Panasonic NI-100DX User manual

© 2011 Panasonic Manufacturing Malaysia Berhad
(6100-K). Unauthorized copying and distribution is a
violation of law.
MEL0310030C3R
Electric Cordless Dry Iron
Model No. NI-100DX
TABLE OF CONTENTS PAGE PAGE
1 Specifications ----------------------------------------------------- 2
2 Pictorial Wiring Diagram--------------------------------------- 2
3 Schematic Diagram---------------------------------------------- 2
4 Disassembly Instructions ------------------------------------- 3
4.1. Removal of Rear Handle Cover------------------------ 3
4.2. Removal of Pilot Lamp----------------------------------- 3
4.3. Removal of Dial Knob ------------------------------------ 3
4.4. Removal of Handle---------------------------------------- 3
4.5. Removal of Iron Weight (For model NI-
100DX)------------------------------------------------------- 4
4.6. Removal of Rating Plate--------------------------------- 4
4.7. Removal of Cover Shell, Handle and Lamp
Cover --------------------------------------------------------- 4
5 Reassembly Instructions---------------------------------------4
5.1. Mounting of Thermostat. ---------------------------------4
5.2. Mounting of Joint Plate -----------------------------------4
5.3. Mounting of Pilot Lamp-----------------------------------5
5.4. Important assembly point --------------------------------5
6 Caution/hints on repairs----------------------------------------5
7 Standard Temperature Setting--------------------------------6
8 Troubleshooting Guide -----------------------------------------7
9 Exploded View and Replacement Parts List-------------8
9.1. Exploded View----------------------------------------------8
9.2. Packing Instruction ----------------------------------------9
9.3. Replacement Parts List---------------------------------10

2
1 Specifications
2 Wiring Connection Dia-
gram
3 Schematic Diagram
RATING AC220V - 1000W, AC240V - 1000W
WEIGHT 1.4kg
DIMENSIONS (D x W x H) 260mm X 129mm X 203.8mm
TEMP.CONTROL RANGE 85°C - 210°C
HANDLE COLOUR WHITE

3
4 Disassembly Instructions
4.1. Removal of Rear Handle Cover
Step 1 Remove the screw indicated and then pull the Rear
Handle Cover.
Step 2 Disconnect the screws indicated slowly.
Caution: Do not pull the terminal tips of the Lead wires.
4.2. Removal of Pilot Lamp
Step 1 Remove the screws holding the Pilot Lamp from the ter-
minal.
4.3. Removal of Dial Knob
Step 1 Insert thin screwdriver lightly in the right and left sides (2
places) of the dial knob. Pressing the handles of both screw
drivers downward make the dial knob come off the handle of
the iron.
4.4. Removal of Handle
Step 1 Remove 2 screws indicated and lift handle.
Step 2 Remove the Contact Pin B together with the washer
before removing the handle.

4
4.5. Removal of Iron Weight (For
model NI-100DX)
Step 1 Remove 3 screws indicated and lift the iron weight.
4.6. Removal of Rating Plate
Step 1 Remove 2 screws indicated and pull backward.
4.7. Removal of Cover Shell, Han-
dle and Lamp Cover
Caution: The cover shell, handle and lamp cover are not
required to be removed unless they are defective.
Step 1 Remove 3 screws indicated and lift the handle. After
remove the cover from the handle, the lamp cover can be
removed from the handle by pressing the lamp cover.
5 Reassembly Instructions
•Reassemble the parts in the reverse order of disassem-
bly.
5.1. Mounting of Thermostat.
Step 1 Tighten each screw firmly. It should be especially fol-
lowed for the thermostat. If the screws are not properly tighten,
it may cause temperature failure.
Caution: Set the thermostat stopper as shown. If setting is
wrong, it may cause a temperature failure.
5.2. Mounting of Joint Plate
Step 1 Be sure to mount the Joint Plate to a thermostat axis
without fail. The dial knob cannot be mounted without this part.

5
5.3. Mounting of Pilot Lamp
Step 1 Properly wire the lead wire E, F and pilot lamp and
screw tightly. Push the lead wire E and F upward and insert.
Mount the rear handle cover.
Caution: If the cord is not fixed in the cord slots, it may be
damaged.
Fix the Contact Pin B together with the washer.
5.4. Important assembly point
Step 1 Wiring screw M3.5 x 5 and M3.5 Washer must be fixed
before using the Stand assembly.
6 Caution/hints on repairs

6
7 Standard Temperature Setting
Step 1 Attach Ohm Meter Probe across both Plug Prongs.
Step 2 Turn the Dial Knob, if the Meter Needle deflect while the Dial Knob is within the Range shown by arrows (A) and (B) then
Iron is Working Normal.
Step 3 If the Meter Needle Deflects before point (A) or after point (B), proceed to step 4.
Step 4 Turn the Dial Knob to “Maximum” Position and Remove Fabric Guide Plate.
(After Removing the Dial Knob the Adjusting Screw can be seen)
Step 5a If the Dial Knob causes the meter to deflect after point (B), turn the Adjusting Screw Anti-Clockwise.

7
Step 5b If the Dial Knob causes the meter to deflect before point (A), turn the Adjusting Screw Clockwise.
Step 6 After Adjusting, check the Setting Range (Step 3).
Step 7 Adjust Till the Needle Deflects within the Range shown by arrows (A) and (B).
Caution: Thermostat with Arrontite cannot be adjust.
8 Troubleshooting Guide

8
9 Exploded View and Replacement Parts List
9.1. Exploded View
9A
9B
26A

9
9.2. Packing Instruction
P4
P6
P2
P5
P6
P1
P3

10
9.3. Replacement Parts List
Safety Ref. No. Part No. Part Name & Description Qty Remarks
1 i1084KKA240A SOLEPLATE COMPLETE ASS'Y 1 AC240V-1000W (M'sia, S'pore, Kuwait)
(1) i1064KKA240A SOLEPLATE COMPLETE ASS'Y 1 AC220V-1000W (Thai, UAE, Oman, Qatar, S.Arabia, Korea)
2 i6264Y-SH32A RATING PLATE 1 AC240V - 100W (M’sia)
(2) i6164Y-QH32A RATING PLATE 1 AC230V - 100W (S’pore)
(2) i6244Y-TH32A RATING PLATE 1 AC220V - 100W (Thai)
(2) i6244Y-QH32A RATING PLATE 1 AC220V - 100W (UAE, Qatar, Oman)
(2) i6264Y-QH32A RATING PLATE 1 AC240V - 100W (Kuwait)
(2) i6244Y-RH32A RATING PLATE 1 AC220V - 100W (S.Arabia, Korea)
3 i4800K-M240A THERMOSTAT ASS’Y 1
4 XSB35+5FN5 WIRING SCREW 8 3 PIN Type
(4) XSB35+5FN5 WIRING SCREW 6 2 PIN Type
5 i90200-0069 COVER SHELL SCREW 2
6 i5600K-0064A PILOT LAMP 1 200V CLASS
7 i56600DC151A LAMP 1
8 i23200-0240B COVER SHELL 2
9a XTN4+12BFN HANDLE SCREW A 2
9b XTW4+16BFN HANDLE SCREW A 1
10 i2020KWKH32B REAR HANDLE COVER 1 White - 3 PIN Type
(10) i2020KWKH41B REAR HANDLE COVER 1 White - 2 PIN Type
11 XTN3+30BFN REAR HANDLE COVER SCREW 1
12 i2830K-0H32A CONTACT PIN HOLDER ASS’Y 1 3 PIN Type
(12) i2830K-0H41A CONTACT PIN HOLDER ASS’Y 1 2 PIN Type
13 XTW3+10PFN CONTACT PIN HOLDER ASS’Y SCREW 1
14 i90200-0035A RATING PLATE SCREW 2
15 i90200-0036A THERMO SCREW A 1
16 i90200-0023A THERMO SCREW B 1
17 XWA4BFF SPRING LOCK WASHER 2
18 i23030-0242A IRON WEIGHT 1 (M’sia, S’pore, Thai, UAE, Oman, Kuwait, Qatar)
19 i90200-0025A IRON WEIGHT SCREW 3
22 XTW3+10BFU CONTACT SPRING HOLDER SCREW 2
23 i20000WK242B HANDLE 1 White
24 i2187KWKH32A DIAL KNOB ASS'Y 1 (M’sia, S’pore, Thai, Korea)
(24) i2188KWKH32A DIAL KNOB ASS'Y 1 (UAE, Oman, Kuwait, Qatar, S.Arabia)
26 i2850KWKH32B STAND ASS'Y 1 3 PIN Type - White (M’sia)
(26) i2850KWKH41B STAND ASS'Y 1 3 PIN Type - White (S’pore)
(26) i2850KWKH42C STAND ASS'Y 1 3 PIN Type - White (Thai)
(26) i2850KWKH43B STAND ASS'Y 1 2 PIN Type - White (UAE, Oman, Qatar)
(26) i2850KWKH56B STAND ASS'Y 1 3 PIN Type - White (Kuwait)
(26) i2850KWKH87B STAND ASS'Y 1 3 PIN Type - White (S.Arabia)
(26) i2850KWKH69B STAND ASS'Y 1 3 PIN Type - White (Korea)
26a i28500WKH32A STAND ASS'Y 1 3 PIN Type - White
27 i28720-0H32A STAND COVER 1 3 PIN Type (M’sia)
(27) i28720-0H56A STAND COVER 1 3 PIN Type (Kuwait)
(27) i28720-0H43A STAND COVER 1 2 PIN Type (UAE, Qatar, Oman)
(27) i28720-0H42A STAND COVER 1 3 PIN Type (Thai)
(27) i28720-0H41A STAND COVER 1 3 PIN Type (S’pore)
(27) i28720-0H87A STAND COVER 1 3 PIN Type (S.Arabia, Korea)
28 XTN4+12BFN STAND COVER SCREW 4
29 i28190-0H32A ROLLER HOLDER 1
30 i2818KKA391B ROLLER ASS'Y 1
31 i28640ZL159A ROLLER COVER 1
32 J33A53000 RUBBER LEGS 2
33 i28540WKH32A SHUTTER 1
34 i28330-0H32A CONTACT SPRING HOLDER 1
35 XTN3+10BFU CONTACT SPRING SCREW 2 2 PIN Type
(35) XTN3+10BFU CONTACT SPRING SCREW 3 3 PIN Type
36 i48100-0240A JOINT PLATE 1
37 XWA35BFF SPRING LOCK WASHER 3
38 i2834K-0H32A CONTACT SPRING A ASS’Y 2
39 i2835K-0H32A CONTACT SPRING B ASS’Y 1 3 PIN Type
39 i2832K-0H32A CONTACT PIN B 1 3 PIN Type
Packing List
P1 i4M941007A POLYBAG 2
P2 i84010-0H32A INSULATION A 1
P3 i84020-0H32A INSULATION B 1
P4 i82000-0H32B INSTRUCTION MANUAL 1 M’sia
(P4) i82000-DH41A INSTRUCTION MANUAL 1 S’pore, Thai, Korea
(P4) i82000-0H41B INSTRUCTION MANUAL 1 UAE, Oman, Qatar, S.Arabia, Kuwait
(P5) i8100Y-HX32A INNER CARTON BOX 1 M’sia
(P5) i8100Y-XH41A INNER CARTON BOX 1 Other
P6 4M9120210A TOP INSULATION 3
