Panasonic CQ-C7402W User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls (Bass/Treble) Bass: ±12dB at 60Hz
Treble: ±12dB at 16kHz
Equalizer Center Frequency 60, 160, 400, 1k, 3k, 6k, 16k (Hz)
Variable Range of Equalizer -12dB to 12dB (2dB step)
Current Consumption Less than 2.2A
(CD mode; 0.5W × 4-speaker)
Maximum Power Output 50W × 4(at 4Ω)
Speaker Impedance 4-8Ω
Pre-amp Output Voltage 5V
Subwoofer Output Voltage 5V
Pre-amp Output Impedance 60Ω
Subwoofer Output Impedance 60Ω
CD Player
Sampling Frequency 8 Times Oversampling
Pick-up Type Astigma 3-Beam
Light Source Semiconductor Laser
Wave Length 790 nm
Frequency Response 20Hz-20kHz (±1dB)
Signal to Noise Ratio 96dB
Total Harmonic Distortion 0.01% (1kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 75dB
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C7402W
WMA MP3 CD Player/Receiver with Full
Dot Matrix Display
FM Stereo Radio
Frequency Range 87.5MHz - 108MHz
Usable Sensitivity 6dB/µV (S/N 30dB)
Stereo Separation 35dB (at 1kHz)
AM Radio
Frequency Range 531kHz - 1,602kHz
Usable Sensitivity 28dB/µV (S/N 20dB)
Dimensions (W×H×D)** 178×50×155mm
Weight** 1.6Kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.
AUTOMOTIVE AFTERMARKET
Specifications*
ORDER NO. ACED060609C3

1 ABOUT LEAD FREE SOLDER (PbF) 3
2 FEATURES 3
3 REPLACEING THE FUSE 3
4 MAINTENANCE 3
5 NOTES 3
6 DIMENSIONS 3
7 LASER PRODUCTS 3
8 WIRING CONNECTION 4
9 DISASSEMBLY INSTRUCTIONS 5
10 TERMINALS DESCRIPTION 8
11 IC BLOCK DIAGRAM 12
12 REPLACEMENT PARTS LIST 16
13 EXPLODED VIEW (Unit) 22
14 CD PLAYER PARTS LIST 23
15 EXPLODED VIEW (CD PLAYER) 26
16 WIRING DIAGRAM 27
17 SCHEMATIC DIAGRAM 33
18 BLOCK DIAGRAM 37
CONTENTS
Page Page
2
CQ-C7402W

1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATURES
• • •
• MP3/WMA Playback from CD-R/RW
• • •
• Fully Motorized Front Panel
• • •
• Six Preset Modes (FLAT, ROCK, POP, VOCAL, JAZZ,
CLUB)
• • •
• SQ7 (7 Bands Sound Quality)
• • •
• DVD Changer Control
• • •
• Delightful sound space thanks to system buildup
• • •
• Maximum Power Output 50W
• • •
• Pre Out Fix Tipe (Silver)
3 REPLACEING THE FUSE
Use fuses of the same specified rating 15 amps. Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
4 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
5 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit
6 DIMENSIONS
7 LASER PRODUCTS
3
CQ-C7402W

8 WIRING CONNECTION
4
CQ-C7402W

9 DISASSEMBLY INSTRUCTIONS
9.1. How to Remove the Flexible PCB(AP2)
5
CQ-C7402W

9.2. How to Install the Main P.C.B. of the Electric Display
6
CQ-C7402W

7
CQ-C7402W

10.1. Main Block
IC601 : C2CBJG000589
Pin
No. Port Description (I/O) (V)
FM AM CD
1 PANEL OPEN PANEL OPEN detection I 0 5.2 5.2
2 PANEL
CLOSE PANEL CLOSE detection I 0 0 5.2
3 NC No Connection - - - -
4 BATT BATT detection I 4.8 5 5
5 ACC ACC detection I 4.8 5 5
6 SDA Electronic VOL data I/O 4.9 4.9 4.9
7 SCLK Electronic VOL clock O 4.9 4.9 4.9
8 NC No Connection - - - -
9 Vss Power supply GND I 0 0 0
10 ST FM ST detection I 5.1 5.2 5.2
11 PLL DI(MO) PLL data output O 0.6 0 0
12 PLL DO(MI) PLL data input I 5.2 5.2 5.2
13 PLL CLK PLL clock output O 4.9 4.9 4.9
14 PLL CE PLL chip enable output O 0 0 0
15 CD RST CD deck reset output O 4.9 4.9 4.9
16 SUB SI SUB u-com Data trans SO 0.6 0.6 0.8
17 NC No Connection - - - -
18 SUB SO SUB u-com data recept SI 4.4 4.4 4.4
19 CH DATA Changer; data
transmission from XM;
FLASH W SO
SI 1.6 1.6 1.6
20 CH CLK Clock transmission from
the changer; FLASH W
CLK
SCK 4.9 4.9 4.9
21 Vdd Power supply I 4.9 4.9 4.9
22 XM SI DATA transmission to
XM; FLASH W SI S0 0 0 0
23 CD SI CD DATA transmission S0
24 CD SCK CD Clock transmission SCK 0 0.4 0
25 CONDENSOR Capacitor for power
supply - 3.3 3.3 3.3
26 CDC SO CD DATA transmission SI 0 0 0
27 CDC STB Changer stororb signal
input INT 0 0 0
28 CD IN DISC in detect I 4.9 4.9 0.4
29 DECK V
CONT DECK power supply control output O 4.9 4.9 4.9
30 CD STB CD frame sink O 3.7 3.7 3.7
31 NC No Connection - - - -
32 Avdd Power supply of D/A
converter I 5.1 5.1 5.1
33 AVREF Reference voltage for
D/A converter I 5.1 5.1 5.1
34 AVGND Reference GND for D/A
converter I 0 0 0
35 AVSS Grand for A/D and D/A
converter I 0 0 0
36 SD FM/AM signal meter
signal input A/D 0.2 0 0.3
37 INIT A Initializ A A/D 0 0 0
38 INIT B Initializ B A/D 0 0 0
39 AIN SPE.ANA A.IN A/D 0 0 0
40 Vss GND I 0 0 0
41 CD MUTE CD deck mute detection I 0 0 5.1
42 NC No Connection - - - -
43 NC No Connection - - - -
44 NC No Connection - - - -
45 CD SW1 CD disc in detection I - - -
46 CD SW2 CD disc in detection I - - -
47 MOD0 Operating mode input 0 I 5.1 5.1 5.1
48 MOD1 Operating mode input 1 I 5.1 5.1 5.1
49 MOD2 Operating mode input 2 I 0 0 0
Pin
No. Port Description (I/O) (V)
FM AM CD
50 H STANDBY External standby input I 5 5 5
51 DC DC CNT DC/DC control for 60W
(CQ-C8401W) O 0 0 0
NC No Connection
(CQ-C7401W) - - - -
52 FP MOTOR1 Front open/close control
1O 4.9 5 4.9
53 FP MOTOR2 Front open/close control
2O 4.9 5 4.9
54 V CNT1 Panel driving voltage
control 1 O 0 0 5
55 V CNT2(NC) No Connection - - - -
56 SA CLK Control for Speana
acquisition O 5 5 4.9
57 EXT MUTE TEL/NAVI MUTE input I 5.3 5.2 5.2
58 AMP CONT External AMP control O 4.9 5 4.9
59 BZ-OUT Buzzer output PPG 0 0 0
60 ANT CONT Motor antenna control O 4.9 5 0
61 DIM1 Dimmer control output 1 O 0 0 0
62 DIM2 Dimmer control output 2 O 0 0 0
63 CDC REM
OUT Remote control code output to Changer O 5 5 5
64 CDC SENS CDC 1/2 detection I 5.1 5.1 5.1
65 CDC 1/2 CDC 1/2 change output O 0 0 0
66 NC No Connection - - - -
67 MWUP MAIN.WAKE.UP.REQ
input I 5 4.9 5
68 NC No Connection - - - -
69 NC No Connection - - - -
70 NC No Connection - - - -
71 NC No Connection - - - -
72 MAIN CONT MAIN power supply
control output O 4.9 4.9 4.9
73 INV CONT INV power supply control
output O 5 5 5
74 AF MUTE Tr-MUTE control O/I 5 5 5
75 RESET Reset input I 5 5 5
76 NC No Connection - - - -
77 NC No Connection - - - -
78 NC GND I 0 0 0
79 Vss GND I 0 0 0
80 X1 Crystal oscillator input I 2 2 2
81 X2 Crystal oscillator output O 2.5 2.5 2.5
82 Vdd Power supply I 5 5 5
83 P00 Pldaun port for writing I 0 0 0
84 P01 Pull-up port for writing I 5.1 5 5.1
85 OFFSET DET PWR-IC OFFSET
detection I 0 0 0
86 STBY PWR-IC STBY control
output O 5 5 5
87 AMP MUTE PWR-IC MUTE control
output O 0 0 0
88 ILL SENS External dimmer control
input I 5 5 5
89 SUBM CNT 3.3V control for SUB
microcomputer O 5 5 5
90 NC No Connection - - - -
91 NC No Connection - - - -
92 NC No Connection - - - -
93 SUB W U
REQ SUB.WAKE.UP.REQ O 4.9 5 4.9
94 DISPM CNT Power supply control
output of display 5V O/I 0 0 0
95 EJE ILL(NC) No Connection - - - -
96 NC No Connection - - - -
97 NC No Connection - - - -
10 TERMINALS DESCRIPTION
8
CQ-C7402W

Pin
No. Port Description (I/O) (V)
FM AM CD
98 S LED Security LED control
output O 0 0 5
99 PANEL IN PANEL detect I 5.2 5.2 5.2
100 EP CS(NC) No Connection - - - -
10.2. Display Block
IC900 C2CBJH000095
Pin
No. Port Part Name & Description I/O (V)
1 A18 FLASH A17 O 1.5
2 A19 FLASH A18 O 1.7
3 A20 FLASH A19 O 1.3
4 NC No Connection - -
5 NC No Connection - -
6 NC No Connection - -
7 A0 LCD driver data or command
distinction O 1.3
8 A1 FLASH A0 O 0.3
9 VSS Ground potential - 0
10 A2 FLASH A1 O 0.4
11 A3 FLASH A2 O 0.4
12 A4 FLASH A3 O 0.4
13 A5 FLASH A4 O 1.3
14 A6 FLASH A5 O 0.4
15 A7 FLASH A6 O 0
16 A8 FLASH A7 O 1.3
17 A9 FLASH A8 O 0
18 A10 FLASH A9 O 0
19 A11 FLASH A10 O 1.5
20 A12 FLASH A11 O 1.7
21 VCC Positive power supply
terminal - 3.5
22 A13 FLASH A12 O 1.4
23 A14 FLASH A13 O 1.6
24 A15 FLASH A14 O 1.7
25 SUB SI UP SO MAIN-u-com communication
data input and external flash
rewritting
- 0.5
26 SUB SO/UP SI MAIN-u-com communication
data output and external
flash rewritting
O 1.8
27 UP CLK External flash rewritting
switch I 3.5
28 NC No Connection - -
29 FLASH RESET FLASH reset control output O 3.5
30 KS1 Key scan signal 1 output I 0
31 NC No Connection - -
32 NC No Connection - -
33 AVCC Positive power supply for A/D
converter - 3.5
34 AVRH A/D converter standard
voltage input - 3.5
35 AVSS/AVRL A/D converter ground
potential - 0
36 TH DETECT Temperature detection input I 1.3
37 KS2 Key scan signal 2 output I 0
38 KS3 Key scan signal 3 output I 0
39 NC No Connection - -
40 VSS Ground potential - 0
41 KI5 Key return signal 5 input I 0
42 KI4 Key return signal 4 input I 0
43 KI3 Key return signal 3 input I 0
44 KI2 Key return signal 2 input I 0
45 NC FLASH writing program
starter I 0
46 NC FLASH writing program
starter I 3.5
47 MD0 Mode setting terminal I 3.5
48 MD1 Mode setting terminal I 3.5
49 MD2 Mode setting terminal I 0
50 S W U REQ SUB-u-com wake up request INT 3.0
51 ROTARY.1 Rotary encoder signal 1(VOL
UP) I 2.5
52 ROTARY.2 Rotary encoder signal 2 (VOL
DOWN) I 2.5
9
CQ-C7402W

Pin
No. Port Part Name & Description I/O (V)
53 KI1(SOURCE) Key return signal 1 INT/I 0
54 REMO INT Remote control signal
interference INT 3.7
55 NC/WP/ACC No Connection O 0
56 NC/A21 No Connection O 0
57 NC/A22 No Connection O 0
58 FLASH CE FLASH chip enable O 3.4
59 LCD CS LCD driver chip select O 3.4
60 NC No Connection - -
61 NC No Connection - -
62 REMO 1 Remote control signal I 3.7
63 NC No Connection - -
64 VLCD CONT VLCD 16V control O 3.4
65 M W U REQ MAIN-u-com wake up request O 0
66 LED ON P.LED control output O 3.4
67 NC No Connection - -
68 NC No Connection - -
69 FLASH OE/ LCD
RD FLASH output enable and LCD driver lead strobe O 3.4
70 LCD WR LCD driver light strobe signal O 3.4
71 FLASH WE FLASH light enable signal O 3.4
72 NC No Connection - -
73 LCD RESET LCD driver reset control O 3.4
74 FLASH RY/BY FLASH ready/busy input I 3.4
75 /RST System reset signal input I 3.5
76 NC No Connection - -
77 X1A No Connection - -
78 X0A Not used I 0
79 VSS Ground - 0
80 X0 MAIN system clock input
(12.5MHz) I 1.3
81 X1 MAIN system clock output
(12.5MHz) O 1.5
82 VCC Positive power supply - 3.5
83 D0 FLASH D0/LCD D0 I 0.9
84 D1 FLASH D1/LCD D1 I 0.9
85 D2 FLASH D2/LCD D2 I 1.1
86 D3 FLASH D3/LCD D3 I 0.9
87 D4 FLASH D4/LCD D4 I 1.0
88 D5 FLASH D5/LCD D5 I 1.1
89 D6 FLASH D6/LCD D6 I 1.1
90 D7 FLASH D7/LCD D7 I 0.8
91 D8 FLASH D8 I/O 0.9
92 D9 FLASH D9 I/O 0.9
93 D10 FLASH D10 I/O 0.9
94 D11 FLASH D11 I/O 0.8
95 D12 FLASH D12 I/O 0.8
96 D13 FLASH D13 I/O 0.7
97 D14 FLASH D14 I/O 0.7
98 D15 FLASH D15 I/O 0.7
99 A16 FLASH A15 O 3.0
100 A17 FLASH A16 O 1.7
10.3. CD Servo Block
IC401 : YESAM275
Pin
No. Port Descriptions I/O (V)
1 CVSS1 GND - 0
2 A22 TP407 - 0
3 CVSS2 GND - 0
4 DVDD1 I/O system (3.3V) power supply - 3.1
5 A10 Address bus of FLASH ROM O 3.1
6 - - - -
7 A11 Address bus of FLASH ROM O 0
8 A12 O 3.1
9 A13 O 3.1
10 A14 O 3.1
11 A15 O 0
12 /CVDD1 CORE CPU system (1.6V) power
supply - 1.6
13 - - - -
14 DVSS1 GND - 0
15 CVSS3 GND - 0
16 /CVDD2 I/O system (3.3V) power supply - 1.6
17 - - - -
18 - - - -
19 READY - - 3.1
20 /PS FLASH ROM selection signal O 3.1
21 - - - -
22 - - - -
23 R/W Lead/light signal to FLASH ROM O 3.1
24 /MSTRB Memory access signal O 3.1
25 - - - -
26 /MSC - - 3.1
27 MUTE Mute signal output (H:Mute on) O 0
28 - - - -
29 - - - -
30 /HOLD - - 3.1
31 BIO SUBO input I 0
32 MP/MC Operation mode setting (external pull-
up) I 3.1
33 DVDD2 I/O system (3.3V) power supply - 3.1
34 CVSS4 GND - 0
35 BD R1 GND I 0
36 - - - -
37 CVSS5 GND - 0
38 - - - -
39 - - - -
40 DVSS2 GND - 0
41 CLK C M AUDIO bit clock input I 1.6
42 SCK Clock input I 3.0
43 LRCK C
MAUDIO L/R identifying signal input I 1.6
44 CDFS Serial frame sink signal input I 2.4
45 DATA
CM AUDIO serial data input I 1.6
46 - - - -
47 SI Serial data input I 0
48 CLK M C AUDIO bit clock output O 1.6
49 SCK Clock input I 3.0
50 CVSS6 GND - 0
51 - - - -
52 CVDD3 CORE CPU system (1.6V) power
supply - 1.6
53 LRCK M
CAUDIO L/R identifying signal output O 1.5
54 CDFS Serial frame sink signal input I 2.4
55 - - - -
56 DVDD3 I/O system (3.3V) power supply - 3.1
57 DVSS3 GND - 0
58 REST
SW Mechanics deck REST SW input I 3.1
10
CQ-C7402W

Pin
No. Port Descriptions I/O (V)
59 DATA M
CAUDIO serial data output O 1.6
60 SO Serial data output O 1.1
61 - - - -
62 - - - -
63 /NMI - - 3.1
64 /INT0 - - 3.1
65 /INT1 - - 3.1
66 BLKCK Subcode block clock pulse input I 0
67 /INT3 - - 3.1
68 CV DD4 CORE CPU system (1.6V) power
supply - 1.6
69 SW1 Mechanics deck SW1 input I 0
70 CVSS7 GND - 0
71 MCLK Clock output (To Servo DSP) O 3.1
72 DVSS4 GND - 0
73 MLD Command load signal output (To
Servo DSP) I 3.1
74 MDATA Command data output (To Servo
DSP) O 3.1
75 DVDD4 I/O system (3.3V) power supply - 3.1
76 DVSS5 GND - 0
77 CLK MD1 Clock mode setting (L fixation) I 0
78 CLK MD2 Clock mode setting (H fixation) I 3.1
79 CLK MD3 Clock mode setting (L fixation) I 0
80 - - - -
81 SW2 Mechanics deck SW2 input I 0.2
82 - - - -
83 EMU0 - - 3.1
84 EMU/OF
F- - 3.1
85 TDO - - 0
86 TDI - - 3.1
87 /TRST - - 0
88 TCK - - 3.1
89 TMS - - 3.1
90 CVSS8 GND - 0
91 CVDD5 CORE CPU system (1.6V) power
supply - 1.6
92 HPIENA GND I 0
93 DVSS6 GND - 0
94 - - - -
95 CLKENA Oscillation output Cainabl signal O 0
96 X1 Crystal Connection O 0.7
97 X2/CLKIN Crystal Connection I 1.0
98 RS Reset signal input I 3.1
99 D0 Data base of FLASH ROM I/O 0
100 D1 I/O 0
101 D2 I/O 0
102 D3 I/O 0
103 D4 I/O 0
104 D5 I/O 0
105 A16 Address bus of FLASH ROM O 3.1
106 DVSS7 GND - 0
107 A17 Address bus of FLASH ROM O 3.1
108 A18 Address bus of FLASH ROM O 0
109 A19 TP419 O 0
110 A20 TP416 O 0
111 CVSS9 GND - 0
112 DVDD5 I/O system (3.3V) power supply - 3.1
113 D6 Data bus of FLASH ROM I/O 0
114 D7 I/O 0
115 D8 I/O 0
116 D9 I/O 0
117 D10 I/O 0
118 D11 Data bus of FLASH ROM I/O 0
119 D12 I/O 0
Pin
No. Port Descriptions I/O (V)
120 STAT Status signal input I 3.0
121 D13 Data path of FLASH ROM I/O 3.1
122 D14 I/O 0
123 D15 I/O 0
124 - - - -
125 CVDD6 CORE CPU system (1.6V) power
supply - 1.6
126 CVSS10 GND - 0
127 - - - -
128 DVSS8 I/O system (3.3V) power supply - 0
129 - - - -
130 DVDD6 I/O system (3.3V) power supply - 3.1
131 A0 Address bus of FLASH ROM O 3.1
132 A1 O 0
133 A2 O 0
134 A3 O 0
135 /RST Reset signal output(To Servo DSP) O 3.1
136 A4 Address bus of FLASH ROM O 0
137 A5 O 3.1
138 A6 O 3.1
139 A7 O 0
140 A8 O 3.1
141 A9 O 3.1
142 CVDD7 CORE CPU system (1.6V) power
supply - 1.6
143 A12 TP406 - 0
144 DVSS9 GND - 0
11
CQ-C7402W

11.1. Main Block
IC201 : C1BB00000796
IC241 : C1BB00001047
IC251 : C1BB00001046
11 IC BLOCK DIAGRAM
12
CQ-C7402W

IC670 : YEAMC14584BE
IC271 : C1EA00000043
IC730 : C0DAEKG00002
IC701 : C0DAZHF00004
IC401 : C1BB00001045
13
CQ-C7402W

IC702 : AN8065S-E1V
IC752 : C0CAABG00012
IC755 : C0DBZGD00040
IC760 : C0GBG0000032
11.2. Display Block
IC901 : C3FBMD000209
IC902 : C0EBF0000374
IC903 : B3MBZ0000006
14
CQ-C7402W

IC403 : YESAM171
IC405 : YESAM270
IC404 : YESAM178
11.3. CD Servo Block
IC402 : YESAM280
15
CQ-C7402W

12 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by ;
mark have special characteristics important for safety.
When replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
• • •
• Order intake period is basically six months after the first
shipment.
Ref. No. Part No. Part Name & Description Remarks
[E3042] Main/Connector Block
IC´s AND TRANSISTORs
IC201 C1BB00000796 IC
IC241 C1BB00001047 IC
IC251 C1BB00001046 IC
IC271 C1EA00000043 IC
IC401 C1BB00001045 IC
IC601 C2CBJG000589 IC
IC630 C0JBAA000372 IC
IC650 C0JBAA000372 IC
IC670 YEAMC14584BE IC
IC701 C0DAZHF00004 IC
IC702 AN8065S-E1V IC
IC730 C0DAEKG00002 IC
IC752 C0CAABG00012 IC
IC755 C0DBZGD00040 IC
IC760 C0GBG0000032 IC
PA51 C5BA00000123 Electronic Tuner
Q55 B1GDGFEH0001 Transistor
Q56 B1AAEC000002 Transistor
Q220 B1GBCFNN0004 Transistor
Q262 B1GBHBEA0004 Transistor
Q266 B1GBHBEA0004 Transistor
Q320 B1GBCFNN0004 Transistor
Q346 B1GBHBEA0004 Transistor
Q362 B1GBHBEA0004 Transistor
Q366 B1GBHBEA0004 Transistor
Q372 YEANC114YKX Transistor
Q376 B1GBCFNN0004 Transistor
Q411 B1CBGF000005 Transistor
Q630 B1GBCFNN0004 Transistor
Q633 B1GDCFJJ0002 Transistor
Q650 YEANC114YKX Transistor
Q651 B1GBCFNN0004 Transistor
Q652 B1GBCFNN0004 Transistor
Q667 B1GBCFNL0001 Transistor
Q680 B1GDGFEH0001 Transistor
Q681 B1GDCFJJ0002 Transistor
Q701 2SD2139TA Transistor
Q730 B1GBCFNN0004 Transistor
Q731 B1GBCFNN0004 Transistor
Q760 B1GBCFNN0004 Transistor
Q790 B1GBNCEJ0003 Transistor
Q791 B1GBNCEJ0003 Transistor
Q792 YEANC114YKX Transistor
Ref. No. Part No. Part Name & Description Remarks
Q793 YEANC114YKX Transistor
DIODEs
D201 B0JCME000012 Diode
D202 B0JCME000012 Diode
D203 B0JCME000012 Diode
D204 B0JCME000012 Diode
D301 B0JCME000012 Diode
D302 B0JCME000012 Diode
D303 B0JCME000012 Diode
D304 B0JCME000012 Diode
D346 B0JCMC000004 Diode
D601 B0JCMC000004 Diode
D630 B3AAB0000143 Diode
D631 B0BC5R600003 Diode
D635 B0BC5R600003 Diode
D636 B0BC5R600003 Diode
D637 B0BC5R600003 Diode
D638 B0BC5R600003 Diode
D639 B0BC5R600003 Diode
D670 B0JCMC000004 Diode
D671 MA3X152A0L Diode
D701 YEADDAM3MA47 Diode
D702 MA736TX Diode
D703 B0BC5R7A0062 Diode
D704 B0JCMC000004 Diode
D705 B0JCME000012 Diode
D706 B0JCME000012 Diode
D707 YEADRB051L40 Diode
D708 MA736TX Diode
D710 B0JCMC000004 Diode
D715 MA3X152A0L Diode
D716 MA721TX Diode
D760 B0BC5R000020 Diode
D761 B0BC3R0A0058 Diode
D770 B0JCMC000004 Diode
D771 B0JCMC000004 Diode
CAPACITORs
C52 YECUS1H470JC Ceramic, 47PF 50WV
C53 F1J1H103A513 Ceramic, 0.01µF 50WV
C54 F2A1A221A449 Electrolytic, 220µF 10WV
C55 F1J1H103A513 Ceramic, 0.01µF 50WV
C56 F3F1E105A001 Tantalum, 1µF 25WV
C57 F2A1A101A450 Electrolytic, 100µF 10WV
C61 YECUS1H183KX Ceramic, 0.018µF 50WV
C62 YECUS1H183KX Ceramic, 0.018µF 50WV
C65 F1J1H1020024 Ceramic, 1000PF 50WV
C206 F2A1C100A502 Electrolytic, 10µF 16WV
C213 F1J1A2250004 Ceramic, 2.2µF 10WV
C215 F1J1A2250004 Ceramic, 2.2µF 10WV
C217 YECUS1C334KX Ceramic, 0.33µF 16WV
C220 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C244 YECUV2A152KX Ceramic, 1500PF 100WV
C245 F2A1C1010089 Electrolytic, 100µF 16WV
C246 YECUS1C104KX Ceramic, 0.1µF 16WV
C247 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C248 F2A0J470A558 Electrolytic, 47µF 6.3WV
C249 YECUS1C104KX Ceramic, 0.1µF 16WV
C251 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C254 F1J1H152A675 Ceramic, 1500PF 50WV
C255 F2A1C1010089 Electrolytic, 100µF 16WV
C257 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C259 YECUS1C104KX Ceramic, 0.1µF 16WV
C261 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C263 ECQV1H474JL2 Plastic Film, 0.47µF 50WV
C265 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C267 ECQV1H474JL2 Plastic Film, 0.47µF 50WV
C271 F1J1H472A675 Ceramic, 4700PF 50WV
C272 F1J1H472A675 Ceramic, 4700PF 50WV
C274 F2A1C4700073 Electrolytic, 47µF 16WV
C275 F1J1C1050013 Ceramic, 1µF 16WV
16
CQ-C7402W

Ref. No. Part No. Part Name & Description Remarks
C278 YECUS1E104ZF Ceramic, 0.1µF 25WV
C279 F2A1C4720027 Electrolytic, 4700µF 16WV
C306 F2A1C100A502 Electrolytic, 10µF 16WV
C313 F1J1A2250004 Ceramic, 2.2µF 10WV
C315 F1J1A2250004 Ceramic, 2.2µF 10WV
C317 YECUS1C334KX Ceramic, 0.33µF 16WV
C320 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C323 F2A1C100A502 Electrolytic, 10µF 16WV
C324 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C325 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C326 F1J1A2250004 Ceramic, 2.2µF 10WV
C327 F2A1A221A449 Electrolytic, 220µF 10WV
C328 F1J1H103A513 Ceramic, 0.01µF 50WV
C331 F1J1A2250004 Ceramic, 2.2µF 10WV
C345 F2A1C100A502 Electrolytic, 10µF 16WV
C349 F2A1A221A449 Electrolytic, 220µF 10WV
C351 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C354 F1J1H152A675 Ceramic, 1500PF 50WV
C355 F2A1C1010089 Electrolytic, 100µF 16WV
C357 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C358 ECEA0JKA221I Electrolytic, 220µF 6.3WV
C359 F2A1A221A449 Electrolytic, 220µF 10WV
C361 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C363 ECQV1H474JL2 Plastic Film, 0.47µF 50WV
C365 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C367 ECQV1H474JL2 Plastic Film, 0.47µF 50WV
C371 F1J1H472A675 Ceramic, 4700PF 50WV
C372 F1J1H472A675 Ceramic, 4700PF 50WV
C374 F2A1H2R20044 Electrolytic, 2.2µF 50WV
C375 F2A1C100A502 Electrolytic, 10µF 16WV
C378 YECUS1E104ZF Ceramic, 0.1µF 25WV
C401 F1J1H120A034 Ceramic, 12PF 50WV
C402 F1J1H120A034 Ceramic, 12PF 50WV
C403 F2A0J101A500 Electrolytic, 100µF 6.3WV
C404 F1J1H103A513 Ceramic, 0.01µF 50WV
C405 F1H1H101A231 Ceramic, 100PF 50WV
C411 F1J1H103A513 Ceramic, 0.01µF 50WV
C412 YECUS1E223KX Ceramic, 0.022µF 25WV
C413 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C414 F2A1A221A449 Electrolytic, 220µF 10WV
C601 YECUZ1C104KX Ceramic, 0.1µF 16WV
C602 YECUZ1H103KX Ceramic, 0.01µF 50WV
C603 F2A0J3310051 Electrolytic, 330µF 6.3WV
C604 EECS0HD104H Electrolytic, 0.1µF 5.5WV
C605 YECUZ1C104KX Ceramic, 0.1µF 16WV
C606 F1H1H180A231 Ceramic, 18PF 50WV
C607 F1J1H180A034 Ceramic, 18PF 50WV
C608 YECUS1C104KX Ceramic, 0.1µF 16WV
C609 F1J1A106A023 Ceramic, 10µF 10WV
C610 YECUS1C104KX Ceramic, 0.1µF 16WV
C631 F2A1H4R7A632 Electrolytic, 4.7µF 50WV
C632 YECUS1E104ZF Ceramic, 0.1µF 25WV
C633 F2A1C470A630 Electrolytic, 47µF 16WV
C634 YECUZ1H103KX Ceramic, 0.01µF 50WV
C635 F1J1H103A513 Ceramic, 0.01µF 50WV
C650 F1J1H103A513 Ceramic, 0.01µF 50WV
C670 F2A1C100A502 Electrolytic, 10µF 16WV
C671 YECUZ1H103KX Ceramic, 0.01µF 50WV
C680 F2A1H2R2A634 Electrolytic, 2.2µF 50WV
C701 F1H1A154A007 Ceramic, 0.15µF 10WV
C702 F2A1C1020069 Electrolytic, 1000µF 16WV
C704 F2A0J470A558 Electrolytic, 47µF 6.3WV
C705 YECUZ1H103KX Ceramic, 0.01µF 50WV
C706 YECUZ1C104KX Ceramic, 0.1µF 16WV
C707 F2A1C1020069 Electrolytic, 1000µF 16WV
C708 ECEA1HKS010I Electrolytic, 1µF 50WV
C713 YECUS1C474KX Ceramic, 0.47µF 16WV
C715 YECUS1E104ZF Ceramic, 0.1µF 25WV
C716 YECUS1C104KX Ceramic, 0.1µF 16WV
C717 YECUS1C104KX Ceramic, 0.1µF 16WV
C718 YECUS1E104ZF Ceramic, 0.1µF 25WV
C719 EEAFC1A820H Electrolytic, 82µF 10WV
C720 YECUS1C104KX Ceramic, 0.1µF 16WV
C721 YECUS1C104KX Ceramic, 0.1µF 16WV
Ref. No. Part No. Part Name & Description Remarks
C730 F1K1E334A022 Ceramic, 0.33µF 25WV
C731 YECUX1C334KX Ceramic, 0.33µF 16WV
C732 EEAFC1C560H Electrolytic, 56µF 16WV
C752 YECUS1C104KX Ceramic, 0.1µF 16WV
C753 YECUS1C104KX Ceramic, 0.1µF 16WV
C754 EEAFC0J560H Electrolytic, 56µF 6.3WV
C755 YECUZ1C104KX Ceramic, 0.1µF 16WV
C756 F1J1C1050013 Ceramic, 1µF 16WV
C757 YECUZ1H103KX Ceramic, 0.01µF 50WV
C758 F2A0J470A558 Electrolytic, 47µF 6.3WV
C760 YECUZ1H103KX Ceramic, 0.01µF 50WV
C761 YECUS1E104ZF Ceramic, 0.1µF 25WV
C762 F2A1C470A630 Electrolytic, 47µF 16WV
C763 YECUS1E104ZF Ceramic, 0.1µF 25WV
C795 YECUS1E104ZF Ceramic, 0.1µF 25WV
C797 YECUS1E104ZF Ceramic, 0.1µF 25WV
RESISTORs
J401 ERJ6GEY0R00V Chip, 0Ω1/10W
J403 ERJ6GEY0R00V Chip, 0Ω1/10W
J404 ERJ6GEY0R00V Chip, 0Ω1/10W
J409 ERJ6GEY0R00V Chip, 0Ω1/10W
J411 ERJ6GEY0R00V Chip, 0Ω1/10W
J501 ERJ8GEY0R00V Chip, 0Ω1/8W
J502 ERJ8GEY0R00V Chip, 0Ω1/8W
J503 ERJ8GEY0R00V Chip, 0Ω1/8W
J504 ERJ8GEY0R00V Chip, 0Ω1/8W
J506 ERJ8GEY0R00V Chip, 0Ω1/8W
J509 ERJ8GEY0R00V Chip, 0Ω1/8W
J510 ERJ8GEY0R00V Chip, 0Ω1/8W
J513 ERJ8GEY0R00V Chip, 0Ω1/8W
J514 ERJ8GEY0R00V Chip, 0Ω1/8W
J515 ERJ8GEY0R00V Chip, 0Ω1/8W
J517 ERJ8GEY0R00V Chip, 0Ω1/8W
J518 ERJ8GEY0R00V Chip, 0Ω1/8W
J520 ERJ8GX0R00V Chip, 0Ω1/8W
J521 ERJ8GX0R00V Chip, 0Ω1/8W
J522 ERJ8GX0R00V Chip, 0Ω1/8W
J523 ERJ8GX0R00V Chip, 0Ω1/8W
J524 ERJ8GX0R00V Chip, 0Ω1/8W
J525 ERJ8GX0R00V Chip, 0Ω1/8W
J526 ERJ8GX0R00V Chip, 0Ω1/8W
J527 ERJ8GX0R00V Chip, 0Ω1/8W
J528 ERJ8GX0R00V Chip, 0Ω1/8W
J529 ERJ8GX0R00V Chip, 0Ω1/8W
J531 ERJ8GX0R00V Chip, 0Ω1/8W
J534 ERJ8GX0R00V Chip, 0Ω1/8W
J536 ERJ8GX0R00V Chip, 0Ω1/8W
J537 ERJ8GX0R00V Chip, 0Ω1/8W
J538 ERJ8GX0R00V Chip, 0Ω1/8W
J539 ERJ8GX0R00V Chip, 0Ω1/8W
J540 ERJ8GX0R00V Chip, 0Ω1/8W
J541 ERJ8GX0R00V Chip, 0Ω1/8W
J542 ERJ8GX0R00V Chip, 0Ω1/8W
J544 ERJ8GX0R00V Chip, 0Ω1/8W
J545 ERJ8GX0R00V Chip, 0Ω1/8W
J546 ERJ8GX0R00V Chip, 0Ω1/8W
J547 ERJ8GX0R00V Chip, 0Ω1/8W
J550 ERJ8GX0R00V Chip, 0Ω1/8W
J551 ERJ8GX0R00V Chip, 0Ω1/8W
J552 ERJ8GX0R00V Chip, 0Ω1/8W
J553 ERJ8GX0R00V Chip, 0Ω1/8W
J554 ERJ6GEY0R00V Chip, 0Ω1/10W
J555 ERJ6GEY0R00V Chip, 0Ω1/10W
J558 ERJ8GX0R00V Chip, 0Ω1/8W
J559 ERJ8GX0R00V Chip, 0Ω1/8W
J560 ERJ8GEY0R00V Chip, 0Ω1/8W
J561 ERJ8GEY0R00V Chip, 0Ω1/8W
J562 ERJ6GEY0R00V Chip, 0Ω1/10W
J563 ERJ8GX0R00V Chip, 0Ω1/8W
J564 ERJ8GEY0R00V Chip, 0Ω1/8W
J565 ERJ8GX0R00V Chip, 0Ω1/8W
J566 ERJ8GEY0R00V Chip, 0Ω1/8W
17
CQ-C7402W

Ref. No. Part No. Part Name & Description Remarks
J567 ERJ8GEY0R00V Chip, 0Ω1/8W
J568 ERJ8GEY0R00V Chip, 0Ω1/8W
J570 ERJ8GEY0R00V Chip, 0Ω1/8W
J571 ERJ8GEY0R00V Chip, 0Ω1/8W
J572 ERJ8GEY0R00V Chip, 0Ω1/8W
J573 ERJ8GEY0R00V Chip, 0Ω1/8W
J575 ERJ8GEY0R00V Chip, 0Ω1/8W
J576 ERJ8GEY0R00V Chip, 0Ω1/8W
J578 ERJ6GEY0R00V Chip, 0Ω1/10W
J579 ERJ8GEY0R00V Chip, 0Ω1/8W
J580 ERJ8GX0R00V Chip, 0Ω1/8W
J582 ERJ8GEY0R00V Chip, 0Ω1/8W
J583 ERJ8GEY0R00V Chip, 0Ω1/8W
L295 ERJ6GEYJ4R7 Chip, 4.7Ω1/10W
L296 ERJ6GEYJ4R7 Chip, 4.7Ω1/10W
L395 ERJ6GEYJ4R7 Chip, 4.7Ω1/10W
L396 ERJ6GEYJ4R7 Chip, 4.7Ω1/10W
R50 ERJ6GEYJ5R6V Chip, 5.6Ω1/10W
R51 ERJ6GEY0R00V Chip, 0Ω1/10W
R54 ERJ6GEYJ101 Chip, 100Ω1/10W
R55 ERJ6GEYJ331 Chip, 330Ω1/10W
R56 ERJ6GEYJ102 Chip, 1kΩ1/10W
R59 ERJ3GEYJ104V Chip, 100kΩ1/16W
R65 ERJ6GEYJ393 Chip, 39kΩ1/10W
R202 ERJ6GEYJ152 Chip, 1.5kΩ1/10W
R203 ERJ6GEYJ103 Chip, 10kΩ1/10W
R213 ERJ3GEYJ562V Chip, 5.6kΩ1/16W
R214 ERJ3GEYJ103V Chip, 10kΩ1/16W
R215 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R216 ERJ3GEYJ123V Chip, 12kΩ1/16W
R217 ERJ3GEYJ183V Chip, 18kΩ1/16W
R220 ERJ3GEYJ750V Chip, 75Ω1/16W
R221 ERJ3GEYJ393V Chip, 39kΩ1/16W
R244 ERJ6GEYJ393 Chip, 39kΩ1/10W
R245 ERJ6GEYJ273 Chip, 27kΩ1/10W
R248 ERJ6GEYJ4R7 Chip, 4.7Ω1/10W
R252 ERJ3GEYJ393V Chip, 39kΩ1/16W
R253 ERJ6GEYJ273 Chip, 27kΩ1/10W
R254 ERJ8GEYJ393V Chip, 39kΩ1/8W
R255 ERJ3GEYJ273V Chip, 27kΩ1/16W
R261 ERJ6GEYJ560 Chip, 56Ω1/10W
R262 ERJ3GEYJ103V Chip, 10kΩ1/16W
R263 ERJ6GEYJ561 Chip, 560Ω1/10W
R265 ERJ6GEYJ560 Chip, 56Ω1/10W
R266 ERJ3GEYJ103V Chip, 10kΩ1/16W
R267 ERJ8GEYJ561V Chip, 560Ω1/8W
R275 ERJ8GEYJ223V Chip, 22kΩ1/8W
R302 ERJ6GEYJ152 Chip, 1.5kΩ1/10W
R303 ERJ6GEYJ103 Chip, 10kΩ1/10W
R313 ERJ3GEYJ562V Chip, 5.6kΩ1/16W
R314 ERJ3GEYJ103V Chip, 10kΩ1/16W
R315 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R316 ERJ3GEYJ123V Chip, 12kΩ1/16W
R317 ERJ3GEYJ183V Chip, 18kΩ1/16W
R320 ERJ3GEYJ750V Chip, 75Ω1/16W
R321 ERJ6GEYJ393 Chip, 39kΩ1/10W
R323 ERJ3GEYJ102V Chip, 1kΩ1/16W
R324 ERJ3GEYJ103V Chip, 10kΩ1/16W
R325 ERJ6GEYJ102 Chip, 1kΩ1/10W
R326 ERJ6GEYJ101 Chip, 100Ω1/10W
R327 ERJ6GEYJ823 Chip, 82kΩ1/10W
R330 ERJ6GEYJ221V Chip, 220Ω1/10W
R345 ERJ6GEYJ560 Chip, 56Ω1/10W
R346 ERJ3GEYJ103V Chip, 10kΩ1/16W
R348 ERJ3GEYJ4R7V Chip, 4.7Ω1/16W
R352 ERJ8GEYJ393V Chip, 39kΩ1/8W
R353 ERJ3GEYJ273V Chip, 27kΩ1/16W
R354 ERJ6GEYJ393 Chip, 39kΩ1/10W
R355 ERJ3GEYJ273V Chip, 27kΩ1/16W
R361 ERJ6GEYJ560 Chip, 56Ω1/10W
R362 ERJ3GEYJ103V Chip, 10kΩ1/16W
R363 ERJ6GEYJ561 Chip, 560Ω1/10W
R365 ERJ6GEYJ560 Chip, 56Ω1/10W
R366 ERJ3GEYJ103V Chip, 10kΩ1/16W
Ref. No. Part No. Part Name & Description Remarks
R367 ERJ6GEYJ561 Chip, 560Ω1/10W
R373 ERJ3GEYJ183V Chip, 18kΩ1/16W
R375 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
R376 ERJ3GEYJ103V Chip, 10kΩ1/16W
R401 ERJ3GEYJ152V Chip, 1.5kΩ1/16W
R402 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R403 ERJ3GEYJ473V Chip, 47kΩ1/16W
R404 ERJ3GEYJ102V Chip, 1kΩ1/16W
R405 ERJ3GEYJ102V Chip, 1kΩ1/16W
R406 ERJ3GEYJ102V Chip, 1kΩ1/16W
R407 ERJ3GEYJ102V Chip, 1kΩ1/16W
R408 ERJ3GEYJ473V Chip, 47kΩ1/16W
R409 ERJ3GEYJ102V Chip, 1kΩ1/16W
R410 ERJ3GEY0R00V Chip, 0Ω1/16W
R411 ERJ3GEY0R00V Chip, 0Ω1/16W
R413 ERJ6GEYJ182 Chip, 1.8kΩ1/10W
R414 ERJ8GEYJ561V Chip, 560Ω1/8W
R417 ERJ3GEYJ100V Chip, 10Ω1/16W
R601 ERJ3GEYJ432V Chip, 4.3kΩ1/16W
R602 ERJ3GEYJ432V Chip, 4.3kΩ1/16W
R605 ERJ3GEYJ102V Chip, 1kΩ1/16W
R607 ERJ3GEYJ333V Chip, 33kΩ1/16W
R608 ERJ3GEYJ822V Chip, 8.2kΩ1/16W
R609 ERJ3GEYJ223V Chip, 22kΩ1/16W
R610 ERJ3GEYJ473V Chip, 47kΩ1/16W
R611 ERJ3GEYJ473V Chip, 47kΩ1/16W
R613 ERJ3GEYJ103V Chip, 10kΩ1/16W
R614 ERJ3GEYJ103V Chip, 10kΩ1/16W
R615 ERJ6GEYJ103 Chip, 10kΩ1/10W
R617 ERJ3GEYJ103V Chip, 10kΩ1/16W
R618 ERJ3GEYJ223V Chip, 22kΩ1/16W
R619 ERJ3GEYJ184V Chip, 180kΩ1/16W
R620 ERJ3GEYJ103V Chip, 10kΩ1/16W
R621 ERJ3GEY0R00V Chip, 0Ω1/16W
R622 ERJ6GEYJ473 Chip, 47kΩ1/10W
R625 ERJ3GEYJ473V Chip, 47kΩ1/16W
R626 ERJ6GEYJ102 Chip, 1kΩ1/10W
R627 ERJ3GEYJ103V Chip, 10kΩ1/16W
R628 ERJ3GEYJ103V Chip, 10kΩ1/16W
R631 ERJ6GEYJ821 Chip, 820Ω1/10W
R632 ERJ6GEY0R00V Chip, 0Ω1/10W
R634 ERJ6GEYJ561 Chip, 560Ω1/10W
R638 ERJ3GEYJ102V Chip, 1kΩ1/16W
R639 ERJ3GEYJ102V Chip, 1kΩ1/16W
R640 ERJ6GEYJ561 Chip, 560Ω1/10W
R643 ERJ3GEYJ184V Chip, 180kΩ1/16W
R646 ERJ3GEYJ104V Chip, 100kΩ1/16W
R653 ERJ3GEYJ512V Chip, 5.1kΩ1/16W
R654 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R655 ERJ6GEYJ103 Chip, 10kΩ1/10W
R656 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R657 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
R658 ERJ6GEYJ473 Chip, 47kΩ1/10W
R659 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R660 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R661 ERJ3GEYJ473V Chip, 47kΩ1/16W
R662 ERJ8GEYJ472V Chip, 4.7kΩ1/8W
R663 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R664 ERJ6GEYJ512V Chip, 5.1kΩ1/10W
R667 ERJ6GEYJ103 Chip, 10kΩ1/10W
R670 ERJ3GEYJ104V Chip, 100kΩ1/16W
R671 ERJ3GEYJ104V Chip, 100kΩ1/16W
R672 ERJ3GEYJ104V Chip, 100kΩ1/16W
R673 ERJ3GEYJ104V Chip, 100kΩ1/16W
R674 ERJ3GEYJ272V Chip, 2.7kΩ1/16W
R675 ERJ6GEYJ272 Chip, 2.7kΩ1/10W
R676 ERJ6GEYJ472 Chip, 4.7kΩ1/10W
R677 ERJ6GEYJ561 Chip, 560Ω1/10W
R680 ERJ6GEYJ561 Chip, 560Ω1/10W
R681 ERJ6GEYJ562 Chip, 5.6kΩ1/10W
R682 ERJ3GEYJ473V Chip, 47kΩ1/16W
R684 ERJ6GEYJ561 Chip, 560Ω1/10W
R685 ERJ3GEYJ561V Chip, 560Ω1/16W
R686 ERJ3GEYJ561V Chip, 560Ω1/16W
18
CQ-C7402W

Ref. No. Part No. Part Name & Description Remarks
R701 ERJ3GEYJ103V Chip, 10kΩ1/16W
R702 ERJ3GEYJ274V Chip, 270kΩ1/16W
R703 ERJ3GEYJ433V Chip, 43kΩ1/16W
R704 ERJ8GEYJ4R7V Chip, 4.7Ω1/8W
R705 ERJ8GEYJ682V Chip, 6.8kΩ1/8W
R715 ERJ3GEYJ472V Chip, 4.7kΩ1/16W
R716 ERJ6GEYJ473 Chip, 47kΩ1/10W
R717 ERJ3GEYJ433V Chip, 43kΩ1/16W
R730 ERJ6ENF6802V Chip, 68kΩ1/10W
R731 ERJ6ENF2203V Chip, 220kΩ1/10W
R732 ERJ6ENF1802V Chip, 18kΩ1/10W
R733 ERJ6ENF1303V Chip, 130kΩ1/10W
R734 ERJ6ENF2201V Chip, 2.2kΩ1/10W
R755 ERJ6GEYJ102 Chip, 1kΩ1/10W
R760 ERJ6GEYJ152 Chip, 1.5kΩ1/10W
R761 ERDS1FJ3R9 Carbon, 3.9Ω1/2W
R780 ERJ8GX0R00V Chip, 0Ω1/8W
R781 ERJ8GX0R00V Chip, 0Ω1/8W
R782 ERJ8GX0R00V Chip, 0Ω1/8W
R790 ERJ3GEYJ223V Chip, 22kΩ1/16W
R791 ERJ6GEYJ223 Chip, 22kΩ1/10W
R795 ERJ3GEYJ102V Chip, 1kΩ1/16W
CONNECTORs
CN251 K2KF29Z00027 Plug, 4P
CN253 K2KF29Z00031 Plug, 4P
CN302 K2HA104B0010 Jack
CN351 K2KF29Z00026 Plug, 4P
CN601 K1MN16BA0111 Connector, 16P
CN651 K1KA18A00074 Connector, 18P
CN670 K1PQ07A00004 Connector, 7P
CN680 YEAE012307 Connector, 8P
CN701 K1FA116B0028 Connector, 16P
CN760 YEAE5339802 Connector, 2P
COILs
L50 G1C150K00011 Coil
L52 G1CR56JA0036 Coil
L53 G1C101JA0036 Coil
L401 G1C101JA0036 Coil
L601 G1C330JA0036 Coil
L602 G1C101JA0036 Coil
L603 G1C330JA0036 Coil
L630 ELEAR330KA Choke Coil
L701 YELTBL01R1AT Coil
L702 G0A151J00006 Coil
SWITCHes
SW601 K0L1BA000099 Switch
SW602 K0L1BA000104 Switch
CRYSTALs
XL401 H0D720400006 Crystal Oscillator
XL601 H0J419400009 Crystal Oscillator
NETWORK RESISTOR
R606 EXBV8V102JV Network Resistor
FILTER
Z50 J0LM00000001 Noise Filter
THERMISTOR
PT701 YERT7AR4R7MT Thermistor
Ref. No. Part No. Part Name & Description Remarks
[E9571] Display Block
IC´s AND TRANSISTORs
IC900 C2CBJH000095 IC
IC901 C3FBMD000209 IC
IC902 C0EBF0000374 IC
IC903 B3MBZ0000006 IC
Q901 B1GBCFNN0009 Transistor
Q902 DTA144EKAT46 Transistor
Q903 B1GBCFNN0004 Transistor
Q904 B1GBCFNN0004 Transistor
Q913 YEANSSTA06T Transistor
Q914 YEANSSTA06T Transistor
DIODEs
D901 B0BC5R600003 Diode
D903 B0BC4R000006 Diode
D904 B0BC5R600003 Diode
D905 B0BC5R600003 Diode
D906 B0BC01100039 Diode
D907 B3AEB0000051 Diode
D909 MA152WKTX Diode
D910 B0BC4R000006 Diode
D911 B0BC4R000006 Diode
D912 B0BC4R000006 Diode
D913 B0BC4R000006 Diode
D914 B0BC4R000006 Diode
D916 B0JCMC000004 Diode
D917 B0BC4R000006 Diode
D918 B0BC4R000006 Diode
D919 B0BC4R000006 Diode
D920 B0BC4R000006 Diode
D923 B0BC4R000006 Diode
CAPACITORs
C902 YECUZ1C104KX Ceramic, 0.1µF 16WV
C903 YECUZ1C104KX Ceramic, 0.1µF 16WV
C904 ECST1CX106R Tantalum, 10µF 16WV
C905 F1H1H100A226 Ceramic, 10PF 50WV
C906 F1H1H100A226 Ceramic, 10PF 50WV
C907 YECUZ1C104KX Ceramic, 0.1µF 16WV
C908 YECUZ1C104KX Ceramic, 0.1µF 16WV
C911 YECUZ1C104KX Ceramic, 0.1µF 16WV
C912 ECST1CX106R Tantalum, 10µF 16WV
C913 YECUZ1C104KX Ceramic, 0.1µF 16WV
C914 YECUS1C105ZF Ceramic, 1µF 16WV
C915 YECUS1C105ZF Ceramic, 1µF 16WV
C916 F1J1H102A672 Ceramic, 1000PF 50WV
C919 YECUZ1H103KX Ceramic, 0.01µF 50WV
C925 F2H1C220A016 Ceramic, 22PF 16WV
C926 F1J1H562A675 Ceramic, 5600PF 50WV
C927 YECUS1E104ZF Ceramic, 0.1µF 25WV
C928 F0F2A223A005 Plastic Film, 0.022µF 100WV
C929 F1L3F1200001 Ceramic, 12PF 3.16kWV
C931 YECUV1C225KX Ceramic, 2.2µF 16WV
C932 YECUV1C225KX Ceramic, 2.2µF 16WV
C933 YECUV1C225KX Ceramic, 2.2µF 16WV
C934 YECUV1C225KX Ceramic, 2.2µF 16WV
C935 YECUV1C225KX Ceramic, 2.2µF 16WV
C936 YECUV1C225KX Ceramic, 2.2µF 16WV
C937 YECUV1C225KX Ceramic, 2.2µF 16WV
C938 YECUZ1C104KX Ceramic, 0.1µF 16WV
C939 YECUV1C225KX Ceramic, 2.2µF 16WV
C940 YECUV1C225KX Ceramic, 2.2µF 16WV
C941 YECUV1C225KX Ceramic, 2.2µF 16WV
C942 YECUV1C225KX Ceramic, 2.2µF 16WV
C973 YECUZ1H103KX Ceramic, 0.01µF 50WV
C974 YECUZ1H103KX Ceramic, 0.01µF 50WV
R921 YECUZ1C104KX Ceramic, 0.1µF 16WV
RESISTORs
FB901 ERJ6GEY0R00V Chip, 0Ω1/10W
19
CQ-C7402W

Ref. No. Part No. Part Name & Description Remarks
FB902 ERJ6GEY0R00V Chip, 0Ω1/10W
FB903 ERJ6GEY0R00V Chip, 0Ω1/10W
R901 ERJ3GEYJ221V Chip, 220Ω1/16W
R902 ERJ3GEYJ103V Chip, 10kΩ1/16W
R903 ERJ3GEYJ103V Chip, 10kΩ1/16W
R904 ERJ3GEYJ103V Chip, 10kΩ1/16W
R905 ERJ3GEYJ103V Chip, 10kΩ1/16W
R906 ERJ3GEYJ221V Chip, 220Ω1/16W
R907 ERJ3GEYJ221V Chip, 220Ω1/16W
R908 ERJ3GEYJ102V Chip, 1kΩ1/16W
R909 ERJ3GEYJ221V Chip, 220Ω1/16W
R910 ERJ3GEYJ103V Chip, 10kΩ1/16W
R911 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R912 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R913 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R914 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R916 ERJ3GEYJ184V Chip, 180kΩ1/16W
R917 ERJ3GEYJ184V Chip, 180kΩ1/16W
R918 ERJ3GEYJ184V Chip, 180kΩ1/16W
R919 ERJ3GEYJ473V Chip, 47kΩ1/16W
R923 ERJ3GEYJ473V Chip, 47kΩ1/16W
R924 ERJ3GEYJ104V Chip, 100kΩ1/16W
R925 ERJ3GEYJ302V Chip, 3kΩ1/16W
R926 ERJ3GEYJ302V Chip, 3kΩ1/16W
R927 ERJ3GEYJ122V Chip, 1.2kΩ1/16W
R928 ERJ3GEYJ222V Chip, 2.2kΩ1/16W
R929 ERJ3GEYJ122V Chip, 1.2kΩ1/16W
R931 ERJ3GEYJ473V Chip, 47kΩ1/16W
R932 ERJ3GEYJ101V Chip, 100Ω1/16W
R933 ERJ3GEYJ821V Chip, 820Ω1/16W
R934 ERJ3GEYJ103V Chip, 10kΩ1/16W
R935 ERJ3GEYJ103V Chip, 10kΩ1/16W
R936 ERJ3GEYJ103V Chip, 10kΩ1/16W
R937 ERJ3GEYJ103V Chip, 10kΩ1/16W
R938 ERJ3GEYJ124V Chip, 120kΩ1/16W
R939 ERJ3GEYJ221V Chip, 220Ω1/16W
R950 ERJ3GEYJ103V Chip, 10kΩ1/16W
R951 ERJ3GEYJ153V Chip, 15kΩ1/16W
R961 ERJ6GEYJ681 Chip, 680Ω1/10W
R962 ERJ6GEYJ472 Chip, 4.7kΩ1/10W
R963 ERJ6GEYJ472 Chip, 4.7kΩ1/10W
R969 ERJ3GEYJ473V Chip, 47kΩ1/16W
R970 ERJ3GEYJ103V Chip, 10kΩ1/16W
R971 ERJ3GEYJ103V Chip, 10kΩ1/16W
CONNECTORs
CN901 K1NZ16D00001 Connector, 16P
CN902 K1MN30BA0242 Connector, 30P
COIL
L907 G1C101M00014 Coil
SWITCHes
SW901 K9AA024A0013 Switch
SW902 K0H1BA000445 Switch
SW903 K0H1BA000445 Switch
SW905 K0H1BA000445 Switch
SW906 K0H1BA000445 Switch
SW907 K0H1BA000445 Switch
SW908 K0H1BA000445 Switch
SW909 K0H1BA000445 Switch
SW910 K0H1BA000445 Switch
SW911 K0H1BA000445 Switch
SW912 K0H1BA000445 Switch
SW913 K0H1BA000445 Switch
SW914 K0H1BA000445 Switch
CRYSTALs
XL900 H0J125500008 Crystal Oscillator
Ref. No. Part No. Part Name & Description Remarks
LCD
LCD901 L5F000000009 LCD
NETWORK RESISTORs
RA901 D1H822140004 Network Resistor
RA902 D1H822140004 Network Resistor
RA903 D1H822140004 Network Resistor
RA904 D1H822140004 Network Resistor
RA905 D1H822140004 Network Resistor
RA907 D1H822140004 Network Resistor
RA908 D1H822140004 Network Resistor
RA909 D1H822140004 Network Resistor
RA910 D1H822140004 Network Resistor
RA911 D1H822140004 Network Resistor
THERMISTOR
TH900 D4CC14730002 Thermistor
TRANSFORMER
L908 G5C1AAA00001 Transformer
DISPLAY TUBE
CFL901 A2CA00000065 Display Tube
ACCESSORIES
PRINTINGS
YEFM285868 Operating Instructions
YEFM294215 Installation Instructions
INSTALLATION PARTs
YEFA131646 Removable Face Plate Case
EUR7641010 Remote Control Unit
(Includes a battery:CR2025)
CR2025/1F Lithium Battery
YEP0FZ5701 Installation Kit (Lock Cancel Plate,
Bolt, Screw, Nut)
YEFC05606 Trim Plate
YEFX0217222 Mounting Collar
YEAJ02871 Power Connector
YEFG04019 Rear Support Strap
Mechanical Parts
MISCELLANEOUS
AP2 YGAP2985 Pc Board Only
AT1 K4ZZ01000048 Terminal
AT2 K4ZZ01000048 Terminal
AT3 K4ZZ01000048 Terminal
CN1 K1NZ16H00002 Connector, 16P
HP1 K4ZZ01000235 Terminal
HP2 K4ZZ01000235 Terminal
ANT51 YEAA10090 Receptacle
1 YEFA032032 Upper Cover
2 YEP0FX13657 Removable Face Plate Unit RTL
3 YEFA132026 Back Cover, Detachable
4 YEFV021965 Magnetic Shield
5 YGP0PT9571Z9 Display PCB w/Component RTL
6 YEFK061261 Holder
7 YEFK061262 Holder
8 YEFX0013085 Transparent Plate
9 YEFX9995444 Shad
11 YEFV023430 Color Screen
12 YEFV023428 Optical Shade, LCD901
13 YEFX0013083 Transparent Plate, VOL
14 YEFX0217216 Case, LCD901
15 YEFX9995490 Spacer
17 CHFC026D018 Front Face Ass´y
20
CQ-C7402W
