Panasonic DT50 series Assembly instructions

DT50 series
M0212-0

Watching TV
Cable /Satellite /Fiber with a box
• Initial setting 11
Antenna /Cable service without a box
• Initial setting 12
• Select channels 13
• Favorite channels (Set) 14
• Favorite channels (Display) 15
• Closed caption 16
• SAP 17
• Other 18
Blu-ray, DVD, Game Console, etc.
•Connecting and viewing (1) 19
• Connecting and viewing (2) 20
• HDMI connection notice 21
• HDMI connection caution 22
• Input signal 23
For best picture
• Picture mode 24
• Auto brightness (ECO) 25
• Aspect 26
• Aspect info. 27
For best audio
• Basic adjustments 28
• Advanced audio 29
3D
2

• Notice 30
• Viewing 3D 31
• Change 3D _=_2D 32
• Adjust 3D images 33
• 3D settings (1) 34
• 3D settings (2) 35
Computer on TV
• Display PC screen 36
• PC adjustments (1) 37
• PC adjustments (2) 38
• Input signal 39
Internet services "VIERA Connect"
Connect to network
•Network connections (1) 40
• Network connections (2) 41
• Network connections (3) 42
• Network connections (4) 43
Network settings
• Setting menu 44
• Connection test 45
• Network connection 46
• Wireless network settings 47
• IP address/DNS settings 48
• Proxy settings 49
• Network link (1) 50
• Network link (2) 51
3

. Software update 52
• New software notice 53
• Networkstatus 54
How to use
• Operate 55
Home network "DLNA"
Get started
• Information 56
Connect to network
•Network connections (1) 57
• Network connections (2) 58
• Network connections (3) 59
• Network connections (4) 60
Network settings
• Setting menu 61
• Connection test 62
• Network connection 63
• Wireless network settings 64
• IP address/DNS settings 65
• Proxy settings 66
• Network link (1) 67
• Network link (2) 68
• Software update 69
• New software notice 70
• Network status 71
Photos
• Viewing Photos 72
4

• Photoview 73
• Options menu 74
• Usingslideshow 75
• Slideshow settings 76
Videos
• Viewing Videos 77
• Video view 78
• Options menu 79
Music
• Playing Music 80
• Music view 81
• Options menu 82
Data information
• Compatible Data format (1) 83
• Compatible Data format (2) 84
• Compatible Data format (3) 85
• Notice 86
Media player
Get started
•Information 87
• Media warning messages 88
• SD card handling cautions 89
Photos
• Viewing Photos 90
• Photo view 91
• Sort the photos 92
• Options menu 93
5

• Multishot 3D /Thumbnails size 94
• Using slideshow 95
• Slideshow settings 96
• Soundtrack settings 97
Videos
• Viewing Videos 98
• Video view 99
• Options menu 100
Music
• Playing Music 101
• Music view 102
• Options menu 103
Data information
• Compatible Data format (1) 104
• Compatible Data format (2) 105
• Compatible Data format (3) 106
• Notice 107
Convenience features
Using VIERA TOOLS
• Using VIERA TOOLS 108
Timer
• Setting menu 109
• Sleep (Off timer) 110
• Timer (On/Off timer) 111
Lock (parental control)
• Setting menu 112
• Lock(l) 113
6

114
. Lock/2>
Password setting 115
Parental control ratings (1) 116
+ Parental controlratings (2) 117
. Parentalcontrol ratings (3) 118
Closed caption 119
+ Settingmenu
e Closedcaption (1) 120
+ Closedcaption (2) 121
. Closedcaption notice 122
VIERA Link TM"HDAVI Control TIn,, 123
.B_s+cfeature
Connecting note (1) 124
.Connecting note (2) 125
e VlERALink connections (1) 126
.wERAL+nkconnect+o0s!2) _27
+ VlERALink connections (3) 128
. VIERA Link settings 129
.wERAL+nksett+ngsfeature!!_ _30
.WERAL+nksett+ngsfeature!2) _3_
+ VIERA Link settings feature (3) 132
• VlERA Link 133
• V lERA Link menu (1) 134
• VIERA Link menu (2) 135
Control by smartphone, etc.
• Smartphone remote 136
Using USB Keyboard /Gamepad
7

137
• Keyboard 138
• Gamepad
All settings
Picture 139
• Setting menu 140
• Basicsettings (1) 141
• _asicsettings (2) 142
• Aspect adjustment....... 143
• PC adjustments (1).................... 144
• PC adjustments (2) 145
• HDM I .settings 146
• Advance picture.. (1) 147
• Advancedpicture (2)
Audio 148
• Settingmenu 149
•Basicsetting s 150
• Advance_ audio.............
• DTV !anguage and SAP settings .... 51
DIGITALAUDIO OUTterminal 52
Network 153
• Networksettings. (1) 154
_ Ne_0rksettings!2) ...... 155
Networksettings_ 3) 156
, Network settings_ (4) 157
tNetworksettings (5)
Timer 158
• Setting menu.....................
8

159
• Sleep (Off .timer) 160
• Timer (On/Off timer)
Lock (parental control) 161
•Setting menu 162
?Lock(1 .............. 163
.Lock(2).......... 164
_ Password setting 165
Parentalcontro!ratings(I) 166
tParental control ratings (2! 167
• Parenta controo ratings.(3)
Setup 168
. Setting menu 169
• 3 D settings. ( 1) 170
•3Dsettings(2)
•NT/Cable.setup (1) 171
172
• ANT/Cable setup (2) 173
• Closed captiono (1) 174
• Closed caption (2) 175
• Closed caption notice 176
• VIERA Linksettings (! ) ........... 177
• VIERA Link_ settings (2) 178
, ECQ/energy_saving (1) 179
•ECO/e nergo saving (2).......... 180
,Advanced etup 181
,Other settings. (1) ............ 182
• other settings !2) .............
9

Support /FAQ
FAQ
• Picture - Viewing 183
• Picture - Snowy /none 184
• Picture - Distortion 185
• Picture - Continue 186
• Sound - none 187
• Sound - Unusual 188
• Networking 189
• Software update 190
• 3D - Viewing 191
• 3D - Format 192
• Other 193
• Menu - Gray-out 194
• Reset to default 195
Care and Cleaning
• Display panel 196
• Cabinet 197
• Pedestal /Power cord 198
Meaning of signs :
_ Press the Remote control button
Letters in box • Remote control button
MENU Letters in Cyan : Menus on screen display
10

Watching TV
Cable /Satellite /Fiber with a box
Initial setting
1. Connecting
Select the wiring method connecting your box to the TV, AV IN or
Antenna/Cable in
I Tip: HDMI will provide the best HD picture I
2. Change INPUT
_ IINPUT
Press the INPUT button to select the proper connection. Wait 2 seconds.
3. Power on your Cable, Satellite or Fiber box
Use the box's remote control to change channels.
* If the box is connected to the TV using a COAX cable (Antenna/Cable in), then
set the TV channel to CH3 or CH4. Note that the picture will not be in HD.
* CC/SAP is not available when watching TV with a Cable or Satellite box
connected via HDMI.
If your box is a high definition, then check that it is outputting 720p or 1080i
signal.
Tip: press the TV's _ button to verify.
Check your box "aspect" or "format" settings. It should be set to 16:9,
Widescreen or FULL.
If the audio volume is too low, check the box's audio settings.
Contact your Cable or Satellite provider for instructions on any box settings.
11

Watching TV
Antenna /Cable service without a box
Initial setting
1. Connect coax
Connect a COAX wire from either an antenna or Basic Cable service to the TV's
"ANTENNA/CABLE IN" screw terminal.
ANTENNA/
TV CABLE IN Antenna
2. Scan the channel
_ IMENUI > >
1. Select Programming source Cable or Antenna in i,,.
2. Select and select scan mode
3. Start scanning.
If at the end of the scanning no channels are found, then check:
Antenna's position - or Availability of Cable service.
Cable, Satellite or Fiber services with a box are typically connected to the TV's
A/V inputs, preferably HDMI, for best HD picture. In such a case, the channel
scanning is not needed (set to Not used).
12

Watching TV
Antenna /Cable service without a box
Select channels
Select desired channel
_or __
• CH buttons are also available on the TV.
Select desired digital channel
To directly enter a digital channel number use
• When turning to a digital channel, press the button to enter the minor number in a
compound channel number.
(e.g. CH15-1 _ _ _ _)
13

Watching TV
Antenna /Cable service without a box
Favorite channels (Set)
Channel numbers registered in Favorite are displayed on the favorite tune screen.
Select the desired broadcast station with the cursor or use the number buttons.
I • Favorite channels cannot be set when using Cable or Satellite box
• Set the Favorite channel
[OPTION] >
Select the list number using _ /V and _ or _ _ _ directly to save the
displayed channel.
Delete a Favorite channel
_[OPTION] >
Select the list number using _ /_ and _ (press and hold) to delete.
* To change the page in
IFAVORITEIor _/_ repeatedly
I
14

Watching TV
Antenna /Cable service without a box
Favorite channels (Display)
Channel numbers registered in Favorite are displayed on the favorite tune screen.
Select the desired broadcast station with the cursor or use the number buttons.
I • Favorite channels cannot be set when using Cable or Satellite box.
To display a Favorite channel
SJFAVORITE]
I
Select the list number using _ /V and _ or _ _ _ directly to displayed
on favorite screen.
* To change the page in
[FAVORITE]or _ /_ repeatedly
15

Watching TV
Antenna /Cable service without a box
Closed caption
Viewing with Closed caption
Switches the Closed caption mode.
(Closed caption Off/Closed caption On /Closed caption On mute )
*CC is not available when watching TV with a Cable or Satellite box connected
via HDMI.
* Contact your Cable or Satellite operator for instructions on enabling CC with
their box.
* The TV's CC button does not operate the Satellite or Cable box's CC function.
* For viewing the CC of digital broadcasting, set the aspect to FULL (If viewing
with H-FILL, JUST, ZOOM or 4:3; characters might be cut off).
* If the CC is set to On on both the receiver and TV when the signal is 480i
(except for the HDMI connection), the CC may overlap on the TV.
* If a digital program is being output in analog format, the CC data will also be
output in analog format.
* If the recorder or output monitor is connected to the TV, the CC needs to be set
up on the recorder or output monitor.
16

Watching TV
Antenna /Cable service without a box
SAP
Listen with SAP (Secondary Audio Programming)
QSAP is not available when watching TV with a Cable or Satellite box connected
via HDMI.
Contact your Cable or Satellite operator for instructions on enabling SAP with
their box.
The TV's _ button does not operate the Satellite or Cable box's
function.
Select the Audio mode for watching TV.
Digital mode: Select available audio service when receiving a digital channel.
Audio track is automatically selected as :i:_:_i_ in
menu.
> > _: _i_
* If you change the audio settings with the _ button, the DTV language and
SAP settings will not change.
(example)
Track number /Number of tracks
...............Current audio track information (language, audio
type)
......Audio service information
Analog mode: Select the desired Audio mode. ( Stereo /SAP /Mono )
17

Watching TV
Antenna /Cable service without a box
Other
1. Information banner
Displays TV status information. Also, when watching programs via the
Antenna/Cable input, INFO will include the channel banner.
IINFOI
Channel /Station identifier /Program title /Closed caption /SAP /
Rating level /Signal resolution /Picture mode /Aspect ratio /
Sleep timer remaining time /Clock
2, Options menu
This menu consists of shortcuts to convenient functions.
OPTION ]
C: : :, ,_ _i : ,_!::::: Specify favorites or type of channels to view when
pressing the channel up/down button.
S::/i: :: :_: :::: Set favorite channel
Edit the channel identifier
_:::_:::: : Check the antenna's signal strength
* Options menu is only available when the TV is using the Antenna/Cable input,
not when using Cable or Satellite box.
18

Watching TV
Blu-ray, DVD, Game Console, etc.
Connecting and viewing (1)
1. Connect device
Verify that the device is connected to the TV properly and connect to desired
terminal. Note which terminal the device is connected to (HDMI 1, HDMI 2,...
Component or Video)
Component and Composite (Video) in terminals are shared.
Please be careful not to confuse the connection when you use Component or
Video.
19

Watching TV
Blu-ray, DVD, Game Console, etc.
Connecting and viewing (2)
2. Select Input
1. Display menu (With the connected equipment turned ON)
IINPUTI
2. Select the input used in step 1
Select correct input source, using _ /V and press
You can also press the corresponding NUMBER button or press I INPUT I
repeatedly to cycle through the available inputs. If you are unsure which input to
select, wait 2 seconds between each selection.
Component and Composite (Video) IN
terminals are shared and must be connected
using the supplied adapter.
NOTE: One red connector is for video and the
other audio.
•
AUDIO
You need to select Video or Component.
(Default: Video)
• PressIINPUT land select
• Press _ /_ to choose Video or
Component,
VIDEO
• For your convenience, you can edit the inputs with labels that are easy to
remember.
d ._m
Edit Labels Set ANT/Cable in
3. Operate using your device's remote control.
