Panasonic KV-SSM100 Service manual

KVSSM100 / KVSS1100
NETWORK SCANNER ADAPTER
ADMINISTRATOR’S GUIDE
Please read these instructions carefully and keep in a safe place for future reference.

2KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
PREFACE
Copyright
Copyright ©2017 Panasonic System Communication Company of North America. All rights reserved.
Trademarks
nPanasonic is a registered trademark of Panasonic Corporation.
nMicrosoft Windows and Windows are either registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
nIntel is a registered trademark of Intel Corporation in the U.S. and other countries.
nAll other trademarks identified herein are the property of their respective owners.
Disclaimer
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in
the preparation of this document to assure its accuracy, Panasonic, its contractors and partners, assume no liability resulting from errors
or omissions in this document or from the use of the information contained herein. The contents and design of the software is subject to
change without notice.
Safety Notification
This product contains a non-user replaceable battery. Battery should be replaced only with the same or equivalent type. Improper use of
replacement may cause overheating, rupture or explosion. Dispose of used batteries according to the instructions of your local solid waste
officials and local regulations.
Document Revision
Version 8 - January, 2018
Software Build - 1.1.1916.0
Note: Adobe Acrobat or Adobe Reader is required to view this PDF document. When using internal hyperlinks in this document,
press [Alt] + [] to return to the page you were on.

3KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
TABLE OF CONTENTS
Preface ................................................................................................... 2
Introduction ............................................................................................ 5
Feature Highlights........................................................................................................ 5
Scanner Compatibility .................................................................................................. 6
Additional Resources.................................................................................................... 6
Acronym Reference ...................................................................................................... 6
Product Overview ................................................................................... 7
Hardware Components ................................................................................................. 7
What’s in the Box? ............................................................................................................ 7
KV-SSM100 Product Layout ............................................................................................. 8
KV-SS1100 Product Layout............................................................................................. 10
Software Components ................................................................................................ 11
Main Menu ...................................................................................................................... 11
Workflows........................................................................................................................ 12
Touch Screen .................................................................................................................. 13
Admin Tool Web Page ..................................................................................................... 14
Before You Begin ...................................................................................15
Prerequisites.............................................................................................................. 16
Scan to Folder................................................................................................................. 16
Scan to Email.................................................................................................................. 16
Scan to Fax...................................................................................................................... 16
Scan to Bluetooth .............................................................................................................. 16
Scan to Printer................................................................................................................... 16
How to Configure & Scan .......................................................................17
Step 1 – Perform Initial Configuration ........................................................................ 17
Set Login Password ........................................................................................................ 17
Network Settings ............................................................................................................ 18
Shared Folder Configuration.......................................................................................... 19
Email Configuration........................................................................................................ 21
Step 2 – Fax Configuration.......................................................................................... 22
Step 3 – Bluetooth Configuration................................................................................ 23
Step 4 – Printer Configuration.................................................................................... 24
Step 5 – Perform Scan ................................................................................................ 27
Scan to Folder................................................................................................................. 27
Scan to Email.................................................................................................................. 29
Scan to Fax...................................................................................................................... 30
Scan to Bluetooth ........................................................................................................... 31
Scan to Printer................................................................................................................ 32
How to Configure LDAP/User Accounts .................................................33
LDAP Management ..................................................................................................... 33
User Account Management......................................................................................... 34

4KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
How to Change Settings.........................................................................37
Changing Settings via Adapter Touch Screen.............................................................. 37
Adapter Touch Screens............................................................................................... 38
Admin Password............................................................................................................. 38
Fax Config........................................................................................................................ 38
Network Settings ............................................................................................................ 38
Scanner Config ............................................................................................................... 38
Share Management ........................................................................................................ 38
Maintenance.................................................................................................................... 38
Email Config.................................................................................................................... 38
About ............................................................................................................................... 38
Changing Settings via Admin Tool............................................................................... 39
Admin Tool Screens.................................................................................................... 40
Admin Password............................................................................................................. 40
Time Settings.................................................................................................................. 40
Miscellaneous Configuration ......................................................................................... 40
Global Network Configuration........................................................................................ 40
Ethernet IP Configuration .............................................................................................. 40
WiFi Configuration .......................................................................................................... 40
Network Share Management ......................................................................................... 41
Email Configuration........................................................................................................ 41
Fax Configuration............................................................................................................ 41
LDAP Management......................................................................................................... 41
User Account Management............................................................................................ 41
System Update................................................................................................................ 42
Plugin Management ....................................................................................................... 42
Enable / Disable Features .............................................................................................. 42
Audit Trail ........................................................................................................................ 42
Logout ............................................................................................................................. 42
Appendix................................................................................................43
A. KV-SSM100 Specifications...................................................................................... 43
B. KV-SS1100 Specifications....................................................................................... 43
C. File Format Support ............................................................................................... 43
D. KV-SSM100 & KV-SS1100 Comparison................................................................... 44
E. Fax Number Format Specifications......................................................................... 44
F. Configuration Import/Export .................................................................................. 45
G. Firmware Update.................................................................................................... 47
H. Factory Reset ......................................................................................................... 49
I. System Recovery ..................................................................................................... 50
J. Logs ........................................................................................................................ 55
K. Troubleshooting ..................................................................................................... 56
L. Product Support...................................................................................................... 59

5KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
INTRODUCTION
This guide outlines procedures for basic configuration and
administration of the Panasonic KV-SSM100/KV-SS1100 Network
Scanner Adapter. The KV-SSM100/KV-SS1100 is a standalone
device that turns a USB-connected Panasonic scanner into an
intuitive, network-enabled document capture and distribution
hub. This enables you to achieve end-to-end process automation,
and, ultimately, greater efficiency, productivity and compliance.
Feature Highlights
The KV-SSM100/KV-SS1100 supports the following key features and functions:
FEATURE FUNCTION
Secure Scanning No scanned data is stored on the unit; assists with HIPAA compliance. Supports user and address
book (LDAP) authentication.
Scan to Folder Enables scanning to network share folder(s) and FTP server(s).
Scan to Email Enables scanning of documents as an email attachment. Supports LDAP search for quick address
look-up. Built-in user accounts are also supported.
Scan to Fax Enables scanning to specified fax number(s) using a fax server or IP network-connected fax/MFP.
Scan to Bluetooth Enables scanning of a PDF document to a Bluetooth-enabled devices.
Note: Support is currently for Android devices only.
Scan to Printer Enables scanning to a Network Printer. Supports auto discovery.
Audit Trail Records all operations that are performed by users, allowing the administrator to view and search
the list for operations of interest.
Auto Cropping Eliminates manual intervention by user.
Auto Rotation Orients page in correct direction.
Batch Scanning Enables user to scan additional pages to the document at the end of a scan operation.
Deskew Corrects skew in scanned images, restoring them to their upright position.
Double Feed & Staple Detection Enables user to take corrective action.
Long Paper Support Handles non-regular document types.
Popular File Formats Supports PDF, Searchable PDF1, BMP, JPEG, TIFF file formats.
Remote Configuration Configure the device remotely via a web browser.
Remove Hole/Border/ Dog Ear/Blank Page Streamlines scanning processes.
SDK Support Supports custom scan workflows. For information, please contact your Panasonic Sales Representative.
Simplex/Duplex/Flatbed Scanning Handles virtually any document type.
Note: Scanner features vary by product model. Flatbed scanning requires additional Panasonic
flatbed scanner.
1Supported by KV-SSM100 only.

6KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Scanner Compatibility
The KV-SSM100/KV-SS1100 supports the following Panasonic scanner models:
Additional Resources
The following documentation is available for the KV-SSM100/KV-SS1100:
Acronym Reference
The following acronyms are used in this guide:
nKV-S1015C
nKV-S1025C
nKV-S1026C
nKV-S1046C-H
nKV-S1065C-H
nKV-S1027C
nKV-S1057C
nKV-S2048C
nKV-S2087
nKV-S4065CL/CW
nKV-S4085CW
nKV-S5055C
nKV-S7075C
nKV-S7097
nKV-S5076H
nKV-S5046H
nKV-S8127
nKV-S8147
nKV-SS080
nPanasonic KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide (this guide)
nPanasonic KV-SSM100/KV-SS1100 Network Scanner Adapter User’s Guide
nPanasonic KV-SSM100/KV-SS1100 Network Scanner Adapter Quick Setup Guide
AC/DC Alternate Current/Direct Current PDF Portable Document Format
ADF Automatic Document Feeder RAM Random Access Memory
BMP Bitmap SDK Software Development Kit
CIFS Common Internet File System SMTP Simple Mail Transport Protocol
CPU Central Processing Unit SSID Service Set Identifier
DHCP Dynamic Host Command Protocol TIFF Tagged Image File Format
DIMM Dual In-line Memory Module TKIP Temporal Key Integrity Protocol
FTP File Transfer Protocol UNC Universal Naming Convention
IP Internet Protocol URI Uniform Resource Identifier
JPEG Joint Photographic Experts Group URL Uniform Resource Locator
LAN Local Area Network USB Universal Serial Bus
LCD Liquid Crystal Display VGA Video Graphics Array
LDAP Light-weight Directory Access Protocol WLAN Wide Local Area Network
LED Light Emitting Diode WiFi Wireless Fidelity
Mbps Megabits per second WPA WiFi Protected Access
OS Operating System
Important: KV-S3105C is not supported.

7KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
ACCESSORY NAME DESCRIPTION
KV-SSM100
or
KV-SS1100
Intel Core™ i5 Tablet Network Scanner Adapter
Network Scanner Adapter
Power Cord One power cord is included
AC Adapter Panasonic AC Adapter PJSWC0004
Quick Start Guide
Warranty
Includes wall-mounting instructions(KV-SS1100 Only),
specifications and product overview
KV-SS1100: One Year Limited Warranty
KV-SSM100: 3 Year Limited Warranty
PRODUCT OVERVIEW
Hardware Components
What’s in the Box?


8KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
KV-SSM100 Product Layout
A: Wireless WAN Antenna
<Only for model with wireless
WAN>
èOperating Instructions - Ref-
erence Manual “Wireless WAN”
B: Wireless LAN Antenna
<Only for model with wireless LAN>
èOperating Instructions - Ref-
erence Manual “Wireless LAN”
C: Ambient Light Sensor
The ambient light sensor is
equipped with an automatic bright-
ness adjustment function that ad-
juststhe display screen. (èpage 16)
Front Camera
èOperating Instructions - Ref-
erence Manual “Camera”
D: Camera Lens
E: Camera Indicator
F: LED Indicators
: Power Indicator
Off: Display off/Hibernation,
Green: Display on.
: Drive status
: Battery status
èpage 15 “When the battery
indicator does not light on”
èOperating Instructions -
Reference Manual “Battery
Power”
G: Wireless LAN Antenna / Blue-
tooth Antenna
<Only for model with wireless LAN>
<Only for model with Bluetooth>
èOperating Instructions - Ref-
erence Manual “Wireless LAN”
“Bluetooth”
H: Windows Button
èOperating Instructions - Ref-
erence Manual “Tablet Buttons”
D
FE
B C
A
Front side
AAmbient Light Sensor
The ambient light sensor is
equipped with an automatic brightness
adjustment function that adjusts
the display screen.
BCamera Lens
CCamera Indicator
DLED Indicators
: Power Indicator
Off: Display off/Hibernation
Green: Display on
: Drive status
: Battery status
EWireless LAN Antenna /
Bluetooth Antenna
FWindows Button

9KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
KV-SSM100 Product Layout (continued)
H
I
J
Left side Right side
FEDCBA
K
L
Top
Bottom
G
AMicrophone
BBuilt-in Bridge Battery
CVolume Button
DPower Switch
ERotation Lock Button
FA Button
GLAN Port
Built-in Gigabit LAN Port
HDC-IN Jack
IHeadset Jack
A headset or headphone can
be connected.
JUSB3.0 Port
KSecurity Lock
A Kensington cable can be connected.
LExpansion Bus Connector

10KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
1Kensington Lock 6DC-in Jack
2Status LED 7LAN (RJ-45) Port
3Power Button 8VGA Port
4Programmable Button* 9Mounting Holes (see mounting instructions
5USB Ports shipped with unit)
*Used to access custom scan workflows.
KV-SS1100 Product Layout

11KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Software Components
Main Menu
After device configuration is complete, the Main Menu displays. The intuitive touch screen enables you to access Scan-to features,
modify configuration settings and view information about the device, such as software version, connection status, IP address, etc. In the
example below, four scan-to functions are enabled. Note that displayed functions vary based on configuration settings.
12
3
FEATURE FUNCTION
1
Scan to Email Enables scanning to destination email address(es).
Scan to Fax Enables scanning to destination fax number(s).
Scan to Folder Enables scanning to a shared network folder(s) and FTP server(s).
Scan to Bluetooth Enables scanning of a PDF document to a mobile device.
Scan to Printer Enables scanning to a Network Printer. Supports auto discovery.
Scan Test Used for system testing purposes.
2Device Settings
This icon (for admin use only) is used to
change adapter configuration settings.
(Admin login [password entry] is required.)
3Information
This icon provides software build, hardware
serial number and network information,
as well as the device’s IP address.
Note: For more information, see Feature Highlights and Prerequisites.

12KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Workflows
PanasonicKVSSM100/KVSS1100NetworkScannerAdapter
Administrator’sGuide

10

Workflows






















*Wiredconnectionshown.KVSSM100/KVSS1100alsosupportswirelessconnectivity.

ScantoFolder/FTP*

ScantoEmail*

ScantoFax*

ScantoBluetooth

*Wired connection shown. KV-SSM100/KV-SS1100 also supports wireless connectivity.
Scan to Printer*

13KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Touch Screen
The adapter’s pop-up keyboard and various setup screens enable you to log
in to the device, enter email addresses, fax numbers, search strings, program
device settings, etc. To open the keyboard, press any enabled field.
Keyboard Navigation
nEnter characters by pressing corresponding keys.
nPress [X] to erase characters/field.
nPress [Shift] to select an upper case character or special symbol.
nPress [Caps] to enter multiple upper case characters.
nPress [Ctrl] to, for example, cut/paste fields (Ctrl + X > Ctrl + V).
nPress [Enter⤶] to save typed information.
Note: An external USB keyboard can be attached to the adapter.
For the KV-SSM100, a USB hub is required.
Screen Navigation
nExit – To exit (collapse) the keyboard or numeric keypad,
touch the upper portion of the display.
nScroll – If a vertical/horizontal scroll bar appears on a screen,
press and drag to view additional information and/or settings.
nSelect – To select a checkbox or radio button, press text
adjacent to checkbox/button.

14KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Admin Tool Web Page
Admin Tool is a utility embedded within the KV-SSM100/KV-SS1100’s
firmware that enables you to configure the device’s software and
plugins remotely, via a web browser. Admin Tool provides access
to additional features, i.e., those that extend beyond adapter touch
screen settings.
Before you can access the Admin Tool, you must complete the Initial
Configuration procedure, which assigns an IP address to the device.
That address is required to open the Admin Tool, as are your Admin
Login credentials (Username/Password).

15KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
BEFORE YOU BEGIN
Before configuring the KV-SSM100/KV-SS1100, confirm that the following steps have been completed:
Power cable is connected to device.
1. Connect the AC adapter to the DC-in jack of the KV-SSM100/KV-SS1100.
2. Connect the AC adapter to the power cord.
Caution: The AC adapter is to be used with the KV-SSM100/KV-SS1100 only.
3. Plug the power cord into an electrical outlet.
Panasonic scanner is installed.
1. Connect USB cable from scanner to adapter.
Connection method is known:
Wired: Cable is connected from adapter’s Ethernet port to network switch/router.
Wireless: Ensure that wireless router is working correctly and that there is no network (Ethernet) cable attached to the adapter.
Have the following information available:
nSSID (e.g., NETGEAR62)
nSecurity Mode (Open, WEP, WPA Personal, WPA2 Personal).
Note: WPA Enterprise and WPA2 Enterprise Wi-Fi networks are not supported at this time.
Network printer is installed (if using Scan to Printer function).
1. Connect network (Ethernet) cable from printer to adapter.
Network is configured. See Prerequisites to follow…
8
First-time Operation
NOTE
l
Note that the computer consumes electricity even when the
computer power is off. If the battery pack is fully charged,
the battery will fully discharge in the following period of time:
Status FZ-VZSU94W FZ-VZSU95W
(optional)
When power is off Approx. 7 weeks Approx. 17 weeks
In sleep*2 Approx. 9 days Approx. 20 days
In hibernation Approx. 7 weeks Approx. 17 weeks
*2 <Only for model with LAN>
If “Wake Up from wired LAN” is enabled, the period
of time will be shorter.
2 Connect your computer to a power out-
let.
The battery charging starts automatically.
CAUTION
lDonotdisconnecttheACadaptoruntiltherst-time
operation procedure is completed.
lWhenusingthecomputerforthersttime,donotcon-
nect any peripheral device (including wired LAN cable)
except the battery pack and AC adaptor.
lHandling the AC adaptor

Problems such as sudden voltage drops may arise dur-
ing periods of thunder and lightning. Since this could
adversely affect your computer, an uninterruptible
power source (UPS) is highly recommended unless
running from the battery pack alone.
3 Turn on the computer.
Press and hold the power switch (A) (longer than 2
seconds) until the power indicator (B) lights.
CAUTION
lDo not press the power switch repeatedly or do not
hold the power switch for ten seconds or longer.
lAny changes from the default setting of the Setup Util-
ity must not be made until the First-time Operation is
completed.
㪈
㪉
3
B
A
KV-SSM100 KV-SS1100

16KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Prerequisites
nScan to Folder1
− Ensure that Network File and Folder Sharing settings and permissions are established correctly.
− If you wish to enter FTP server addresses or UNC paths to manually locate the shared folders, have the path information available.
− If access to shared folders is on an FTP server and/or requires authentication, you must manually locate the folders. Know your login
credentials (Username and Password).
nScan to Email1
− Have the SMTP server address ready, e.g., smtp.xyz.net.
− Know your login credentials (Username and Password), if authentication is required.
nScan to Fax2
− Ensure that the fax server platform – whether software, cloud service (e.g., eFax, GFI Faxmaker, etc.) or IP network-connected fax/
MFP – is capable of converting email to a fax transmission.
− Ensure that the fax server is connected to the PSTN in order to send faxes.
− Ensure that email has been configured on the device, as the adapter sends the scanned document to the designated email server,
which then converts and relays the document via fax.
− Know your email domain for fax transmissions, e.g., efaxsend.com.
Important: For client/server communication, SSL encryption can be enabled to ensure that the documents are encrypted during
transmission to the fax server. Once transmitted, it is up to the fax server to ensure secure transmission of the document to its
intended recipient(s).
nScan to Bluetooth2
− Ensure that the Scan to Bluetooth feature has been enabled via the Admin Tool.
− Ensure that the mobile device has the Bluetooth feature turned on.
Note: Support is currently for Android devices only.
nScan to Printer3
− Network printer and KV-SSM100/KV-SS1100 Network Scanner Adapter must be installed on the same network.
− Have the Shared path and/or HTTP path (IP address) of the network printer(s) available, in the event that you must manually
add the device(s).
− When adding a printer using a Shared path or using HTTP path (IP address), have the credentials for the computer where the
printer is located available.
− If adding network printers via Active Directory, have the Domain, Login and Password available.
1This feature is enabled by default and set up during the Initial Configuration process.
2This feature is initially disabled and must be enabled after Initial Configuration is complete.
3This feature is enabled by default and set up via the adapter's Scan to Printer button.

17KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
HOW TO CONFIGURE & SCAN
A new device – or a device where factory defaults have been reset – must be configured before scanning operations can be performed.
During this Initial Configuration, the software wizard, running on the device, steps you through the process.
First, you will confirm DHCP network settings that are automatically discovered (or manually enter the values), as well as configure
shared folders. Shared folders can be automatically discovered on the network (or manually entered). FTP server addresses can be
manually entered as well, but cannot be discovered. After you configure shared folders, you will configure email settings, e.g., SMTP
server address, security parameters, default sender email, etc.
Once the Initial Configuration is complete, you can configure Scan to Fax via the adapter’s touch screen or Admin Tool. Likewise, you can
enable the Scan to Bluetooth feature via the Admin Tool.
Note:
nYou can choose to “Skip” Share Management and/or Email Configuration screens. For example, you may wish to enable the Scan to
Folder or Scan to Email feature only.
nIf you “Skip” both configurations, the Main Menu reads, (No scan destinations configured). You can still configure features via the
Device Settings screen or Admin Tool.
Step 1: Perform Initial Configuration
Set Login Password
1. Press [Power] button to turn adapter On.
Note:
n To turn adapter Off, press and hold the [Power] button for 3 - 5 seconds.
n To wake unit from sleep mode, press [Power] button.
2. Press [Configure Device Now].
Note:
n For information on loading a configuration from a USB drive,
see Configuration Import/Export.
3. Enter Admin Password of your choice.
Note:
n The password must be at least six (6) characters in length.
n The password is case sensitive.
n After Initial Configuration, you can change the default password
via Device Settings or Admin Tool.
n Password is required to change Device Settings.
Important: Remember to store your password in a safe place.
4. Re-enter to Confirm password.
5. Press [Enter⤶] to save password.
6. Continue with Network Settings…

18KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Network Settings
1. Select your method of network connection – Wired or Wireless…
a. Wired Settings (default)
When DHCP checkbox is selected, the adapter will obtain the
IP address from the DHCP server on the network. Deselect this
checkbox to manually input the IP address settings.
Note: Ethernet cable must be attached to adapter from network
switch in order for IP address to be obtained.
You can choose to Enable/Disable DNS Update. When enabled, the
adapter will register its hostname with the DNS server, allowing
access to the unit through its hostname.
Press [Next], and then continue with Shared Folder Configuration…
b. Wireless Settings
Connect to a Wi-Fi network by pressing [Wireless Discovery].
Note:
nIf necessary, see Before You Begin > Connection method is known.
n SSID field, e.g., NETGEAR62, will be automatically populated.
You can also manually input the SSID information, if the adapter
cannot detect the SSID through Wireless Discovery.
n If Wireless Discovery is selected, the Security Mode and Encryption
Mode fields are automatically populated.
2. Choose WiFi Network.
3. Press [Select].
4. Enter Security Key.
5. Press [Next].
Note: If an error should occur, see Troubleshooting.
Share Management screen displays…
6. Continue with Shared Folder Configuration…

19KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Shared Folder Configuration
In Share Management, you configure shared folders as scan destinations when performing Scan to Folder. SMB/CIFS (Windows Network
Share) and FTP protocols are supported. If necessary, see Scan to Folder Prerequisites.
You can use Network Discovery to search for public Windows shares within the network or perform a Manual Setup, where shared
folder paths (FTP or UNC) and login credentials (Username and Password) are specified. Manual Setup is required if…
nAccess to the computer is password-protected. You will need to manually specify the username and password.
nYou wish to add FTP network shares. FTP does not support discovery, so you must enter the path for FTP network shares manually.
Network Discovery
1. Press [Add] to add a shared folder.
2. Press [Search] to automatically search shared folders.
In Network Discovery, you can see the various workgroups/domains
that the adapter has discovered.
Important: If no network shares are discovered, i.e., Search screen is
blank, go to Manual Setup, as the computer is likely password protected,
in which case you must enter the folder path and login credentials
manually.
3. Select the workgroup/domain and PC where the shared folders are
located.
4. Press [Select Share].
5. Enter Friendly Name (required).
Note: You cannot add two shares with the same Friendly Name.
6. Enter Subpath (optional).
Note: The Friendly Name and Subpath will be displayed on the screen
in the list of shares.
7. Under Security, you have three Authentication (login) modes to
choose from…
a. No login (not recommended) – Remove checkbox from Use
Authentication. Network share can then be writable by anyone.
b. Direct Login (recommended) – Select Specify Credentials directly and
enter Username and Password. Admin provides the login credentials
to use right now. The credentials are stored on the adapter’s hard
drive and retrieved when access to this network share is required.
c. User Credentials – Select Use Logged-in user’s credentials. These
credentials will NOT be used to actually write to the share, only to test
connectivity. Important: In order to use this selection, the adapter’s
authentication setting must be turned on.
Note: To select a checkbox or radio button, press text adjacent to
checkbox/button.
8. When finished, press [Add Share]
9. Press [Next].
10. Continue with Email Configuration…

20KV-SSM100/KV-SS1100 Network Scanner Adapter Administrator’s Guide
Manual Setup
Again, Manual Setup is required if…
nAccess to the computer is password-protected. You will need to manually specify the username and password.
nYou wish to add FTP network shares. FTP does not support discovery, so you must enter the path for FTP network shares manually.
1. Press [Add] to add a shared folder.
Note: If Network Discovery was unsuccessful, press [ ] to return
to Add Share screen.
2. Enter FTP address or UNC Path.
Note: Valid path names for network shares are:
nFTP: ftp://MyServer/MyShare
nUNC: \\MyServer\MyShare\
3. Press [Configure].
4. Enter Friendly Name (required).
5. Enter Subpath (optional).
Note:
nThe Friendly Name and Subpath will be displayed on the screen
in the list of shares.
nYou cannot add two shares with the same name.
6. Under Security, set Use Authentication.
7. Press [Add Share].
Share Management screen displays shared folder path…
8. Repeat 1-7 to add another shared folder.
Note:
nEdit: To edit shared folder settings, highlight the folder and press
[Edit]. Make necessary changes and press [Update Share].
nRemove: To remove one or more shared folders, highlight the
folder(s) and press [Remove] or [Remove All]. Press [Yes] to confirm.
9. When finished, press [Next].
Note: If an error should occur, see Troubleshooting.
10. Continue with Email Configuration…
