Panasonic Toughbook CF-Y7BWAZAJM User manual

Y7
Wireless, 14.1" LCD, Integrated DVD Multi Drive
■Full Magnesium Alloy Case
■Shock-mounted Hard Drive
■Drop- and Spill-resistant
■3.7 lbs.; Lightweight, Ultra-thin Design
■Mobile Broadband-ready Design
toughbook Y7
Panasonic recommends Windows Vista®Business.
toughbook

SOFTWARE •GenuineWindowsVista®Business(withXPdowngradeoption)
 •Setup,Diagnostic,DMIViewer,OnlineReferenceManual,Adobe®Reader,Hard
DiskDataEraseUtility,RecoveryDVD,WinDVD8,B’sRecorderGOLD9BASIC,
B’sCLiP7
CPU •Intel®CoreTM2DuoProcessorL7500
–4MBL2cache
–Processorspeed1.60GHz
–800MHzFSB
STORAGE & MEMORY •1024MBSDRAM(DDR2533)standard,expandableto2048MB*
(PC2-4200memoryisrequired)
 •80GBharddrive(shock-mountedandremovable**)
 •DVDSuperMULTIDrivewithDualLayerSupport
DISPLAY •14.1"1400x1050SXGA+TFTactivematrixcolorLCD
 •Externalvideosupportupto2048x1536at16.7millioncolors
 •Intel®GM965integratedvideocontrollermax.384MB(DVMT)VRAMonXP*
 •Anti-glarecoating
AUDIO •AnalogDevicesAD1884compliantaudiocodec
 •Intel®highdefinitionaudiocompliant
 •Integratedstereospeakers
 •Convenientkeyboardvolumecontrols(Fn+F5/F6keys)
EXPANSION SLOTS •PCcardtypeIIx1
 •SecureDigital(SDHC)cardx1
KEYBOARD & INPUT •87-keywithdedicatedWindows®key
 •Electrostatictouchpadwithverticalscrollingsupport
INTERFACE •Minidockboxreplicator 50-pin
 •Externalvideo D-sub15-pin
 •Headphones/speaker Mini-jackstereo
 •Microphone/linein Mini-jack
 •USB2.0(x2) 4-pin
 •10/100/1000Ethernet RJ-45
 •56KbpsModem RJ-11
WIRELESS •OptionalintegratedmobilebroadbandWWAN
 •Intel®WirelessWiFiLink4965AG802.11a/b/g
 •Bluetooth®v.2.0+EDR
 •Security
 –Authentication:LEAP,WPA,802.1x,EAP-TLS,EAP-FAST,PEAP
 –Encryption:CKIP,TKIP,128-bitand64-bitWEP,HardwareAES
 •Slideon/offswitch
POWER SUPPLY •Lithiumionbatterypack(10.65V,5700mAh)
 •Batteryoperation:5.5hours***
 •Batterychargingtime:approximately5hoursoff,6.5hourson***
 •ACAdapter:AC100V-240V50/60Hz,autosensing/switching
worldwidepowersupply
 •Pop-up,on-screenbatterystatusreporting
POWER MANAGEMENT •Suspend/ResumeFunction,Hibernation,Standby,ACPIBIOS
 •Economymode
SECURITY FEATURES •PasswordSecurity:Supervisor,User,HardDiskLock
 •Cablelockslot
 •Trustedplatformmodule(TPM)securitychipv.1.2
 •Computrace®theftprotectionagentinBIOS****
 •Fingerprintscanner(option)
WARRANTY •3-yearlimitedwarranty,partsandlabor
DIMENSIONS & WEIGHT •1.4"/1.8"(H)x12.2"(W)x10.0"(D)
 •3.7lbs.
Formoreinformation,call1.800.662.3537orvisit
usontheWebatpanasonic.com/toughbook.
Panasonicisconstantlyenhancingproductspecificationsandaccessories.Specificationssubject
tochangewithoutnotice.Trademarksarepropertyoftheirrespectiveowners.©2008Panasonic
CorporationofNorthAmerica.Allrightsreserved.
ssY702/08
Wireless, 14.1" LCD, Integrated DVD Multi Drive
toughbook Y7
■Full Magnesium Alloy Case
■Shock-mounted Hard Drive
■Drop- and Spill-resistant
■3.7 lbs.; Lightweight, Ultra-thin Design
■Mobile Broadband-ready Design
Y7
toughbook
 *Totalusablememorywillbelessdependinguponactualsystem
configuration.Vistamax.VRAMis251MBwith1GBofmemory,
or358MBwith1.5GBormoreofmemory.
 **Harddriveremovalshouldonlybeattemptedbyatechnicianwith
theproperequipment.
 ***Batteryperformancefeaturessuchaschargetimeandlifespancan
varyaccordingtotheconditionsunderwhichthecomputerandbattery
areused.Batteryoperationandrechargetimeswillvarybasedonmany
factors,includingscreenbrightness,applications,features,power
management,batteryconditioningandothercustomerpreferences.
BatterytestingresultsfromMobileMark2007.
****Requiressoftwareandactivationtoenabletheftprotection.
*****AccessoriesandIntegratedOptionsmayvarydependingonyour
notebookconfiguration.
 PleaseconsultyourresellerorPanasonicrepresentativebeforepurchasing.
Panasonic recommends Windows Vista®Business.
INTEGRATED OPTIONS*****
•MobileBroadbandSolutions
–EV-DORev.A
–HSDPA
•Fingerprintscanner
ACCESSORIES*****
•ACAdapter(3-pin) CF-AA1633AM
•ToughMateComUniversal
CarryingCase(largecapacity)  COMUNIV-P
•ToughMateBusiness-rugged
Top-loadingCase FM-BRTL-P
•ExternalUSBFloppyDrive CF-VFDU03U
•LithiumIonBatteryPack CF-VZSU45U
•MemoryCard
–1GB CF-WMBAY01G
•MiniDockBoxReplicator  CF-VEBU05BU
•LargeVenueDLPProjector  PT-DW5100U
•MobileLCDProjector  PT-LB60U
