Panasonic CQ-DP151W User manual

ORDERNo. ACED010318C3
AUTOMOTIVE CONSUMERELECTRONICS
CQ-DP151W/ CQ-DP101W
CD Player/ Receiver
SPECIFICATIONS
Specification*
1

General
PowerSupply DC12V(11V-16V),
TestVoltage14.4V
NegativeGround
ToneAdjustmentRange Bass ;±12dBat100Hz
Treble;±12dBat10kHz
CurrentConsumption Less than 2.2A(CDplaymode,
0.5W×4ch)
MaximumPowerOutput 45W×4ch (at1kHz, Vol. Max.)
SuitableSpeakerImpedance 4-8
Pre-AMPOutputVoltage 2V(CDplaymode;1kHz, 0dB)
OutputImpedance
<CQ-DP151W> 200
<CQ-DP101W> 600
FMStereo Radio
FrequencyRange 87.5-108.0MHz
UsableSensitivity 11.0dBf(1.25 V, 75 )
AMRadio
FrequencyRange 531 -1,602kHz
UsableSensitivity 28dB/ V(25 V, S/N20dB)
CDPlayer
Sampling Frequency 32 times oversampling
Pick-Up Type Astigma 3-beam
LightSource SemiconductorLaser
Wavelength 780nm
FrequencyResponse 20Hzto 20,000Hz(±1dB)
Signal to Noise Ratio 96dB
Wowand Flutter Belowmeasurablelimits
Channel Separation 75dB
Dimensions** 178(W)×50(H)×150(D)mm
Weight** 1.5kg
*Specificationsand thedesign aresubjectto possible
modification withoutnotice dueto improvements.
** Dimensionsand Weightshown areapproximate.
2001 Matsushita Communication Industrial Co., Ltd. All rights
reserved. Unauthorizedcopying and distribution isaviolation of
law.
2

1. FEATUERS
-PLL (Phase LockedLoop)synthesizedtuning.
-18-FM, 6-AMpresets withpreset scan
-Digital servoforreliableCD playback.
-Removableface plate.
2. REPLACEING THE FUSE
Use fuses ofthesamespecifiedrating (15A). Using differentsubstitutes or fuses withhigher
ratings, or connecting theunitdirectlywithoutafuse, couldcause fireor damagetothestereo
unit.
3. MAINTENANCE
Your productsisdesignedand manufacturedtoensureaminimum ofmaintenance. Use asoft
clothfor routineexterior cleaning. Neveruse benzine, thinneror othersolvents.
4. NOTES
[RADIOBLOCK]
Donotalign theAM/FMpackageblock. Whenthepackageblock isnecessary, itwill besupplied
alreadyalignedatthefactory.
[CD DECK BLOCK]
Thismodel has no servoalignmentpointsbecause microcomputercontrolstheservocircuit.
[OTHER]
Thefollowing tabledescribes thedifferences between2models.
CQ-DP151W CQ-DP101W
Pre-Ampoutput
connector Rear, Front Rear
Remotecontrol unit Included Notincluded
5. LASER PRODUCTS
3

6. DIMENSIONS
7. WIRING CONNECTION
4

5

8. BLOCK DIAGRAM
6

9. TERMINALSDESCRIPTION
9.1. MainBlock
IC600 :C2BBGE000526
Pin
No. Port Description I/O (V)
1INITC Initial C I 4.9
2LEVEL-R Notused - -
3LEVEL-L Notused - -
4AVSS Analog ground - -
5AFMUTE AFmute O 5.1
6P. IC
STBY PowerAmp. stand-by O 5.0
7AVREF Reference voltage - 5.1
8CD-SO CD data I 3.2
9CD-SI CD data O 3.8
10 CD-SCK CD clock O 5.0
11 CD.C
DATA Notused - -
12 NC Noconnection - -
13 CD.C
CLK Notused - -
14 REMOUT Notused - -
15 PLL CE PLL controllerchipenable O 0
16 PLL
DATA(MI) Datafrom PLL I 5.1
17 PLL
DATA
(MO)
Datafor PLL O 0
18 PLL CLK Clock for PLL O 0
19 NC Noconnection - -
20 NC Noconnection - -
21 CD-
RESET CD reset O 5.0
22 NC Noconnection - -
23 NC Noconnection - -
24 NC Noconnection - -
25 NC Noconnection - -
26 NC Noconnection - -
27 NC Noconnection - -
28 CD-ON CD poweron O 5.0
29 CD-MUTE CD mutecontrol I 0
30 CD-SW2 Notused - -
31 NC Noconnection - -
32 NC Noconnection - -
33 Vss Ground - 0
7

34 NC Noconnection - -
35 /ST FMstereodetection I 4.6
36 IC2-CLK Electronicvolumeclock O5.0
37 IC2-DATA Electronicvolumedata I/O 5.0
38 LED Notused - -
39 /HDB Notused - -
40 BZIN PowerSWdetection I 4.9
41 LCD-DI
(MO) LCD dataoutput O 0
42 LCD-DO
(MI) LCD datainput I 5.0
43 LCD-CLK LCD clock O 0
44 LCD-CE LCD chipenableoutput O 0.2
45 POWER
LED Pilotlampon O 0
46 ANT.CONTMotor antennacontrol O 0
47 NC Noconnection - -
48 NC Noconnection - -
49 NC Noconnection - -
50 BZOUT Notused - -
51 NC Noconnection - -
52 NC Noconnection - -
53 NC Noconnection - -
54 NC Noconnection - -
55 PANEL Panel detect I4.8
56 CD
POWER CD powercontrol O 5.1
57 PWRCNT Powercontrol O 5.1
58 ACC ACC detection I 4.5
59 RDS
DATA Notused - -
60 /RESET Resetinput I 4.7
61 REM Remocon datainput I 4.4
62 BATT Batterydetection I 4.7
63 RDS CLK Notused - -
64 CD.C.STB (Ground pull-down) I 0
65 MUTE Mutecontrol O 5.1
66 NC (Connecting toground) - 0
67 CD. C2 (Connecting toground) - 0
68 VDD +5V powersupply -5.1
69 X2 Crystal oscillator - 3.0
70 X1 Crystal oscillator - 1.7
71 Vss (Ground pull-down) - 0
72 NC Noconnection - -
73 TEL
MUTE Telephonemute I4.9
74 AVDD +5V powersupply -5.1
8

75 AVREF (Connecting toVDD) -5.1
76 NC (Connecting toground) - 0
77 SD Searchdetect I0.6
78 INITD Initial valueD I5.1
79 INITA Initial valueA I5.1
80 INITB Initial valueB I5.1
Note1:Voltagemeasuermentsarewithrespecttoground, withavoltmeter(internal resistance :
10Mohms).
9.2. DisplayBlock
IC901 :YEAMLC75853W
Pin
No. Port Description I/O (V)
1-8 SEG1-8 Notused - -
9-35 SEG9-35 LCD segment O 2.5
36-
40 NC Noconnection - -
41-
43 COM1-3 LCD common O 2.5
44-
49 KS1-6 Key dataoutput O 0.9
50-4 KI1-5 Key datainput I 0
55 TEST (Connecting toground) - 0
56 VDD +5V powersupply -5.1
57 VDD1 Ground through capacitor - 3.3
58 VDD2 Ground through capacitor - 1.7
59 Vss Ground - 0
60 OSC CR oscillator - 3.9
61 DO Key dataoutput O 4.4
62 CE Chipenable I 0
63 CLK LCD clock I 0
64 DI LCD datainput I 0
9.3. CD ServoBlock
IC201 :C2BBFD000188
9

Pin
No. Port Description I/O (V)
1A0 Address output O 3.8
2/RST Servoprocessor reset O5.1
3RFOK Servoprocessor RFOK
signal I4.9
4/PS2 IC301 mute O5.1
5/PC1 IC301 mute O 0
6TRV Toraverse motor control O 2.5
7LOD Loading motor control O 2.5
8PS2 Notused - -
9PC1 Notused - -
10 PC Notused - -
11 IFR (Connecting toground) - 0
12 NC Noconnection - -
13 VPP Notused - -
14 X2 Crystal oscillator - 3.3
15 X1 Crystal oscillator - 2.9
16 VSS Ground - 0
17 VDD +5V powersupply -5.1
18 /RESET Resetinput I 5.1
19 TP19 Notused - -
20 TP20 Notused - -
21 TP21 Notused - -
22 AMUTE AFmute O 0
23 CDON CD poweron I 5.0
24 INTP1 (Connecting toground) - 0
25 INTP0 (Connecting toground) - 0
26 SIMO Serial data I 0
27 SOMI Serial data O2.9
28 SCKM Shift clock for serial data I5.0
29 Q1SW1 Disc insensor signal I4.6
30 Q3SW3 Disc outsensor signal I4.6
31 Q6SW6 (Option sensor) I4.7
32 SW4 Disc clamp I 0
33 SW5 InnerSW I4.9
34 SW2 Feederarm I 5.1
35 TP35 Notused - -
36 TP36 Notused - -
37 TP37 Notused - -
38 VDD +5V powersupply -5.1
39 VSS Ground - 0
40 /XEN Servoprocessor XEN
signal
O 0
