Panasonic KX-TG7160E User manual

This unit is Caller ID compatible. To display the caller’s phone
number, you must subscribe to Caller ID service.
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and save them for
future reference.
Operating Instructions
Model No. KX-TG7160E
KX-TG7180E
Digital Cordless Answering System
KX-TG7160
TG7160-7180E(e).book Page 1 Thursday, July 27, 2006 12:45 PM

Introduction
2Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Introduction
Thank you for purchasing a new Panasonic digital cordless phone.
For your future reference
Attach or keep original receipt to assist with any repair under warranty.
Note:
LThis equipment is designed for use on the UK and Republic of Ireland analogue telephone
network.
LIn the event of problems, you should contact your equipment supplier in the first instance.
Declaration of Conformity:
LPanasonic Communications Co., Ltd. declares that this equipment is in compliance with the
essential requirements and other relevant provisions of Radio & Telecommunications
Terminal Equipment (R&TTE) Directive 1999/5/EC.
Declarations of Conformity for the relevant Panasonic products described in this manual
are available for download by visiting:
http://www.doc.panasonic.de
Contact:
Panasonic Services Europe
a Division of Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Your phone
Note:
LThe handsets have been pre-registered for use with their base unit. If not registered, see
page 30.
Serial No. (found on the bottom of the base unit)
Date of purchase
Name and address of dealer
KX-TG7160
(Big button type
handset)
KX-TG7180
(Bone conduction
type handset)
TG7160-7180E(e).book Page 2 Thursday, July 27, 2006 12:45 PM

Table of Contents
3
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Preparation
Accessory information . . . . . . . . . . . . . . .4
Expanding your phone system . . . . . . . . .6
Important information . . . . . . . . . . . . . . . .7
Bone conduction earpiece (KX-TG7180
only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . .9
Displays . . . . . . . . . . . . . . . . . . . . . . . . .10
Connections . . . . . . . . . . . . . . . . . . . . . . 11
Battery installation/replacement . . . . . . .11
Battery charge . . . . . . . . . . . . . . . . . . . .12
Turning the power on/off. . . . . . . . . . . . .13
Symbols used in these operating
instructions . . . . . . . . . . . . . . . . . . . . . . .13
Display language . . . . . . . . . . . . . . . . . .13
Date and time . . . . . . . . . . . . . . . . . . . . .13
Accessibility features
Voice announce . . . . . . . . . . . . . . . . . . .14
Making/Answering Calls
Making calls . . . . . . . . . . . . . . . . . . . . . .15
Answering calls . . . . . . . . . . . . . . . . . . .16
Phonebook
Handset phonebook . . . . . . . . . . . . . . . .17
Chain dial . . . . . . . . . . . . . . . . . . . . . . . .18
Handset Settings
Handset settings. . . . . . . . . . . . . . . . . . .19
Time settings . . . . . . . . . . . . . . . . . . . . .21
Base Unit Settings
Base unit settings . . . . . . . . . . . . . . . . . .22
Caller ID Service
Using Caller ID service. . . . . . . . . . . . . .23
Caller list. . . . . . . . . . . . . . . . . . . . . . . . .23
Voice mail service. . . . . . . . . . . . . . . . . .24
Answering System Features
Answering system . . . . . . . . . . . . . . . . .25
Turning the answering system on/off . . .25
Greeting message . . . . . . . . . . . . . . . . .25
Listening to messages . . . . . . . . . . . . . .26
Direct command operation using the
handset . . . . . . . . . . . . . . . . . . . . . . . . . 27
Remote operation. . . . . . . . . . . . . . . . . .27
Answering system settings. . . . . . . . . . . 29
Multi-unit Operation
Operating additional units . . . . . . . . . . . 30
Registering a handset to the base unit. .30
Intercom between handsets . . . . . . . . . .31
Transferring calls between handsets . . . 31
Conference calls . . . . . . . . . . . . . . . . . .32
Copying phonebook entries . . . . . . . . . .32
Useful Information
Using the belt clip. . . . . . . . . . . . . . . . . .33
Using the shoulder rest attachment . . . .33
Character entry . . . . . . . . . . . . . . . . . . .34
Error messages . . . . . . . . . . . . . . . . . . .36
Troubleshooting . . . . . . . . . . . . . . . . . . .36
Specifications . . . . . . . . . . . . . . . . . . . . . 40
Conditions of guarantee. . . . . . . . . . . . . 41
Index
Index . . . . . . . . . . . . . . . . . . . . . . . . . . 42
TG7160-7180E(e).book Page 3 Thursday, July 27, 2006 12:45 PM

Preparation
4Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Accessory information
Included accessories
*1 The handset cover comes attached to the handset.
No. Accessory items Quantity
1AC adaptor for base unit
Part No. PQLV207EZ (PQLV207E)
1
2Telephone line cord
Part No. PQJA87S or PQJA10180Z (for UK)
1
3Rechargeable batteries AAA (R03) size
Part No. HHR-55AAAB or HHR-4EPT
2
4Handset cover*1
Part No. PQYNTG8100E
1
5Belt clip
Part No. PQKE10464Z1
1
6Shoulder rest
Part No.PQZXTG7160E
1
123456
TG7160-7180E(e).book Page 4 Thursday, July 27, 2006 12:45 PM

Preparation
5
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Additional/replacement accessories
Please contact your nearest Panasonic dealer for sales information.
*1 Maximum capacity of 750mAh
Note:
LYou can expand your phone system by registering additional compatible Panasonic
handsets (page 6).
No. Model No. Description
1P03P*1 2 rechargeable nickel metal hydride (Ni-MH) batteries,
AAA (R03) size
2KX-TCA717EX Wall-Mounting Adaptor
3KX-TCA94EX Headset
4KX-A272 DECT repeater
23
TG7160-7180E(e).book Page 5 Thursday, July 27, 2006 12:45 PM

Preparation
6Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Expanding your phone system
You can expand your phone system by registering the following optional handsets to a single
base unit (KX-TG7160 or KX-TG7180): max. 6
Please contact your nearest Panasonic dealer for sales information.
Handset feature overview for KX-TGA711, KX-TGA715, and KX-TGA717
Operations and features of the 3 different accessory handsets have certain differences as
indicated in the table below.
Handsets: max. 6
Additional digital
cordless handset
KX-TGA711E
Additional digital
cordless handset
KX-TGA715E
(Big button type
handset)
Additional digital
cordless handset
KX-TGA717E
(Bone conduction
type handset)
Feature KX-TGA711 KX-TGA715 KX-TGA717 Page
Description Available as
accessory
handset only
Same handset
supplied with
KX-TG7160
Same handset
supplied with
KX-TG7180
—
Big button — rr—
Bone conduction
earpiece
——rpage 8
Call restriction r———
Headset jack — rrpage 9
Voice announce — rrpage 14
TG7160-7180E(e).book Page 6 Thursday, July 27, 2006 12:45 PM

Preparation
7
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Important information
General
LUse only the AC adaptor included with this
product, noted on page 4.
LDo not connect the AC adaptor to any AC
outlet other than a standard 220–240 V
AC outlet.
LThis product is unable to make calls when:
– the portable handset battery(ies) need
recharging or have failed.
– there is a power failure.
LDo not open the base unit, charger, or
handset other than to replace the
battery(ies).
LThis product should not be used near
emergency/intensive care medical
equipment and should not be used by
people with pacemakers.
LCare should be taken that objects do not
fall onto, and liquids are not spilled into,
the unit. Do not subject this product to
excessive smoke, dust, mechanical
vibration or shock.
Environment
LDo not use this product near water.
LThis product should be kept away from
heat sources such as radiators, cookers,
etc. It should also not be placed in rooms
where the temperature is less than 5 °C or
greater than 40 °C.
LThe AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
Warning:
LTo prevent the risk of electrical shock, do
not expose this product to rain or any
other type of moisture.
LUnplug this product from power outlets if it
emits smoke, an abnormal smell, or
makes unusual noise. These conditions
can cause fire or electric shock. Confirm
that smoke has stopped emitting and
contact an authorised service centre.
Battery caution
LWe recommend using the battery(ies)
noted on page 5. Use only rechargeable
battery(ies).
LDo not mix old and new batteries.
LDo not dispose of the battery(ies) in a fire,
as they may explode. Check with local
waste management codes for special
disposal instructions.
LDo not open or mutilate the battery(ies).
Released electrolyte from the battery(ies)
is corrosive and may cause burns or injury
to the eyes or skin. The electrolyte may be
toxic if swallowed.
LExercise care when handling the
battery(ies). Do not allow conductive
materials such as rings, bracelets or keys
to touch the battery(ies), otherwise a short
circuit may cause the battery(ies) and/or
the conductive material to overheat and
cause burns.
LCharge the battery(ies) in accordance
with the information provided in these
operating instructions.
LOnly use the included base unit (or
charger) to charge the battery(ies). Do not
tamper with the base unit (or charger).
Failure to follow these instructions may
cause the battery(ies) to swell or explode.
Information on Disposal for Users of
Waste Electrical & Electronic Equipment
(private households)
TG7160-7180E(e).book Page 7 Thursday, July 27, 2006 12:45 PM

Preparation
8Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
This symbol on the products and/or
accompanying documents means that used
electrical and electronic products should not
be mixed with general household waste. For
proper treatment, recovery and recycling,
please take these products to designated
collection points, where they will be
accepted on a free of charge basis.
Alternatively, in some countries you may be
able to return your products to your local
retailer upon the purchase of an equivalent
new product.
Disposing of this product correctly will help
to save valuable resources and prevent any
potential negative effects on human health
and the environment which could otherwise
arise from inappropriate waste handling.
Please contact your local authority for
further details of your nearest designated
collection point.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
For business users in the European
Union
If you wish to discard electrical and
electronic equipment, please contact your
dealer or supplier for further information.
Information on Disposal in other
Countries outside the European Union
This symbol is only valid in the European
Union.
If you wish to discard this product, please
contact your local authorities or dealer and
ask for the correct method of disposal.
Bone conduction earpiece
(KX-TG7180 only)
The handset features a bone conduction
earpiece that uses vibrations to create
sound during your telephone conversations.
For proper operation press the bone
conduction earpiece against your face near
the ear.
Normally, sound enters the ear canal and
vibrates the eardrum. People feel the
vibration within the inner ear and
comprehend it as it is received by the
auditory nerve.
Place the bone conduction earpiece against
your face (not your ear). Try different
locations to find which location works best.
Start with the temple area.
Note:
LDo not place the bone conduction
earpiece on a hearing aid. Howling or
other interference may be heard.
LThe effectiveness of the bone conduction
earpiece will vary by the type and degree
of hearing loss of the user.
External ear
Middle ear Inner ear
Auditory
nerve
Sound
Bone
conduction
earpiece
TG7160-7180E(e).book Page 8 Thursday, July 27, 2006 12:45 PM

Preparation
9
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
LAs sound is generated by vibration, users
with normal hearing can use the handset
by placing the bone conduction earpiece
against the ear, as an ordinary telephone.
LIf the bone conduction earpiece gets dusty
or greasy, clean it with a soft, dry cloth.
Controls
Handset (KX-TG7160)
Handset (KX-TG7180)
ASpeaker
BCharge contact
CHeadset jack
D{j/OK}(Menu/OK)
E{k} (Phonebook)
F{C} (Talk)
GNavigator key ({^}/{V}/{>}/{<})
H{s} (Speakerphone)
N
B
A
O
P
Q
R
L
K
M
F
G
I
H
J
D
C
E
B
A
N
O
Q
R
L
K
M
F
G
I
H
J
D
C
E
P
TG7160-7180E(e).book Page 9 Thursday, July 27, 2006 12:45 PM

Preparation
10 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
I{R}(Recall)
JCharge indicator/Ringer indicator/
Message indicator
KKX-TG7160
Receiver
KX-TG7180
Bone conduction earpiece
LDisplay
M{R} (Redial/Pause)
N{ih} (Off/Power)
O{C/T}(Clear/Mute)
PDial keypad
Q{INT}(Intercom)
RMicrophone
Base unit
ACharge contact
BSpeaker
C{x} (Page)
D{4}(Erase)
E{■}(Stop)
FAnswer on indicator/{s}(Answer on)
GNavigator key: {^}/{V}/{7}/{8}
H{6}(Play)/Message indicator
Displays
Display icons
G H
ABCDEF
Display
icon
Meaning
wWithin range of a base unit
LWhen flashing: Handset
is searching for base unit.
(out of range of base unit,
handset is not registered
to base unit, no power on
base unit)
LHandset is accessing base
unit. (intercom, paging,
changing base unit
settings, etc.)
kHandset is on an outside
call.
uAnswering system is on.
(page 25)
5Battery strength
[2] Handset number (Standby
display setting, page 19)
LLine is being used by
another handset.
LAnswering system is
being used by another
handset or the base unit.
TG7160-7180E(e).book Page 10 Thursday, July 27, 2006 12:45 PM

Preparation
11
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Connections
When connecting the AC adaptor to the
base unit, a short beep will be heard. If it is
not heard, check the connections.
Note:
LNever install telephone wiring during a
lightning storm.
LThe AC adaptor must remain connected
at all times. (It is normal for the adaptor to
feel warm during use.)
LThe AC adaptor should be connected to a
vertically oriented or floor-mounted AC
outlet. Do not connect the AC adaptor to a
ceiling-mounted AC outlet, as the weight
of the adaptor may cause it to become
disconnected.
LThe unit will not work during a power
failure. We therefore recommend you
also connect a corded-type telephone
(without AC adaptor) to the same
telephone line using a T-adaptor. Your
Panasonic sales shop can offer you more
information about connection possibilities.
Location
LFor maximum distance and noise-free
operation, place your base unit:
– away from electrical appliances such as
TVs, radios, personal computers or
other phones.
– in a convenient, high and central
location.
Battery
installation/replacement
Important:
LUse only the included rechargeable
batteries noted on page 4, 7.
LWhen replacing batteries, we recommend
using the Panasonic rechargeable
batteries noted on page 5, 7.
LWipe the battery ends (S, T) with a dry
cloth.
LWhen installing the batteries, avoid
touching the battery ends (S, T) or the
unit contacts.
1Press the notch on the handset cover
firmly and slide it in the direction of the
arrow.
LWhen replacing batteries, remove the
old batteries positive (S) end first.
2Insert the batteries negative (T) end
first. Close the handset cover.
Use only the included AC
adaptor and telephone
line cord.
(220–240 V, 50 Hz)
To telephone
network
Hook
TG7160-7180E(e).book Page 11 Thursday, July 27, 2006 12:45 PM

Preparation
12 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Battery charge
Place the handset on the base unit for
about 7 hours before initial use.
When charging, the battery icon is shown as
follows.
When the batteries are fully charged, 5
remains on the display.
LThe charge indicator lights up when the
handset is placed on the base unit.
LThe pictured model is KX-TG7160.
Note:
LIt is normal for the handset to feel warm
during charging.
LIf you want to use the unit immediately,
charge the batteries for at least 15
minutes.
LClean the charge contacts of the handset
and base unit with a soft, dry cloth once a
month, otherwise the batteries may not
charge properly. Clean more often if the
unit is exposed to grease, dust, or high
humidity.
Battery strength
Panasonic Ni-MH battery performance
(included batteries)
Note:
LIt is normal for batteries not to reach full
capacity at the initial charge. Maximum
battery performance is reached after a few
complete cycles of charge/discharge
(use).
LActual battery performance depends on a
combination of how often the handset is in
use and how often it is not in use
(standby).
LBattery operating time may be shortened
over time depending on usage conditions
and ambient temperature.
LEven after the handset is fully charged,
the handset can be left on the base unit
without any ill effect on the batteries.
LThe battery strength may not be displayed
correctly after you replace the batteries. In
this case, place the handset on the base
unit and charge for at least 7 hours.
Charge
contact
Battery icon Battery strength
5High
6Medium
7Low
When flashing: Needs
to be charged.
Operation Operating time
In continuous use KX-TG7160:
12 hours max.
KX-TG7180:
10 hours max.
In continuous
standby mode
150 hours max.
TG7160-7180E(e).book Page 12 Thursday, July 27, 2006 12:45 PM

Preparation
13
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Turning the power on/off
Power on
Press {ih} for about 1 second.
Power off
Press {ih} for about 2 seconds.
Symbols used in these
operating instructions
Display language
1{ih} i{j/OK}
2Press {^} or {V} to select “Handset
Setup”. i{>}
3Press {^} or {V} to select “Display
Setup”. i{>}
4Press {^} or {V} to select “Select
Language”. i{>}
5Press {^} or {V} to select the desired
language. i{>}i{ih}
Note:
LIf you select a language you cannot read,
press {ih}, press {j/OK}, press {^} 3
times, press {>}, press {V} 2 times, press
{>}, press {V}, press {>}, select the
desired language, press {>}, then press
{ih}.
LTo change the voice announce language,
see page 14.
Date and time
1{j/OK}
2Press {^} or {V} to select “Handset
Setup”. i{>}
3Press {^} or {V} to select “Time
Settings”. i{>}
4Press {^} or {V} to select “Set Date &
Time”. i{>}
5Enter the current day, month, and year.
Example: 17 May, 2006
{1}{7}{0}{5}{0}{6}
6Enter the current hour and minute.
Example: 3:30 PM
{0}{3}{3}{0}iPress {*} until
“03:30 PM”is displayed.
7{j/OK}i{ih}
Note:
LTo correct a digit, press {<}or {>}to
move the cursor to the digit, then make
the correction.
LThe date and time may be incorrect after a
power failure. In this case, set the date
and time again.
Symbol Meaning
{j/OK}Press {j/OK}.
iProceed to the next operation.
“ ” Select the words in quotations
shown on the display (e.g.,
“Handset Setup”) by
pressing {^} or {V}.
TG7160-7180E(e).book Page 13 Thursday, July 27, 2006 12:45 PM

Accessibility features
14 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Voice announce
The voice announce features allow the
handset to announce displayed phone
number. (Caller ID announce/List
announce)
Caller ID announce
When you receive an outside call which has
phone number information, the handset
announces the displayed phone number
from the handset speaker.
LTo announce outside caller’s phone
number, you must first subscribe to Caller
ID service (page 23).
LThe announcement is heard at the ringer
volume (page 19).
List announce
The handset announces phone numbers
from the handset speaker while you are
viewing the redial list, caller list, and
phonebook.
LIf the displayed phone number has a
P(pause), the handset inserts a 0.5
second pause for each P and if the
number has the other symbols, (for
example, ;, #, etc.) the handset skips the
symbols and announces the next number.
Setting volume for voice
announce
You can set the volume for list announce.
The volume for caller ID announce is set
when setting the ringer volume on (page
19).
1{j/OK}
2“Handset Setup”i{>}
3“Other Options”i{>}
4“Voice Announce”i{>}
5“Volume”i{>}
6Select the desired volume.
LTo turn the voice announce feature off,
select the volume “Off”.
7{>}i{ih}
Note:
LThe caller ID announce is heard at the
handset ringer volume (page 19). When
the volume for voice announce is set to
“Off”, the handset does not announce
the phone number regardless of the ringer
volume.
Selecting language for voice
announce
1{j/OK}
2“Handset Setup”i{>}
3“Other Options”i{>}
4“Voice Announce”i{>}
5“Select Language”i{>}
6Select the desired language. i{>}
i{ih}
Note:
LTo change the display language, see page
13.
TG7160-7180E(e).book Page 14 Thursday, July 27, 2006 12:45 PM

Making/Answering Calls
15
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Making calls
1Lift the handset and dial the phone
number.
LTo correct a digit, press {C/T}, then
enter the correct number.
2{C}
3When finished talking, press {ih} or
place the handset on the base unit.
Speakerphone
1During a conversation, press {s} to turn
on the speakerphone.
LSpeak alternately with the caller.
2When finished talking, press {ih}.
Note:
LFor best performance, use the
speakerphone in a quiet environment.
LTo switch back to the receiver, press
{C}.
To adjust the receiver or speaker volume
Press {^} or {V} while on a call.
Redial feature
Previously dialled phone numbers (each 24
digits max.) can be redialled.
To make a call using the redial list
The last 10 phone numbers dialled are
stored in the redial list.
1{R}
2Press {^} or {V} to select the desired
number.
3{C} / {s}
To erase numbers in the redial list
1{R}
2Press {^} or {V} to select the desired
number. i{>}
3“Erase”i{>}
4“Yes”i{>}i{ih}
Other features
Mute
While mute is turned on, you will be able to
hear the other party, but the other party will
not be able to hear you.
To mute your voice, press {C/T}.
LTo return to the conversation, press
{C/T}again.
Call waiting - {R}button
If a second call is received while in a
conversation with the first caller, a beep tone
will be heard. Press {R}button to switch
between callers.
This service requires a subscription. Consult
your service provider/telephone company
for details.
Note:
LIf your unit is connected to a PBX (private
branch exchange), pressing {R}can allow
you to access certain features of your host
PBX such as transferring an extension
call. Consult your PBX dealer for details.
LYou can change the recall time (page 22).
Pause button (for PBX/long distance
service users)
A pause is sometimes required when
making calls using a PBX or long distance
service.
Example: If you have to dial {0}before
dialling outside numbers manually, you will
probably need to pause after dialling {0}
until you hear a dial tone.
1{0}i{R}
2Dial the phone number. i{C} / {s}
Note:
LA 3 second pause is inserted each time
{R} is pressed. Press repeatedly to
insert longer pauses.
TG7160-7180E(e).book Page 15 Thursday, July 27, 2006 12:45 PM

Making/Answering Calls
16 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Answering calls
1Lift the handset and press {C} or {s}
when the unit rings.
LYou can also answer a call by pressing
any dial key from {0}to {9}, {*}, {#},
or {INT}. (Any key answer feature)
2When finished talking, press {ih} or
place the handset on the base unit.
Auto talk feature
You can answer calls simply by lifting the
handset off the base unit. You do not need to
press {C}. To turn this feature on, see
page 19.
To adjust the handset ringer volume
when receiving a call
Press {^} or {V}.
Handset locator
Using this feature, you can locate the
handset if it has been misplaced.
1Press {x} on the base unit.
2To stop paging, press {x} on the base
unit or press {ih} on the handset.
TG7160-7180E(e).book Page 16 Thursday, July 27, 2006 12:45 PM

Phonebook
17
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Handset phonebook
The handset phonebook allows you to make
calls without having to dial manually. You
can add 50 names and phone numbers to
the handset phonebook.
Adding entries to the handset
phonebook
1{k} i{j/OK}
2“New Entry”i{>}
3Enter the party’s name (16 characters
max.; page 34). i{j/OK}
4Enter the party’s phone number (24
digits max.). i{j/OK}
5“Save”i{>}i{ih}
Note:
LStep 1 variation:
{j/OK}iPress {^} or {V} to select
“Ph.Book Setup”. i{>}
Finding and calling a handset
phonebook entry
Handset phonebook entries can be
searched for by first character or by scrolling
through all handset phonebook entries.
When you have found the desired entry,
press {C}.
Scrolling through all entries
1{k}
2Press {^} or {V} to display the desired
entry.
Searching by first character (index
search)
1{k}
2Press the dial key ({0}to {9}) which
contains the character you are
searching for (page 34).
LPress the same dial key repeatedly to
display the first entry corresponding to
each letter located on that dial key.
LIf there is no entry corresponding to
the letter you selected, the next entry
will be displayed.
LTo change the character entry mode:
{R} iSelect the character entry
mode. i{>}
3Press {^} or {V} to scroll through the
phonebook if necessary.
Editing entries in the handset
phonebook
Changing a name, phone number
1Find the desired entry (page 17). i
{j/OK}
2“Edit”i{>}
3Edit the name if necessary (16
characters max.; page 34). i
{j/OK}
4Edit the phone number if necessary (24
digits max.). i{j/OK}
5“Save”i{>}i{ih}
Erasing entries from the handset
phonebook
Erasing an entry
1Find the desired entry (page 17). i
{j/OK}
2“Erase”i{>}
3“Yes”i{>}i{ih}
Erasing all entries
1{k} i{j/OK}
2“Erase All”i{>}
3“Yes”i{>}
4“Yes”i{>}i{ih}
TG7160-7180E(e).book Page 17 Thursday, July 27, 2006 12:45 PM

Phonebook
18 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Chain dial
This feature allows you to dial phone
numbers in the handset phonebook while
you are on a call. This feature can be used,
for example, to dial a calling card access
number or bank account PIN that you have
stored in the handset phonebook, without
having to dial manually.
1While on a call, press {k}.
2Press {^} or {V} to select the desired
entry.
LTo search by first character (index
search), see page 17.
3Press {>}to dial the number.
TG7160-7180E(e).book Page 18 Thursday, July 27, 2006 12:45 PM

Handset Settings
19
Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
Handset settings
LWhen customising the handset, the current item or setting is indicated by >.
To customise the handset:
1{j/OK}
2Press {^} or {V} to select “Handset Setup”. i{>}
3Press {^} or {V} to select the desired item in the handset settings menu. i{>}
4Press {^} or {V} to select the desired item in the sub-menu. i{>}
LIn some cases, you may need to select from a second sub-menu. i{>}
5Press {^} or {V} to select the desired setting then press {>}or follow the instruction in the
rightmost column of the chart.
LTo exit the operation, press {ih}.
Handset settings
menu
Sub-menu Sub-menu 2 Feature (default setting)
Time Settings Set Date &
Time
— Date and time: page 13
Alarm — Set the alarm: page 21
Ringer Setup Ringer Volume — Handset ringer volume
(Maximum)*1
Ext. Ringtone
(External ringtone)
— Ringtones for outside calls
(“Ringtone 1”)*2*3
Int. Ringtone
(Intercom ringtone)
— Ringtones for intercom
calls
(“Ringtone 3”)*3
Display Setup Standby
Display
— Standby mode display
(“Off”)*4
Select
Language
— Display language
(“English”): page 13
Contrast — Display contrast (Level 3)
Registration Register H.set
(Register handset)
— page 30
Other Options New Msg. Alert
(New message
alert)
— New message alert
(“Off”)*5
Keytones — Keytones on/off (“On”)
Auto Talk — Auto talk on/off (“Off”)*6
Voice Announce Volume Voice announce volume
(“Middle”): page 14
Select
Language
Voice announce language
(“English”): page 14
TG7160-7180E(e).book Page 19 Thursday, July 27, 2006 12:45 PM

Handset Settings
20 Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333
*1 When the ringer is turned off, the handset will ring:
– at the minimum level for alarm
– at the minimum level for intercom calls
– at the maximum level for paging
*2 If you select one of the melody ringtones, the ringtone will continue to sound for several
seconds if the caller hangs up before you answer. You may hear a dial tone or no one
on the line when you answer a call.
*3 The preset melodies in this product are used with permission of © 2006 Copyrights
Vision Inc.
*4 If “Off”is selected, only current date and time are displayed.
If “Handset Number”is selected and the current handset number is 2, “[2]”is
displayed.
*5 This feature alerts you when new messages have been recorded:
– Answering system (page 25)
The message indicator on the handset flashes until you have listened to all new
messages.
While message alert is on, battery operating time is shortened (page 12).
*6 Auto talk feature allows you to answer calls simply by lifting the handset off the base
unit. You do not need to press {C}.
TG7160-7180E(e).book Page 20 Thursday, July 27, 2006 12:45 PM
