Panasonic CQ-RX400U User manual

© 2008 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
ORDER NO. ACED080115C7
C4
AUTOMOTIVE AFTERMARKET
CQ-RX400U
AAC WMA MP3 CD Player/Receiver
TABLE OF CONTENTS PAGE PAGE
1 Service Navigation----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3 Features ------------------------------------------------------------- 4
4 Technical Descriptions----------------------------------------- 5
5 Block Diagram----------------------------------------------------- 9
6 Wiring Connection Diagram ---------------------------------12
7 Schematic Diagram---------------------------------------------13
8 Schematic Diagram-2 ------------------------------------------16
9 Printed Circuit Board-------------------------------------------17
10 Exploded View and Replacement Parts List -----------21
11 Schematic Diagram for Printing with Letter Size-----31

2
1 Service Navigation
1.1. About Lead Free Solder (PbF)
Distinction of PbF PCB :
• PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• Pb free solder has a higher melting point than standard sol-
der; Typically the melting point is 50 - 70°F (30 - 40°C)
higher. Please use a soldering iron with temperature control
and adjust it to 700 ± 20°F (370 ± 10°C). In case of using
high temperature soldering iron, please be careful not to
heat too long.
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
1.2. Laser Products
1.3. Replacing the Fuse
Use fuses of the same specified rating 15 amps. Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
1.4. Maintenance
Your product is designed and manufactured to ensure a mini-
mum of maintenance. Use a dry, a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvents.
1.5. Notes
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the fac-
tory.
[CD DECK BLOCK]
This model has no servo alignment points because microcom-
puter controls the servo circuit.

3
2 Specifications
2.1. Specifications*
2.2. Dimensions
General
Power Supply DC 12V (11V - 16V)
Test Voltage 14.4V
Negative Ground
Current Consumption Less than 2.1A
(CD mode, 0.5W 4-Channels)
Maximum Power Output 50W ×4 channels (at 1kHz), volume
control maximum
Tone/SQ Adjustable Range SQ Low/Bass:±12dB
(at 60 Hz, 80 Hz, 100 Hz, 200Hz)
SQ Mid: ±12 dB
(at 500 Hz, 1 kHz, 2 kHz, 3kHz)
SQ High/Treble: ±12 dB
(at 10 kHz, 12 kHz, 15 kHz, 18 kHz)
Speaker Impedance 4 - 8 Ω
Pre-amp Output Voltage 2.0 V (CD mode: 1 kHz, 0 dB)
Pre-amp Output Impedance 200 Ω
USB Connector
USB Standard Compatibility 1.1/2.0 Full Speed
Maximum Supply Current 500 mA
Front AUX input
Input impedance 10 kΩ
Allowable external input 2.0 V
Connector 3.5mmφStereo mini-pin
Dimensions (W×H×D)** 178×50×160mm (7”×1-5/16"×6-5/16")
Weight** 1.2 kg (2 lbs. 10 oz)
Disc Player
Sampling Frequency 8 times oversampling
DA Converter 1 bit DAC System
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wave Length 790 nm
Frequency Response 20 Hz - 20 kHz (±1 dB)
Signal to Noise Ratio 96 dB
Total Harmonic Distortion 0.01 % (1 kHz)
Wow and Flutter Below Measurable Limits
Channel Separation 85 dB
FM Radio
Frequency Range 87.9 MHz - 107.9 MHz
Usable Sensitivity 10.2 dBf (0.9 µV, 75 Ω)
50 dB Quieting Sensitivity 15.2 dBf (1.6 µV, 75Ω)
Frequency Response 30 Hz - 15 kHz (±3 dB)
Alternate Channel Selectivity 75 dB
Stereo Separation 35 dB (at 1 kHz)
Image Rejection Ratio 55 dB
IF Rejection Ratio 100 dB
Signal/Noise Ratio 62 dB
AM Radio
Frequency Range 530 kHz - 1710 kHz
Usable Sensitivity 27 dB/µV (22µV, S/N 20 dB)
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
** Above specifications comply with EIA standards.

4
3 Features
• SQ3 (3-Band Sound Quality).
• USB Connector
• The AUX Input terminal is equipped on the front panel.
• Expansion Module (The optional Hub unit: CY-EM100U)
• The optional adapter (Direct Cable for iPod, CA-DC300U)
allows you to connect the optional iPod® series.
• The optional adapter (Conversion Cable for DVD/CD
Changer:CA-CC30U) allows you to connect the optional
Panasonic CD changer unit (CX-DP880U).
• XM Satellite Radio. (The optional XM receiver: XMD1000
with optional Digital Adaptor Cable:XMDPAN110)
• The optional XM Direct with optional Digital Adaptor
Cable:CNPPAN2)
• Sirius Satellite Radio. (The optional Sirius Satellite receiver:
SIR-PAN1)
• Hands Free Phone System. (The optional Bluetooth hands-
free kit: CY-BT200U)
• AAC/MP3/WMA Playback from CD-R/RW.
• Anti-Theft System.

5
4 Technical Descriptions
4.1. Terminals Description
4.1.1. Main Block
IC601 : YESAM463
Pin
No Port Description I/O Vol [V]
FM AM CD
1 DBGP0 Not used - 0 0 0
2 DBGP1 Not used - 0 0 0
3 DBGP2 Not used - 0 0 0
4 RDS CLK Not connected - - - -
5 RM DATA Remote control data I 4.6 4.6 4.6
6 CDC STB/
SYSID4 CD changer Strobe; or Hub connection device ID
4
I0 0 0
7 EVENT Hub event detection I 0 0 0
8 RESET System reset I 4.9 4.9 4.9
9 XT1 Crystal oscillator 1
(32.768kHz) I1.01.01.0
10 XT2 Crystal oscillator 2
(32.768kHz) O1.41.41.4
11 VSS Ground - 0 0 0
12 CF1 Ceramic oscillator 1
(13.50MHz) I1.41.41.4
13 CF2 Ceramic oscillator 2
(13.50MHz) O1.31.31.3
14 VDD +5V power supply - 5.0 5.0 5.0
15 INI A Initialization mode A
(RX200U: Pulled up; Oth-
ers: Pulled down)
I4.94.94.9
16 VSM Signal meter intensity
(Tuner) I0 0 0
17 INI B Initialization mode B
(Pulled down) I0 0 0
18 USB FLG Not connected - 0 0 0
19 USB RESET Not connected - 0 0 0
20 NC Not connected - - - -
21 SYSID1 Hub connection device ID
1I5.05.05.0
22 SYSID2 Hub connection device ID
2I5.05.05.0
23 USB MUTE Not connected - 0 0 0
24 CDC DATA Serial data from CD
changer I0 0 0
25 CDC CLK/
SYSID3 Serial clock for CD changer; or Hub connec-
tion device ID 3
I0 0 0
26 CD DI (CD SI) Serial data to CD O 0 0 3.0
27 CD DO (CD
SO) Serial data from CD I 3.2 3.2 2.2
28 CD CLK Serial clock for CD O 0 0 3.0
29 CD CE (FS) Chip enable for CD O 0 0 0.9
30 NC Not connected - - - -
31 NC Not connected - - - -
32 NC Not connected - - - -
33 SUB READY0 Sub ready from CD servo I 5.1 5.1 4.9
34 REG READY0 Reg. ready from CD servo I 5.1 5.1 0
35 CD SW1 CD detection switch 1 I 4.9 4.9 4.9
36 CD SW2 CD detection switch 2 I 4.9 4.9 4.9
37 CD DMUTE CD mute I 0 0 5.1
38 CD LIMIT SW CD limit detection switch I 5.1 5.1 5.1
39 VSS Ground - 0 0 0
40 VDD +5V power supply - 4.9 4.9 4.9
41 CD MUTE Mute for Pick-up driver O 0 0 0
42 CD S/L CD Sleding/Loading mode
switch O4.94.94.9
43 CD F/R CD loading direction: For-
ward/Reverse O0 0 0
44 CD RESET CD reset O 4.9 4.9 4.9
45 HUB ACC
CNT Power supply control for Hub (External device) O0 0 0
46 HUB CNT Hub connection check
request O 4.9 4.9 4.9
47 USB ENBL Not connected - 0 0 0
48 USB SLP Not connected - 0 0 0
49 LCD DI Serial data to LCD O 4.9 4.9 4.9
50 LCD DO Serial data from LCD I 4.3 4.3 4.3
51 LCD CLK Serial clock for LCD O 4.9 4.9 4.9
52 LCD CE Chip enable for LCD CPU O 0 0 0
53 E-VOL I2C
DATA Serial data for Audio signal processor (volume) O 4.9 4.9 4.9
54 E-VOL I2C
CLK Serial clock for Audio sig- nal processor O 4.9 4.9 4.9
55 VDD +5V power supply - 4.9 4.9 4.9
56 VSS Ground - 0 0 0
57 E-VOL MUTE Not connected - - - -
58 POWER CNT System power supply con-
trol O 4.9 4.9 4.9
59 STBY Standby mode for Power
amplifier O 4.9 4.9 4.9
60 NC Not connected - - - -
61 NC Not connected - - - -
62 SUB CLK
OUT Not connected - 0 0 0
63 NC Not connected - - - -
64 BEEP Beep tone O 0 0 0
65 USB IN Not connected - 0 0 0
66 ACC ACC level detection I 5.2 5.2 5.2
67 NC Not connected - - - -
68 MODE B Rotary encoder detection
B for volume I 5.0 5.0 5.0
69 MODE A Rotary encoder detection
A for volume I 5.0 5.0 5.0
70 EXT
MUTE(NC) Not connected - - - -
71 PANEL IN Front panel detection I 4.9 4.9 4.9
72 BATT Battery level detection I 4.6 4.6 4.6
73 RDS
DATA(NC) Not connected - - - -
74 CDC REM
OUT Remote control for CD changer O0 0 0
75 HUB-TX Transmission data to Hub O 0 0 0
76 HUB-RX Reception data from Hub I 0 0 0
77 USB RXD Not connected - 0 0 0
78 USB TXD Not connected - 0 0 0
79 FM MODE Power supply control for
FM mode O4.9 0 0
80 AM MODE Power supply control for
AM mode O04.90
81 MONO(NC) Not connected - - - -
82 ST FM stereo indication I 5.1 5.1 5.1
83 DI/DO Serial data for EEPROM I/O 0 0 0
84 CS Chip select for EEPROM O 0 0 0
85 SK Serial clock for EEPROM O 0 0 0
86 NC Not connected - - - -
87 VREG Connected to capacitor - 3.0 3.0 3.0
88 VSS Ground - 0 0 0
89 VDD (PLL) +5V power supply - 5.0 5.0 5.0
90 OSC FM/AM FM/AM local oscillation
frequency I 1.4 1.4 1.4
91 NC Ground - 0 0 0
92 FM/AM IFC FM/AM center frequency I 0 0 0
93 NC Ground - 0 0 0
Pin
No Port Description I/O Vol [V]
FM AM CD

6
4.2. IC Block Diagram
4.2.1. Main Block
IC201 : YESAM440
IC271 : YESAM438
IC671 : YESAM391
IC771 : YESAM426
94 EO FM/AM phase detection
error O2.22.22.2
95 SUBPD(NC) Not connected - - - -
96 SSC SD sensitivity control O 0 0 0
97 ANT CNT(NC) Not connected - - - -
98 AMP CNT Not connected - 4.9 4.9 4.9
99 AF MUTE Audio signal mute O 0 0 0
100 AMP MUTE Mute for Power amplifier O 4.9 4.9 4.9
Pin
No Port Description I/O Vol [V]
FM AM CD

7
IC751 : YESAM424
IC801 : YESAM429

8
IC791 : YESAM344
IC851 : YESAM437
IC852 : YESAM439
4.2.2. Display Block
IC901 : YESAM427
IC902 : YESAM264

9
5 Block Diagram
5.1. Main-1 Block
22
CQ-RX400U MAIN (1/3)
7231-02-11(1/3)
PA51
FM / AM TUNER
AT51
2 FM ANT
FM VT
FM / AM OSC
FM / AM IFC
VSM
SD / ST IND
AM VT
1
17
16 1
AM ANT L-CH
R-CH R-CH
212011146
16929094
Q401
EO
AM MODE
HUB L
CD L
5
AUX L 7
15
16
3INPUT
SEL VOLUME
TONE FADER
IC201
AUDIO SIGNAL PROCESSOR
XL602
32.8KHz
IC602
EEPROM
1819
5453
SDA SCLK
DO
REAR
E-VOL
I2C
LR
FRONT
LR
R-CH
Q251
RR+
RR-
R-CH
R-CH
224
14
1615
1413
1211
10 9
87
65
43
21
STBY MUTE
FL+
FL
RL FL-
FR+
FR-
RL+
RL-
IC271
POWER AMP
BATT
ACC
AMP CNT
CN701
CN250
12
21
23
5
3
Q366
MUTE
R-CH
Q365
MUTE Q261
SW
Q52,602
Q55,601
TU+B FM VCC
AM VCC
POW
SW
POW
SW
80
FM MODE
SDA
83
4
DI
3
DI/DO
SK
85
2
SK CS
84
1
CS
59
STBY
100
AMP MUTE
99
AF MUTE
9
XT1
10
XT2
XL601
13.5KHz
12
CF1
13
CF2
SCLK
79
82
BAT DET
IC601(1/3) SYSTEM CONTROL

10
5.2. Main-2/Display Block
7231-05-11 7231-02-11(2/3)
75
76
24
74
25
6
46
21
22
45
7
6
3
3
1
12
8
12
2131
3
11 12
456
78910
11
2
2
5
IC671
IC791
IC751
POWER SUPPLY
Q752
Q751
Q770
4
9
13
10
1
1
HUB L L-CH
R-CH
DATA
REMO
SCLK
STRB
HCNT
EVENT
ACC
SYS ID1
SYS ID2
R-CH
CN671
INV
15V
LIMIT
BATT
BATT
SW5V
BATT
BATT
ACC
BATT
4VDD5V2 VDD5V1
POW
SW
IC781 IC771
POW
SW
DSP3.3V
7CD+B
POW
SW
10 AMP CNT
13
9
3
15
1
54 5V
REG
4
21
3
2
6AUD9V TU+B
DELAY
START
CQ-RX400U MAIN(2/3)/DISPLAY
AUX L
D+
D–
2
7
8
9
6
5
12
13
11
10
2
1515
3
2
1
17
18
20
17
18
20
7
8
9
6
5
12
13
11
10
MODE B
MODE A
RM DATA
EVENT
HUB CNT
CDC STB
CDC CLK
CDC REMO
CDC DATA
HUB TX 64BEEP
HUB RX
HUB ACC
CNT
66
ACC
58
PWR CNT
COMP
VCC
ACC
MODE 1
ILM
11
98
AMP CNT MODE 2
BATT
72 RESET
8
15 3
PANEL
71
LCD DI
49 LCD DO
50 LCD CLK
51 LCD CE
52
5
69
68
MODE A
REMO
MODE B
IC701
BATT
CHECK
VDD5V2
CN971CN901
IC601(2/3)
SYSTEM CONTROL
61
64
63
62
1
D901
Q901 PWR
SW
5V
SOURCE
LED
DRIVE IC902
IR
RECEIVE
SW901
Q902
R-CH
L-CH
D+
D–
VBUS
CN903
CN902
AUX
USB
USB
2
P2
47
ENBL
17
FLG
DI
DO
CL
CE
54
VDD
1
P1
50–53 45–48 39–42 3–36
LD901
KEY-IN
MATRIX
SEG
1–34
COM
1–4
KS
3–6
KI
2–5
IC901
LCD DRIVE
ILL10V
DSP
CD
BAT DET

11
5.3. Main-3/CD Interface Block
M
M
+
-
-
7231-02-11(3/3)3032-14-53Optical Pic-up Ass'y
A
B
E
F
7
9
3
2
11
4
1
A
B
E
F
LPD
LD3.3V
F+
F-
T+
T-
SP+
SP-
SL+
SL-
CD SW1
CD SW2
CD LIMIT SW
PD
LD
I-V
AMP
FOCUS
COIL
TRACKING
COIL
CD L
35 CD SW1
36 CD SW2
43 CD F/R
38 CD LIMIT SW
15
6
7
72
20
9
7
24
4
18
19
13
14
8
7
6
5
2
8
21
10 VREF
VCC
11
6
22
14
16
18
20
10
12
7
5
17
15
19
4
3
1
2
8
21
6
22
14
16
18
20
16
15
14
13
10
12
7
5
17
15
19
4
3
1
18
17
12
11
27
26
2
1
733224252322
DAC
XL801
16.93MHz
IC852
CQ-RX400U MAIN(3/3)
MUTE
TRACKING
COIL
DRIVE
FOCUS
COIL
DRIVE
SPINDLE
MOTOR
DRIVE
SLED
MOTOR
DRIVE
IC851
PICK-UP DRIVE
DSP3.3V
Q871
FDO
LIMIT SW X IN X OUT
TDO
SPDO
SLDO
SERVO
CTL
LD
DRIVE
EFM
DEM
ADC
LDS
A
C
B
D
F
E
LDO
VREF
FE
TE
IC801
RF AMP,SERVO,DSP
CN801
SPINDLE
MOTOR
SLED
MOTOR
CN2 CN1
37
38
UHD+
UHD-
12
13
SOMI
SIMO
22
14
UCLK
NSS
1
21
19
20
18
21
11
38
2
CP RESET
CP READY
SOMI
SIMO
UCLK
NSS
NRESET
CP READY
XIN
D+
D–
SPI SPI
34
CD DO
33
76
78
CD DI
CD CLK
44
CD CE
37
CD MUTE
41 CD DMUTE
USB TXD
USB RXD
USB RESET
USB MUTE
USB IN
USB SLP
SUB CLK
42 62
48
65
23
19
77
78
47
48
16
2
44
45
CD S/L
27
CD RESET
26 28
SUB READY
29
46
45
44
43
50
47
49
48
REG READY
DO
DI
CL
56
55
54
ST-IN
ST-CLK
ST-REQ
CONT0
CE
10
9
11
15
31
33
46
52 18
ST DATA
ST CK
ST REQ
28
27
26
LRCK
STCLK
SDAT
MCLKD
CD DATA
CD CMD
CD CLK
CE CD DSP
TXD
RXD
RESET
USB MUTE REQ
USB IN
SLEEP
R-CH
R-CH
L-CH
6
7
XL101
CF1
CF2
IC101
USB CONTROL
IC151
CP CONTROL
IC601(3/3)
SYSTEM
CONTROL

12
6 Wiring Connection Diagram
AT051
CN250
31 64
5
2
13 1
2
CN701
1
CN971
CN801 1
21
2
22
Extension
Connector
Jig Part No.
[YESFZS2076]
Preamp Out
(Front) (Rear)
Optical
Pic-Up
Ass'y
Main P.C.B
[7231-02-11] CD Interface P.C.B
[3032-14-53]
(Bottom View)
Loading/Feed
Motor
Limit
SW
Display P.C.B
[7231-05-11]
(Bottom View)
1
2
19
CN901
22
21
2
1
SW2 SW1
Spindle
Motor
CN2
CN1
1
16
1
CN903
AUX
1516
CN671
12 14
12 11
13
2
19
20
20
CN902
13
254
4
Power
Connector
External Amplifier Control
Motor Antenna Relay Control
Power (ACC or IGN)
Battery(15A)
Ground
Rear Speakers
4
/
/
4
Front Speakers

13
7 Schematic Diagram
7.1. Main-1 Block
7231-02-11
CQ-RX400U MAIN 1/2
8.8
5.0
5.0
4.0
4.0
4.0
4.0
0
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
0
0
7.3
7.3
5.0
14.4
7.4
0
7.3
7.3
7.3
7.2
0
7.2
7.2
7.2
7.3
0
7.3
14.4
7.3
4.9
7.3
0
4.9
0
0
5.0
4.0
0
00
5.0
0
4.9
0
5.0
5.0
5.0
4.9
0
5.0
4.6
0
0
0
0
14.3
0
0
0
1.3
0
0
0
0
0
8.1
8.1
1.3
0
3.6
3.6
0
0
0
5.1
0
8.1
0
8.1
8.1 4.9
0
0
0
8.1
0
8.2
0
8.2
8.0
8.0
7.2
1.3
2.2
0
0
5.0
5.0
0
0
0
0
0
0
0
0
0
3.2
3.2
0
5.1
5.2
6.4
5.0
4.9
8.0
14.0
13.4
4.9
3.2
9.1
1.2
9.5
1.6
1.6
1.5
2.1
1.7
1.7
1.7
1.8
1.7 1.6
0
1.9
1.9
3.2
1.6
1.6
2.4
0
3.2
1.5
1.6
1.6
1.7
0
1.5
0
0
5.0
1.6
0
5.1
5.6
5.0
4.9
3.3
3.3
4.0
0
1.2
1.2
1.1
3.1
5.1
0
3.1
3.1
0
1.5
3.1
0
3.1
00 0.9 3.0
3.0
2.2
4.9
0
4.9
5.1 3.1 2.3
0 0
0
3.1
0
0
1.5
3.1
0
1.5
1.5
3.1
3.1
1.5
1.5
1.5
0
1.6
3.8
3.4
1.6
4.9
1.6
0
3.9
3.3
7.4
0
7.4
3.6
3.6
1.6
8.0
8.0
1.6
1.6
3.8
3.5
0
0.5V/DIV,10uS/DIV 1V/DIV,10uS/DIV
1V/DIV,20nS/DIV
2V/DIV,50mS/DIV
2V/DIV,10mS/DIV
3032-14-53 CN1
8V
8V
8V
9V
9V 9V
9V
9V
L
R
L
R
L
R
L
R
L
R
L
R
L
R
5V
5V
5V
5V
5V
5V
5V
5V
10V
10V
10V
10V
R
L
R
R
L
3.3V
3.3V
3.3V
3.3V
3.3V 3.3V
3.3V 3.3V
3.3V
3.3V
3.3V
3.3V
5V
5V
5V
5V
5V
5V
5V
5V
5V
5V
5V
5V
5V
L
R
L
R
LR
L
R
R
LL
R
L
R
L
R
L
R
L
R
L
RL
R
L
RR
L
R
L
L
L
L
R
RR
R
L
5V
8V
8V
8V
7231-05-11 CN901
YESAP387
YESAD155
YESAN154
YESAN152
YESAN154 YESAN152
YESAN149
YESAD188
YESAD191
YESAD191
YESAD155
YESAD155
YESAD149
YESAD150
YESAD189
B1CBGF000005
YESAD144
YESAM463
YESAM440
YESAM391
YESAM438
YESAM429
YESAM437 YESAM439
YESAM441
YESAN153 YESAN153
YESAN155
YESAN155
YESAD188
YESRTD016
YESAD193
YESLT032
YESAM344
YESAD192
YESAD192
YESAN079
YESAM424
YESAD197
YESAD196
YESAD198
YESAN157
YESAD192
YESAD192
YESAD192
YESAD192
YESAD192
YESAD192
YESAD192
YESAD192
YESAN156
YESAD144
YESAD143
YESAD167
YESAD133
YESAD133
PIN49
PIN51,PIN52
Waveform Pin No.
10
0.027
0.027
47K
47K
6.3V330
6.3V330
47K
50V2.2
16V22
9V
5V
1V/DIV,20nS/DIV
1V/DIV,10mS/DIV
1V/DIV,5uS/DIV
1V/DIV,5uS/DIV
YESAN155
YESAN155
YESAD143
1/4W
1/4W
YESAM400
YESAM426 YESAD195
YESAD192
YESAD192
YESAD192
YESAD192
0
0
0
0
0
0
0
AMP,
ANT_CNT
0
5.0
0
5.0
11.0
5.0
5.0
5.2
0
5.0
47K
47K
YESAM436
1/4W
00
5.0
0
0
0 0

14
7.2. Main-2 Block
7231-02-11
CQ-RX400U MAIN 2/2
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
YESAM464
YESAD187 YESAD187
0
0
0
0
0
0
1.8
0
0
0
3.3
0
0
0 0 0 0
0
0
3.3
0
3.3
0
0
0
0
0
0
0
3.3
3.3
0
3.3
0 0
3.3
1.7 1.6
0
0
0
3.3
3.3
0
0
3.3
0
0
3.3
0
3.3
0
0
0
YESAD194
10
YESAM465
(L)
6.3V100

15
7.3. Display Block
7231-05-11
CQ-RX400U DISPLAY
L
R
L
R
L
5V
5V 5V
5V
5V
10V
10V
10V
4.2
4.8
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.4
2.4
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.4
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5 2.5
2.5
2.5 2.5
5.0
5.0
5.0
5.0
0
5.0
0
0
0
5.0
5.0
1.6
0
0
0
4.2
0
4.9
4.8
4.3
0
4.3
5.0
5.0
4.2
0.5V/DIV,1mS/DIV
0.5V/DIV,1mS/DIV
1V/DIV,10uS/DIV
2V/DIV,5mS/DIV
2V/DIV,5mS/DIV
PIN3-PIN36
PIN39-PIN42
PIN60
PIN62
PIN63,PIN64
Waveform Pin No.
YESAM264
YESAD189
YESAN150
YESAD155
YESAD186
YESAD180
YESAD150
YESAN151
YESAM427
YESAD189
YESAD190
YESAD190
YESAS133
YESXDCM043
CN971
470 470
470
470
470
470
820
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
YESAD166
180
1/4W
0.1
0.1
0.1
0.1
0.1 0.1
0.1
0.1

16
8 Schematic Diagram-2
8.1. CD Interface Block
CQ-RX400U
CD_3.3V
CD_LIMIT
CD_M.GND
CD_M.GND
CD_A.GND
3.3V
3.3V
3.3V
The following symbol is shown on the schematic diagram.
3.3V

17
9 Printed Circuit Board
9.1. Main Block (Top View)

18
9.2. Main Block (Bottom View)

19
9.3. Display Block

20
9.4. CD Interface Block
