Panasonic Diga DMR-ES40V User manual

VQT0R75
DVD Recorder
Model No. DMR-ES40V
If you have any questions, contact
In the U.S.A: 1-800-211-PANA (7262)
In Canada: 1-800-561-5505
The appearance of your DVD Recorder may differ slightly from that shown in the illustrations.
Playback
SKIP/ INDEX
SLOW/
SEARCH
REW FF
PLAY
S
TIME SLIP
FUNCTIONSDIRECT NAVIGATOR
TOP MENU
RETURN
SUB MENU
PLAY
SEARCH
(Cue/Review)
SKIP
(VISS)
PAUSE
STOP
Recording
REC REC MODE
DUBBING
DVDVHS
DVD
OPERATION
SELECT
VHS DVD VHS DVD
OPERATION
SELECT
VHS DVD VHS DVD
VHS DVD
CH REC
O
S
VHS DVD
CH REC
O
S
DVD
VHS DVD
DUBBING
VHS DVD
VHS
DUBBING
DVD VHS DVD
VHS
DVD
VHS
OPERATION
SELECT
VHS DVD
XP EPSP LP SP EP VP
Reference pages on the operating instructions are indicated as (F○○ ).
Before performing operations,
Before performing operations,
be sure to select drive .
be sure to select drive .
Before performing operations,
Before performing operations,
be sure to select drive .
be sure to select drive .
The VHS indicator
lights up on the unit.
The DVD indicator
lights up on the unit.
To restart playback:
PLAY
To stop recording:
The list of titles recorded (Title View) is shown.
You can play and edit a desired title (F33).
DIRECT NAVIGATOR
DIRECT NAVIGATOR
DIRECT NAVIGATOR
DIRECT NAVIGATOR
Press to select the channel.
Press
REC MODE
to select the recording mode.
Press
REC
to start recording.
on the main uniton the main unit
While both DVD and VHS are stopped, press and hold for about
3 seconds or more (F55, 56).
One Touch Transfer (Dubbing)
One Touch Transfer (Dubbing)
One Touch Transfer (Dubbing)
One Touch Transfer (Dubbing)
DMR-ES40VPPC.indd1DMR-ES40VPPC.indd1 2005/08/0114:37:512005/08/0114:37:51

Connection
Connection
DVD PRIORITY output and DVD/VHS output
OPTICAL
R - AUDIO - L VIDEO
S VIDEO
R - AUDIO - L VIDEO
R
- AUDIO - L VIDEO
S VIDEO
RF IN
RF OUT
DIGITAL AUDIO OUT
(PCM/BITSTREAM)
YPBPR
COMPONENT VIDEO OUT (480p / 480i)
VHF/UHF
RF IN
VHF/UHF
RF IN
VIDEO
OUT
R L
AUDIO OUT
AUDIO IN
R L VIDEO IN
TV
Audio/Video cable 75 coaxial cable
Antenna cable
Video cassette recorder
Audio/Video cable
75 coaxial cable
indicates included accessories.
indicates accessories not included.
Use a splitter if you also
want to connect the
antenna to your VCR.
AC power supply cord
Splitter
Cable TV
Outdoor
antenna
Indoor
antenna
OPTICAL
R - AUDIO - L VIDEO
S VIDEO
R - AUDIO - L VIDEO
R
- AUDIO - L VIDEO
S VIDEO
DIGITAL AUDIO OUT
(PCM/BITSTREAM)
YP B P R
COMPONENT VIDEO OUT (480p / 480i)
DVD PRIORITY OUT
DVD/VHS COMMON output
DVD PRIORITY output
Connection (without Audio/Video cable)
Connect in numerical order to .
After this connection, set the RF output channel “CH3”
or “CH4” (F15).
Connection (with Audio/Video cable)
Connect in numerical order to .
After this connection, set the RF output channel “OFF”
(F15).
The unit has DVD/VHS COMMON output terminals and
DVD PRIORITY output terminals.
DVD/VHS COMMON OUT
For DVD/VHS COMMON output terminals, both DVD and VHS signals
can be output.
DVD PRIORITY OUT
This is the dedicated terminal for enjoying pictures played on DVD in
higher picture quality (F14).
DMR-ES40VPPC.indd2DMR-ES40VPPC.indd2 2005/08/3011:47:362005/08/3011:47:36

Plug-in Auto Tuning
Plug-in Auto Tuning
The unit’s display
English
Español
Français
Press ENTER
Pulse ENTER
Appuyer sur ENTER
Select Language
Seleccione el idioma
Sélection de Langue
Set Channels Automatically
Ch.
Set Channels Automatically
Proceeding . . .

1
Set Clock Automatically
Auto Clock Setting is complete.
9/1/2005 12:15 AM
DST............. On
Time Zone.... CST
CH3 (Default setting) CH4 OFF
Press
DVD/VHS POWER
to turn on the DVD Recorder.
Press to select an RF output channel number.
Each time you press the button:
Connection - (without Audio/Video cable)
Select “CH3” or “CH4” which displays the
screen on the right.
Connection - (with Audio/Video cable)
Select “OFF”.
Use
ENTER
to select the language and press
ENTER
.
Press
ENTER
to start Plug-in Auto Tuning.
The unit then proceeds with Auto Clock Setting.
The time is displayed when Auto Clock Setting is finished.
Press
ENTER
to exit the screen.
If the unit couldn’t set the clock automatically (F44)
To start Plug-in Auto Tuning again (F15)
To change the RF output channel (F19)
DMR-ES40VPPC.indd3DMR-ES40VPPC.indd3 2005/08/0114:37:532005/08/0114:37:53

DMR-ES40V
Transferring (Dubbing)
Transferring (Dubbing)
Disc Comparison (F6)
Playing the disc on other DVD players
;: Possible, V: Impossible
F
F
One Touch Transfer
One Touch Transfer
55
When you want to transfer (dub) from the
selected start point to the end of the tape
Easy transferring (dubbing) with one button
When you want to transfer (dub) a whole disc
When you want to transfer (dub) from the
beginning of the selected title to the end of the
disc
Easy transferring (dubbing) with one button
Suitable methods
Direction
From
From
To
To
Type of transfer (dubbing) you want
DVD-RAM
DVD-RW
DVD-R
+R
VHS
VHS
DVD-RAM
DVD-R
DVD-RW
+R
( DVD Video Recording format ,
DVD-Video format)
Easy transferring (dubbing)with one button
Cannot transfer (dub)
DVD-Video
[including
finalized disc (DVD-R,
DVD-RW, +R) and +RW]
VHS
56
Repeat recording
Recording both Main and SAP
of MTS broadcast (F9)
Recording 16:9 aspect picture
Playback on another unit
Recording broadcasts that
allow one copy
The picture is recorded
in 4:3 aspect.
The picture is recorded
in 4:3 aspect.
The picture is recorded
in 4:3 aspect.
After finalizing the disc After finalizing the disc After finalizing the disc
CPRM (
F 58)
compatible discs only
(DVD-Video format) (DVD-Video format)
(DVD Video Recording
format)
Only playback is
available with this unit.
w
Finalize
Play on other
DVD equipment
Record to DVD-R, etc.
After recording, it is necessary to finalize (close) DVD-R, DVD-RW and +R in order to be able to play them
on other DVD players.
(finalizeF31, 58)
DMR-ES40VPPC.indd4DMR-ES40VPPC.indd4 2005/08/0114:37:502005/08/0114:37:50
