Panasonic WH-MXC09G3E5 User manual

© Panasonic Corporation 2015.
Order No: PAPAMY1504024CE
Mono bloc Unit
WH-MXC09G3E5 WH-MXC12G6E5
Destination
Europe
Turkey
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
PRECAUTION OF LOW TEMPERATURE
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.

3
1. Safety Precautions
Read the following “SAFETY PRECAUTIONS” carefully before installation of (Mono bloc) Air-to-Water Heat
pump system (hereafter referred to as “Mono bloc unit”).
Electrical works and water installation works must be done by licensed electrician and licensed water system
installer respectively. Be sure to use the correct rating and main circuit for the model to be installed.
The caution items stated here must be followed because these important contents are related to safety. The
meaning of each indication used is as below. Incorrect installation due to ignorance or negligence of the
instructions will cause harm or damage, and the seriousness is classified by the following indications.
WARNING This indication shows the possibility of causing death or serious injury.
CAUTION This indication shows the possibility of causing injury or damage to properties only.
The items to be followed are classified by the symbols:
Symbol with white background denotes item that is PROHIBITED from doing.
Symbol with dark background denotes item that must be carried out.
Carry out test run to confirm that no abnormality occurs after the installation. Then, explain to user the operation, care and
maintenance as stated in instructions. Please remind the customer to keep the operating instructions for future reference.
If there is any doubt about the installation procedure or operation, always contact the authorized dealer for advice and
information.
WARNING
1. Do not install Mono bloc unit near handrail of veranda. When installing Mono bloc unit at veranda of high rise building, child may climb
up to Mono bloc unit and cross over the handrail and causing accident.
2.
Do not use unspecified cord, modified cord, join cord or extension cord for power supply cord. Do not share the single outlet with other
electrical appliances.
Poor contact, poor insulation or over current will cause electrical shock or fire.
3. Do not tie up the power supply cord into a bundle by band. Abnormal temperature rise on power supply cord may happen.
4. Do not insert your fingers or other objects into the unit, high speed rotating fan may cause injury.
5. Do not sit or step on the unit, you may fall down accidentally.
6. Keep plastic bag (packaging material) away from small children, it may cause suffocation.
7. Do not use pipe wrench to install refrigerant pipe. It might deform the piping and cause the unit to malfunction.
8. Do not purchase unauthorized electrical parts for installation, service, maintenance and etc.. They might cause electrical shock or fire.
9. This unit is a multi supply appliances. All circuits must be disconnected before accessing to the unit terminals.
10. Do not modify the wiring of Mono bloc unit for installation of other components (i.e. heater, etc.). Overloaded wiring or wire connection
points may cause electrical shock or fire.
11. Do not add or replace refrigerant other than specified type. It may cause product damage, burst and injury etc.
12.
For electrical work, follow the local national wiring standard, regulation and this installation instruction. An independent circuit and
single outlet must be used. If electrical circuit capacity is not enough or defect found in electrical work, it will cause electrical shock or
fire.
13. For water circuit installation work, follow to relevant European and national regulations (including EN61770) and local plumbing and
building regulation codes.
14. Must engage an authorized dealer or specialist for installation. If installation is defective, it will cause water leakage, electrical shock or
fire.
15. Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electrical shock or fire.
16. Only use the supplied or specified installation parts. Else, it may causes Mono bloc unit vibrate, fall, water leakage, electrical shock or
fire.
17. Install at a flat, strong and firm location which is able to withstand the Mono bloc unit’s weight. If the location is slanting, or strength is
not enough the set will fall and cause injury.

4
WARNING
18. This equipment is strongly recommended to be installed with Residual Current Device (RCD) on-site according to the respective
national wiring rules or country-specific safety measures in terms of residual current.
19. The unit is only for use in a closed water system. Utilization in an open water system may lead to excessive corrosion of the water
piping and risk of incubating bacteria colonies, particularly Legionella, in water.
20. If there is any doubt about the installation procedure or operation, always contact the authorized dealer for advice and information.
21. Select a location where in case of water leakage, the leakage will not cause damage to other properties.
22. When installing electrical equipment at wooden building of metal lath or wire lath, in accordance with electrical facility standard, no
electrical contact between equipment and building is allowed. Insulator must be installed in between.
23. This installation may be subjected to building regulation approval applicable to respective country that may require to notify the local
authority before installation.
24. Any work carried out on the Mono bloc unit after removing the front panel which is secured by screws, must be carried out under the
supervision of authorized dealer and licensed installation contractor.
25.
This unit must be properly earthed, the electrical earth must not be connected to a gas pipe, water pipe, the earth of a lightening rod or
a telephone. Otherwise there is a danger of electrical shock in the event of an insulation breakdown or electrical earth fault in the
Mono bloc unit.
CAUTION
1. Do not install the Mono bloc unit in areas where there is a risk of flammable gas leakage. There is a risk of fire if flammable gas
accumulates near or around the Mono bloc unit.
2. Do not release refrigerant during piping work for installation, re-installation and during repairing a refrigeration parts. Take care of the
liquid refrigerant, it may cause frostbite.
3. Make sure the power supply cord does not contact with hot part (i.e. water piping). High temperature may cause insulator of power
supply cord damage hence electrical shock or fire.
4. Do not touch the sharp aluminium fin, sharp parts may cause injury.
5. Do not apply excessive force to water pipes that may damage the pipes. If water leakage occurs, it will cause flooding and damage to
other properties.
6. Carry out drainage piping as mentioned in installation instructions. If drainage is not perfect, water leakage may happen and may
cause damage to properties of the user.
7. The piping installation work must be flushed before the Mono bloc unit is connected to remove contaminants. Contaminants may
damage the Mono bloc unit components.
8. Select an installation location where it is accessible for maintenance.
9.
Power supply connection to Mono bloc unit.
Power supply point should be in easily accessible place for power disconnection in case of emergency.
Must follow local national wiring standard, regulation and this installation instruction.
Strongly recommended to make permanent connection to a circuit breaker. It must be a double pole switch with a minimum
3.0 mm gap.
- Power supply 1: Use approved 30A circuit breaker.
- Power supply 2: Use approved 30A circuit breaker.
10. Ensure the correct polarity is maintained throughout all wiring. Otherwise, it will cause electrical shock or fire.
11. After installation, the installer is obliged to verify correct operation of the Mono bloc unit. Check the connection point for water leakage
during test run. If leakage occurs, it will cause damage to other properties.
12.
Installation work.
Four or more people are required to carry out the installation work. The weight of Mono bloc unit might cause injury if carried by less
than four people.

5
2. Specifications
2.1 WH-MXC09G3E5
Item Unit Refrigerant System
Performance Test Condition EN14511
Cooling Condition (Ambient/Water) A35W7 -
Cooling Capacity kW 7.00 -
BTU/h 23900 -
kcal/h 6020 -
EER W/W 3.17 -
kcal/hW 2.72 -
Heating Condition (Ambient/Water) A7W35 A2W35
Heating Capacity kW 9.00 9.00
BTU/h 30700 30700
kcal/h 7740 7740
COP W/W 4.84 3.59
kcal/hW 4.16 3.08
Air Flow m3/min (ft3/min) Cooling: 89.5 (3160)
Heating: 76.8 (2710)
Refrigeration Control Device Expansion Valve
Refrigeration Oil cm3 FV50S (1200)
Refrigerant (R410A) kg (oz) 2.30 (81.2)
Compressor Type Hermetic Motor (Rotary)
Motor Type Brushless (4-poles)
Rated Output kW 3.00
Fan Type Propeller Fan
Material PP
Motor Type DC (8-poles)
Input Power W -
Output Power W 60
Fan Speed rpm
Cooling: 540 (Top Fan) 580 (Bottom Fan)
Heating: 490 (Top Fan) 530 (Bottom Fan)
Heat Exchanger Fin material Aluminium (Pre Coat)
Fin Type Corrugated Fin
Row × Stage × FPI 2 × 51 × 18
Size (W × H × L) mm 903.7 × 1295.4 × 38.1
Item Unit Mono bloc Unit
Dimension Height mm (inch) 1410 (55-1/2)
Width mm (inch) 1283 (50-1/2)
Depth mm (inch) 320 (12-19/32)
Net Weight kg (lbs) 148 (326)
Noise Level dB-A Cooling: 49
Heating: 49
Cooling: -
Heating: -
Power Level dB Cooling: 67
Heating: 66
Cooling: -
Heating: -
Power Source (Phase, Voltage, Cycle) ø Single
V 230
Hz 50

6
Item Unit Mono bloc Unit
Input Power kW Cooling: 2.21
Heating: 1.86
Cooling: -
Heating: 2.51
Maximum Input Power For Mono bloc Unit kW 5.41
Power Supply 1: Phase (ø) / Max. Current (A) / Max. Input Power (W) Single / 25.0 / 5.41k
Power Supply 2: Phase (ø) / Max. Current (A) / Max. Input Power (W) Single / 13.0 / 3.00k
Power Supply 3: Phase (ø) / Max. Current (A) / Max. Input Power (W) - / - / -
Starting Current A 10.2
Running Current A Cooling: 10.2
Heating: 8.6
Cooling: -
Heating: 11.6
Maximum Current For Mono bloc Unit A 25.0
Power Factor % Cooling: 94
Heating: 94
Cooling: -
Heating: 94
Power factor means total figure of compressor and outdoor fan motor.
Power Cord Number of core -
Length m (ft) -
Thermostat Electronic Control
Protection Device Electronic Control
Item Unit Water System
Performance Test Condition EN14511
Operation Range Outdoor Ambient °C Cooling: 16 ~ 43
Heating: -20 ~ 35
Water Outlet °C
Cooling: 5 ~ 20
Heating: 25 ~ 55
Internal Pressure Differential kPa Cooling: 14.3
Heating: 22.8
Water Pipe Diameter Inlet mm (inch) 30 (1-3/16)
Outlet mm (inch) 30 (1-3/16)
Water Drain Hose Inner Diameter mm (inch) 15.00 (19/32)
Pump Motor Type DC Motor
No. of Speed 7 (software selection)
Input Power W 50
Hot Water Coil Type Brazed Plate
No. of Plates 36
Size (H × W × L) mm 65 × 120 × 376
Water Flow Rate l/min (m3/h) Cooling: 20.1 (1.2)
Heating: 25.8 (1.5)
Pressure Relief Valve Water Circuit kPa Open: 300, Close: 265 and below
Flow Switch Magnetic Lead Switch
Protection Device A Residual Current Circuit Breaker (30)
Expansion Vessel Volume I 10
MWP bar 3
Capacity of Integrated Electric Heater kW 3.00
Note:
1. Cooling capacities are based on outdoor air temperature of 35°C Dry Bulb with controlled water inlet temperature of 12°C and water outlet
temperature of 7°C.
2. Heating capacities are based on outdoor air temperature of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb) with controlled
water inlet temperature of 30°C and water outlet temperature of 35°C.
3. Specifications are subjected to change without prior notice for further improvement.

9
3. Features
Inverter Technology
oEnergy saving
High Efficiency
Compact Design
Environment Protection
oNon-ozone depletion substances refrigerant (R410A)
Easy to use remote control
Weekly Timer setting
Quality Improvement
oRandom auto restart after power failure for safety restart operation
oGas leakage protection
oPrevent compressor reverse cycle
oInner protector to protect compressor
Serviceability Improvement
oBreakdown Self Diagnosis function
oSystem Status Check Buttons for servicing purpose
oSystem Service Mode Button for servicing purpose
oFront maintenance design for Mono bloc unit
Operation Condition
Water outlet temperature (°C) Ambient temperature (°C)
Maximum 20 43
COOLING Minimum 5 16
Maximum 55 35
HEATING Minimum 25 -20
NOTICE: When the outdoor temperature is out of the above temperature range, the heating capacity will drop
significantly and Mono bloc unit might stop for protection control.

10
4. Location of Controls and Components
4.1 Mono Bloc Unit
A
ir inlet (rear)
A
ir outlet
Air inlet (side)
Handle
(2 pieces front and 2 pieces behind)
Cabinet Front Plate
Top Plate

11
4.1.1 Main Components
Component name
PCB
Pressure relief valve
Flow switch
Pressure gauge
Water pump
RCCB
Bushing
Cabinet front plate
Connector name
Water inlet
Water outlet
Cabinet top plate
Overload protector
Heater assembly
Expansion vessel
Cover
Air purge valve
1
2
a
b
3
4
5
6
7
8
9
10
11
12
13
14
View without cabinet top plate
Optional cord / cable :-
•
2-way valve cable (3 × min 0.5mm²)
•
3-way Valve cable (3 × min 0.5mm²)
•
Booster Heater cord (3 × min 1.5mm²)
•
Room Themostat cable (4 or 3 × min 0.5mm²)
•
Tank OLP cable (2 × min 0.5mm²)
•
Tank Sensor cable (2 × min 0.3mm²)
•
External Controller cable (2 × min 0.5mm²)
•
Solar Three-way Valve cable (3 × min 0.5mm²)
•
Solar Pump Station cable (2 × min 0.5mm²)
Type
designation
60245 IEC
57 or heavier
cord / cable
Remote Control
Power Supply 1
Power Supply 2
7
It is advisable to avoid more than 2
blockage directions. For better ventilation
& multiple-outdoor installation, please
consult authorized dealer/specialist.
2
7
10
8
1
13
10
6
3
4
11
12
5
A
14
9
a
b
(VIEW
WITHOUT
COVER)
DETAIL A DETAIL A
FOR
WH-MXC12G6E5
(WITHOUT OLP
COVER)
FOR
WH-MXC09G3E5
(WITHOUT OLP
COVER)
a b

20
5. Dimensions
5.1 Mono Bloc Unit
(579)
400 356
154
1410
615426.5
175
275
413
30
cc
70
277
320
152
1283
256 (30)
293
318.5
50
45 45 45
83.5
Unit: mm
<Top View
>
<Front View>
<Back View>
<Side View><Side View>

21
6. Refrigeration And Water Cycle Diagram
A
ir Purge Va
l
v
e
Mono bloc Unit
Pipe
Temp.
Sensor
Defrost
Sensor
Water Inlet
Temp.
Sensor
Water Outlet
Temp.
Sensor
Hex Water Outlet
Temp.
Sensor
Refrigerant
Temp.
Sensor
Air
Temp.
Sensor
Bypass
Exit
Temp.
Sensor
Eva
Exit
Temp.
Sensor Backup Heater
Outdoor
Side
Expansion
Vessel
Pressure
Relief
Valve
Air Purge Valve
Water
Flow
Switch
Water
Pump
Water
Inlet
(Connec
t
to
Sanitary
Tank)
Water
Outlet
(Connec
t
to
Sanitary
Tank)
Drain
Refrigerant Cycle (Heating)
Water Cycle
Heat
Exchanger
Heat
Exchanger
Strainer Strainer
Subcooler
Receiver
4-Way
Valve
2-Way Valve
Gas Side
(3-Way Valve)
Liquid Side
(3-Way Valve)
Pressure
Switch
High Pressure
Sensor
Compressor Discharge
Temp. Sensor
Compressor
Water
Pressure
Gauge
Capillary
Tube
Expansion
Valve
Strainer StrainerExpansion
Valve
(Bypass)
Refrigerant Cycle (Cooling)
Muffler
