l
Sewage water capacity...............................................................................85 l + 45 l (optional)
Recommended maximum power..................................................................................... 42 kW
Battery capacity - Engine...................................................................................................110A
Battery capacity - Service............................................................................................ 2 x 110A
Battery capacity - Spare battery.........................................................................................110A
Battery capacity - Bow thruster............................................................................................50A
Cabins.......................................................................................................................................2
Architect.................................................................................Marc LOMBARD, Garroni Design
Note: The capacities indicated are maximum (including options).

9/124
SAILS CLASSIC JIB REEFER PERFORMANCE
CERTIFICATION
DESIGN CATEGORY
The SUN ODYSSEY 42DS model conforms to the directive 2003/44/CE.
Mainsail (classic).......39,4 m2..................37,9 m2....................... 40,7 m2
Genoa........................42,7 m2..................42,7 m2....................... 45,7 m2
Asymmetric spinnaker 135 m2...................130 m2.........................135 m2
Symmetrical spinnaker125 m2 ............................... .........................125 m2
I................................. 15,85 m.................15,85 m....................... 16,30 m
J..................................4,86 m...................4,86 m.........................4,86 m
P .............................. 14,88 m.................15,23 m....................... 15,48 m
E.................................4,45 m...................4,85 m.........................4,45 m
The sails are the main propulsion means of the SUN ODYSSEY 42DS.
CE Category Maximum number of per-
sons
A8
B10
C14
D14
Design category Wind force
(Beaufort scale) Significant height of waves to be conside-
red
(in metres H 1/3)
Vessel designed for naviga-
tion:
A - "At high sea"
B - "In open sea"
C - "Near to the coast"
D - "In sheltered waters"
Over 8
Up to and including 8
Up to and including 6
Up to and including 4
Over 4 m
Up to and
including4m
Up to and
including2m
Up to and
including 0,5 m
1
SPECIFICATIONS AND WARRANTY

10/124
Category A: At high sea
This craft is designed to operate in winds that may exceed wind force 8 (Beaufort scale) and in
significant wave heights of 4 m and above.
This craft is largely self-sufficient. Abnormal conditions such as hurricanes are excluded.
Such conditions may be encountered on extended voyages, for example across oceans, or
inshore when unsheltered from the wind and waves for several hundred nautical miles.
Category B: In open sea
This craft is designed to operate in winds up to Beaufort force 8 and the associated wave
heights (significant wave height up to 4 m, see Note 1 below).
Such conditions may be encountered on offshore voyages of sufficient length, or on coastal
waters when unsheltered from the wind and waves for several dozens of nautical miles.
These conditions may also beexperienced on inland seas of sufficient size for thewave height
to be generated.
Category C: Near to the coast
This craft is designed to operate in winds up to Beaufort force 6 and the associated wave
heights (significant wave height up to 2 m, see Note 1 below). You may meet with such
conditions in exposed inland waters, in estuaries and in coastal waters with moderate weather
conditions.
Category D: In sheltered waters
This craft is designed to operate in winds up to Beaufort force 4 and the associated wave
heights (occasional maximum waves of 0,5 m height).
Such conditions may be encountered in sheltered inland waters, and in coastal waters in fine
weather.
NOTE:
- The significant wave height is the mean height of the highest one-third of the waves, which
approximately corresponds to the wave height estimated by an experienced observer. Some
waves will be double this height.
- The creation of different design categories results from the need to distinguish between
different levels of risk according to the construction of the boats.
The parameters for the characteristics are established to define the conditions of navigation
which each category may encounter; they serve purely to evaluate the boat designs and are
not to be used to limit the geographical areas in which these boats may operate..
- One boat may be classed in several design categories at the same time, each with their
different maximum capabilities.

11/124
YOUR BOAT
Version
NAME OF THE BOAT .............................................................
NAME OF THE OWNER .............................................................
ADDRESS .............................................................
.............................................................
.............................................................
HULL NUMBER .............................................................
SERIAL NUMBER .............................................................
REGISTRATION NUMBER .............................................................
DELIVERY DATE .............................................................
DOOR KEY NUMBER .............................................................
MAKE OF ENGINE .............................................................
ENGINE SERIAL NUMBER .............................................................
ENGINE KEY NUMBER .............................................................
JEANNEAU (Establishment of the company SPBI)
BP 529 - 85505 LES HERBIERS cedex - FRANCE
Tel. [phone] - Fax [phone]
Internet : http://www.jeanneau.com(fr).
Your agent
1
SPECIFICATIONS AND WARRANTY

13/124
SAFETY
SAFETY EQUIPMENT
GENERAL INFORMATION
GAS SYSTEM
RECOMMENDATIONS FOR GAS
FIGHT AGAINST FIRE
BILGE PUMP SYSTEM
EMERGENCY TILLER
2

14/124
SAFETY EQUIPMENT
Swimming ladder (means of coming back onboard) (Reference 1)
Position of the liferaft (Reference 2) - not supplied

15/124
GENERAL INFORMATION
DANGERS
The major hazards concern:
- The gas system.
- The electrical system.
- Manoeuvring the vessel and the sails.
- The motorisation.
Please refer to the relevant paragraphs.
DANGER
- Fuel leaks or vapour represent a danger of fire and explosion.
- Leave the engine compartment ventilated for a long time before starting the
engine.
- There may be danger of fire or explosion if direct or alternating current
systems are incorrectly used. Refer to chapter Electricity.
- Someboats are equippedwitharetractableladderorremovable.Makesure
the ladder is in place and deployed as soon as you are on board.
- Reduce speed in waves.
WARNING
- Before you sail, list the compulsory safety equipment.
- Don't exceed the number of persons indicated in the chapter 'Specifications'.
- The total weight of the persons and equipment must never exceed the
maximum load recommended by the manufacturer.
- Use the seats provided.
ADVICE - RECOMMENDATION
- When sailing, never padlock or lock the liferaft locker.
- Before putting to sea, carefully read the launching instructions shown on the liferaft.
- Closethe deckhatches andportholes beforeeach trip (including the companionwayhatch
in heavy weather).
- Don't store anything below the floorboards.
- Ensure that movable items are firmly secured when the boat is under way.
2
SAFETY

16/124
GAS SYSTEM
LOCATION
REF Designation
1 Gas cylinder locker
2 Gas kill valve on bottle
3 Supply Gas
4 Connector gas copper
5 Supply valve
6Drain
