Panasonic KX-TGP600 Service manual

Document Version 2017-01
Model No.
SIP Cordless Phone
KX-TGP600
Please use this supplement manual together
with the latest English Administrator Guide.
Supplement for Administrator Guide

1. Additional Information for Specifying the Server Address
1.1 Basic format
Format: <scheme>://<user>:<password>@<host>:<port>/<url-path>/<file name>
* The server name (<host>) may be the IP address or the domain.
* Maximum length: 384 characters
1.2 Macros used with file names
Macro Format {XXXX} Macro Expansion
{MAC}
If the URL contains {MAC}, it will be replaced with the
device’s MAC address in uppercase letters.
Example: {MAC} → 0080F0C571EB
{mac}
If the URL contains {mac}, it will be replaced with the
device’s MAC address in lowercase letters.
Example: {mac} → 0080f0c571eb
{MODEL}
If the URL contains {MODEL}, it will be replaced with
the device’s model name.
Example: {MODEL} → KX-TGP600
{fwver}
If the URL contains {fwver}, it will be replaced with the
device’s firmware version.
Example: {fwver} → 01.000
Note
• Macros distinguish between uppercase and lowercase letters.
• Macros not specified above will be treated as strings of characters.
1.3 Target WEB Settings/Configuration Parameters
WEB Setting Configuration Parameter
DHCP Host Name DHCP_HOST_NAME
Standard File URL CFG_STANDARD_FILE_PATH
Product File URL CFG_PRODUCT_FILE_PATH
Master File URL CFG_MASTER_FILE_PATH
- CFG_ROOT_CERTIFICATE_PATH
- CFG_CLIENT_CERT_PATH
- CFG_PKEY_PATH
Firmware File URL FIRM_FILE_PATH
HTTP User Agent HTTP_USER_AGENT
-XMPP_ROOT_CERT_PATH
-XMPP_CLIENT_CERT_PATH
-XMPP_PKEY_PATH
-LDAP_ROOT_CERT_PATH
-LDAP_CLIENT_CERT_PATH
-LDAP_PKEY_PATH
-HS_LANGUAGE_PATHx
-WEB_LANGUAGE_PATHx
User Agent SIP_USER_AGENT
-SIP_TLS_ROOT_CERT_PATH
-SIP_TLS_CLIENT_CERT_PATH
-SIP_TLS_PKEY_PATH
-POWER_ON_DISPLAY_LOGO_PATH
-DISPLAY_WALLPAPER_DARK_PATH
-DISPLAY_WALLPAPER_LIGHT_PATH
2. Additional Information for Specifying the LDAP Server
Add "ldap://"or "ldaps://" before the LDAP server address.
(Example) LDAP_SERVER="ldap://141.170.10.178"

KX‐TGP600SoftwareFileVersion01.129orlater
1. 4.5.4 VoIP Settings [Line 1]–[Line 8]
Change the followings in " SRTP Mode " on page 136
(Before)
Value Range
(After)
Value Range
2. 5.3.2 Handset Registration Settings
Add the following configuration parameter.
NEXT_REGISTERED_HS_NUMBER
Value Format
Description
Value Range
Default Value
3. 5.3.12 XSI Settings
Add the following configuration parameter.
XSI_PHONEBOOK_CYCLIC_INTVL
Value Format
Description
Value Range
Default Value
XSI_PHONEBOOK_RESYNC_DURATION
Value Format
Description
Value Range
Default Value
0–1439
0
0
INTEGER
Specifies the time range, in minutes, during which connected units can access the server.
Xsi Directory (Phonebook) files will be downloaded at a random time within this range.
0
INTEGER
Specifies the interval, in minutes, between periodic checks for updates
of the Xsi Directory (Phonebook) files.
If this parameter is set to "0", the timing is the same as updating the
configuration files.
0–40320
• SRTP
• RTP/SRTP
Note
• When RTP/SRTP is selected, operation is in RTP mode.
• SRTP
• RTP/SRTP
Note
• RTP/SRTP: Use only RTP for outgoing calls, and RTP or SRTP for incoming calls.
INTEGER
Specifies the handset number to register or deregister.
・0: The handset number will be registered in order starting with the lowest available
number. (1 to 8)
・1-8: If the specified handset number is already registered, it will be deregistered.
If the specified handset number is not registered, it will be registered.
Note
If the handset IPEI parameters are registered on a base unit, this setting is invalid.
0 - 8
(0: Normal order, 1: handset 1, 2: handset 2, … 8: handset 8)

BSD_GROUP_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
BSD_GROUPCOM_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
BSD_ENTERPRISE_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
BSD_ENTERPRISECOM_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
BSD_PERSONAL_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
N
N
BSD_GROUPCOM_ENABLE_1, BSD_GROUPCOM_ENABLE_2,
…,BSD_GROUPCOM_ENABLE_8
BOOLEAN
Specifies whether to enable or disable the "Group Common" type for Xsi phonebooks.
・Y: Enable
・N: Disable
N
BSD_ENTERPRISE_ENABLE_1, BSD_ENTERPRISE_ENABLE_2,
…,BSD_ENTERPRISE_ENABLE_8
・Y: Enable
・N: Disable
N
BSD_ENTERPRISECOM_ENABLE_1, BSD_ENTERPRISECOM_ENABLE_2
,…,BSD_ENTERPRISECOM_ENABLE_8
BOOLEAN
Specifies whether to enable or disable the "Enterprise Common" type for Xsi phonebooks.
・Y: Enable
・N: Disable
BOOLEAN
Specifies whether to enable or disable the "Enterprise" type for Xsi phonebooks.
BSD_GROUP_ENABLE_1, BSD_GROUP_ENABLE_2,…,BSD_GROUP_ENABLE_8
BOOLEAN
Specifies whether to enable or disable the "Group" type for Xsi phonebooks.
・Y: Enable
・N: Disable
BSD_PERSONAL_ENABLE_1, BSD_PERSONAL_ENABLE_2,…,BSD_PERSONAL_ENABLE_8
BOOLEAN
Specifies whether to enable or disable the "Personal" type for Xsi phonebooks.
・Y: Enable
・N: Disable
N

4. 5.3.27 SRTP Settings
Change the followings in " SRTP_CONNECT_MODE_n " on page 269
(Before)
Value Range
(After)
Value Range
5. 5.3.32 Call Control Settings
Add the following configuration parameter.
VM_SUBSCRIBE_SPECIFIC_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
Change the followings in " IDLE_SOFT_KEY_A " on page 298
(Before)
Value Range
(After)
Value Range
Change the followings in " IDLE_SOFT_KEY_B " on page 298
(Before)
Value Range
(After)
Specifies the defined name of a voice mail box.
Max. 32 characters
Empty string
• 0: SRTP
• 1: RTP/SRTP
Note
• When RTP/SRTP is selected, operation is in RTP mode.
• 0: SRTP
• 1: RTP/SRTP
• 2: RTP&SRTP (Panasonic PBX only)
Note
• 0: Use only SRTP for outgoing and incoming calls.
• 1: Use only RTP for outgoing calls, and RTP or SRTP for incoming calls.
• 2: Use RTP or SRTP for both outgoing and incoming calls.
This value is valid only when the unit is connected to a Panasonic PBX.
"SRTP_MIX_TRANSFER_ENABLE_n" must also be set to "Y".
STRING
VM_SUBSCRIBE_SPECIFIC_1, VM_SUBSCRIBE_SPECIFIC_2, ...,
VM_SUBSCRIBE_SPECIFIC_8
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page
• 7: Intercom Call
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page

Value Range
Change the followings in " IDLE_SOFT_KEY_C " on page 299
(Before)
Value Range
(After)
Value Range
Add the following configuration parameter.
SHARED_STOP_LINE_SEIZE
Value Format
Description
Value Range
Default Value
BOOLEAN
Specifies whether to stop seizing the line of the Shared Call at the unit side or not.
・Ｙ: Stop seizing line
・N: Seize line
N
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page
• 7: Intercom Call
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page
• 7: Intercom Call
• 1: Phonebook
• 2: Menu
• 3: Outgoing Call Log
• 4: Incoming Call Log
• 5: Redial
• 6: Page

KX‐TGP600SoftwareFileVersion01.148orlater
1. 5.3.1 System Settings
Add the following configuration parameter.
FWD_DND_MENU_ENABLE
Value Format
Description
Value Range
Default Value
BLOCK_ANONY_MENU_ENABLE
Value Format
Description
Value Range
Default Value
ANONY_CALL_MENU_ENABLE
Value Format
Description
Value Range
Default Value
TIME_ZONE_SET_ENABLE
Value Format
Description
Value Range
Default Value
2. 5.3.2 Handset Registration Settings
Add the following configuration parameter.
IPEI_CHANGE_HS_ENABLE
Value Format
Description
Value Range
Default Value
3. 5.3.12 XSI Settings
Add the following configuration parameter.
BSD_MULTI_TYPE_ENABLE
Value Format
Description
Value Range
Default Value
・Y: Enable
・N: Disable
N
BOOLEAN
Specifies whether you can select the type of Xsi phonebook.
Specifies whether the "Time Zone" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
N
BOOLEAN
Specifies whether the "Fwd/DND" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Y
BOOLEAN
BOOLEAN
Y
BOOLEAN
Specifies whether the "Anonymous Call" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Specifies whether the "Block Anonymous" setting is displayed in MENU.
・Y: Displayed
・N: Not displayed
Y
Specifies whether to enable the ability to change handset registration with IPEI.
・Y: Enable changing
・N: Disable
N
BOOLEAN

4. 5.3.13 XMPP (UC-ONE) Settings
Add the following configuration parameter.
UC_USERID_CASE_SENSITIVE
Value Format
Description
Value Range
Default Value
5. 5.3.21 NAT Settings
Add the following configuration parameter.
EXTERNAL_RTP_PORTx
Value Format
Description
Value Range
Default Value
6. 5.3.22 SIP Settings
Add the following configuration parameter.
SIP_REPLACE_ENABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
SEND_180_ALERT_ENABLE
Value Format
Description
Value Range
Default Value
SIP_INC_INVITE_RTP_MODE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
INTEGER
x=1-10
Specifies the port number of the router in Static NAT status.
BOOLEAN
Specifies whether the authentication ID is case-sensitive when accessing the UC server.
・Y: Enable
・N: Disable
N
0, 1024 - 59998 (only even ports)
0: Disable
0
SIP_REPLACE_ENABLE_1, SIP_REPLACE_ENABLE_2,…,
SIP_REPLACE_ENABLE_8
INTEGER
Specifies whether to send RTP after receiving a second INVITE.
・0: Start receiving RTP after receiving a second INVITE
・1: Start sending/receiving RTP after receiving a second INVITE
0
SIP_INC_INVITE_RTP_MODE_1, SIP_INC_INVITE_RTP_MODE_2,…,
SIP_INC_INVITE_RTP_MODE_8
BOOLEAN
Specifies whether to send 180 before an alert.
・Y: Send 180
・N: Do not send 180
N
BOOLEAN
Specifies whether to use "Replaces Header".
・Y: Use "Replaces Header"
・N: Do not use "Replaces Header"
Y

7. 5.3.23 SIPxTLS Settings
Add the following configuration parameter.
SIP_TLS_RANDOM_PORT
Value Format
Description
Value Range
Default Value
8. 5.3.28 VQ Report by PUBLISH
Add the following configuration parameter.
VQREPORT_SEND_OPT_CODEC_ENABLE
Value Format
Description
Value Range
Default Value
VQREPORT_SEND_OPT_NW_CHANGE
Value Format
Description
Value Range
Default Value
9. 5.3.30 Telephone Settings
Add the following configuration parameter.
CNIP_FROM_ENABLE
Value Format
Description
Value Range
Default Value
BOOLEAN
BOOLEAN
Specifies whether to use the 'FROM' header or the 'PAI' header in CNIP (Calling Number
Identification Presentation).
Specifies whether to enable the sending of VQREPORT (SIP-PUBLISH) when the codec is
changed.
・Y: Send VQREPORT when a change of codec is detected
・N: Send VQREPORT at the end of a conversation
Specifies whether to assign a random port (ephemeral port) number or a static port
number.
Note
・All lines that use SIP-TLS are defined by this parameter.
・UDP/TCP ports are unaffected by this parameter.
・Y: Assign a random TLS port number
・N: Assign a static TLS port number (Refer to SIP_SRC_PORT_n)
Y
BOOLEAN
N
INTEGER
Specifies the number of consecutive times the MOS (Mean Opinion Score) value may fall
below the threshold value specified by either ALERT_REPORT_MOSQ_CRITICAL or
ALERT_REPORT_MOSQ_WARNING before the phone sends VQREPORT.
The ALERT_REPORT_TRIGGER setting determines whether
ALERT_REPORT_MOSQ_CRITICAL or ALERT_REPORT_MOSQ_WARNING is used as the
threshold.
0–5
(The number of consecutive times. 0:Disable)
Example:
If "2" is specified and the MOS value falls within the threshold 2 consecutive times,
VQREPORT is sent.
0
・Y: Use 'FROM' header
・N: Use 'PAI' header
N

HS_IDLE_DISPLAY_TYPE
Value Format
Description
Value Range
Default Value
NOISE_REDUCTION_MODE_HSy
Parameter Name Example
Value Format
Description
Value Range
Default Value
TALK_ON_CHARGE_MODE_HSy
Parameter Name Example
Value Format
Description
Value Range
Default Value
10. 5.3.32 Call Control Settings
Add the following configuration parameter.
FWD_SYNCHRO_FORCE_DISABLE_n
Parameter Name Example
Value Format
Description
Value Range
Default Value
CONF_SERVER_HOLD_ENABLE
Value Format
Description
Value Range
Default Value
Specifies whether to synchronize the Call Forward settings in
FWD_DND_SYNCHRO_ENABLE_n.
・Y: Do not synchronize
・N: Synchronize
N
INTEGER
Specifies what is shown on the display in standby mode.
NOISE_REDUCTION_MODE_HS1, NOISE_REDUCTION_MODE_HS2, …,
NOISE_REDUCTION_MODE_HS8
INTEGER
Specifies whether to enable the Noise Reduction feature of each handset.
・0: Disable Noise Reduction
・1: Enable Noise Reduction
・Y: Hold the call
・N: Do not hold the call
N
FWD_SYNCHRO_FORCE_DISABLE_1, FWD_SYNCHRO_FORCE_DISABLE_2,…,
FWD_SYNCHRO_FORCE_DISABLE_8
BOOLEAN
Specifies whether to hold the call when connecting an N-party conference.
BOOLEAN
・0: Off
・1: Phone Number
・2: Phone Number and Handset Name
・3: Handset Name
3
0
0
TALK_ON_CHARGE_MODE_HS1,TALK_ON_CHARGE_MODE_HS2, …,
TALK_ON_CHARGE_MODE_HS8
INTEGER
Specifies whether to enable the Talk On Charger feature of each handset.
・0: Disable Talk On Charger
・1: Enable Talk On Charger
