Panasonic CQVD7001U - CAR A/V DVD NAV User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 10A(During Disc Playback)
Maximum Power Output 50W×4ch
Compatible Speaker
Impedance 4Ω
Video Input Signal Composite Video Signal,
1.0 Vp-p (75Ω)
Audio Input Sensitivity 2 Vrms
Video Output Signal Composite Video Signal,
1.0 Vp-p (75Ω)
Pre-Amp Output Voltage 2 Vrms
Pre-Amp Output Impedance Less than 600Ω
FM Stereo Radio
Frequency Range 87.9 - 107.9MHz
Usable Sensitivity 12.2dBf
Stereo Separation 40dB (1kHz)
S/N Ratio 63dB
AM Stereo Radio
Frequency Range 530 - 1710kHz
Usable Sensitivity 25 dB/µV
Image Rejection Ratio 50 dB
© 2005 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-VD7001U
In-Dash 7” Widescreen Color LCD
Monitor/DVD Receiver
Audio Section
Output voltage/Impedance 2 Vrms/600 Ω
Frequency Characteristics
(When “LARGE” is Selected)
Front L/R, Center,
Rear (Surround) L/R 20Hz - 20kHz (±1 dB)
Delay Time
Dolby Digital
Center 0-5ms
Rear (Surround) L/R 0 -15 ms
Dolby Pro Logic
Rear (Surround) L/R 15-30 ms
Distortion
Front L/R 0.01% (1kHz,0dB,PCM Input)
Dynamic Range 96dB (During CD Playback)
S/N Ratio 100dB (During CD Playback)
Monitor
Liquid Crystal Panel 7” wide
Screen Dimensions (W×H×D) 6-1/16” × 3-7/16” × 6-15/16”
(154 × 87 × 177mm)
Number of Pixels 336,960 pixels
(234 vertical × 480 horizontal × 3)
Valid Pixel Ratio Over 99.99%
Display Method Transparent color filter format
Drive Method TFT (Thin Film Transistor)
active matrix format
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER No.ACED050201C1
C7

Light Source Internal light
(Built-in small fluorescent lamp)
Dimensions** (W × H × D) 7” × 1-15/16” × 6-1/2”
(178 × 50 × 165 mm)
Weight** 5lbs. 5oz. (2.4 kg)
1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATURES 3
3 REPLACING THE FUSE 3
4 MAINTENANCE 3
5 LASER PRODUCTS 3
6 DIMENSIONS 3
7 WIRING CONNECTION 4
8 DISASSEMBLY INSTRUCTIONS 5
9 TERMINALS DESCRIPTION 7
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
• • •
• Above specifications comply with EIA standards.
10 PACKAGE AND IC BLOCK DIARAM 11
11 PACKING PARTS LIST 20
12 REPLACEMENT PARTS LIST 21
13 EXPLODED VIEW (Unit) 34
14 DVD PLAYER PARTS LIST 35
15 EXPLODED VIEW (DVD Deck) 39
16 WIRING DIAGRAM 40
17 SCHEMATIC DIAGRAM 47
18 BLOCK DIAGRAM 55
CONTENTS
Page Page
2
CQ-VD7001U

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATURES
• • •
• Integration of the monitor, FM/AM radio, DVD Video, Video
CD player and CD/MP3/WMA player
• • •
• Built-in AV Input/Output Terminals
• • •
• Built-in Dolby Digital decoder, DTS decoder
• • •
• Built-in DSP
• • •
• GUI (Graphic User Interface)
• • •
• ID code
• • •
• CS Auto (Circle Surround Automotive)
• • •
• Touch Panel Operation
• • •
• DVD-R, DVD-RW Playback
3 REPLACING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to this unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 LASER PRODUCTS
6 DIMENSIONS
3
CQ-VD7001U

7 WIRING CONNECTION
4
CQ-VD7001U

8 DISASSEMBLY INSTRUCTIONS
8.1. How to Remove the Flexible PCB(AP1)
5
CQ-VD7001U

8.2. How to Disassemble & assemble
6
CQ-VD7001U

9.1. Main Block
IC601 : C2DBLK000071
Pin
No. Port Description I/O Vol (V)
1 AVREF0 Reference voltage for A/D
converter - 3.2
2 AVSS Ground for A/D converter - 0
3 ANT CNT Antenna control O 3.2
4 RM CUT Ext. remote control output cut
off O 0
5 AVREF1 Reference voltage for A/D
converter - 3.2
6 Touch RESET Touch Panel reset O 3.2
7 TN CNT Ext. TV tuner control O 3.2
8 IC/FLMD0 Flash memory update control - 0
9 VDD +3V power supply - 3.2
10 REGC Bypass capacitor terminal for
voltage reg. - 2.5
11 VSS Ground - 0
12 X1 Crystal osillator terminal I 1.1
13 X2 Crystal osillator terminal - 1.2
14 /RESET System reset I 3.2
15 XT1 (Connecting to ground) - 0
16 XT2 Not used - 2.5
17 CH CHANGE Not used - 0
18 CH STB/XM
DET2 Changer data strobe / XM connection check I 5.0
19 RDS DATA RDS data I 3.3
20 RDS CLK RDS clock I 0
21 CHC SENS Twin-changer adapter
detection I 0
22 OSD CS OSD chip select O 1.0
23 OSD DO OSD control data O 0.6
24 OSD CLK OSD data shift clock O 2.2
25 XM
SO(MO)/TXDA0 XM data O 5.0
26 CH DATA/XMSI
/RXDAO Changer data / XM data I 0
27 CH CLK/XM
DET1 Changer clock / XM detection signal I 3.1
28 REMO DATA Ext. remote control signal I 5.0
29 CHC REM OUT Changer remote control code O 5.1
30 I2C CLK I2C bus clock O 5.1
31 I2C DATA I2C bus data O 5.1
32 OSD RESET OSD reset O 3.2
33 EVSS Ground for ext. unit - 0
34 EVDD +3V power supply for ext. unit - 3.2
35 DVD TX(MO) DVD deck TX data O 3.2
36 DVD RX(MI) DVD deck RX data I 3.2
37 BEEP Beep signal O 0
38 AMP CNT Ext. AMP control O 3.2
39 AMP STB Ext. AMP stand-by O 5.0
40 TFT SI(MI) TFT unit communication data I 0
41 TFT SO(MO) TFT unit communication data O 0.5
42 TFT CLK TFT unit communication clock O 5.0
43 AMP MUTE Internal power AMP mute O 0
44 SYS ON System power (5V) control for
SW PCB O 0
45 NAVI REMO
OUT NAVI remote control data O 0
46 ENTER ENTER key I 3.3
47 FRONT MUTE Audio signal (BEEP NAVI)
mute O 5.0
48 VD COUNT Vertical drive signal count I 5.0
49 REAR MUTE Video out mute O 5.0
50 NC (Ground pull down) O 0
Pin
No. Port Description I/O Vol (V)
51 DE EMPH I2C1 I2C1 de-emphasis control O 0
52 SYS MUTE (F) System mute (FRONT) O 5.0
53 SYS MUTE (S) System mute (SURROUND) O 5.0
54 SYS MUTE (C) System mute (CENTER) O 5.0
55 SYS MUTE(SW) System mute (SW) O 5.0
56 BATT SENS Battery level detection I 5.0
57 ACC SENS ACC level detection I 5.0
58 PULSE Monitor position detection
pulse I 5.0
59 SYS PWR System power control O 5.0
60 MAIN PWR Main power control O 3.2
61 MONI PWR Monitor power control O 3.2
62 NAVI RM CH NAVI remote control output
change O 0
63 MODE LED MODE LED on/off O 3.2
64 EJECT LED EJECT LED on/off O 0
65 NAVI LED NAVI LED on/off O 0
66 MA Drive mechanism control
signal O 3.2
67 MB Drive mechanism control
signal O 3.2
68 MC Drive mechanism control
signal O 3.2
69 BVSS Ground for bus I/F - 0
70 BVDD Power supply for bus I/F - 3.2
71 FAN CNT Fan motor power control O 3.2
72 ROTARY.1 Rotary encoder signal (VOL
DOWN) I 0
73 ROTARY.2 Rotary encoder signal (VOL
UP) I 3.3
74 DSP INIT DSP initialise detection I 3.3
75 RADIO CNT Radio power control O 3.2
76 DVD MUTE DVD mute request / Flash
memory update cnt. I 3.3
77 DSP SCK Shift clock for DSP
communication data O 2.8
78 DSP SDA DSP communication data O 3.1
79 DSP RESET DSP reset O 3.2
80 DVD CNT DVD deck power control O 3.2
81 DVD RESET Reset signal for DVD deck
control MPU O 3.2
82 FRAM HOLD F-RAM hold O 0
83 FRAM CLK Shift clock for F-RAM data O 0
84 FRAM DO F-RAM serial data O 0
85 FRAM CS F-RAM chip select O 3.2
86 FRAM WP F-RAM write protect O 0
87 SW PWR Switching power supply
frequency change O 0
88 MODE MODE key detection I 3.2
89 JOY A/D ADC input terminal for joy stic
signal I 3.3
90 NAVI DISP NAVI display activity detection I 3.3
91 NAVI SENS NAVI system connection
detection I 3.3
92 SIDE BRAKE Side break detection I 3.3
93 INIT DET Destination detection I 0
94 POSI SENS ADC input terminal for
monitor position signal I 2.4
95 NAVI MUTE NAVI mute I 0
96 OFFSET DET Power IC abnormality
detection I 0
97 AD KEY ADC input terminal for AD
key signal I 3.3
98 REVERSE REVERSE signal detection I 3.3
99 FRAM DI F-RAM serial data I 0
100 V NAVI NAVI RGB signal change O 0
9 TERMINALS DESCRIPTION
7
CQ-VD7001U

9.2. TFT Block
IC401 : C2BBFD000592
PIN
No. Name Description I/O (V)
1 UCOM 5V In connection with VDD A/D
converter standard voltage input - 5.1
2 Avss A/D converter ground potential - 0
3 IC/VPP Internal connection terminal (in
connection to ground) - 0
4 VDD Positive power supply - 5.1
5 VSS GND - 0
6 X1 Main system clock - 2.3
7 X2 Main system clock - 2.6
8 RESET System reset input I 5.0
9XT1 In connection with VDD. - 5.1
10 XT2(NC) No Connection - -
11 TFT
RESET System Reset input I 5.0
12 MONIO
VD Vertial SYNC signal I 1.9
13 HPOS0 H Position Data 0 I/S 3.0
14 HPOSI H Position Data 1 I/S 3.0
15 HPOS2 H Position Data 2 I/S 0
16 HPOS3 H Position Data 3 I/S 0
17 HPOS4 H Position Data 4 I/S 2.8
18 SIDE2 ASPECT switch signal output Side
black 2 O 0
19 SIDE1 ASPECT switch signal output Side
black 1 O 0
20 ZOOM ASPECT switch signal output
Zoom/just mode switch control O 0
21 JUST ASPECT switch signal output Just
display O 0
22 EVSS Ground port - 0
23 EVDD Port power supply - 5.1
24 I2C Data I2C Data O 5.0
25 I2C Clock I2C clock O 5.0
26 MONI
CNT - - -
27 BL CNT Backlight power supply control
output O 5.1
28 TFT Data Serial communications data output
for the main CPU O 0
29 TFT COM Serial communications data input
for the main CPU I 0
30 TFT CLK Serial communications clock for
the main CPU I 5.0
31 TOUCH
SW Switch output for touch panel SW detection O 4.6
32 NC - - -
33 X- Transistor SW output for touch
panel side X (- pole) O 0
34 Y- Transistor SW output for touch
panel sideY (- pole) O 0
35 X+ Transistor SW output for touch
panel side X (+ pole) O 5.1
36 Y+ Transistor SW output for touch
panel side Y (+ pole) O 5.1
37 XG Touch panel side X with respect
to - pole I 0
38 YG Touch panel side Y with respect
to - pole I 1.0
39 XR Touch panel side X with respect
to + pole I 0
40 YR Touch panel side Y with respect
to + pole I 1.0
41 A/D KEY A/D key input for TILT and
OPEN/CLOSE I 5.1
42 Light
SENS DIMMER input I 4.1
43 EJECT
KEY Eject key input I 5.1
PIN
No. Name Description I/O (V)
44 NC No Connection - -
8
CQ-VD7001U

9.3. DVD Servo Block
IC501 C1AB00001622
Pin
No. Port Descriptions I/O(V )Vol (V)
1 VDDIO I/O pad power (3.3V) - 3.3
2MD10 SDRAM data bus I/O 0
3MD11 SDRAM data bus I/O 0.6
4 VDD Core power (1.8V) - 1.8
5MD12 SDRAM data bus I/O 0
6 VSSIO I/O pad ground - 0
7MD13 SDRAM data bus I/O 0.7
8MD14 SDRAM data bus I/O 0.5
9MD15 SDRAM data bus I/O 0
10 VDDIO I/O pad power (3.3V) - 3.3
11 /DQM1 SDRAM data byte enable O 0
12 MA9 SDRAM address bus O 0
13 MA8 SDRAM address bus O 0
14 VSSIO I/O pad ground - 0
15 MA7 SDRAM address bus O 2.3
16 MA6 SDRAM address bus O 1.9
17 VSS Core ground - 0
18 MA5 SDRAM address bus O 1.1
19 VDDIO I/O pad power (3.3V) - 3.3
20 MA4 SDRAM address bus O 2.0
21 MA3 SDRAM address bus O 2.3
22 MCLK SDRAM clock O 1.7
23 VSSIO I/O pad ground - 0
24 CKE SDRAM clock enable O 3.3
25 MA2 SDRAM address bus O 2.3
26 MA1 SDRAM address bus O 1.0
27 VDDIO I/O pad power (3.3V) - 3.3
28 MA0 SDRAM address bus O 1.0
29 MA10 SDRAM address bus O 0
30 MA11 Not used - -
31 VSSIO I/O pad ground - 0
32 MA12 SDRAM address bus O 2.1
33 MA13 SDRAM address bus O 2.1
34 VDD Core power (1.8V) - 1.8
35 /CS0 SDRAM primary bank chip select O 2.7
36 VDDIO I/O pad power (3.3V) - 3.3
37 /RAS SDRAM command bit O 3.1
38 /CAS SDRAM command bit O 2.9
39 /WE SDRAM command bit O 3.2
40 VSSIO I/O pad ground - 0
41 /DQM0 SDRAM data byte enable O 0
42 /DQM2 SDRAM data byte enable O 0
43 MD16 SDRAM data bus I/O 0.5
44 VDDIO I/O pad power (3.3V) - 3.3
45 MD17 SDRAM data bus I/O 0.5
46 MD18 SDRAM data bus I/O 0.5
47 VSS Core ground - 0
48 MD19 SDRAM data bus I/O 0.7
49 VSSIO I/O pad ground - 0
50 MD20 SDRAM data bus I/O 0
51 MD21 SDRAM data bus I/O 1.5
52 MD22 SDRAM data bus I/O 1.0
53 VDDIO I/O pad power (3.3V) - 3.3
54 MD23 SDRAM data bus I/O 0
55 MD24 SDRAM data bus I/O 0.5
56 MD25 SDRAM data bus I/O 0.5
57 VSSIO I/O pad ground - 0
58 MD26 SDRAM data bus I/O 0.5
59 MD27 SDRAM data bus I/O 0.8
60 MD28 SDRAM data bus I/O 0
61 MD29 SDRAM data bus I/O 1.0
62 VDDIO I/O pad power (3.3V) - 3.3
63 MD30 SDRAM data bus I/O 0.7
64 MD31 SDRAM data bus I/O 0.5
65 /DQM3 SDRAM data byte enable O 0
66 /CS1 Not used O -
67 VSSIO I/O pad ground - 0
68 SPDIF S/PDIF digital audio output O 1.3
69 VSS Core ground - 0
Pin
No. Port Descriptions I/O(V )Vol (V)
70 AIN Digital audio input for digital micro I 3.3
71 AOUT3 Serial audio data (Left/Right CH) O 0
72 AOUT2 Serial audio data (Center/LFE CH) O 0
73 AOUT1 Serial audio data (Sound Left/Right CH) O 0
74 AOUT0 Serial audio data (Left/Right CH) O 0
75 VDDIO I/O pad power (3.3V) - 3.3
76 PCMCLK Audio DAC PCM sampling clock O 1.8
77 VDD Core power (1.8V) - 1.8
78 ACLK Audio interface serial data clock O 1.7
79 LRCLK Left/Right channel clock O 1.7
80 /SRST Reset signal O 3.3
81 /RSTP Power on reset I 3.3
82 VSSIO I/O pad ground - 0
83 RXD1 Not used - -
84 SSPIN1 SSP1 data in / UART1 16X clock I/O 15
85 VSS Core ground - 0
86 SSPOUT1 SSP1 sata out / UART1 DTR I/O 0
87 SSPCLK1 SSP1 clock / UART1 CTS I/O 3.3
88 SSPCLK0 Not used - -
89 VDD Core power (1.8V) - 1.8
90 SSIN0 Not used - -
91 VDDIO I/O pad power (3.3V) - 3.3
92 SSPOUT0 Not used - -
93 TXD0 UART0 serial data O 3.2
94 RXD0 UART0 serial data I 3.0
95 /CTS0 Not used - -
96 /RTS0 Not used - -
97 VSSIO I/O pad ground - 0
98 CXI Crystal Oscillator terminal I 1.6
99 CXO Not used - -
100 OSCVSS Oscillator ground - 0
101 OSCVDD Oscillator power (1.8V) - 1.8
102 MVCLVDD Main/Video clock PLL power (3.3V) - 3.3
103 SCEN Not used - -
104 MVCKVSS Main/Video clock PLL Ground - 0
105 ACLKVSS Audio clock PLL ground - 0
106 SCMD Not used - -
107 ACLKVDD Audio clock PLL power - 3.3
108 VDDDAC DAC digital power (1.8V) - 1.8
109 VSSDAC DAC digital ground - 0
110 CVBS2/CR/R Composite Cr/Component Cr/SCART Red O 0.5
111 IOM Cascaded DAC differential output O 1.0
112 C/CB/B Chrominance/Component Cb/SCART Cb O 0.7
113 VAA3 DAC analog power (3.3V) - 3.3
114 Y/G Luminance/SCART G O 0.4
115 VSSA DAC analog ground - 0
116 VREF Not used - -
117 VAA - - 1.8
118 CVBS/C Composite/S-Video Chrominance O 0.5
119 RSET Current setting resistor connection O 1.4
120 COMP Compensation capacitor connection O 2.0
121 VSS Core ground - 0
122 VCLK Not used - -
123 VSYNC Not used - -
124 HSYNC Not used - -
125 VDDIO I/O pad power (3.3V) - 3.4
126-
131 VI07-02 Not used - -
132 VSSIO I/O pad ground - 0
133 Not used - -
134 Not used - -
135 VDD Core power (1.8V) - 1.9
136-
139 AD31-28 Not used - -
140 VDDIO I/O pad power (3.3V) - 3.4
141-
144 AD27-24 Not used - -
145 /PWE3 Not used - -
146 AD23 Not used - -
147 VSSIO I/O pad ground - 0
148-
150 AD22-20 Not used - -
151-
153 AD19-17 Address/Data bus I/O 0
9
CQ-VD7001U

Pin
No. Port Descriptions I/O(V )Vol (V)
154 VDDIO I/O pad power (3.3V) - 3.4
155 AD16 Address/Data bus I/O 0
156 /PWE2 Not used - -
157,
158 AD15, 14 Address/Data bus I/O 0
159 VDD Core power (1.8V) - 1.9
160 SCLK External bus clock O 2.1
161 ACK Programmable WAIT/ACK/RDY control I 3.4
162 VSSIO I/O pad ground - 0
163-
168 AD13-08 Address/Data bus I/O 0
169 VDDIO I/O pad power (3.3V) - 3.4
170 /PWE1 Not used - -
171 VSS Core ground - 0
172-
176 AD7-3 Address/Data bus I/O 0
177 VSSIO I/O pad ground - 0
178-
180 AD02-00 Address/Data bus I/O 0
181 VDDIO I/O pad power (3.3V) - 3.4
182 /PWE0 Byte write enable O 0
183 ALE Address latch enable O 0
184-
187 LA0-3 Latch address O 3.3
188 VSSIO I/O pad ground - 0
189 RD Read signal O 3.4
190 LHLDA Not used - -
191 LHLD Not used - -
192 VDD Core power (1.8V) - 1.9
193 /PCS0 Peripheral chip select 0 O 3.4
194 XI01 Not used - -
195 DACCS2 DAC output select 2 O 3.4
196 VDDIO I/O pad power (3.3V) - 3.4
197 DACCS1 DAC output select 1 O 3.4
198 NINTCPPM Not used - -
199 CPPMCS Not used - -
200 XI06 Not used - -
201 VSS Core ground - 0
202 FRAMCS FRAM chip selection O 0
203 DACRST DAC reset O 0
204 VSSIO I/O pad ground - 0
205 FEPCS Front End Pro. LSI chip select O 3.4
206 FEPRST Front End Pro. reset O 3.4
207 SODCCS SODC LSI chip selection O 3.4
208 NINTHOST HOST interrupt I 3.4
209 NINTDDC DDC interrupt I 3.2
210 VDDIO I/O pad power (3.3V) - 3.4
211 NINTDSC DSC interrupt I 3.5
212 VDD Core power (1.8V) - 1.9
213 DSYNV DVD parallel mode sector SYNC I 3.4
214 DREQ DVD parallel mode data request O 3.4
215 DCLK Data sampling clock I 3.4
216 DSTB Parallel mode data valid/Serial mode clock I 0.7
217 DVD0 DVD drive parallel data port I 0
218 VSSIO I/O pad ground - 0
219 DVD1 DVD drive parallel data port I 0
220 DVD2 DVD drive parallel data port I 0
221 DVD3 DVD drive parallel data port I 3.4
222 DVD4 DVD drive parallel data port I 0.8
223 DVD5 DVD drive parallel data port I 0.8
224 VDDIO I/O pad power (3.3V) - 3.4
225 DVD6 DVD drive parallel data port I 3.4
226 DVD7 DVD drive parallel data port I 3.4
227 MD0 SDRAM data bus I/O 0.5
228 VSSIO I/O pad ground - 0
229 MD1 SDRAM data bus I/O 0
230 VSS Core ground - 0
231 MD2 SDRAM data bus I/O 0.8
232 MD3 SDRAM data bus I/O 0.8
233 VDDIO I/O pad power (3.3V) - 3.3
234 MD4 SDRAM data bus I/O 3.3
235 MD5 SDRAM data bus I/O 0
236 MD6 SDRAM data bus I/O 0.8
237 VSSIO I/O pad ground - 0
Pin
No. Port Descriptions I/O(V )Vol (V)
238 MD7 SDRAM data bus I/O 0
239 MD8 SDRAM data bus I/O 0
240 MD9 SDRAM data bus I/O 0
10
CQ-VD7001U

10.1. Main Block
IC101 : C0ABBB000090
IC102 : C0JBAA000102
IC151, IC604 : C0JBAA000115
IC203, IC252, IC301, IC302 : C0ABBB000105
IC201, IC202 : C0ABCB000051
IC351 : C1AB00001604
IC608 : C0JBAB000255
10 PACKAGE AND IC BLOCK DIARAM
11
CQ-VD7001U

IC303 : C0ZBZ0000770
IC602 : C3GBCC000001
IC612 : C0FBBD000065
12
CQ-VD7001U

IC609, IC610 : C0JBAZ001166
IC611 : C0JBAZ000525
IC754 : C0DBAMG00015
13
CQ-VD7001U

IC751 : AN8065SE1
IC752, IC753, IC755 : C0DBEKG00001
IC756 : C0CBABC00037
10.2. TFT Block
IC422 : C0FBBD000038
14
CQ-VD7001U

IC451 : C0DBAZZ00095
IC801 : AN2526FH
15
CQ-VD7001U

IC421 : C3EBDC000049
IC802, IC803, IC863 : C0JBAR000155
IC861 : C1AB00001825
16
CQ-VD7001U

IC804 : C0ZBZ0000432
IC941 : C0ABBB000069
IC951 : C0DBAZA00013
IC902 : C0ABBB000105
17
CQ-VD7001U

IC101 : AN8703FH-V
IC271 : YEAMT7ST08UL
IC275, IC561 : C0JBAZ001014
IC311 : C0GBY0000012
IC321 : C0GBH0000006
10.3. DVD Deck Block
18
CQ-VD7001U

IC411 : YEAMC78L05E2
IC441 : MN13821JP
IC631, IC641 : C0JBAH000082
IC651 : C3GBCC000001
IC652 : C0JBAB000255
19
CQ-VD7001U

11 PACKING PARTS LIST
• • •
• Item numbers listed below should not order regular spare parts. (not available)
Item
No. Part No. Part Name & Description Q’ty Remarks
1 - Inner Carton 1 Not available
2 - Packing Pad (Left) 1Not available
3 - Packing Pad (Right) 1Not available
4 - Packing Pad (A) 1Not available
5 - Packing Pad (B) 1Not available
6 - Packing Pad (C) 1Not available
7 - Packing Pad (D) 1Not available
8 - Packing Pad (E) 1Not available
9YEFX9995413 Remote Control Unit 1
10 CR2025/1F Lithium Battery (CR2025) 1
11 YEFX9991793 Wiping Cloth 1
12 - Operation Instructions 1Not available
-Installation Instructions 1Not available
13 YEP9FZ2739 Trim Plate 1
14 YEFG012694 Mounting Collar 1
15 YEFX0052714 Mounting Spring 2
16 ZZBISVD7001A Bis kit (Mounting Bolt, Tapping Screw, Hex. Nut) 1
17 YEFG04019 Rear Support Strap 1
18 ZZBISVD7001B Bis Kit (Round Head Screw, Flat-Head Screw, Round Head Screw) 1
19 ZZBISVD7001E Bis Kit (Spacer, Double-Faced Adhesive Tape) 1
20 YAJ024C113A Power Connector 1
21 WAVS05M6000T Reverse Extension Cord 1
22 YEAT034C012 Clip Connector 1
20
CQ-VD7001U
