Panasonic TCL42U30 - 42" LCD User manual

© Panasonic Corporation 2011.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.MTNC110102CE
B32 Canada: B61
42 inch Class 1080p LCD HDTV
Model No. TC-L42U30
LA14 Chassis

2
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General Guidelines ----------------------------------------3
2 Warning --------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ----------4
2.2. About lead free solder (PbF) ----------------------------5
3 Service Navigation------------------------------------------------6
3.1. PCB Layout --------------------------------------------------6
3.2. Applicable signals ------------------------------------------6
4 Specifications ------------------------------------------------------7
5 Service Mode -------------------------------------------------------8
5.1. How to enter into Service Mode ------------------------8
5.2. SRV-TOOL------------------------------------------------- 10
5.3. Hotel mode------------------------------------------------- 11
5.4. Data Copy by SD Card --------------------------------- 12
6 Troubleshooting Guide---------------------------------------- 15
6.1. Check of the IIC bus lines------------------------------ 15
6.2. Power LED Blinking timing chart --------------------- 16
6.3. LCD Panel test mode ----------------------------------- 16
7 Disassembly and Assembly Instructions --------------- 17
7.1. Pedestal ---------------------------------------------------- 17
7.2. Rear cover ------------------------------------------------- 17
7.3. AC cord ----------------------------------------------------- 17
7.4. P-Board ----------------------------------------------------- 18
7.5. Side AV bracket------------------------------------------- 18
7.6. A-Board ----------------------------------------------------- 18
7.7. Control panel comp -------------------------------------- 19
7.8. Speaker unit ---------------------------------------------- 19
7.9. Metal bracket right --------------------------------------- 19
7.10. VESA metal and Metal vertical bracket------------- 19
7.11. A-Board bracket ------------------------------------------ 20
7.12. Metal bracket top ----------------------------------------- 20
7.13. Metal bracket bottom and Metal bracket
bottom center---------------------------------------------- 20
7.14. Barrier ------------------------------------------------------- 20
7.15. TC-Board --------------------------------------------------- 20
7.16. LCD Top MTG and LCD side MTG ------------------ 21
7.17. LCD Panel ------------------------------------------------- 21
7.18. KA-Board --------------------------------------------------- 21
7.19. EMI processing ------------------------------------------- 22
8 Measurements and Adjustments -------------------------- 34
8.1. VCOM Adjustment (Flicker Adjustment) ----------- 34
8.2. Voltage chart of A-board-------------------------------- 35
8.3. Picture level adjustment (RF) ------------------------- 35
9 Block Diagram --------------------------------------------------- 37
9.1. Main Block Diagram ------------------------------------- 37
9.2. Block (1/3) Diagram ------------------------------------- 38
9.3. Block (2/3) Diagram ------------------------------------- 39
9.4. Block (3/3) Diagram ------------------------------------- 40
10 Wiring Connection Diagram--------------------------------- 41
10.1. Caution statement.--------------------------------------- 41
10.2. Wiring ------------------------------------------------------- 41
11 Schematic Diagram--------------------------------------------- 43
11.1. Schematic Diagram Note ------------------------------ 43
11.2. Replacement Parts List Note-------------------------- 43
11.3. A-Board (1/8) Schematic Diagram------------------- 44
11.4. A-Board (2/8) Schematic Diagram------------------- 45
11.5. A-Board (3/8) Schematic Diagram------------------- 46
11.6. A-Board (4/8) Schematic Diagram ------------------ 47
11.7. A-Board (5/8) Schematic Diagram ------------------ 48
11.8. A-Board (6/8) Schematic Diagram ------------------ 49
11.9. A-Board (7/8) Schematic Diagram ------------------ 50
11.10. A-Board (8/8) and KA-Board Schematic
Diagram ---------------------------------------------------- 51
11.11. TC-Board (1/3) Schematic Diagram ---------------- 52
11.12. TC-Board (2/3) Schematic Diagram ---------------- 53
11.13. TC-Board (3/3) Schematic Diagram ---------------- 54
12 Printed Circuit Board------------------------------------------ 55
12.1. A-Board ---------------------------------------------------- 55
12.2. KA-Board -------------------------------------------------- 57
12.3. TC-Board -------------------------------------------------- 58
13 Exploded View--------------------------------------------------- 59
13.1. Exploded View-------------------------------------------- 59
13.2. Electrical Replacement Parts List ------------------- 61

3
1 Safety Precautions
1.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
4. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.
5. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the
wires have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.
6. When conducting repairs and servicing, do not twist the Faston connectors but plug them straight in or unplug them straight
out.
1.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed metal-
lic cabinet part on the equipment such as screwheads,
connectors, control shafts, etc. When the exposed metal-
lic part has a return path to the chassis, the reading
should be 100 Mohm and over.
When the exposed metal does not have a return path to
the chassis, the reading must be .
1.1.2. Leakage Current Hot Check (See
Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5kohm, 10 watts resistor, in parallel with a
0.15μF capacitors, between each exposed metallic part
on the set and a good earth ground such as a water pipe,
as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensi-
tivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the volt-
age at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliamp. In case a measure-
ment is outside of the limits specified, there is a possibility
of a shock hazard, and the equipment should be repaired
and rechecked before it is returned to the customer.
Figure 1

4
2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensi-
tive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor [chip] components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as [anti-static (ESD protected)] can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise ham less motion such as the brush-
ing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient
to damage an ES device).

5
2.2. About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please
use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb sol-
der. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto the
opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder. How-
ever, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.

6
3 Service Navigation
3.1. PCB Layout
3.2. Applicable signals
* Mark: Applicable input signal for Component (Y, PB, PR), HDMI and PC
Note
• Signals other than above may not be displayed properly.
• The above signals are reformatted for optimal viewing on your display.
Board Name Function
A-Board Main
TC-Board Tcon, Double Speed
KA-Board Remote Receiver, LED, Cat’s eye
P-Board Power Supply
Non serviceable
P-Board should be exchanged for service.
Control Panel Comp Control Panel
Non serviceable
Control Panel Comp should be exchanged for service.
horizontal frequency (kHz) vertical frequency (Hz) COMPONENT HDMI PC
525 (480) / 60i 15.73 59.94 * *
525 (480) /60p 31.47 59.94 * *
750 (720) /60p 45.00 59.94 * *
1,125 (1,080) /60i 33.75 59.94 * *
1,125 (1,080) /60p 67.43 59.94 *
1,125 (1,080) /60p 67.50 60.00 *
1,125 (1,080) /24p 26.97 23.98 *
1,125 (1,080) /24p 27.00 24.00 *
640 ×400 @70 31.47 70.08 *
640 ×480 @60 31.47 59.94 *
Macintosh13 inch (640 ×480) 35.00 66.67 *
640 ×480 @75 37.50 75.00 *
852 ×480 @60 31.44 59.89 *
800 ×600 @60 37.88 60.32 *
800 ×600 @75 46.88 75.00 *
800 ×600 @85 53.67 85.08 *
Macintosh16 inch (832 ×624) 49.73 74.55 *
1,024 ×768 @60 48.36 60.00 *
1,024 ×768 @70 56.48 70.07 *
1,024 ×768 @75 60.02 75.03 *
1,024 ×768 @85 68.68 85.00 *
Macintosh 21 inch (1,152 ×870) 68.68 75.06 *
1,280 ×768 @60 47.78 59.87 *
1,280 ×1,024 @60 63.98 60.02 *
1,366 ×768 @60 48.39 60.04 *

7
4 Specifications
Note
• Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
Power Source AC 110-127 V, 60 Hz
Power Consumption
Rated Power Consumption 210 W
Standby Condition 0.3 W
Display panel
Aspect Ratio 16:9
Visible screen size 42 inch class (42.0 inches measured diagonally)
(W ×H ×Diagonal) 36.6 inch ×20.6 inch ×42.0 inch (930 mm ×523 mm ×1,067 mm)
(No. of pixels) 2,073,600 (1,920 (W) ×1,080 (H)) [5,760 ×1,080 dots]
Sound
Speaker 1-way 2 bottom SP System
Audio Output 20 W [10 W + 10 W] ( 10 % THD )
PC signals VGA, SVGA, XGA, WXGA, SXGA
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Channel Capability-
ATSC/NTSC (Digital/Analog)
VHF/ UHF: 2 - 69, CATV: 1 - 135
Operating Conditions Temperature: 32 °F - 95 °F (0 °C - 35°C)
Humidity: 20 % - 80 % RH (non-condensing)
Connection Terminals
VIDEO IN 1-2 VIDEO: RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
AUDIO L - R: RCA PIN Type ×2 0.5 V [rms]
COMPONENT IN Y: 1.0 V [p-p] (including synchronization)
PB, PR: ±0.35 V [p-p]
AUDIO L-R: RCA PIN Type ×2 0.5 V [rms]
HDMI 1-3 TYPE A Connector ×3.
OThis TV supports [HDAVI Control 5] function.
PC D-SUB 15PIN: R,G,B / 0.7 V [p-p] (75 Ω)
HD, VD / 1.0 - 5.0 V [p-p] (high impedance)
Card slot SD CARD slot ×1
DIGITAL AUDIO OUT PCM / Dolby Digital, Fiber Optic
FEATURES 3D Y/C FILTER, CLOSED CAPTION,
V-Chip, HDAVI Control 5
Vesa compatible, VIERA IMAGE VIEWER
Dimensions (W ×H ×D)
Including TV stand 40.2 inch ×26.3 inch ×11.4 inch (1,021 mm ×666 mm ×288 mm)
TV Set only 40.2 inch ×24.9 inch ×4.3 inch (1,021 mm ×632 mm ×107 mm)
Mass
Including TV stand 42.0 lb. (19.0 kg) NET
TV Set only 37.5 lb. (17.0 kg) NET

8
5 Service Mode
5.1. How to enter into Service Mode
5.1.1. Purpose
After exchange parts, check and adjust the contents of adjustment mode.
While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds.
5.1.2. Key command
[1] button...Main items Selection in forward direction
[2] button...Main items Selection in reverse direction
[3] button...Sub items Selection in forward direction
[4] button...Sub items Selection in reverse direction
[VOL] button...Value of sub items change in forward direction ( + ), in reverse direction ( - )
5.1.3. How to exit
Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.

9
5.1.4. Contents of adjustment mode
• Value is shown as a hexadecimal number.
• Preset value differs depending on models.
• After entering the adjustment mode, take note of the value in each item before starting adjustment.
Main item Sub item Sample Data Remark
ADJUST CONTRAST 2E
COLOR 00
TINT 00
SUB-BRT 000
BACKLGT 91EB
V COM 171
WB-ADJ R-GAIN FF
G-GAIN FC
B-GAIN AE
R-CENT 4B
G-CENT 80
B-CENT DF
OPTION Boot ROM Factory Preset.
STBY-SET --
EMERGENCY ON
CLK MODE OFF
CLOCK FC8
EDID-CLK HIGH
AGING COUNT Built-in test patterns can be
displayed.
ALL WHITE
ALL BLACK
ALL RED
ALL GREEN
ALL_BLUE
RASTER1
RASTER2
RASTER3
RASTER4
4DIN1
4DIN2
GRAY WHITE
GRAY RED
GRAY GREEN
GRAY BLUE
FLICKER0
GS1
1 PIX STRIPE
2 PIX STRIPE
1 LINE_STRIPE
COLORBAR
WIDHT COLORBAR
OUTER
LIGHT CHECK
FLICKER1
FLICKER2
FLICKER3
SRV-TOOL 00 See next.

10
5.2. SRV-TOOL
5.2.1. How to access
1. Select [SRV-TOOL] in Service Mode.
2. Press [OK] button on the remote control.
5.2.2. Display of SOS History
SOS History (Number of LED blinking) indication.
From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment.
This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory ship-
ment setting].
5.2.3. POWER ON TIME/COUNT
Note : To display TIME/COUNT menu, highlight position, then press MUTE for 3 sec.
Time : Cumulative power on time, indicated hour : minute by decimal
Count : Number of ON times by decimal
Note : This indication will not be cleared by either of the self-checks or any other command.
5.2.4. Exit
1. Disconnect the AC cord from wall outlet.

11
5.3. Hotel mode
1. Purpose
Restrict a function for hotels.
2. Access command to the Hotel mode setup menu
In order to display the Hotel mode setup menu:
While pressing [VOLUME (-)] button of the main unit,
press [INPUT] button of the remote control three times
within 2 seconds.
Then, the Hotel mode setup menu is displayed.
3. To exit the Hotel mode setup menu
Disconnect AC power cord from wall outlet.
4. Explain the Hotel mode setup menu
Item Function
Mode Select hotel mode off/on
Input Select input signal modes.
Set the input, when each time power is
switched on.
Selection:
-/RF/HDMI1/HDMI2/HDMI3/Comp./Video/PC
• OFF: give priority to a last memory.
Channel Select channel when input signal is RF.
Set the channel, each time power is switched
on.
Selection:
Any channel number or [-].
[-] means the channel when turns off.
Volume Adjust the volume when each time power is
switched on.
Range:
0 to 100
Vol. Max Adjust maximum volume.
Range:
0 to 100
OSD Ctrl Restrict the OSD.
Selection:
OFF/PATTERN1
• OFF: No restriction
• PATTERN1: restriction
FP Ctrl Select front key conditions.
Selection:
OFF/ALL/PATTERN1
• OFF: altogether valid.
• ALL: altogether invalid.
• PATTERN1: only input key is valid.
Pow Ctrl Select POWER-ON/OFF condition when AC
power cord is disconnected and then con-
nected.
OFF: The same condition when AC power
cord is disconnected.
ON: Forced power ON condition.

12
5.4. Data Copy by SD Card
5.4.1. Purpose
(a) Board replacement (Copy the data when exchanging A-board):
When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board.
(b) Hotel (Copy the data when installing a number of units in hotel or any facility):
When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other
TVs.
5.4.2. Preparation
Make pwd file as startup file for (a) or (b) in a empty SD card.
1. Insert a empty SD card to your PC.
2. Right-click a blank area in a SD card window, point to New, and then click text document. A new file is created by default
(New Text Document.txt).
3. Right-click the new text document that you just created and select rename, and then change the name and extension of the
file to the following file name for (a) or (b) and press ENTER.
File name:
(a) For Board replacement : boardreplace.pwd
(b) For Hotel : hotel.pwd
Note:
Please make only one file to prevent the operation error.
No any other file should not be in SD card.

13
5.4.3. Data copy from TV set to SD Card
1. Turn on the TV set.
2. Insert SD card with a startup file (pwd file) to SD slot.
On-screen Display will be appeared according to the startup file automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement : 2770
(b) For Hotel : 4850
Data will be copied from TV set to SD card.
It takes around 2 to 6 minutes maximum for copying.
4. After the completion of copying to SD card, remove SD card from TV set.
5. Turn off the TV set.
Note:
Following new folder will be created in SD card for data from TV set.
(a) For Board replacement : user_setup
(b) For Hotel : hotel

14
5.4.4. Data copy from SD Card to TV set
1. Turn on the TV set.
2. Insert SD card with Data to SD slot.
On-screen Display will be appeared according to the Data folder automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement : 2771
(b) For Hotel : 4851
Data will be copied from SD card to TV set.
4. After the completion of copying to SD card, remove SD card from TV set.
(a) For Board replacement : Data will be deleted after copying (Limited one copy).
(b) For Hotel : Data will not be deleted and can be used for other TVs.
5. Turn off the TV set.
Note:
1. Depending on the failure of boards, function of Data copy for board replacement does not work.
2. This function can be effective among the same model numbers.

15
6 Troubleshooting Guide
Use the self-check function to test the unit.
1. Checking the IIC bus lines
2. Power LED Blinking timing
6.1. Check of the IIC bus lines
6.1.1. How to access
Self-check indication only:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control
for more than 3 seconds.
Self-check indication and forced to factory shipment setting:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote con-
trol for more than 3 seconds.
6.1.2. Exit
Disconnect the AC cord from wall outlet.
6.1.3. Screen display
6.1.4. Check Point
Confirm the following parts if NG was displayed.
DISPLAY Check Ref. No. Description Check Point
DTVSOC IC8001 Nile-TCON A-Board
SYSMPU IC8001 MPU (Nile-TCON) A-Board
TUN TU8302 TUNER A-Board
MEM1 IC8503 EEPROM (Nile-TCON) A-Board
MEM2 IC8004 EEPROM (SYSMPU) A-Board
AMP IC2106 AUDIO AMP A-Board
ZWEI2 IC9006 ZWEI2 TC-Board
EPOP

16
6.2. Power LED Blinking timing chart
1. Subject
Information of LED Flashing timing chart.
2. Contents
When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the
defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
6.3. LCD Panel test mode
Purpose:
To find the possible failure point where in LCD Panel or Printed Circuit Board when the abnormal picture is displayed.
How to Enter:
While pressing [VOLUME ( - )] buttonof the main unit, press [SUB MENU] button of the remote control three times within 2
seconds.
How to Exit:
Disconnect AC plug from wall outlet.
How to confirm:
If the abnormal picture is displayed, go into LCD Panel test mode to display the several test patterns.
And then, judge by the following method.
Still abnormal picture is displayed: The cause mustbe in LCD Panel or TC board.
Normal picture is displayed: The cause must be in A board.
Remarks:
The test pattern is created by the circuit in TC board.
In LCD Panel test mode, this test pattern is displayed unaffected by signal processing for RF or input signal.
If the normal picture is displayed, LCD Panel or TC board must be okay and the cause of failure must be in A board.
Blinking Times Contents Check point
1 BACK LIGHT SOS LCD PANEL
P-Board
2 SUB 1.8V SOS A-Board
3 SUB 1.2V SOS A-Board
4 POWER SOS A-Board
P-Board
9 ZWEI2 SOS TC-Board
10 SUB 3.3V SENSE A-Board
12 SOUND SOS A-Board
Speaker

17
7 Disassembly and Assembly Instructions
7.1. Pedestal
1. Lay down the unit so that the rear cover faces upward.
2. Remove the 4 screws.
3. Remove the pedestal.
7.2. Rear cover
1. Remove the 16 screws (A).
2. Remove the 1 screw (B).
3. Remove the rear cover.
7.3. AC cord
1. Remove the screw and Remove the AC cord bracket.
2. Remove the bushing of the AC cord from the AC cord
bracket.
3. Disconnect the connector (P1) of AC cord.

18
7.4. P-Board
1. Remove the 6 screws.
2. Disconnect the connectors (P1, P2, P3 and P4).
3. Remove the P-Board.
7.5. Side AV bracket
1. Remove the side AV bracket.
7.6. A-Board
1. Remove the 5 screws.
2. Disconnect the connector (A03, A04, A10, A11 and A21).
3. Remove the A-Board.

19
7.7. Control panel comp
1. Disconnect the connector (K1).
2. Remove the 2 screws.
3. Remove the control panel comp.
7.8. Speaker unit
1. Remove the 4 screws.
2. Remove the speaker unit.
7.9. Metal bracket right
1. Remove the 2 screws.
2. Remove the Metal bracket right.
7.10. VESA metal and Metal vertical
bracket
1. Remove the 10 screws.
2. Remove the VESA metal and Metal vertical bracket.

20
7.11. A-Board bracket
1. Remove the 3 screws.
2. Remove the A-Board bracket.
7.12. Metal bracket top
1. Remove the 3 screws.
2. Remove the Metal bracket top.
7.13. Metal bracket bottom and Metal
bracket bottom center
1. Remove the 4 screws (C).
2. Remove the 4 screws (D).
3. Remove the Metal bracket bottom and Metal bracket bot-
tom center.
7.14. Barrier
1. Remove the barrier.
7.15. TC-Board
1. Disconnect the connector (TC01, TC04, TC05 and
TC06).
2. Remove the 2 screws.
3. Remove the TC-Board.
