Panasonic HDC-TM40K User manual

2011 CamCorder
HDC-TM40
High Definition Camcorder
16.8x Optical ZOOm
Capture a wide range of images, from sweeping landscapes to close-ups of distant objects,
without image degradation.
panasOnic’s lightest mOdel
Go anywhere without the hassle of carrying around heavy equipment.
pOWeR O.i.s.
Minimizes the effects of hand shake for virtually blur-free close-ups and long-zoom shots.
16gB Built-in memORy
Shoot up to 6 hours of HD footage with no need for an additional memory card.
•2.7"LCD
•Intelligent Auto
•Pre-Record
Screen image
simulated.

03/11 Specifications subject to change without notice.
2011 CamCorder
HDC-TM40 High Definition Camcorder
GENERAL
Power Supply (Battery / AC Adapter) DC3.6V / 5.0V
Power Consumption Max. 3.5W (Recording) / Max. 7.7W (Charging)
Weight (w/o Battery) Approx. 0.37lb (169g)
Dimension (W x H x D) 2.03 x 2.26 x 4.27 [in] (51.5 x 57.5 x 108.5 [mm])
Media Built-in memory (16GB), SD/ SDHC/ SDXC
Memory Card
On-Screen Display Language Please refer to “OSD” sheet
IMAGE SENSOR
Image Sensor 1/5.8" MOS
Total Pixels 1.50 megapixels
Effective Pixels Motion Image 1.19 megapixels [16:9]
Still Image 1.19 megapixels [16:9]
LENS SECTION
Lens Brand Panasonic Lens
F Value F1.8 (WIDE) / 2.6 (TELE)
Optical Zoom 16.8X
Focal Length 2.9 - 48.7mm
35mm Film Camera Equivalent 42.9 - 721mm (16:9) [Motion Image]
42.9 - 721mm (16:9) [Still Image]
Filter Diameter –
CAMERA SECTION
Standard Illumination 1400 lx
Minimum Illumination 7.0 lx (1/25 Low Light Scene Mode)
1 lx (Color Night View)
Image Stabilizer POWER O.I.S. [Optical Image Stabilizer]
Focus Auto / Manual
White Balance Auto / Indoor1 / Indoor2 / Sunny / Cloudy / White Set
Shutter Speed Motion Image [60i] Auto Slow Shutter
ON: 1/30 - 1/8000
OFF: 1/60 - 1/8000
Still Image
Iris Auto / Manual
Zoom Intelligent Zoom OFF 16.8X
Intelligent Zoom –
Digital Zoom 50X/1200X (The maximum value of zoom
magnification)
Backlight Compensation Yes
MONITOR
EVF –
Monitor (LCD) 2.7" Wide LCD (230,400 dots)
STILL IMAGE SECTION
Recording Format JPEG
Recording
Image Size
Still Picture 2.1 megapixels (1920 x 1080), 0.5 megapixels
(960 x 540), [16:9]
Simultaneous Recording –
Creating Still Picture From
Motion Picture
2.1 megapixels (1920 x 1080), 0.5 megapixels
(960 x 540), [16:9]
Flash –
DPOF –
RECORDING SECTION
Signal System 1080 / 60i
Recording Format MPEG4-AVC/ H.264 (AVCHD standard compliant)
iFrame: MPEG-4 AVC/ H.264 (MPEG-4 AVC file
format compliant (.MP4))
Recording / Playback Mode HA (17Mbps / VBR), (1920 x 1080)
HG (13Mbps / VBR), (1920 x 1080)
HX (9Mbps / VBR), (1920 x 1080)
iFrame (28Mbps/VBR), (960 x 540)
Audio Recording System Dolby Digital (2 ch)
iFrame: AAC (2 ch)
Microphone 2 ch Stereo
Speaker Dynamic Type
Media Remaining Indication –
INTERFACES
AV –
HDMI Yes (mini)
Microphones (stereo mini) –
Headphone (stereo mini) –
USB 2.0 Hi-Speed
AV Multi Yes
OTHERS
LED Video Light Yes
Accessory Shoe –
STANDARD ACCESSORIES
AC Adapter Yes
AC Cable Yes
DC Cable Included AC Adapter
Rechargeable Battery Pack Min. 1790 mAh / Lithium-Ion
AV Multi Cable Yes
AV Cable –
IR Remote –
Shoe Adapter –
USB Cable Yes
SD Memory Card –
Included Software HD Writer LE 1.0
Lens Hood –
Stylus Pen –
