Panasonic ES8249 User manual

© Panasonic Electric Works Co., Ltd. 2008.
All rights reserved. Unauthorized copying and distri-
bution is a violation of law.
Order Number SD0810U54CE
E6
Rechargeable Shaver
Model No. ES8249
North America
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Troubleshooting Guide ----------------------------------------- 3
4 Disassembly and Assembly Instructions ---------------- 7
5 Schematic Diagram ---------------------------------------------12
6 Exploded View and Replacement Parts List -----------13

2
1Warning
Caution:
• Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-
ing iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
2 Specifications

3
3 Troubleshooting Guide
3.1. Main unit and charging adaptor

4

5
3.2. Self-cleaning recharger

6
3.3. Operation of Self-cleaning Recharger

7
4 Disassembly and Assembly Instructions
4.1. Disassembly Instructions
Follow the procedure below to disassemble the main unit.
1. Remove the cap, the outer foil and the inner blade.
2. How to disassemble the housing A and B.
a. Loosen a screw.
b. Remove the bottom cover.
c. Slide the trimmer handle up.
d. Loosen a screw.
e. Slide the trimmer handle down.
f. Remove the trimmer sliding downward.
g. Remove the upper rear panel.
h. Loosen two screws.
i. Remove the rear panel.
j. Loosen six screws.
k. Remove the housing B.
3. To remove the trimmer driving bar or the slit blade driving
bar, press bars outward.
4. Pull up the battery and chassis block from the linear
motor side first. Then, slide it upward and take it out from
the housing A.
NOTE:
Do not pull the battery and chassis block forcefully
due to connecting the linear motor by the lead wires.

8
5. Take out the battery from the chassis.
6. Take out the tube holder.
7. Move gently the linear motor assembly down and unhook
it and remove the float springs from housing A.
8. Unsolder the lead wires from the module.

9
4.2. Caution in Assembly
NOTE:
When reassembling, replace the new waterproof seal. Make sure whether there is NO foreign substance sticking around a part
covered with waterproof seal.
1. Solder the lead wires with the module.
NOTE:
Make sure of the color of lead wires.
2. When inserting the module and chassis block into the
housing A, confirm if the module does not get any dam-
age or deformation.
3. Make sure that the lead wires set in position to avoid
abnormal noise. Install (+) terminal of battery into the ter-
minal plate at the bottom cover side and firmly set the bat-
tery sliding the direction of arrow. Attach (-) terminal of
battery.
NOTE:
Once taking the battery out, the shaver is RESET.
The shaver must be charged for about 10 seconds
first.
NOTE:
Completely discharge and then fully charge before
returning the shaver to the customer.

10
4. Set the linear motor assembly on the housing A and slid-
ing it upward to hook. Confirm that the lead wire tube fits
to the housing A firmly and no foreign substance sticking
around. Attach the tube holder with the lock lever shaft to
housing A with care of the direction.
5. When putting the housing A and the housing B together,
make sure if the waterproof seal must be fitted properly
and no foreign substance sticking around.
6. Tighten six screws.
NOTE:
Make sure to attach the connecting plate.
7. Insert two hooks on top of the rear panel into the dent of
housing first and attach the rear panel firmly. Set the rear
panel with the position “LOCK”.
NOTE:
Make sure of the smooth movement of the lock lever
shaft.

11
8. Attach the bottom cover and tighten a screw.
9. Set the trimmer driving bar and the slit blade driving bar.
10. Set the trimmer and tighten a screw. If the position is not
properly, it makes the deformation of the hook.

12
5 Schematic Diagram

Model No. : ES8249 Exploded View
6 Exploded View and Replacement Parts List

Model No. : ES8249 Parts List
Safety
Ref.
No. Part No. Part Name & Description Q'ty Remarks
1 WES8243X7158 PROTECTIVE CAP 1
2 WES9161C OUTER FOIL 1
3 WES9068PC INNER BLADE 1ST (for U.S.A.)
3 WES9068C INNER BLADE 1ST (for Canada)
4 WES8258L1007 LINEAR MOTOR ASSEMBLY 1
5 WES8258L1087 TRIMMER DRIVING BAR 1
6 WES8258L1077 SLIT BLADE DRIVING BAR 1
7 WES8258L1177 FINISHING BLADE DRIVING BAR 1
8 WES8258L0327 WATERPROOF RUBBER 1
9 WES8258K3267 FOIL RELEASE BUTTON 2 (2PCS/PK)
10 WES8258L0537 TUBE HOLDER 1
11 WES8249S3058 HOUSING A 1 (for SILVER MODEL)
11 WES8249K3058 HOUSING A 1 (for BLACK MODEL)
12 WES8258H3067 HOUSING B 1
13 WES8258L0497 TERMINAL BASE 1
14 WES8238H0527 TERMINAL COVER 1
15 WES8176L6007 P TIGHT SCREW 6 (M2-12)
16 WES8238L0487 CONNECTING PLATE 1
17 WES8249L2128 MODULE 1
18 WES8163L2509 RECHARGEABLE BATTERY 1 (LM-ION TYPE)
19 WES8258S1507 TRIMMER 1 (for SILVER MODEL)
19 WES8255K1507 TRIMMER 1 (for BLACK MODEL)
20 WES8238L6007 P TIGHT SCREW 1 (M2-6)
21 WES8258S3857 REAR PANEL (UPPER) 1 (for SILVER MODEL)
21 WES8255K3857 REAR PANEL (UPPER) 1 (for BLACK MODEL)
22 WES8258K3367 REAR PANEL 1
23 WES8249S3120 BOTTOM COVER 1 (for SILVER MODEL)
23 WES8249K3128 BOTTOM COVER 1 (for BLACK MODEL)
24 WES8176L6057 TAPPING SCREW 3 (M2-8)
25 WES8249S3030 BODY BLOCK 1 (for SILVER MODEL)
25 WES8249K3038 BODY BLOCK 1 (for BLACK MODEL)
26 WES8228K7658 CHARGING ADAPTOR 1 (A-2 PLUG)
27 WES8258K7357 WATER TANK 1
28 WES8259K4219 SELF-CLEANING RECHARGER 1
29 WES035P551 DETERGENT CARTRIDGE 1 [BG]
30 WES8259K7018 SOFT CASE 1
- WES8249S8000 INDIVIDUAL BOX 1 (for SILVER MODEL)
- WES8249K8008 INDIVIDUAL BOX 1 (for BLACK MODEL)
- WES8249K8108 OPERATING INSTRUCTIONS 1
