Panasonic KX-TGA470C User manual

Thank you for purchasing a Panasonic product.
Please read this installation
manual before using the unit
and save it for future reference.
For assistance, please call
1-800-561-5505 or visit us at
www.panasonic.ca
This unit is an additional handset compatible with the following
series of Panasonic Digital Cordless Phone:
KX-TG4711/KX-TG4731/KX-TG4741/KX-TG4771/
KX-TG7731/KX-TG7741
(The corresponding models are subject to change without
notice.)
You must register this handset with your base unit before it can
be used. This installation manual describes only the steps
needed to register and begin using the handset. Please read
the base unit’s operating instructions for further details.
Charge the batteries for about 7 hours before initial use.
Additional Digital Cordless Handset
Model No. KX-TGA470C
Installation Manual
PNQX5096ZA TT1211MG0 (A)
Printed in China
TGA470C(en).fm Page 1 Tuesday, November 22, 2011 5:52 PM

2
Accessory information
Supplied accessories
*1 Please read the base unit’s operating instructions for replacement
battery information.
*2 The handset cover comes attached to the handset.
Note:
LPlease read the base unit’s operating instructions for additional/
replacement accessories.
– Optional headsets: RP-TCA95, KX-TCA400, KX-TCA430
LThe suffix (C) in the following model numbers will be omitted in these
instructions: KX-TG4711C/KX-TG4731C/KX-TG4741C/KX-TG4771C/
KX-TG7731C/KX-TG7741C series.
Accessory item/Part number Quantity
Charger 1
AC adaptor/PNLV226 1
Rechargeable batteries*1 2
Handset cover*2 1
Belt clip 1
TGA470C(en).fm Page 2 Tuesday, November 22, 2011 5:52 PM

3
Setting up
Connections/Wall mounting
Note:
LUse only the supplied Panasonic AC adaptor PNLV226.
LThe AC adaptor must remain connected at all times. (It is normal for
the adaptor to feel warm during use.)
LMake sure that the wall and the fixing method are strong enough to
support the weight of the unit.
Battery installation/Battery charging
Important:
LUse the supplied rechargeable batteries. For replacement, we
recommend using the Panasonic rechargeable batteries noted in the
base unit’s operating instructions.
LWipe the battery ends (S, T) with a dry cloth.
LAvoid touching the battery ends (S, T) or the unit contacts.
LConfirm correct polarities (S, T).
LUSE ONLY Ni-MH batteries AAA (R03) size.
LDo NOT use Alkaline/Manganese/Ni-Cd batteries.
To power outlet Hooks
25.4 mm
(1 inch)
Screws
(Not supplied)
TGA470C(en).fm Page 3 Tuesday, November 22, 2011 5:52 PM

4
Charge for about 7 hours.
LWhen the batteries are fully charged, “Fully charged”is displayed.
Note:
LWhen the language selection is displayed after installing the batteries
for the first time, you can select your desired language.
{r}: Select the desired setting. s{SAVE}s{OFF}
LIf the batteries are fully charged, but the operating time seems to be
shorter, clean the battery ends (S, T) and the charge contacts with a
dry cloth and charge again.
Registering a handset to a base unit
1Base unit:
Press and hold {LOCATOR}for about 5 seconds.
LDepending on the base unit, a registration tone sounds.
LIf all registered handsets start ringing, press {LOCATOR}again to
stop, then repeat this step.
2Handset:
Place the handset on the base unit or charger, then wait until a long
beep sounds and wis displayed.
Note:
LIf an error tone sounds, or if _is displayed, register the handset
according to the base unit’s operating instructions.
Confirm
“Charging”
is displayed.
Rechargeable
Ni-MH ONLY
TGA470C(en).fm Page 4 Tuesday, November 22, 2011 5:52 PM

5
Display language
1{MENU}(11)
2{r}: Select the desired setting. s{SAVE}
3{OFF}
Belt clip
NTo attach NTo remove
