Panasonic PD50 User manual

PD50
Stationary 2D Code Reader
054731_Panasonic_3164euen-PD50 02.11.2005 13:59 Uhr Seite 1

2
Overview
High-speed 360°
Rotation and Reverse
Rotation Inspections
High
accuracy
Special software
enables
Simple
setting
Red LED guide
light enables
Easy
installation
Stationary 2D Code Reader PD50
054731_Panasonic_3164euen-PD50 02.11.2005 13:59 Uhr Seite 2

All-in-one design: LED lighting, optics, camera, CPU and
interfaces in one compact unit
Can read 2D codes made by inkjet printing, laser marking,
stamping, engraving, etc.
Suitable for Data Matrix ECC200 code and QR code
Easy installation and easy setup
Accurate, high-speed reading
Rugged IP67 metal body
Excellent connectivity
3
054731_Panasonic_3164euen-PD50 02.11.2005 13:59 Uhr Seite 3

Integrated design
All components for lighting, optics, image acquisition (camera) and signal
processing (CPU) are combined in one unit and are mutually optimised to
ensure that reading codes is performed quickly, reliably and with virtually no
maintenance.
Easy height adjustment with
pilot spot system
Two LEDs project red spots on the working surface. The correct
working distance is indicated when the two spots intersect and
appear as one. This combined spot also shows the centre of the
inspection area, which is useful for aligning the sensors’ field of view.
Robust aluminium body
PD50 can be used in harsh industrial
environments. Its compact aluminium housing
and robust connectors conform to the
protection class IP67.
4
Stationary 2D Code Reader PD50
The Hardware
054731_Panasonic_3164euen-PD50 02.11.2005 13:59 Uhr Seite 4

5
Flexible setup
PD50 can be setup in two different ways. If you prefer to
configure PD50 with a PC or a notebook, our free software
PDTOOL will quickly and easily assist you step-by-step.
Automatic teach-in and other useful functions allow even un-
experienced users to configure the PD50. Alternatively, if
you don’t use PCs in your production environment, settings
can be done with the Operation and Finder Unit. These small,
panel-mountable devices can also monitor images and results
during inspection.
360° high-speed reading
PD50 can read codes, regardless of their rotation angle.
As long as the code is within the sensor’s field of view,
it will be read reliably, even if partially stained, destroyed,
mirrored or even reversed. Thanks to its RISC CPU, PD50 can
achieve a processing time of only 30 ms.
Integration made easy
PD50 can be easily integrated into existing machines. While
decoding results are output via its RS232 port, signals for the
inspection trigger, program change, readability flag, etc. are
handled by the digital interface. Furthermore, PD50 can be
easily connected to our GT series touch-screen displays
because both devices communicate via MEWTOCOL. These
displays are a good solution, if customised user interfaces are
required.
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 5

Easy-to-use setup software PDTOOL
You can configure the PD50 with the optional Operation and Finder Units or – even more comfortably – with our free-of- charge
Windows-based software PDTOOL. First-time users easily grasp the settings principles and are aided by such functions as auto-
teaching.
Just use the mouse to move the inspection area
position or change the size.
After setting the inspection area, you can perform teaching with
one click using a non-defective code sample. The exposure time
and the 2D code type are automatically detected, eliminating
complicated setting processes.
The code type to be read is indicated. The detail setting mode allows you to configure the
code setting, settings for black/white reversed code
and horizontally flipped code, etc.
Free-of-charge download at:
www.lightpix.net
The setting flow indicator shows
you what to do next at a glance.
6
Stationary 2D Code Reader PD50
The Software
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 6

Excellent decoding capabilities
PD50 reads Data Matrix ECC200 and QR codes. The codes can be created by printing, laser marking, engraving, etching and
stamping. Furthermore, even distorted, displaced or inversed codes can be read reliably.
Real-time image storage
Being equipped with a dedicated image memory, PD50 allows real-time
image storage during inspection. Up to 8 images can be saved in a ring
buffer. You can define whether to save each inspection image or only
images with negative inspection results. These images can be transferred
to PDTOOL, where they can be viewed or stored as Bitmap files, e.g. for
quality control reports.
7
Superior robustness
Thanks to its pre-processing functions, PD50 can read stamped or engraved codes on metal surfaces. Possible distortions caused
by material reflections, oil, oxidation or other impurities, for example, will be filtered out reliably, resulting in a clear and de-codable
image.
쑽
Object code Captured images
Stainsin the cells
White spots made by
the reflection of cells
Black spots made by
stains on the metal surface
Pre-
treatment
Clear image without
distortions
Proceed image
▲
054731_Panasonic_3164euen-PD50 02.11.2005 15:01 Uhr Seite 7

Stationary 2D Code Reader PD50
System Configuration
Overview
8
02 x 1.6
05 x 04
15 x 12
30 x 25
25 x 20
20 x 16
10 x 08
Field of view
Installation
distance
15 25 45 60 80 105 55
Unit: mm
Types of Main Units
Field of view
USB: Easy connection to PC (PDTOOL) dedicated port with
USB1.1 using standard cable.
LVDS: Low Voltage Differential Signal method.
Attachment of finder unit screen is possible for checking
inspection results. Settings can also be altered using the
switches on the front panel.
RS232C: Can be connected to other Panasonic display devices and
PCs and inspection results can be easily monitored and
settings easily changed.
I/O: Connection to PLC or sensor. The PLC has functions
installed to interpret inspection results as a trigger signal
for
the sensor, as a switch for the product type or as teaching
input.
Field of view
Installation Distance
ANE2803
RS232C Cable
ANE2813
Operation Unit Cable
ANE2823
RS232C +
Operation Unit Cable
RS232C
I/O
LVDS
AETOOL
USB1.1
GT11 PC
PLC Fiber Sensor
The finder image shown here has
been reduced in resolution, so is
darker that the actual screen
image.
Operation/Finder Unit
or
or
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 8

Item Specification
Order Number ANPD050-02 ANPD050-05 ANPD050-10 ANPD050-15 ANPD050-20 ANPD050-25 ANPD050-30
Configuration Via software free of charge software PDTOOL or optional Operation/Finder unit
Field of view W x H (mm) 2 x 1.6 5 x 4 10 x 8 15 x 12 20 x 16 25 x 20 30 x 25
Minimum Cell Size (µm) 28 x 28 71 x 71 139 x 139 213 x 213 284 x 284 355 x 355 434 x 434
Installation distance (mm) 15 ± 0.5 25 ± 1.5 45 ± 2.5 60 ± 3.0 80 ± 4.0 105 ± 5.5 55 ± .0
Sensing element Colour-CMOS with 330.000 pixels
Resolution 352 x 288 pixels
Detection capability Min. 5 pixels per cell
Integrated light White LED, light amount half-life: min. 30.000 h (at 25°C)
Exposure time 0.03 to 50 ms
Visual pilot beam Red LED
RS232C (when using optional cable)
1.200 – 57.6000 bit/s, 8 bit ASCII, full duplex
5 Opto-coupler inputs, max. 30 VDC
(trigger, teach, 3 x type change)
5 PhotoMOS outputs, 5-24 VDC
(ready, alarm, 3 x data)
USB 1.1 for communication with PC (98SE, ME, 2000, XP)
LVDS for communication with Operation/Finder Unit
Processing time 30 ms
Operation voltage 24 VDC ± 10%
Current consumption ≤0.5 A
Ambient temperature use/storage 0 to +40°C / -20 to +60°C
Ambient humidity Usage and storage: 35 to 85% RH (@ 25°C no freezing or condensation)
Housing IP671), aluminium
Weight Approx. 400 g (Main Unit)
Digital I/O
Others
SerialInterfaces
≤
Item Specification
Readable Square codes: 10 x 10 cells to 44 x 44 cells
code type Rectangular codes: 8 x 18 cells, 8 x 32 cells, 12 x 26 cells,
12 x 36 cells, 16 x 36 cells, 16 x 48 cells
Supports black/white reversed codes, horizontally-flipped codes, and dots.
Model Model 1 and Model 2
Model 1: 21 x 21 cells to 49 x 49 cells (Ver. 1 to 8)
Model 2: 21 x 21 cells to 49 x 49 cells (Ver. 1 to 8)
Supports black/white reversed codes, horizontally-flipped codes, and dots.
Technical Specifications
Main Units
2D Code Reading
9
Data matrix
ECC200 Matrix Size The matrix size is
automatically
identified.
The model,
matrix size, and
the error correction level
are automatically
identified.
QR code Matrix Size
Error
correction level L (7%), M (15%), Q (25%), H (30%)
Operation Unit Finder Unit
ANE12
Display 2-inch colour LCD
Backlight life 40,000 (at 25°C)∆
Housing material Plastic
Weight Approx. 200g
ANE11
Display 7-segment, 3 colours
Setting function Mode, SET, Parameter, Type, Trigger, UP/DOWN
Housing material Plastic
Weight Approx. 200g
1) Expect when USB cable is connected
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 9

10
Stationary 2D Code Reader PD50
Technical Specifications/Dimensions
Main Units
All dimensions are in mm.
ANPD050-02 ANPD050-05•10•15•25•30
Operation Unit Finder Unit
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 10

11
Related Products
Vision Sensor
Our newly developed LightPix AE20 combines the ease of use of a conventional photoelectric
sensor with the inspection possibilities of an entry-level vision system. It is fast, cost effective and
suitable for various two-dimensional sensing tasks.
Compact Machine Vision Systems Imagechecker A100/200
A100/200 Machine Vision systems are our entry-level compact system with multi-purpose
functionality. With dimensions of just 120 x 40 x 70mm, the A-Series Imagechecker is one of the
smallest of its kind. It allows high-speed, dual-camera processing (A200) with a robust and mature
stand-alone hardware.
Colour Image Processing Systems AX30/AX40
Once colour-related product failures require detection, AX30/AX40 are the perfect solution. They
evaluate images of up to two cameras with respect to minute colour differences, checks
objects features, measures dimensions, compares patterns and much more.
High-Speed Machine Vision System PV300
PV300 combines the merits of A- and AX-Series Imagecheckers. Furthermore, it is equipped with
a second processor and thus allows ultra-high-speed inspection.
PC-Based Machine Vision
P400 and P400S Imagecheckers represent the next generation of PC-based Machine Vision.
The systems are user-friendly and offer multiple functions for a wide range of sophisticated
industrial inspection applications. High-end solutions materialise with a simple mouse-click.
High-End Machine Vision: Imagechecker AG50
One of the most demanding Machine Vision applications is the surface inspection of discrete
parts. The Imagechecker AG50 is an extremely powerful device that solves such complex tasks
quickly, reliably and with precision.
Laser Marking Systems
Accurate and distinct non-removable marking of almost any product can be achieved with our
Laser Markers. We offer various CO2and FAYb models ranging from 12 to 30 Watt.
054731_Panasonic_3164euen-PD50 02.11.2005 14:00 Uhr Seite 11

Global Network ServicesGlobal Network Services
Copyright © 2005 • Printed in Germany
3164 euen 11/05
Global Network
Asia Pacific China JapanNorth America Europe
Please contact our Global Sales Companies in:
Europe
Headquarters Panasonic Electric Works Europe AG Rudolf-Diesel-Ring 2, 83607 Holzkirchen, Tel. [phone], Fax [phone], www.panasonic-electric-works.com
Austria Panasonic Electric Works Austria GmbH Josef Madersperger Str. 2, 2362 Biedermannsdorf, Tel. [phone], Fax [phone], www.panasonic-electric-works.at
PEW Electronic Materials Europe GmbH Industriehafenstraße 9, 4470 Enns, Tel. [phone], Fax [phone], www.panasonic-electronic-materials.com
Benelux Panasonic Electric Works
Sales Western Europe B.V.
De Rijn 4, (Postbus 211), 5684 PJ Best, (5680 AE Best), Netherlands, Tel. [phone], Fax [phone], www. panasonic-electric-works .nl
Czech Republic Panasonic Electric Works Czech s.r.o. Prumyslová 1, 34815 Planá, Tel. [phone], Fax [phone], www.panasonic-electric-works.cz
France Panasonic Electric Works
Sales Western Europe B.V. French Branch Office, B.P. 44, 91371 Verrières le Buisson CEDEX, Tél. [phone], Fax [phone], www.panasonic-electric-works.fr
PEW Electronic Materials France S.A.R.L. 26 Allée du Clos des Charmes, 77090 Collegien, Tél. [phone], Fax [phone], www.panasonic-electronic-materials.com
Germany Panasonic Electric Works Deutschland GmbH Rudolf-Diesel-Ring 2, 83607 Holzkirchen, Tel. [phone], Fax [phone], www.panasonic-electric-works.de
Ireland Panasonic Electric Works UK Ltd. Dublin 12, Tel. [phone], Fax [phone], www.panasonic-electric-works.co.uk
Italy Panasonic Electric Works Italia s.r.l. Via del Commercio 3-5 (Z.I. Ferlina), 37012 Bussolengo (VR), Tel. [phone], Fax [phone], www.panasonic-electric-works.it
PEW Building Materials Europe s.r.l. Viale Elvezia 18, 20154 Milano (MI), Tel. [phone], Fax [phone], www.panasonic-building-materials.com
PEW Lighting Europe s.r.l. Via del Commercio 3-5 (Z.I. Ferlina), 37012 Bussolengo (VR), Tel. [phone], Fax [phone]
Nordic Countries Panasonic Electric Works Nordic AB Sjöängsvägen 10, 19272 Sollentuna, Sweden, Tel. [phone], Fax [phone], www.panasonic-electric-works.se
PEW Fire & Security Technology Europe AB Citadellsvägen 23, 21118 Malmö, Tel. [phone], Fax [phone], www.panasonic-fire-security.com
Portugal Panasonic Electric Works España S.A. Portuguese Branch Office, Avda Adelino Amaro da Costa 728 R/C J, 2750-277 Cascais, Tel. [phone], Fax [phone]
Spain Panasonic Electric Works España S.A. Barajas Park, San Severo 20, 28042 Madrid, Tel. [phone], Fax [phone], www.panasonic-electric-works.es
Switzerland Panasonic Electric Works Schweiz AG Grundstrasse 8, 6343 Rotkreuz, Tel. [phone], Fax [phone], www.panasonic-electric-works.ch
United Kingdom Panasonic Electric Works UK Ltd. Sunrise Parkway, Linford Wood, Milton Keynes, MK14 6LF, Tel. [phone], Fax [phone], www.panasonic-electric-works.co.uk
North & South America
USA PEW Corporation of America 629 Central Avenue, New Providence, N.J. 07974, Tel. [phone], Fax [phone]
Head Office USA
Asia Pacific / China / Japan
China Matsushita Electric Works (China) Co., Ltd. 2013, Beijing Fortune, Building No. 5, Dong San Huan Bei Lu, Chaoyang District, Beijing, Tel. [phone], Fax [phone]
Hong Kong Panasonic Electric Works Rm1601, 16/F, Tower 2, The Gateway, 25 Canton Road, Tsimshatsui, Kowloon, Hong Kong, Tel. [phone], Fax [phone]
(Hong Kong) Co., Ltd.
Japan Matsushita Electric Works, Ltd. 1048 Kadoma, Kadoma-shi, Osaka 571-8686, Japan, Tel. [phone], Fax [phone], www.mew.co.jp/e-acg/
Singapore
Panasonic Electric Works Asia Pacific Pte. Ltd. 101 Thompson Road, #25-03/05, United Square, Singapore 307591, Tel. [phone], Fax [phone]
Panasonic Electric Works
054731_Panasonic_3164euen-PD50 02.11.2005 13:59 Uhr Seite 12
