Panasonic RX-ES29EE User manual

nRADIO
Frequency range
FM 87.50-108.00 MHz (50 kHz steps)
A
M522-1629 kHz (9 kHz steps)
nCD PLAYER
Sampling frequency 44.1 kHz
Decoding 16 bit linear
Beam source Semiconductor laser (wavelength
780 nm)
No. of channels 2 channel, stereo
Wow and flutter Below measurable limit
D/A converter MASH (1 bit DAC)
nTAPE RECORDER
Track system Stereo
Monitor system Variable sound monitor
Recording system AC bias
Erasing system Multi Pole magnet
Frequency range
Normal position 50-14000 Hz
©2004 Matsushita Electric Industrial Co. Ltd.. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
RX-ES29EE
Colour
(S)..........Silver Type
nGENERAL
Speakers 8cm5.4Ωx2
Jacks
Output Phones: 3.5 mm stereo (16-32Ω)
Power requirement
A
C230-240 V, 50 Hz
Power consumption 30 W
Battery 12 V [Eight R20/LR20 (D, UM-1)
batteries]
lDo not use rechargeable type batteries
Memory backup for
computer/clock
6 V [Four R6/LR6 (AA, UM-3)
batteries]
lDo not use rechargeable type batteries
Dimensions 529 mm (W) x 144 mm (H) x 276
mm (D)
Mass 4.4 kg without batteries
Power consumption in standby
mode
2.7 W
Notes:
1. Specifications are subject to change without notice.
2. Mass and dimensions are approximate.
Portable Stereo CD System
Specification
Order No. MD0411556C3

1 Safety Precautions 3
1.1. GENERAL GUIDELINES 3
2 Before Repair and Adjustment 4
3 Protection Circuitry 4
4 Handling the Lead Solder 4
4.1. About lead free solder (PbF) 4
5 Precaution of Laser Diode 5
6 Handling Precautions For Traverse Deck 6
7 Accessories 7
8 Operation Procedures 8
8.1. Main Unit 8
8.2. Remote Control 9
9 Information on MP3 10
10 Disassembly and Main Component Replacement Procedures
and Operational Check 11
10.1. Disassembly flow chart 11
10.2. Checking Procedure for each major P.C.B. 12
10.3. Procedures for Replacing Pinch Roller and Head Block
(Deck Mechanism Unit) 20
10.4. Procedures for Replacing Motor, Capstan Belt A, Capstan
Belt B, and Winding Belt (Deck Mechanism Unit) 20
10.5. Procedures for Replacing Parts on Deck Mechanism PCB
22
10.6. Procedures of Replacing Traverse Base (Unit), Driving
Gear, and Cam Gear (CD Mechanism Unit) 22
10.7. Procedures for Replacing Optical Pickup (CD Mechanism
Unit) 25
10.8. Procedures for Replacement Traverse Gear A and
Traverse Gear B (CD Mechanism Unit) 26
11 Procedure for checking of the major P.C.B. 28
11.1. Checking the Main P.C.B., Panel P.C.B., Deck Mechanism
P.C.B., CD Servo P.C.B., Battery P.C.B., Sensor P.C.B.,
Power-On P.C.B., Power and Standby LED P.C.B. 28
12 Self Diagnostic Function 29
12.1. Self-diagnosis Function 29
12.2. Setting of doctor mode 31
13 Measurements and Adjustments 37
13.1. Tuner Section 37
13.2. Deck Section 38
14 Voltage Measurement 40
14.1. Main P.C.B. 40
14.2. CD Servo P.C.B. 41
15 Waveform Chart 42
16 Notes of Schematic Diagram 43
17 Schematic Diagram 44
17.1. CD SERVO CIRCUIT 44
17.2. MAIN CIRCUIT and POWER ON CIRCUIT 46
17.3. MAIN (TUNER) CIRCUIT 53
17.4. MAIN (DECK) CIRCUIT 55
17.5. PANEL CIRCUIT, STANDBY LED CIRCUIT, BATTERY
CIRCUIT, POWER CIRCUIT and SENSOR CIRCUIT 57
18 Printed Circuit Board 58
18.1. CD SERVO P.C.B 58
18.2. MAIN P.C.B. 59
18.3. PANEL P.C.B. and DECK MECHANISM P.C.B. 61
18.4. STANDBY LED P.C.B., BATTERY P.C.B., POWER ON
P.C.B. and SENSOR P.C.B. 62
18.5. POWER P.C.B. 63
19 Wiring Connection Diagram 64
20 Type Illustration of IC 痴, Transistors and Diodes 66
21 Terminal Function Of IC 痴67
21.1. IC801 (MN101C74GAA1): Microprocessor 67
22 Troubleshooting Flowchart (CD Section Circuit) 68
23 Parts Location and Replacement Parts List 70
23.1. Deck Mechanism (RAA4401-1V) 71
23.2. CD Loading Mechanis m
73
23.3. Cabinet Part List 75
23.4. Electrical Part List 77
23.5. Packaging Materials & Accessories Parts List 83
23.6. Packaging 83
CONTENTS
Page Page
2
RX-ES29EE

1 Safety Precautions
1.1. GENERAL GUIDELINES
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, ensure that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
3. After servicing, check for leakage current checks to prevent from being exposed to shock hazards.
1.1.1. LEAKAGE CURRENT COLD CHECK
1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Using an ohmmeter measure the resistance value, between the jumpered AC plug and each exposed metallic cabinet part on
the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the
chassis, the reading should be between 1MΩand 5.2Ω.
When the exposed metal does not have a return path to the chassis, the reading must be .
Fig. 1
1.1.2. LEAKAGE CURRENT HOT CHECK (See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kΩ, 10 watts resistor, in parallel with a 0.15µF capacitors, between each exposed metallic part on the set and a
good earth ground such as a water pipe, as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent) may
be used to make the hot checks, leakage current must not exceed 1/2 milliamp. Should the measurement is outside of the limits
specified, there is a possibility of a shock hazard, and the equipment should be repaired and re-checked before it is returned
to the customer.
3
RX-ES29EE

2 Before Repair and Adjustment
Disconnect AC power, discharge Power Supply Capacitors C301, C131, C231, C310, C307, C309 and C331 through a 10 Ω,1W
resistor to ground. DO NOT SHORT-CIRCUIT DIRECTLY (with a screw driver blade, for instance), as this may destroy solid state
devices.
After repairs are completed, restore power gradually using a variac, to avoid overcurrent.
Current consumption at AC 220 V, 50 Hz in NO SIGNAL mode should be ~180 mA respectively.
Current consumption at AC 240 V, 60 Hz in NO SIGNAL mode should be ~129 mA respectively.
3 Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
· No sound is heard when the power is turned on.
· Stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and negative speaker connection wires are
“shorted”, or if speaker systems with an impedance less than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
2. Determine the cause of the problem and correct it.
3. Turn on the power once again after one minute.
Note:
When the protection circuitry functions, the unit will not operate unless the power is first turned off and then on again.
4 Handling the Lead Solder
4.1. About lead free solder (PbF)
Distinction of PbF P.C.B. :
P.C.B.s (manufactured) using lead free solder will have a PbF stamp on the P.C.B.
Caution:
· Pb free solder has a higher melting point than standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher.
Please use a high temperature soldering iron. In case of the soldering iron with temperature control, please set it to 700 ± 20°F
(370 ± 10°C).
· Pb free solder will tend to splash when heated too high (about 1100°F/600°C).
· When soldering or unsoldering, please completely remove all of the solder on the pins or solder area, and be sure to heat the
soldering points with the Pb free solder until it melts enough.
4
RX-ES29EE

5 Precaution of Laser Diode
Caution :
This product utilizes a laser diode with the unit turned "ON", invisible laser radiation is emitted from the pick up lens.
Wavelength : 780 nm
Maximum output radiation power from pick up : 100 µW/VDE
Laser radiation from pick up unit is safety level, but be sure the followings:
1. Do not disassemble the optical pick up unit, since radiation from exposed laser diode is dangerous.
2. Do not adjust the variable resistor on the pick up unit. It was already adjusted.
3. Do not look at the focus lens using optical instruments.
4. Recommend not to look at pick up lens for a long time.
ACHTUNG :
Dieses Produkt enthält eine Laserdiode. Im eingeschalteten Zustand wird unsichtbare Laserstrahlung von der Lasereinheit
abgestrahlt.
Wellenlänge : 780nm
Maximale Strahlungsleistung der Lasereinheit :100µW/VDE
Die Strahlung an der Lasereinheit ist ungefährlich, wenn folgende Punkte beachtet werden:
1. Die Lasereinheit nicht zerlegen, da die Strahlung an der freigelegten Laserdiode gefährlich ist.
2. Den werkseitig justierten Einstellregler der Lasereinhit nicht verstellen.
3. Nicht mit optischen Instrumenten in die Fokussierlinse blicken.
4. Nicht über längere Zeit in die Fokussierlinse blicken.
ADVARSEL :
I dette a apparat anvendes laser.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
nUse of Caution Labels
5
RX-ES29EE

The laser diode in the traverse deck (optical pickup) may break
down due to potential difference caused by static electricity of
clothes or human body.
So, be careful of electrostatic breakdown during repair of the
traverse deck (optical pickup).
lHandling of CD traverse deck (optical pickup)
1. Do not subject the traverse deck (optical pickup) to
static electricity as it is extremely sensitive to electrical
shock.
2. The short land between the No.4 (LD) and No.5 (GND)
pins on the flexible board (FFC) is shorted with a solder
build-up to prevent damage to the laser diode.
3. Take care not to apply excessive stress to the flexible
board (FPC board) (Fig 6.1).
4. Do not turn the variable resistor (laser power
adjustment). It has already been adjusted.
Fig 6.1
lGrounding for electrostatic breakdown prevention
1. Human body grounding (Fig 6.2)
Use the anti-static wrist strap to discharge the static
electricity from your body.
2. Work table grounding (Fig 6.2)
Put a conductive material (sheet) or steel sheet on the
area where the traverse deck (optical pickup) is placed,
and ground the sheet.
Caution :
The static electricity of your clothes will not be grounded
through the wrist strap. So, take care not to let your
clothes touch the traverse deck (optical pickup).
Fig 6.2
Caution when Replacing the Optical Pickup :
The traverse has a short point shorted with solder to protect
the laser diode against electrostatics breakdown. Be sure to
remove the solder from the short point before making
connections.
6 Handling Precautions For Traverse Deck
6
RX-ES29EE

7 Accessories
Note : Refer to Packing Materials & Accessories Parts List (Section 23.5) for the part number.
Remote Control.....1pc
AC cord.....1 pc
7
RX-ES29EE

8 Operation Procedures
8.1. Main Unit
8
RX-ES29EE

8.2. Remote Control
9
RX-ES29EE

9 Information on MP3
10
RX-ES29EE

10 Disassembly and Main Component Replacement
Procedures and Operational Check
“ATTENTION SERVICER”
Some chassis components may be have sharp edges. Be careful when disassembly and servicing.
1. This section describes procedures for checking the operation of the major printed circuit boards and replacing the main
components.
2. For reassembly after operation checks or replacement, reverse the respective procedures.
Special reassembly procedures are described only when required.
3. Select items from the following index when checks or replacement are required.
Warning:
This product uses a laser diode. Refer to “Precaution of Laser Diode”.
ACHTUNG:
Die Lasereinheit nicht zerlegen.
Die Lasereinheit darf nur gegen eine vom Hertsteller spezifizierte Einheit ausgetauscht werden.
10.1. Disassembly flow chart
The following chart is the procedure for disassembling the casing and inside parts for internal inspection when carrying out the
servicing.
To assemble the unit, reverse the steps shown in the chart below.
11
RX-ES29EE

10.2.1. Disassembly of Top Cabinet Unit.
Step 1: Remove 10 screws.
Step 2: Remove 2 screws.
Step 3: Flip up the handle as arrow direction shown.
Step 4: Use a screw driver and insert into the hole. Slide the
screw driver to the direction shown to open the cassette panel.
Note: Be careful not to exert strong force as it may cause
damage to the chassis.
10.2. Checking Procedure for each major P.C.B.
12
RX-ES29EE

Step 5: Cassette panel will automatically open.
Step 6: Remove 2 screws.
Step 7: Lift up the Top Cabinet as arrow shown.
Step 8: Flip the Top Cabinet over as arrow shown.
Step 9: Detach the FFC wire (CP401).
10.2.2. Disassembly of Panel P.C.B.
Follow (step 1) to (step 9) of item 10.2.1.
Step 1: Lift the upper section of the front panel slightly towards
you as arrow shown.
Step 2: While lifting, push the lower section of the front panel
in the direction shown by the arrow to release the catches.
13
RX-ES29EE

Step 3: Remove the Front Panel from Top Cabinet as arrow
shown.
Step 4: Remove 6 screws.
Step 5: Release 2 catches.
Step 6: Flip over the Control Button Unit with the Panel P.C.B.
as arrow shown.
Step 7: Remove the Jog Knob using a screwdriver as arrow
shown.
Caution: Do not exert strong force as it may cause damage to
the top cabinet.
14
RX-ES29EE

Step 8: Release 6 catches.
Step 9: Remove the Panel P.C.B. as arrow shown.
Step 10: Flip the Panel P.C.B. over.
10.2.3. Disassembly of Speakers.
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 10) of item 10.2.2.
Step 1: Remove 8 screws.
Step 2: Flip the both side speakers as arrow shown.
Step 3: Desolder the wire at speaker terminal to remove
speaker.
10.2.4. Disassembly of Deck Mechanism.
Follow (step 1) to (step 9) of item 10.2.1.
15
RX-ES29EE

Step 1: Remove 4 screws.
Note: Be careful of connectors (CP1301 & CP1902) while
removing the deck mechanism.
Step 2: Remove the deck mechanism as arrow shown.
Step 3: Release the connector (CP1450) to remove the deck
mechanism.
10.2.5. Disassembly of Main, Standby
LED, Power On and Sensor P.C.B.
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 3) of item 10.2.4.
Step 1: Remove 2 screws.
Step 2: Release 4 clutches.
Step 3: Remove the Mecha Chassis.
16
RX-ES29EE

Step 4: Remove 2 screws.
Step 5: Release all the connectors (CP501, CP402 & CP801).
Step 6: Release 3 Catches and remove Power On P.C.B. and
Standby Led P.C.B..
Step 7: Release the Sensor P.C.B. as arrow shown.
Step 8: Remove the Main P.C.B. as arrow shown.
10.2.6. Disassembly of Battery and Power
P.C.B.
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 3) of item 10.2.4.
Follow (step 1) to (step 8) of item 10.2.5.
Step 1: Remove 1 screw.
Step 2: Remove the Battery Support P.C.B..
Note: Remember to place the Battery Support P.C.B. to
original location.
17
RX-ES29EE

Step 3: Remove the Battery P.C.B. as arrow shown.
Step 4: Remove 3 screws.
Step 5: Remove the Transformer together with battery P.C.B.
and Power P.C.B. as arrow shown.
10.2.7. Disassembly of CD Loading
Mechanism.
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 3) of item 10.2.4.
Follow (step 1) to (step 8) of item 10.2.5.
Step 1: Remove 4 screws.
18
RX-ES29EE

Step 2: Remove the CD Loading Mechanism as arrow shown.
10.2.8. Replacement of Cassette Panel.
Follow (step 1) to (step 9) of item 10.2.1.
Step 1: Remove the cassette open spring.
Step 2: Push the cassette panel slowly to the right.
19
RX-ES29EE

Step 3: Push the cassette panel slowly to the left using a screw
driver.
Caution: Be careful of using/exerting strong forces.
Step 4: Remove the cassette panel from top cabinet as arrow
shown.
10.3. Procedures for Replacing
Pinch Roller and Head Block
(Deck Mechanism Unit)
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 3) of item 10.2.4.
10.4. Procedures for Replacing
Motor, Capstan Belt A,
Capstan Belt B, and Winding
Belt (Deck Mechanism Unit)
Follow (step 1) to (step 9) of item 10.2.1.
Follow (step 1) to (step 3) of item 10.2.4.
Follow (step 1) of item 10.3.
20
RX-ES29EE
