Supplementary Instructions for
Fingerprint Reader
Personal Computer
Model No. CF-T8 Series
Names and Functions of Parts ................. 2
Overview ..................................................... 4
Installation .................................................. 5
Useful Information ..................................... 9
Troubleshooting....................................... 13
Contents
DFQX5729ZA HS0110-0
DFQX5712ZAW8F8T8OIVXPM.indd11DFQX5712ZAW8F8T8OIVXPM.indd11 2010/01/2213:03:362010/01/2213:03:36

2
Names and Functions of Parts
Except the following, refer to the Operating Instructions for the computer.
(Appearance may differ, depending on models.)
Fingerprint Reader
DFQX5712ZAW8F8T8OIVXPM.indd22DFQX5712ZAW8F8T8OIVXPM.indd22 2010/01/2213:03:372010/01/2213:03:37

3
This section explains how your fingerprints are enrolled and authenticated.
1Slide your finger toward yourself.
To prevent a reading error.
ASet the first joint of your index finger on the sensor as illustrated to the left.
BSlide your finger toward yourself while keeping it in contact with the
fingerprint sensor.
CSlide your finger down until the sensor is visible.
OK NG
When the fingerprint sensor does not enroll or authenticate your
fingerprint properly:
• You slid your finger too fast or too slow.
• Your finger was soiled or it has a scar on the surface.
• Your finger was wet or extremely dry.
• Your fingerprint does not have sufficient data for personal identification.
For further information, refer to “Troubleshooting (For Devices)”.
(Îpage 13)
We shall not be liable for any loss or damage whatsoever resulting
from your Fingerprint device or neglect of Fingerprint device use, or
any data loss resulting from such developments as Fingerprint au-
thentication device malfunctioning.
CAUTION
How to Use the Fingerprint Reader
It is strongly recommended to enroll at least two fingers.
NOTE
DFQX5712ZAW8F8T8OIVXPM.indd33DFQX5712ZAW8F8T8OIVXPM.indd33 2010/01/2213:03:372010/01/2213:03:37

4
Fingerprint’s Outline
The conventional security systems use ID/passwords and token devices such as
IC cards to authenticate users. Therefore the passwords and token devices are
exposed to the risk of being lost, stolen and hacking.
The Fingerprint authentication method uses user’s fingerprints instead of
passwords for security authentication. You can use your fingerprints to start up
your computer and log on Windows.
We recommend you use the Fingerprint Reader in combination with the TPM
(Trusted Platform Module) to increase the security level of your computer.
Precautions
Security Functions
Fingerprint Authentication Technology does not guarantee complete authenti-
cation and individual identification. Please acknowledge we shall not be liable
for any loss or damage whatsoever resulting from the use of, or inability to use
your Fingerprint device.
The Fingerprint authentication method uses multiple fingerprints, encryption
keys, credentials data and passwords. You might not be able to use your data if
you lose fingerprints, keys, credentials and passwords, so keep them in a safe
place. For further information, refer to “Backup”. (Îpage 9)
General interaction with 3rd party applications: There is no guarantee that
there will not be any negative interaction with any 3rd party software, and
will not accept any responsibility for such an interaction.
Overview
Performed by the Computer Administrator Performed by each user
Step 3
User Fingerprint Enrollment
User’s Data
• Windows Logon Password
• Fingerprint
• Fingerprint Backup Password
• Power-on Security
Step 1
TPM Installation ( Installation Manual of
“Trusted Platform Module (TPM)”)
(If the TPM is not being used, skip this step.)
(If the TPM is not being used, skip this step.)
Step 2
Fingerprint Utility Installation
Step 4
TPM Initialization
Recommended Installation Procedure
This manual describes Steps 2, 3and the initial part of Step 4.
DFQX5712ZAW8F8T8OIVXPM.indd44DFQX5712ZAW8F8T8OIVXPM.indd44 2010/01/2213:03:382010/01/2213:03:38

5
Installation
Step 1 TPM Installation
Refer to on-screen manuals Installation Manual of “Trusted Platform Module
(TPM)”. (<Model with Windows 7> Click (Start) and input “C:\util\drivers\tpm\
README.pdf”, and press
Enter
. / <Model with Windows XP> Click [start] - [Run],
input “C:\util\drivers\tpm\README.pdf”, and click [OK].)
If the TPM is not being used, skip this step.
Step 2 Fingerprint Utility Installation
Performed by the Computer Administrator.
1Log on to Windows as an Administrator.
2Close all other programs.
3<Model with Windows 7>
Click (Start) and input “C:\util\drivers\fngprint\install
\32-bit\setup.exe”, and press
Enter
.
<Model with Windows XP>
Click [start] - [Run], input “C:\util\drivers\fngprint\install
\32-bit\setup.exe”, and click [OK].
The “Protector Suite ∗.∗Setup” screen appears.
4Click [Next].
Installation starts. Follow the on-screen instructions.
5When the “Protector Suite ∗.∗has been successfully
installed.” message appears, click [Finish].
At the confirmation message, click [Yes].
The computer restarts.
6Log on to Windows as an Administrator.
The “Fingerprint software” icon appears.
“Getting Started with the Fingerprint Reader” may appear if you touch the
sensor before enrolling fingerprints.
NOTE
DFQX5712ZAW8F8T8OIVXPM.indd55DFQX5712ZAW8F8T8OIVXPM.indd55 2010/01/2213:03:382010/01/2213:03:38

6
Installation
Step 3 User Fingerprint Enrollment
Performed by each user.
1<Model with Windows 7>
Click (Start) - [All Programs] - [Protector Suite] - [Control
Center].
<Model with Windows XP>
Click [start] - [All Programs] - [Protector Suite] - [Control
Center].
2
Carefully read the License Agreement, and then click [Accept].
3<Model with Windows XP>
Click [Next].
4Select an enrollment mode, and click [Apply].
• Follow the on-screen instructions.
Enrollment mode
Fingerprint data is saved in either of two methods. A device to save fingerprint
data cannot be changed unless Fingerprint Utility is reinstalled.
• Enrollment to the biometric device
All enrolled fingerprints are stored directly to the sensor. The user data will
be secured by the hardware protection keys obtained by the fingerprint
sensor. There is a limit to the number of fingerprints that can be enrolled.
The numbers of fingers to register for the fingerprint sensor may vary
depending on the characteristics of fingers.
NOTE
• Enrollment to the hard disk
All enrolled fingerprints are stored on the hard disk. There are no limits for
the numbers of fingers to register, although there is a limit for the numbers
of those for Power-on security.
5Enroll your fingerprint following the on-screen instructions.
DFQX5712ZAW8F8T8OIVXPM.indd66DFQX5712ZAW8F8T8OIVXPM.indd66 2010/01/2213:03:392010/01/2213:03:39

7
Step 4 TPM Initialization
Performed by the Computer Administrator.
If the TPM is not being used, skip this step.
1<Model with Windows 7>
Click (Start) - [All Programs] - [Protector Suite] - [Control
Center].
<Model with Windows XP>
Click [start] - [All Programs] - [Protector Suite] - [Control
Center].
2Click [Settings] -[Advanced Settings] - [Trusted Platform
Module(TPM)].
3Click [Initialize].
When the initialization is successfully completed, and then click [OK].
4Start “Control Center” (Îpage 8), click [Identify] -
[Multifactor], and choose a method of authentication.
We recommend you use the Power-on Security feature. This feature
prevents unauthorized access to the user’s computer at the BIOS level.
A
Start “Control Center”. (Îpage 8)
BClick [Identify] - [Status].
CClick [Power-on security status] - [Change].
DClick [Edit], and Add the check mark to [Enable power-on security], and then
click [Apply].
E
Click [Identify] - [Power-on Password].
F
When the “Power-on Security” screen appears, click [Manage Passwords...].
GSelect [Power-On] in [Password Types], and click [Set password...].
HEnter the Power-On password, and click [OK].
IClick [Close].
JAdd a check mark for [Power-On] in [Password Types].
KEnter the Power-On password, and click [OK].
LClick [Apply].
DFQX5712ZAW8F8T8OIVXPM.indd77DFQX5712ZAW8F8T8OIVXPM.indd77 2010/01/2213:03:392010/01/2213:03:39

8
More Advanced Security
You can increase your computer’s security level by setting the BIOS level
described in this section.
There is [Fingerprint Security] in [Security] menu in the Setup Utility. Can be
changed only when [Set Supervisor Password] is set.
Sub-Menu Protection
You can change displayed or not displayed and enabled or
disabled of the Sub-Menu.
Not Protected
Protected
Power-on Security
Change Enable or Disable of Power-on Security (Îpage 7).
When the Power-on Security is set to [Disabled], the Power-on
Security does not function even if [Power-on Security] is set to
[Enabled] on the Setup Utility.
Disabled
Enabled
Security mode
You can start up Windows by sliding a registered finger when
[Simple] is set.
If you set [High], you have to enter Supervisor Password by
following authentication in Power-on Security.
It will not be displayed if Power-on Security is disabled.
Simple
High
Starting “Control Center” screen
1<Model with Windows 7>
Click (Start) - [All Programs] - [Protector Suite] - [Control
Center].
<Model with Windows XP>
Click [start] - [All Programs] - [Protector Suite] - [Control Center].
2Swipe your finger.
The “Fingerprint Control Center” screen appears.
You can start “Control Center” with the following procedure, too.
A
Right-click the “Fingerprint software” icon in the notification area.
BSelect [Start Control Center].
DFQX5712ZAW8F8T8OIVXPM.indd88DFQX5712ZAW8F8T8OIVXPM.indd88 2010/01/2213:03:402010/01/2213:03:40

9
The file described below is necessary for recovering the Fingerprint authentication
data. Back up this file periodically in a safe location such as removable disk to avoid
data loss resulting from some accidents. We recommend you to store the file in a
removable disk or network drive because the benefit of Fingerprint authentication
security can be reduced if you keep the file in the internal hard disk drive.
The backup password described below is necessary for bypassing the Fingerprint
authentication. We recommend you set the backup password using the “Manage
Fingerprints” wizard. If you do not define the backup password, you may lose your
data in case of authentication hardware failure.
File used by each user
• Backup user passport data
(Default name: <User Account>.vtp)
You need this file when you replace the embedded fingerprint device, or the
hard disk drive, or when reinstalling Windows. This file contains the finger-
prints, encryption keys, and logon authentication data.
Password used by each user
• Backup password for enrollment
This backup password can be used in case of hardware failure to bypass the
fingerprint authentication.
Backup
How to Backup:
Select “Identify” in “Account Operations” to save the user data.
AStart “Control Center” (Îpage 8)
BClick [Identify] - [Account Operation]
For further information, refer to the Protector Suite Help menu.
AStart “Control Center” (Îpage 8)
BClick [Help] - [Help].
NOTE
The passwords other than those explained above are also used for secu-
rity, so do not lose them. For further information, refer to the Protector Suite
Help menu.
AStart “Control Center” (Îpage 8)
BClick [Help] - [Help].
CAUTION
Useful Information
DFQX5712ZAW8F8T8OIVXPM.indd99DFQX5712ZAW8F8T8OIVXPM.indd99 2010/01/2213:03:412010/01/2213:03:41

10
Password Bank*1limitations: The following web pages and Windows ap-
plications cannot be supported.
• Web pages which are created by the following technologies:
- Web forms created on the fly using JavaScript.
- Web forms which looks as one form (i.e. logon field, password field), but
internally created with two independent forms.
- There can be auto submit problems with web forms which do not have
Submit button. All forms that you cannot submit with
Enter
will be entered
by Password Bank, but not submitted.
• Applications which do not use standard Windows controls and draw controls
by their own.
• This includes any Java based application.
*1 For information of these functions, refer to the Protector Suite Help menu.
AStart “Control Center” (Îpage 8)
BClick [Help] - [Help].
“Sensor Scrolling Feature” is not supported.
Handling & Maintenance
The enrolling and authentication sensitivity may decline under the con-
ditions below. Wipe off stains or moisture on the sensor surface with a
soft cloth.
• The surface of the fingerprint sensor is soiled with dust, skin oil, or sweat.
• The surface of the fingerprint sensor is wet as a result of moisture or
condensation.
Static electricity may also cause the sensor to malfunction. To make
your finger static-free, touch a metal surface before placing it on the fin-
gerprint sensor. Exercise caution against static electricity in winter and
other dry conditions.
Malfunction or damage may occur when:
• The fingerprint sensor surface was damaged by the strong rubbing of a solid
material, scratches, or being pecked with a pointed item.
• The sensor was touched with a finger soiled with mud, damaging the sensor
surface with a tiny substance, and staining the surface.
• The sensor surface was covered with a seal, or soiled with ink.
Limitations in Use
Useful Information
DFQX5712ZAW8F8T8OIVXPM.indd1010DFQX5712ZAW8F8T8OIVXPM.indd1010 2010/01/2213:03:412010/01/2213:03:41
