ORDER NO. CPD0310021A1
Notebook Computer
CF-73
Model Number Reference
The following models are numbered in accordance with the types of CPU, LCD and HDD etc. featured by product.
Model No. CF-731234X56
1: CPU type
J: Intel® Pentium®M Processor 1.6 GHz
2: LCD type
C: 13.3-type TFT with Touch Screen
3: HDD type / RAM size
Q: 60 GB / 512 MB
4: Drive / Modem –LAN
T: DVD-ROM & CD-R/RW Drive (Combo Drive) / Wireless LAN
5: Operation System
D: Microsoft® Windows® 2000
K: Microsoft® Windows® XP Professional
6: Area
M: Refer to above area table
This is the Service Manual for
the
following areas.
M …for U.S.A. and Canada

Replacement Parts List Comparison Table
CF-73JCQTXxM Q'T
Y
CF-73ECQTXxM CF-73JCQTXxM
Main Block Unit
E 1 DL3U11256GAA DL3U11256KAA PCB, MAIN RTL 1
E 3 DL3U11258AAA DL3U11258BAA PCB, FRONT RTL 1
E 4 DL3U21258AAA DL3U21258BAA PCB, REAR RTL 1
E 5 DL3U31258AAA DL3U31258BAA PCB, LED RTL 1
E 6 DL3U41258AAA DL3U41258BAA PCB, I/O RTL 1
E 7 DL3U61258AAA DL3U61258BAA PCB, SPEAKER L RTL 1
E 8 DL3U71258AAA DL3U71258BAA PCB, SPEAKER R RTL 1
E 24 N3CABSD00001 N3CABSD00003 HDD 1
Mechanical Parts
K 16 DFMY5033ZB DFMY5033YA ASS'Y RHE 1
K275 -------- DFMY0354ZA HP THERMAL SHEET 1
K276 -------- DFHR8464ZA HP CUSHION 1
Accessories
A 5 DFQX5379WB DFQX5424ZA MANUAL 1
A11 DFHR9039ZA-0 DFHR9084ZA STYLUS PEN 1
Packing Material
P 6 DFPE0404ZA DFPE0753ZA HOLDER 1
Note: Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
REF. NO. and
AREA PART NO. DESCRIPTION

Replacement Parts List
CF-73JCQTXxM PART NO. DESCRIPTION Q'TY
C1 3 676 677 693 787 EEFCD0D101R CAPACITOR, 2V, 100µF 6
C1014182227323640444861
123 126 128 132 137 164 176 186
187 190 193 194 197 204 205 207
208 209 210 211 214 215 216 217
218 219 220 221 223 224 234 235
240 241 250 251 252 253 254 259
260 261 262 263 276 283 284 287
288 289 290 291 292 298 301 306
307 309 310 327 330 331 334 335
338 348 351 354 357 358 361 362
363 370 397 414 415 416 418 419
420 434 435 436 437 438 500 506
542 741
F1G1C104A042 CAPACITOR, 16V, 0.1µF 101
C172 173 F1G1H6R0A452 CAPACITOR, 50V, 6pF 2
C188 F1G1H7R0A452 CAPACITOR, 50V, 7pF 1
C189 F1G1H5R00004 CAPACITOR, 50V, 5pF 1
C199 407 F1G1C473A004 CAPACITOR, 16V, 0.047µF 2
C228 326 547 668 674 ECJ3YB1E106M CAPACITOR, 25V, 10µF 5
C243 244 246 247 299 300 F1G1H330A451 CAPACITOR, 50V, 33pF 6
C270 271 410 411 412 501 523 527
528 548 552 600 601 611 612 F1G1H102A496 CAPACITOR, 50V, 1000pF 15
C279 281 F1G1H8R0A452 CAPACITOR, 50V, 8pF 2
C295 F1L3D102A012 CAPACITOR, 2000V, 1000pF 1
C299 300 F1G1H470A451 CAPACITOR, 50V, 47pF 2
C339 340 341 342 343 344 345 346
507 508 731 F1J1E105A009 CAPACITOR, 25V, 1µF 11
C355 360 ECST1AC476R CAPACITOR, 10V, 47µF 2
C371 372 738 739 F4Z0J1570003 CAPACITOR, 6.3V, 150µF 4
C457891112131516171920
21 24 25 26 29 30 31 33 34 35 37 38
39 41 42 43 45 46 47 54 56 60 202
203 206 212 213 222 232 237 238
239 256 258 268 269 293 297 308
311 313 315 317 328 329 332 333
337 352 364 365 398 402 403 417
538 666 673
F1J0J106A013 CAPACITOR, 6.3V, 10µF 71
C409 F1G0J683A001 CAPACITOR, 6.3V, 0.068µF 1
C4951535563647274787982
86 88 90 91 94 95 168 183 185 257
278 314 323 324 325 367 408 423
539 704 726 733 742 743 744 746
779 794 797 799
F1G1E103A062 CAPACITOR, 25V, 0.01µF 41
Note: Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components use only manufacturer's specified parts.
Main PCB
REF. NO and AREA

C5052808384899399100105
111 117 165 166 180 225 226 229
233 236 316 318 319 320 321 374
377 378 394 426 427 428 429 430
431 432 433 609 615 648 649 660
661 691 707 784 786
F1J0J106A013 CAPACITOR, 6.3V, 10µF 47
C516 642 643 644 654 655 656 706
735 736 760 F1L1E106A017 CAPACITOR, 25V, 10µF 11
C520 541 546 556 617 667 670 672
729 732 762 764 796 F1H1H104A748 CAPACITOR, 50V, 0.1µF 13
C525 526 F1H1H152A748 CAPACITOR, 50V, 1500pF 2
C531 532 550 F1G1H220A451 CAPACITOR, 50V, 22pF 3
C544 F1G1H471A496 CAPACITOR, 50V, 470pF 1
C551 723 F4Z1A1070002 CAPACITOR, 10V, 100µF 2
C553 F1G1H152A450 CAPACITOR, 50V, 1500pF 1
C59 F1G1H222A450 CAPACITOR, 50V, 2200pF 1
C616 F1H1H223A783 CAPACITOR, 50V, 0.022µF 1
C627175768185969798101
102 103 104 106 107 108 109 110
112 113 114 115 116 118 119 122
127 131 135 136 138 139 141 142
145 147 148 151 152 153 154 155
156 157 158 159 160 161 162 163
167 169 170 171 174 175 177 178
179 200 227 230 231 249 286 294
296 347 356 359 373 375 376 379
380 381 382 383 384 385 387 391
396 401 421 422 614
F1G1C104A042 CAPACITOR, 16V, 0.1µF 87
C646 658 F1H1C334A072 CAPACITOR, 16V, 0.33µF 2
C647 659 669 F1J1C475A083 CAPACITOR, 16V, 4.7µF 3
C65 67 70 533 536 549 F1G1H221A495 CAPACITOR, 50V, 220pF 6
C650 651 662 663 EEFUD0D271XR CAPACITOR, 2V, 270µF 4
C66 87 92 120 121 124 125 129 130
133 134 143 144 149 150 195 196
198 201 277 504 727 728 734 763
791
DCUM1A1051BD CAPACITOR, 10V, 1µF 26
C671 675 F1G1H821A450 CAPACITOR, 50V, 820pF 2
C697 F1H1H222A748 CAPACITOR, 50V, 2200pF 1
C701 F1J0J475A009 CAPACITOR, 6.3V, 4.7µF 1
C705 F1J1H224A533 CAPACITOR, 50V, 0.22µF 1
C722 F4Z1A107A002 CAPACITOR, 10V, 100µF 1
C73 272 273 274 275 302 303 368
369 399 400 545 F1G1H1010005 CAPACITOR, 50V, 100pF 12
C730 772 773 774 DCUI1C106HDB CAPACITOR, 16V, 10µF 4
C781 783 785 F4Z0J1570004 CAPACITOR, 6.3V, 150µF 3
CA1 2 EZASCE101M CAPACITOR ARRAY 2
CN10 K1KAG0A00011 CONNECTOR 1
CN11 K1FA109B0054 CONNECTOR 1
CN12 K1MN36B00019 CONNECTOR 1
CN13 K1KB40B00024 CONNECTOR 1
CN14 K1KA62B00002 CONNECTOR 1
CN15 K1KB30A00131 CONNECTOR 1
CN16 17 K1FB104B0033 CONNECTOR 2
CN18 K1KAC0A00041 CONNECTOR 1
CN19 DFJS243ZA012 CONNECTOR 1
CN2 K1MMZZB00002 CONNECTOR 1

CN20 K1KA84A00003 CONNECTOR 1
CN3 DFJP201ZA002 CONNECTOR 1
CN4 K1KBZZA00030 CONNECTOR 1
CN5 K1FB115B0093 CONNECTOR 1
CN6 K1NAF0D00002 CONNECTOR 1
CN600 K1KA10B00198 CONNECTOR 1
CN7 K1KA08B00137 CONNECTOR 1
CN9 K1MMC4B00007 CONNECTOR 1
D1248910 MA2J72900L DIODE 6
D15 16 22 640 MA3S132E0L DIODE 4
D20 21 B0KB00000035 DIODE 2
D3 652 655 659 B0JDBE000002 DIODE 4
D5671112131417232425631
632 633 MA3J14700L DIODE 14
D600 601 606 B0JCCE000002 DIODE 3
D604 B0JDAE000004 DIODE 1
D609 612 616 MA3S132D0L DIODE 3
D627 634 635 636 637 638 EC10QS04TL DIODE 6
D629 630 664 665 DEDRB081L20 DIODE 4
D641 B2ABAM000001 DIODE 1
D643 644 645 646 647 648 666 667
668 MAZ80620ML DIODE 9
D651 DEDSPB64SVR DIODE 1
D656 MA2S111-TX DIODE 1
D657 658 663 DEDF1J3ETP DIODE 3
D660 MAZ81200ML DIODE 1
D661 MAZ81800ML DIODE 1
F1 K5H2021A0003 FUSE, 63V, 2A 1
IC1 C2GBC0000190 IC, CPU 1
IC12 C1DB00000900 IC, PCMCIA CONTROLLER 1
IC13 C1DB00000902 IC, LAN CONTROLLER 1
IC14 C2CBHF000243 IC, EC 1
IC15 C1DB00000941 IC, SUPER I/O 1
IC17 C3FBKC000076 IC, FWH 1
IC18 C0JBZZ000299 IC, THERMAL SENSOR 1
IC19 C0JBZZ000300 IC, CLOCK GENERATOR 1
IC2 C1DB00001100 IC, MCH-M 1
IC20 DA2205IDBLET IC, BIPOLAR LOGIC 1
IC21 22 C0JBAZ001978 IC, QUICK LOGIC 2
IC24 DA7W66UT12L0 IC, CMOS 1
IC25 28 31 DA7SH08U85L0 IC, AND GATE 3
IC27 37 DA7W14UT12L0 IC, INVERTER 2
IC29 30 DA7ST08U85L0 IC, AND GATE 2
IC3 C1DB00001002 IC, ICH4-M 1
IC32 DA7S32UT85L0 IC, OR GATE 1
IC33 93LC46BT/SN IC, EEPROM 1
IC34 C0CBABC00140 IC, REGULATOR 1
IC35 36 ADM211EARSRL IC, RS232C TRANSCEIVER 2
IC4567891011 C3ABSG000001 IC, DDR SDRAM 8
IC40 41 C0DBZHG00004 IC, USB POWER CONTROL 2
IC42 43 44 C0EBE0000204 IC, VOLTAGE DETECTOR 3
IC600 C0DBAFH00019 IC, DC/DC CONTROLLER 1
IC601 C0DBALH00001 IC, DC/DC CONVERTER 1
IC602 614 C0DBZZZ00057 IC, DRIVER 2
IC605 616 C0DBAHH00009 IC, DC/DC CONVERTER 2
IC606 C0DBAFH00011 IC, DC/DC CONTROLLER 1
IC608 DA7W02UT12L0 IC, CMOS 1
IC609 DA7S14UT85L0 IC, INVERTER 1

IC613 C0DBDJH00007 IC, CHARGER 1
IC615 C0DBEGH00003 IC, REGULATOR 1
IC617 C0DBAZZ00039 IC, DC/DC CONVERTER 1
IC618 C0ABBA000093 IC, OP AMP 1
IC619 C0ABZA000036 IC, AMP 1
IC620 621 C0EBH0000216 IC, RESET 2
IC622 C0DBAKZ00005 IC, DC/DC CONTROLLER 1
L1234131415 J0JGC0000038 INDUCTOR 7
L12 G5BYC0000008 INDUCTOR 1
L16 17 19 20 21 22 23 24 28 29 J0JHC0000074 INDUCTOR 10
L25 26 J0MAB0000116 INDUCTOR 2
L5678 J0JCC0000186 INDUCTOR 4
L600 612 G1CR60ZA0045 INDUCTOR 2
L601 G1C6R8ZA0044 INDUCTOR 1
L602 G1C4R7ZA0044 INDUCTOR 1
L604 G1C4R7MA0022 INDUCTOR 1
L608 611 DDAZS100MT3T INDUCTOR 2
L610 G1A160H00001 INDUCTOR 1
L613 614 G1C4R7MA0077 INDUCTOR 2
L615 G1C220MA0077 INDUCTOR 1
L9 10 11 DDB5Z034A-Y INDUCTOR 3
PS1 2 ERY32SA120VA POLY SW 2
Q1 2 DETU3904T106 TRANSISTOR 2
Q25 30 33 601 671 676 690 691 707
712 727 728 UNR9113J0L TRANSISTOR 12
Q3 4 24 600 654 673 701 702 706 DA3LN01STL TRANSISTOR 9
Q5 15 16 34 627 629 631 632 633
634 635 636 661 664 665 666 669
670 677 678 679 680 692 698 711
714 715 730 732
UNR9213J0L TRANSISTOR 29
Q6 8 12 13 14 23 29 704 705 B1DHDC000021 TRANSISTOR 9
Q603 607 618 619 693 694 DAFDS6690A TRANSISTOR 6
Q604 605 608 609 B1DFGC000001 TRANSISTOR 4
Q612 613 622 623 628 630 DAFDS6912A TRANSISTOR 6
Q617 663 708 722 723 724 DAFDN359AN TRANSISTOR 6
Q625 626 B1GKCFJN0004 TRANSISTOR 2
Q651 652 672 675 683 684 687 689
697 UNR9214J0L TRANSISTOR 9
Q653 B1MBEDA00007 TRANSISTOR 1
Q667 718 720 XP0331200L TRANSISTOR 3
Q674 700 B1DDDC000002 TRANSISTOR 2
Q681 682 685 686 717 B1DDED000002 TRANSISTOR 5
Q695 XP0421400L TRANSISTOR 1
Q699 710 B1DHGC000005 TRANSISTOR 2
Q7 10 11 17 18 19 21 27 31 32 713 XP0421300L TRANSISTOR 11
Q703 709 716 726 731 B1CFGD000004 TRANSISTOR 5
Q9 B1ADKD000004 TRANSISTOR 1
R1 ERJ2GEJ681X RESISTOR, 1/16W, 680Ω1
R100 101 102 104 105 110 147 149
151 162 164 166 174 175 178 193
194 207 218 247 253 254 268 285
292 295 296 297 298 515 516 529
530 551 574
ERJ2GEJ473X RESISTOR, 1/16W, 47KΩ35
R108 109 111 114 125 169 179 204
222 223 224 225 226 239 246 541
542
ERJ2GEJ104X RESISTOR, 1/16W, 100KΩ17
R11 28 30 ERJ2GEJ331X RESISTOR, 1/16W, 330Ω3

R12 47 113 119 120 129 281 ERJ2GEJ560X RESISTOR, 1/16W, 56Ω7
R121 123 131 177 202 213 214 217
244 248 249 250 271 286 287 528
532 534 543 549 550 570 571 575
607 653 659 783 794 797
ERJ2GE0R00X RESISTOR, 1/16W, 0Ω30
R128 ERJ2RKF22R6X RESISTOR, 1/16W, 22.6Ω1
R130 ERJ2GEJ470X RESISTOR, 1/16W, 47Ω1
R132 133 ERJ3GEYJ106V RESISTOR, 1/16W, 10MΩ2
R134 135 234 265 513 552 747 ERJ2GEJ472X RESISTOR, 1/16W, 4.7KΩ7
R136 ERJ2RKF1803X RESISTOR, 1/16W, 180KΩ1
R157 158 159 ERJ3EKF75R0V RESISTOR, 1/16W, 75Ω3
R182 243 567 568 569 675 676 709
710 711 713 714 787 788 ERJ2GEJ105X RESISTOR, 1/16W, 1MΩ14
R186 ERJ2RKF5601X RESISTOR, 1/16W, 5.6KΩ1
R191 637 643 742 759 ERJ3GEY0R00V RESISTOR, 1/16W, 0Ω5
R192 195 196 650 774 ERJ2RKF1002X RESISTOR, 1/16W, 10KΩ5
R144 163 181 215 220 232 233 784
786 ERJ2GEJ101X RESISTOR, 1/16W, 100Ω9
R241 511 519 581 582 753 ERJ2GEJ474X RESISTOR, 1/16W, 470KΩ6
R25 44 45 596 ERJ2RKF1001X RESISTOR, 1/16W, 1KΩ4
R256 507 573 652 ERJ2GEJ223X RESISTOR, 1/16W, 22KΩ4
R258 259 260 261 262 ERJ2GEJ333X RESISTOR, 1/16W, 33KΩ5
R26 ERJ2RKF2001X RESISTOR, 1/16W, 2KΩ1
R27 184 536 538 539 750 ERJ2GEJ562X RESISTOR, 1/16W, 5.6KΩ6
R29 ERJ2GEJ132X RESISTOR, 1/16W, 1.3KΩ1
R3 16 17 38 39 ERJ2RKF27R4X RESISTOR, 1/16W, 27.4Ω5
R31 ERJ2RKF30R1X RESISTOR, 1/16W, 30.1Ω1
R32 34 ERJ2RKF3010X RESISTOR, 1/16W, 301Ω2
R33 35 115 116 ERJ2RKF1500X RESISTOR, 1/16W, 150Ω4
R36 92 93 94 95 185 187 188 189 ERJ2RKF49R9X RESISTOR, 1/16W, 49.9Ω9
R37 ERJ2RKF1000X RESISTOR, 1/16W, 100Ω1
R40 41 112 ERJ2RKF36R5X RESISTOR, 1/16W, 36.5Ω3
R43 ERJ2GEJ220X RESISTOR, 1/16W, 22Ω1
R4849505152535455565758
171 172 562 563 660 661 ERJ2GEJ100X RESISTOR, 1/16W, 10Ω17
R5 18 19 ERJ2RKF54R9X RESISTOR, 1/16W, 54.9Ω3
R501 502 503 504 505 506 531 584
585 589 590 592 ERJ3GEYJ101V RESISTOR, 1/16W, 100Ω12
R509 510 ERJ6GEYJ222V RESISTOR, 1/10W, 2.2KΩ2
R514 522 ERJ2RHD473X RESISTOR, 1/16W, 47KΩ2
R517 518 545 554 ERJ2GEJ564X RESISTOR, 1/16W, 560KΩ4
R520 524 ERJ2RHD104X RESISTOR, 1/16W, 100KΩ2
R521 525 636 638 642 644 ERJ3GEYJ3R3V RESISTOR, 1/16W, 3.3Ω6
R523 526 ERJ2RHD333X RESISTOR, 1/16W, 33KΩ2
R535 RL1220SR47F RESISTOR, 1/4W, 0.47Ω1
R544 ERJ3GEYJ562V RESISTOR, 1/16W, 5.6KΩ1
R546 553 D0HA103ZA001 RESISTOR, 1/16W, 10KΩ2
R556 558 565 566 701 D1BDR0470002 RESISTOR, 1/8W, 0.047Ω5
R557 583 702 703 705 706 758 D1BDR0330001 RESISTOR, 1/8W, 0.033Ω7
R560 657 ERJ2GEJ153X RESISTOR, 1/16W, 15KΩ2
R577 743 744 745 RL1220SR10F RESISTOR, 1/4W, 0.1Ω4
R579 ERJ2RKF3902X RESISTOR, 1/16W, 39KΩ1
R580 ERJ2RKF1102X RESISTOR, 1/16W, 11Ω1
R59 60 ERJ2RKF1200X RESISTOR, 1/16W, 120Ω2
R6 ERJ2RKF39R2X RESISTOR, 1/16W, 39.2Ω1

R600 606 608 ERJ3EKF2150V RESISTOR, 1/16W, 215Ω3
R601 603 610 611 ERJ3EKF1100V RESISTOR, 1/16W, 110Ω4
R604 ERJ3EKF4531V RESISTOR, 1/16W, 4.53KΩ1
R605 ERJ3EKF7501V RESISTOR, 1/16W, 7.5KΩ1
R609 ERJ3EKF5101V RESISTOR, 1/16W, 5.1KΩ1
R61 173 DBT10KC1513P THERMISTOR 2
R612 658 681 708 ERJ3GEYJ100V RESISTOR, 1/16W, 10Ω4
R613 ERJ3EKF5103V RESISTOR, 1/16W, 510KΩ1
R614 ERJ3EKF5361V RESISTOR, 1/16W, 5.36KΩ1
R62 67 106 107 118 126 154 155
160 161 165 167 168 200 205 206
227 228 229 231 236 237 240 242
269 284 289 290 291 293 301 302
537 547 548 561 564 578 593 599
615 616 651 740 776 779
ERJ2GEJ103X RESISTOR, 1/16W, 10KΩ46
R634 639 ERJM1WSF3M0U RESISTOR, 1W, 3MΩ2
R64 65 66 141 142 143 170 180 235
252 ERJ2GEJ102X RESISTOR, 1/16W, 1KΩ10
R649 674 ERJ2RKF2002X RESISTOR, 1/16W, 20KΩ2
R655 773 ERJ2RKF4701X RESISTOR, 1/16W, 4.7KΩ2
R656 ERJ2RKF1502X RESISTOR, 1/16W, 15KΩ1
R673 ERJ2RKF2402X RESISTOR, 1/16W, 24KΩ1
R68 183 ERJ2GEJ221X RESISTOR, 1/16W, 220Ω2
R7 ERJ2GEJ151X RESISTOR, 1/16W, 150Ω1
R70 ERJ2RKF4750X RESISTOR, 1/16W, 475Ω1
R700 707 ERJ2GEJ224X RESISTOR, 1/16W, 220KΩ2
R7174757677787980818283
84 85 86 87 88 89 90 91 103 ERJ2GEJ330X RESISTOR, 1/16W, 33Ω20
R712 ERJ2GEJ824X RESISTOR, 1/16W, 820KΩ1
R746 RL1220SR15F RESISTOR, 1/16W, 0.15Ω1
R752 ERJ2GEJ154X RESISTOR, 1/16W, 150KΩ1
R754 755 D0HA302ZA001 RESISTOR, 1/16W, 3KΩ2
R756 ERJ2RKD114X RESISTOR, 1/16W, 110KΩ1
R757 D1BA3652A005 RESISTOR, 1/16W, 36.5KΩ1
R760 ERA3EKB1623V RESISTOR, 1/16W, 162KΩ1
R761 ERA3EEB1692V RESISTOR, 1/16W, 16.9KΩ1
R777 ERJ2RKF1203X RESISTOR, 1/16W, 120KΩ1
R778 ERJ2RKF1503X RESISTOR, 1/16W, 150KΩ1
R790 791 D0HB154ZA002 RESISTOR, 1/16W, 150KΩ2
R792 789 D0HA104ZA001 RESISTOR, 1/16W, 100KΩ2
R795 D1ZZ00000046 RESISTOR, 1W, 5MΩ1
RA12345678910 D1HG1008A001 RESISTOR ARRAY 10
RA11 12 13 14 15 16 17 18 19 20 21
22 23 D1HA56080001 RESISTOR ARRAY 13
RA24 29 30 34 49 D1H84734A024 RESISTOR ARRAY 5
RA25 26 27 28 32 35 37 38 48 DEARA8AJ103M RESISTOR ARRAY 9
RA31 D1H87504A024 RESISTOR ARRAY 1
RA33 46 50 D1H81034A024 RESISTOR ARRAY 3
RA36 47 D1H81044A024 RESISTOR ARRAY 2
RA40 41 42 D1H82204A024 RESISTOR ARRAY 3
RA43 44 DEARA8AJ472M RESISTOR ARRAY 2
RA45 D1H81014A024 RESISTOR ARRAY 1
X1 H0J143500040 OSCILLATOR, 14.31818MHz 1
X2 H0J327200051 OSCILLATOR, 32.768KHz 1
X3 H0J250500025 OSCILLATOR, 25MHz 1
X5 H2D800400015 OSCILLATOR, 8MHz 1

C800 801 804 807 808 811 812 813
814 866 867 868 869 870 872 892
893 896 900 902 904 906 907 939
941 952
F1J0J106A013 CAPACITOR, 6.3V, 10µF 26
C802 809 810 815 816 817 821 822
824 825 826 828 830 831 832 833
834 837 838 839 840 871 873 874
875 876 877 878 879 880 881 882
883 884 885 886 887 888 889 890
891 894 895 897 898 899 903 905
908 909 928 933 953 954
F1G1C104A042 CAPACITOR, 16V, 0.1µF 54
C803 805 806 901 918 922 F1G1C104A042 CAPACITOR, 16V, 0.1µF 6
C819 820 919 920 921 923 924 925
926 927 F1G1H100A452 CAPACITOR, 50V, 10pF 10
C827 829 835 836 934 F1G1E103A062 CAPACITOR, 25V, 0.01µF 5
C865 942 943 EEFCD0D101R CAPACITOR, 2V, 100µF 3
C910 911 912 913 914 915 916 917 F1G1H102A496 CAPACITOR, 50V, 1000pF 8
C929 F1H1H472A748 CAPACITOR, 50V, 4700pF 1
C930 F1G1H471A496 CAPACITOR, 50V, 470pF 1
C931 F1G1H1010005 CAPACITOR, 50V, 100pF 1
C935 F1J0J475A009 CAPACITOR, 6.3V, 4.7µF 1
C936 F1H1H104A748 CAPACITOR, 50V, 0.1µF 1
C937 F1J1H224A533 CAPACITOR, 50V, 0.22µF 1
C938 ECJ3YB1E106M CAPACITOR, 25V, 10µF 1
C940 DCS0JTA151M CAPACITOR, 6.3V, 150µF 1
CN800 K1KAZZA00021 CONNECTOR 1
CN801 K1KA20B00112 CONNECTOR 1
CN802 K1MN13B00073 CONNECTOR 1
CN803 K1MN16B00123 CONNECTOR 1
D800 B0JCCE000002 DIODE 1
D801 EC10QS04TL DIODE 1
D802 MAZ80620ML DIODE 1
F800 K5H2021A0003 FUSE, 63V, 2A 1
IC800 C1DB00000907 IC, VGA CONTROLLER 1
IC801 C0JBZZ000297 IC, CLOCK GENERATOR 1
IC802 803 C3ABQJ000018 IC, MEMORY 2
IC804 DA7S14UT85L0 IC, INVERTER 1
IC805 C0DBAFH00011 DC/DC CONTROLLER 1
IC806 C0DBEGH00003 IC 1
L800 801 802 803 804 805 806 808 J0JGC0000038 INDUCTOR 8
L807 G1C4R7MA0022 INDUCTOR 1
Q800 UNR9213J0L TRANSISTOR 1
Q801 B1DHDC000021 TRANSISTOR 1
Q802 803 B1CFGD000004 TRANSISTOR 2
Q804 806 DAFDS6690A TRANSISTOR 2
Q805 XP0421300L TRANSISTOR 1
R801 802 810 819 843 861 862 879
881 ERJ2GEJ103X RESISTOR, 1/16W, 10KΩ9
R804 848 ERJ2GEJ470X RESISTOR, 1/16W, 47Ω2
R805 840 841 844 845 ERJ2RKF1001X RESISTOR, 1/16W, 1KΩ5
R806 818 842 ERJ2GEJ220X RESISTOR, 1/16W, 22Ω3
R807 838 ERJ2GEJ102X RESISTOR, 1/16W, 1KΩ2
R809 ERJ2RKF4990X RESISTOR, 1/16W, 499Ω1
VGA PCB

R832 833 857 ERJ2GEJ330X RESISTOR, 1/16W, 33Ω3
R834 836 ERJ2GEJ222X RESISTOR, 1/16W, 2.2KΩ2
R835 873 ERJ2GEJ105X RESISTOR, 1/16W, 1MΩ2
R837 ERJ2GEJ331X RESISTOR, 1/16W, 330Ω1
R839 ERJ3GEYJ100V RESISTOR, 1/16W, 10Ω1
R846 847 851 852 ERJ2RKF1200X RESISTOR, 1/16W, 120Ω4
R849 850 ERJ2GEJ472X RESISTOR, 1/16W, 4.7KΩ2
R853 854 855 856 863 869 872 ERJ2GE0R00X RESISTOR, 1/16W, 0Ω7
R860 ERJ2GEJ104X RESISTOR, 1/16W, 100KΩ1
R864 D0HA103ZA001 RESISTOR, 1/16W, 10KΩ1
R865 D0HA183ZA001 RESISTOR, 1/16W, 18KΩ1
R868 ERJ2GEJ223X RESISTOR, 1/16W, 22KΩ1
R871 ERJ2RKF5601X RESISTOR, 1/16W, 5.6KΩ1
R875 ERJ2GEJ100X RESISTOR, 1/16W, 10Ω1
R878 ERJ3GEYJ472V RESISTOR, 1/16W, 4.7KΩ1
RA800 801 802 803 804 805 806 807 DEARA8CJ330M RESISTOR ARRAY 8
RA816 817 818 819 D1H83304A024 RESISTOR ARRAY 4
X800 H0J270500050 OSCILLATOR, 27MHz 1
REAR PCB
C1000 1003 1004 1013 1023 1025
1109 F1H1H103A748 CAPACITOR, 50V, 0.01µF 7
C1001 1072 1074 1075 F1L1E106A017 CAPACITOR, 25V, 10µF 4
C1002 1008 1057 1070 1078 F1J0J106A013 CAPACITOR, 6.3V, 10µF 5
C1007 1011 1014 1016 1027 1032
1056 1060 1063 1066 1077 1093
1100 1105 1107
F1H1H104A748 CAPACITOR, 50V, 0.1µF 15
C1009 1012 1104 F1H1H102A748 CAPACITOR, 50V, 1000pF 3
C1010 1015 1018 1019 1024 1026
1061 1094 1097 1101 1102 1103 F1H0J224A002 CAPACITOR, 6.3V, 0.22µF 12
C1022 1028 1053 1089 DCUM1A1051BD CAPACITOR, 10V, 1µF 4
C1054 1055 F1H1H101A737 CAPACITOR, 50V, 100pF 2
C1062 1065 F1H1H102A737 CAPACITOR, 50V, 1000pF 2
C1064 F1H1H222A748 CAPACITOR, 50V, 2200pF 1
C1068 F1H1H221A748 CAPACITOR, 50V, 220pF 1
C1079 1080 1081 1082 F1H1H104A731 CAPACITOR, 50V, 0.1µF 4
C1086 1087 F4Z1A107A002 CAPACITOR, 10V, 100µF 2
C1088 1090 F1H1A474A028 CAPACITOR, 10V, 0.47µF 2
C1091 ECST1CY105R CAPACITOR, 16V, 1µF 1
C1095 1099 ERJ3GEY0R00V RESISTOR, 1/16W, 2
C1096 1098 F1H1H272A748 CAPACITOR, 50V, 2700pF 2
C1106 1108 ECST0JC476R CAPACITOR, 6.3V, 47µF 2
CA1000 1001 EZASCE101M CAPACITOR ARRAY 2
CN1000 K1KBC0A00056 CONNECTOR 1
CN1001 1003 DFJP201ZA005 CONNECTOR 2
CN1002 K1KA08B00137 CONNECTOR 1
CN1005 DFJP02C75YAJ CONNECTOR 1
CN1006 K1KA09B00048 CONNECTOR 1
D1000 DEDEC31QS03L DIODE 1
D1002 MAZ81800ML DIODE 1
D1003 1004 DEDF1J3ETP DIODE 2
F1000 K5H2021A0003 FUSE, 63V, 2A 1
F1001 K5H1021A0003 FUSE, 63V, 1A 1
F1002 K5H2021A0003 FUSE, 63V, 2A 1
IC1000 C1BB00000773 IC, AC97 CODEC 1
IC1001 C0CBCBD00005 IC, REGULATOR 1
IC1005 DA7W14UT12L0 IC, INVERTER 1
IC1006 1009 C0ABBA000075 IC, OP AMP 2

IC1007 C0DBAZZ00052 IC, REGULATOR 1
IC1008 C1BB00000776 IC, HEADPHONE AMP 1
IC1010 DA7W66UT12L0 IC, OP AMP 1
IC1011 C1BB00000293 IC, DETECTOR 1
JK1000 1001 DFJJD6S10ZAG JK 2
JK1002 K2EZ2B000039 JK 1
L1000 J0JGC0000038 INDUCTOR 1
L1001 1002 3000 J0JHC0000074 INDUCTOR 3
L1005 1006 1007 1008 1009 1010 J0JCC0000186 INDUCTOR 6
L1011 G1C4R7ZA0047 INDUCTOR 1
L1012 DDB5Z028C-L INDUCTOR 1
LD1000 1001 1002 1003 1004 1006 SEC1703C LED 6
LD1005 B3ACB0000097 LED 1
LD1007 SEC2764C LED 1
Q1000 1001 1002 1003 1004 1005 UNR9113J0L TRANSISTOR 6
Q1006 1007 1008 1013 1014 1015
1017 XP0421300L TRANSISTOR 7
Q1009 UNR9213J0L TRANSISTOR 1
Q1010 B1DFGD000013 TRANSISTOR 1
Q1011 DA3LN01STL TRANSISTOR 1
Q1018 B1DDED000002 TRANSISTOR 1
R1000 1001 1002 1003 1004 1006 ERJ3GEYJ331V RESISTOR, 1/16W, 330Ω6
R1005 1007 1048 ERJ3GEYJ471V RESISTOR, 1/16W, 470Ω3
R1045 1100 1101 1102 1103 ERJ3GEYJ102V RESISTOR, 1/16W, 1KΩ5
R1008 ERJ3GEYJ221V RESISTOR, 1/16W, 220Ω1
R1009 ERJ3GEYJ101V RESISTOR, 1/16W, 100Ω1
R1010 1011 1012 ERJ3GEYJ470V RESISTOR, 1/16W, 47Ω3
R1016 1018 1020 1024 1026 1047
1055 1059 1085 1104 1105 1112 ERJ3GEYJ103V RESISTOR, 1/16W, 10KΩ12
R1017 1032 1056 1057 1058 ERJ3GEYJ473V RESISTOR, 1/16W, 47KΩ5
R1027 1028 1054 1091 1093 ERJ3GEYJ223V RESISTOR, 1/16W, 22KΩ5
R1029 1060 1069 ERJ3GEYJ472V RESISTOR, 1/16W, 4.7KΩ3
R1046 1061 1067 1068 ERJ3GEYJ104V RESISTOR, 1/16W, 100KΩ4
R1049 1050 ERJ6GEYJ222V RESISTOR, 1/10W, 2.2KΩ2
R1051 1052 1077 1078 1081 1099 ERJ3GEY0R00V RESISTOR, 1/16W, 0Ω7
R1053 1092 1096 ERJ3GEYJ333V RESISTOR, 1/16W, 33KΩ3
R1062 ERJ3GEYJ100V RESISTOR, 1/16W, 10Ω1
R1063 ERJL14UJ30MU RESISTOR, 1/4W, 0.03Ω1
R1065 ERJ3EKF3902V RESISTOR, 1/16W, 39KΩ1
R1066 ERJ3EKF2201V RESISTOR, 1/16W, 2.2KΩ1
R1070 ERJ3GEYJ562V RESISTOR, 1/16W, 5.6KΩ1
R1072 1073 1074 1075 ERJ3GEYJ203V RESISTOR, 1/16W, 20KΩ4
R1086 1088 1090 1095 1098 ERJ3GEYJ153V RESISTOR, 1/16W, 15KΩ5
R1089 1094 ERJ3GEYJ224V RESISTOR, 1/16W, 220KΩ2
SW1000 1001 EVQPLDA15 SW 2
X1000 DECU01590003 OSCILLATOR, 24.576MHz 1
LED PCB
CN1300 DFJP217ZA005 CONNECTOR 1
LD1300 SEC2764C LED 1
LD1301 SEC1703C LED 1
Q1300 1301 XP0421300L TRANSISTOR 2
R1300 ERJ3GEYJ471V RESISTOR, 1/16W, 470Ω1
R1301 ERJ3GEYJ221V RESISTOR, 1/16W, 220Ω1
R1302 ERJ3GEYJ331V RESISTOR, 1/16W, 330Ω1
FRONT PCB
C1400 F1H1H104A748 CAPACITOR, 50V, 0.1µF 1
C1401 F1J0J106A013 CAPACITOR, 6.3V, 10µF 1
C1402 F1H1H103A748 CAPACITOR, 50V, 0.01µF 1
CN1400 1401 K1MN12B00115 CONNECTOR 2

R1400 ERJ3GEYJ101V RESISTOR, 1/16W, 100Ω1
SW1400 K0ZZ00000613 SW 1
SW1401 1402 EVQPLDA15 SW 2
SPEAKER L PCB
C1600 1601 F1H1C224A074 CAPACITOR, 16V, 0.22µF 2
C1602 F1L1C685A008 CAPACITOR, 16V, 6.8µF 1
C1603 F1H1H104A748 CAPACITOR, 50V, 0.1µF 1
C1605 1607 1609 1612 1613 F1L1E106A017 CAPACITOR, 25V, 10µF 5
C1611 F1H1H223A783 CAPACITOR, 50V, 0.022µF 1
CN1600 K1KA04B00137 CONNECTOR 1
CN1601 DFJP201ZA002 CONNECTOR 1
IC1600 C0ABZA000039 IC, POWER AMP 1
R1600 ERJ3GEYJ100V RESISTOR, 1/16W, 10Ω1
R1601 1602 ERJ1TYJ5R6U RESISTOR, 1W, 5.6Ω2
SPEAKER R PCB
C1700 1701 F1H1C224A074 CAPACITOR, 16V, 0.22µF 2
C1702 F1L1C685A008 CAPACITOR, 16V, 6.8µF 1
C1703 F1H1H104A748 CAPACITOR, 50V, 0.1µF 1
C1705 1707 1709 1712 1713 F1L1E106A017 CAPACITOR, 25V, 10µF 5
C1711 F1H1H223A783 CAPACITOR, 50V, 0.022µF 1
CN1700 K1KA04B00137 CONNECTOR 1
CN1701 DFJP201ZA002 CONNECTOR 1
IC1700 C0ABZA000039 IC, POWER AMP 1
R1700 ERJ3GEYJ100V RESISTOR, 1/16W, 10Ω1
R1701 1702 ERJ1TYJ5R6U RESISTOR, 1W, 5.6Ω2
I/O PCB
C3000 F1J0J106A013 CAPACITOR, 6.3V, 10µF 1
CA3000 3001 3002 3003 3004 3005 EZASCE181M CAPACITOR ARRAY 6
CA3006 3007 EZASCE101M CAPACITOR ARRAY 2
CN3000 K1MN36B00019 CONNECTOR 1
CN3001 K1FB136B0039 CONNECTOR 1
C1501 F1H1H103A748 CAPACITOR, 50V, 0.01µF 1
C1502 1503 1504 1505 F1H1H102A737 CAPACITOR, 50V, 1000pF 4
C1506 1507 F1H1H104A783 CAPACITOR, 50V, 0.1µF 2
CN1501 K1MN04B00003 CONNECTOR 1
CN1502 K1KA08B00137 CONNECTOR 1
D1501 MA2S111-TX DIODE 1
D1502 1503 1504 1505 MA3J14700L DIODE 4
IC1501 C1DB00001043 IC, TOUCH SCREEN CONTROLLER 1
L1501 1502 1503 1504 J0JCC0000186 INDUCTOR 4
Q1501 XP0411400L TRANSISTOR 1
R901 902 906 907 908 ERJ3GEYJ103V RESISTOR, 1/16W, 10KΩ5
R903 905 ERJ3GEYJ104V RESISTOR, 1/16W, 100KΩ2
R904 ERJ3GEYJ392V RESISTOR, 1/16W, 3.9KΩ1
RA1501 D1H81024A024 RESISTOR ARRAY 1
X900 H2D400400012 OSCILLATOR, 4MHz 1
TS PCB

E25
B
E9
E13
E3 K10
K33
E4
K77
K30
K34
E15
K25
K89
K18
K4
K90
E12
K24
K10
K95
K8
K30-2
K30-1
K30-1
K30-3
K30-4
E10
E11
K16
K88
K20
K25
K32
K85
K1
K31
K91
K13
K3
E5
K101
BK101
BK101
BK102
BK104
BK101
BK104
BK104
CK114
HK110
BK104 BK108
B
AK108
EK112
K81
K81 K80
E28
DK105
CK113
E21
K304
K86 E6
E27
K93
K47
BK108
BK102
K5
K88
K83
K74
K73
K79
K87
K300
K72
K27-2
K27-7
K27-6
K27-7
K27-1
K27
K82
K27-8
K27-9
K27-3
K27-5
K78
K17
K29
K27-4
K27-4
K6
E14
B
C
D
Screw tightening torque
0.2 ± 0.02 N · m
(2.0--± 0.2 kgf · cm)
0.1 ± 0.01 N · m
(1.0--± 0.1 kgf · cm)
0.4 ± 0.02 N · m
(4.0--± 0.2 kgf · cm)
E
H
0.17 ± 0.02 N · m
(1.7 -± 0.2 kgf · cm)
1.2 ± 0.1 N · m
(12.0- -± 1.0 kgf · cm)
Exploded View
CF-73JCQTXxM
Top Cabinet Section
K275

GE16-2
AK54
AK54
AK53 BK104
BK104
B
A
B
F
G
K104
BK101
BK101
BK104
FK103
FK103
K12
K94
K51
K69
K66
K52
K7
K26 E29
K21
K21
K21
K19
E16-1
K48
E16
K14 K22 E26
E1
A2
K15
K96
K49
E24
K28-4
K28-4
K28-1
K28-3
BK101
BK101
K28-2
K92
E2
E31
K65
E30-1
E30
K84
K28
K76
K75
K21
K67
K68
K50
K2
Screw tightening torque
0.13 ± 0.01 N · m
(1.3--± 0.1 kgf · cm)
0.2 ± 0.02 N · m
(2.0--± 0.2 kgf · cm)
0.8 ± 0.1 N · m
(8.0--± 1.0 kgf · cm)
0.1 ± 0.02 N · m
(1.0--± 0.2 kgf · cm)
A
K200
CF-73JCQTXxM
Bottom Cabinet Section
K276

B
Screw tightening torque
0.2 ± 0.02 N · m
(2.0--± 0.2 kgf · cm)
K45-6
K45-9
K45-5
K45-2
K45-7
K45-1
K45
E19
E23
K58
K40
K59
K44
K303
E22
K61
K63
a
K43
K43
K60
K61
K41
K56
K56
K64
E51-3
K99
K98
E20
E21
K55
E18
E42
K63
K63
K60
K46
E7
E8
E32
E50
K302
K301
E33
E33-1
E19
K58
K59
E23
K40
E32-1
K62
K62
K45-8
K45-3
K45-4
K45-8
BK104
BK115
BK115
BK108
BK109
BK109
BK104
BK101
BK115
BK115
FK45-12
FK45-12
K45-11
K45-11
F0.8 ± 0.1 N · m
(8.0--± 1.0 kgf · cm)
Display Section
CF-73JCQTXxM

E51-2-1
E51-2-2
E51-1
E51
E51-2-3
E51-2-5
E51-2-4
E51-2-4
E51-2
Display Section
CF-73JCQTXxM
a
E51-3
E51-2
