Panasonic ES-LV61 User manual

Operating Instructions
(Household) Rechargeable Shaver
Model No. ES‑LV61
Before operating this unit, please read these instructions completely and save them for future use.
Thank you for choosing a Panasonic shaver ES‑LV61. With
our WET/DRY technology, you can enjoy using your
Panasonic shaver dry or in the shower or bath for gentle
and easy shaving. Please read all instructions before use.
Important
This shaver has a built‑in rechargeable battery. Do not throw into
fire, apply heat, or charge, use, or leave in a high temperature
environment.
Before use
This WET/DRY shaver can be used for wet shaving using
shaving lather or for dry shaving.You can use this watertight
shaver in the shower and clean with water. The following symbol
means suitable for use in a bath or shower.
Treat yourself to wet lather shaves for at least three weeks and
notice the difference.Your Panasonic WET/DRY shaver requires
a little time to get used to because your skin and beard need
about a month to adjust to any new shaving method.
Using the shaver
Caution
The outer foil is very thin and can be damaged if not used
correctly. Check that the foil is not damaged before using
the shaver. Do not use the shaver if the foil is damaged as
you will cut your skin.
Terminate the usage when there is an abnormality or failure.
Do not share your shaver with your family or other people.
Doing so may result in infection or inflammation.


•
•
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
Charging the shaver
Never use the AC adaptor in the bathroom or shower room.
Do not use any power cord or AC adaptor other than the AC
adaptor (RE7‑59).
Plug in the AC adaptor into a household outlet where there is
no moisture and handle it with dry hands.
Hold the AC adaptor when disconnecting it from the household
outlet. If you tug on the power cord, you may damage it.
The supply cord cannot be replaced. If the cord is damaged,
the AC adaptor should be scrapped.
Cleaning the shaver
Warning
Disconnect the power cord from the shaver before
cleaning it in water to prevent electric shock.
Keep both the inner blades inserted. If only one of the inner
blades is inserted, the shaver may be damaged.
If you clean the shaver with water, do not use salt water or hot
water. Do not soak the shaver in water for a long period of
time.
Clean the housing only with a soft cloth slightly dampened
with tap water or soapy tap water. Do not use thinner, benzine,
alcohol or other chemicals.
Storing the shaver
Store the shaver in a place with low humidity after use.
Do not store the shaver where it will be exposed to direct
sunlight or other heat sources.
Disconnect the power cord when storing the shaver.
•

•
•
•
•
•

•
•
•

•
•
•
Do not bend the power cord or wrap it around the shaver.
Keep the oil away from children.
Parts identification










a
c
e
b
d
f
g










AProtective cap
BOuter foil section
1Foil frame
2System outer foil
3System outer foil release
buttons
CInner blades
DMain body
4Foil frame release buttons
5LCD panel
a. Used time
b. Battery capacity
c. Charge status
d. Sonic vibration
e. Foil/blade check
f. Clean
g. Battery capacity
6Appliance socket
7Lock ring
8Power switch [0/1]
9Trimmer
:Trimmer handle
EAC adaptor (RE7‑59)
;Power cord
•
•
<Appliance plug
FTravel case
GCleaning brush
HOil
Using the lock ring
Use the lock ring to lock or unlock the power switch.
Rotate the lock ring until it clicks.
Rotate the lock ring to “ ” to unlock the power
switch:
For when shaving, washing the shaver, lubricating
the shaver.
Rotate the lock ring to “ ” to lock the power
switch:
For when carrying the shaver.
Charge
Charging the shaver
1
1Insert the appliance plug into
the shaver.
2
2Plug in the AC adaptor into a
household outlet.
1
2
Turn the shaver off before attaching.
Charging is completed after approx. 1 hour.
You cannot operate the shaver while charging.
•
•
FEN
Printed in Japan
ES0000XX000X X0000‑00000
Panasonic Electric Works Co., Ltd.
http://panasonic.net
2 3
ES-LV61_AUS.indb 1 2011/02/28 17:14:09

Reading the LCD panel when charging
The LCD panel shows the remaining battery capacity from 0% to
100%, in 10% increments.
While charging After charging is completed
The indicators glow.
Battery capacity and Charge status
will light up and then turn off after 5
seconds.
After charging is completed, turning the power switch ON with
the shaver plugged in will cause Battery capacity and Charge
status to light up and then turn off after 5 seconds. This shows
that the shaver is fully charged.
Recommended ambient temperature for charging is 5‑35 °C. The
battery may not charge properly or at all under extreme low or
high temperatures.
The indicators on the LCD panel blink when there is a problem
with charging.
When charging the shaver for the first time or when it has not
been in use for more than 6 months, the indicators on the LCD
panel may not glow. It will eventually glow if kept connected.
•
•
•
Shave
Using the shaver
1
1Rotate the lock ring to
unlock the power switch
and press the power
switch.
Page 3
2
2Hold the shaver
as illustrated
above and shave.
We recommend using the shaver in an ambient temperature
range of 5 ‑ 35 °C. If used outside this range, the appliance may
stop operating.
Start out shaving by applying gentle pressure to your face.
Stretch your skin with your free hand and move the shaver back
and forth in the direction of your beard.You may gently increase
the amount of pressure as your skin becomes accustomed to
this shaver. Applying excessive pressure does not provide a
closer shave.
Caution
If you press the power switch for more than 2 seconds, the
sonic vibration cleaning mode is activated. Page 5
You cannot shave in this mode.
Do not place your fingers on the power switch while using the
shaver. This may cause the shaver to turn off or enter the sonic
vibration cleaning mode. Place your fingers on the finger rest
while using the shaver.
•
•
•
Using the trimmer
You can change the pivot action. Slide the handle up to “ ”
when using the trimmer.
FREE
You can move the shaver head.
LOCK
You can lock the shaver head.
Slide the trimmer handle up. Place at a right
angle to your skin and move downwards to
trim your sideburns.
Reading the LCD panel when using
During use After use
The used time is shown.
The indicators turn off after
5 seconds.
The shown time returns to
[0’00”] after 10 minutes.
•
•
The used time and the
remaining battery capacity are
shown alternately after turning
off the shaver.
When the battery capacity is low
You can shave 1 to 2 times after “10%”
appears.
(This will differ depending on usage.)
•
“10%” appears and blinks.
A full charge will supply enough power for approx. 14 shaves of
3 minutes each. (This will differ depending on usage.)
•
Clean
Cleaning the shaver
We recommend that you clean your shaver with the the sonic
vibration cleaning mode when the faucet symbol appears on
the LCD panel.
1. Disconnect the power cord from the shaver.
2. Apply some hand soap and some water to
the outer foil.
3. Rotate the lock ring to unlock the power
switch.
4. Press the power switch for more than 2
seconds to activate the sonic vibration
cleaning mode.
appears on the LCD panel.
After about 20 seconds, it will be
automatically turned off, or you can turn it
off by pressing the power switch.
•
•
4
5. Remove the outer foil section and press the
power switch for more than 2 seconds to
activate the sonic vibration cleaning mode
and clean it with running water.
6. Wipe off any drops of water with a dry cloth.
7. Dry the outer foil section and the shaver
completely.
8. Attach the outer foil section to the shaver.
9. Lubricate the shaver.
5
7
Lubrication
To maintain shaving comfort for a long time, it is recommended
that the oil provided with the shaver is used.
1. Switch off the shaver.
2. Apply one drop of oil to each of the outer foils.
3. Raise the trimmer and apply a drop of oil.
4. Switch the shaver on, and run it for approximately
five seconds.
5. Switch off the shaver, and wipe off any excess oil
from the outer foils with a soft cloth.
Cleaning with the brush
Clean the inner blades using the
short brush by moving it in direction
(A).
Clean the system outer foil, the
shaver body and the trimmer using
the long brush.
Do not move the short brush in
direction (B) as it will damage the
inner blades and affect their
sharpness.
Do not use the short brush to
clean the outer foils.
•
•
(A) (B)
Replacing the system outer foil and the inner blades
system outer foil once every year
inner blades once every two years
Replacing the system outer foil
1. Press the foil frame release buttons and lift
the outer foil section upwards.
2. Press the system outer foil release buttons
and pull down the system outer foil.
3. Align the foil frame mark ( ) and the
system outer foil mark ( ) and securely
attach together.
The system outer foil cannot be reversely
attached.
Always insert the system outer foil to the
foil frame when attaching to the shaver.
4. After turning the foil frame mark
( ) to the front, securely attach the
outer foil section to the shaver until it clicks.
•
•
1
23

Perform steps 1to 4and lift the battery, and then remove it.




For environmental protection and recycling of materials
This shaver contains a Lithium‑ion battery.
Please make sure that the battery is disposed of at an officially
assigned location, if there is one in your country.
Specifications
Power source See the name plate on the AC adaptor.
(Automatic voltage conversion)
Motor voltage 3.6 V
Charging time Approx. 1 hour
This product is intended for household use only.
•
Replacing the inner blades
1. Press the foil frame release buttons and lift
the outer foil section upwards.
2. Remove the inner blades one at a time.
Do not touch the edges (metal parts) of
the inner blades to prevent injury to your
hand.
3. Insert the inner blades one at a time until
they click.
•
1
23
Replacement parts
Replacement parts are available at your dealer or Service Center.
Replacement parts for
ES‑LV61
System outer foil and
inner blades WES9030
System outer foil WES9171
Inner blades WES9170
Removing the built‑in rechargeable battery
Remove the built‑in rechargeable battery before disposing of the
shaver. Please make sure that the battery is disposed of at an
officially designated location if there is one. Do not dismantle or
replace the battery so that you can use the shaver again. This
could cause fire or an electric shock.
Please contact an authorised service center.
Disconnect the power cord from the shaver when removing the
battery.


•
4 5
