Panasonic TH-L32C22T User manual

© Panasonic Corporation 2010. Unauthorized
copying and distribution is a violation of law.
ORDER NO. MTV1002015CE
LCD TV
Model No. TH-L32C22T
Chassis: KM06V
Destination: THAILAND
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.1.1. Leakage Current Cold Check---------------------- 3
1.1.2. Leakage Current Hot Check (See Figure
1.) --------------------------------------------------------- 3
2 Warning -------------------------------------------------------------- 4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices---------- 4
2.2. About lead free solder (PbF)---------------------------- 5
3 Service Navigation ----------------------------------------------- 6
3.1. Service Hint ------------------------------------------------- 6
3.2. Service Hint (TH-L32C22TY) --------------------------- 7
4 Specifications ----------------------------------------------------- 8
5 Service Mode -----------------------------------------------------10
5.1. How to enter into Service Mode ----------------------10
5.1.1. Contents of adjustment mode --------------------10
5.1.2. How to exit---------------------------------------------10
5.2. SRV-TOOL -------------------------------------------------11
5.2.1. How to access ----------------------------------------11
5.2.2. Display of SOS History -----------------------------11
5.2.3. POWER ON TIME/COUNT -----------------------11
5.2.4. Exit ------------------------------------------------------ 11
5.3. Service Mode Adjustment------------------------------ 12
5.3.1. Self Check Mode ------------------------------------ 12
5.3.2. Hotel Mode Adjustment ---------------------------- 12
5.3.3. Hotel Mode-------------------------------------------- 12
6 Troubleshooting Guide --------------------------------------- 13
6.1. Check of the IIC bus lines------------------------------ 13
6.1.1. How to access --------------------------------------- 13
6.1.2. Exit ------------------------------------------------------ 13
6.1.3. Screen display --------------------------------------- 13
6.1.4. Check Point ------------------------------------------- 13
6.2. Power LED Blinking timing chart --------------------- 14
6.3. No Power--------------------------------------------------- 14
7 Disassembly and Assembly Instructions--------------- 15
7.1. AC Cord Dressing---------------------------------------- 15
7.2. Backcover Screw and Long Metal Frame---------- 16
7.3. Speaker Assembly Fixing ------------------------------ 17
7.4. Speaker Assembly & Small Part Installation ------ 18
7.5. Dressing Sp. Wire to Cabinet Ribs ------------------ 19
7.6. Pedestal Assembly 1 ----------------------------------- 20
7.7. Pedestal Assembly 2------------------------------------ 21

TH-L32C22T
2
8 Measurements and Adjustments -------------------------- 22
8.1. Voltage chart of A-board-------------------------------- 22
8.2. Voltage chart of P-board-------------------------------- 22
8.3. Voltage chart of IP-board - TH-L32C22TY--------- 22
8.4. Picture level adjustment (RF) ------------------------- 23
9 Block Diagram --------------------------------------------------- 24
9.1. Main Block Diagram ------------------------------------- 24
10 Wiring Connection Diagram --------------------------------- 25
10.1. Wire Dressing & Connections 1 ---------------------- 25
10.2. Wire Dressing & Connections 2 - TH-
L32C22TY-------------------------------------------------- 27
11 Schematic Diagram--------------------------------------------- 29
11.1. Schematic Diagram Notes ----------------------------- 29
11.2. A Board ----------------------------------------------------- 30
11.2.1. A Board - Sheet : 001 (1 / 6)---------------------- 30
11.2.2. A Board - Sheet : 001 (2 / 6)---------------------- 31
11.2.3. A Board - Sheet : 001 (3 / 6)---------------------- 32
11.2.4. A Board - Sheet : 001 (4 / 6)---------------------- 33
11.2.5. A Board - Sheet : 001 (5 / 6)---------------------- 34
11.2.6. A Board - Sheet : 001 (6 / 6)---------------------- 35
11.2.7. A Board - Sheet : 003 (1 / 6)---------------------- 36
11.2.8. A Board - Sheet : 003 (2 / 6)---------------------- 37
11.2.9. A Board - Sheet : 003 (3 / 6)---------------------- 38
11.2.10. A Board - Sheet : 003 (4 / 6)---------------------- 39
11.2.11. A Board - Sheet : 003 (5 / 6)---------------------- 40
11.2.12. A Board - Sheet : 003 (6 / 6)---------------------- 41
11.3. P Board ----------------------------------------------------- 42
11.3.1. P Board (1 / 3)---------------------------------------- 42
11.3.2. P Board (2 / 3)---------------------------------------- 43
11.3.3. P Board (3 / 3)---------------------------------------- 44
11.4. IP Board (TH-L32C22TY) ------------------------------ 45
11.4.1. IP Board (1 / 4)--------------------------------------- 45
11.4.2. IP Board (2 / 4)--------------------------------------- 46
11.4.3. IP Board (3 / 4)--------------------------------------- 47
11.4.4. IP Board (4 / 4)--------------------------------------- 48
12 Printed Circuit Board ------------------------------------------ 49
12.1. A-Board ----------------------------------------------------- 49
12.2. A-Board ----------------------------------------------------- 50
12.3. P-Board ----------------------------------------------------- 51
12.4. P-Board ----------------------------------------------------- 51
12.5. IP-Board (TH-L32C22TY) ------------------------------ 52
12.6. IP-Board ---------------------------------------------------- 52
13 Exploded View and Replacement Parts List ----------- 53
13.1. Exploded View and Mechanical Replacement
Parts List --------------------------------------------------- 53
13.2. Electrical Replacement Parts List-------------------- 53
13.2.1. Replacement Parts List Notes ------------------- 53
13.2.2. Electrical Replacement Parts List --------------- 54

TH-L32C22T
3
1 Safety Precautions
1.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
4. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.
5. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the
wires have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.
6. When conducting repairs and servicing, do not twist the Faston connectors but plug them straight in or unplug them straight
out.
1.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed
metallic cabinet part on the equipment such as
screwheads, connectors, control shafts, etc. When the
exposed metallic part has a return path to the chassis, the
reading should be 100 Mohm and over.
When the exposed metal does not have a return path to
the chassis, the reading must be .
1.1.2. Leakage Current Hot Check (See
Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5kohm, 10 watts resistor, in parallel with a
0.15μF capacitors, between each exposed metallic part
on the set and a good earth ground such as a water pipe,
as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more
sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the
voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliamp. In case a
measurement is outside of the limits specified, there is a
possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the
customer.
Figure 1

TH-L32C22T
4
2Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor [chip] components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as [anti-static (ESD protected)] can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or
comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise ham less motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD)
sufficient to damage an ES device).

TH-L32C22T
5
2.2. About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please
use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb
solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto the
opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.

TH-L32C22T
6
3 Service Navigation
3.1. Service Hint
1. Remove the Back Cover.
2. Remove the A Board / P Board by pulling out.

TH-L32C22T
7
3.2. Service Hint (TH-L32C22TY)
1. Remove the Back Cover.
2. Remove the A Board / IP Board by pulling out.

TH-L32C22T
8
4 Specifications
Power Source AC Single 220-240 V, 50 / 60 Hz
Power Consumption
Average use 78 W
Standby Condition 0.6 W
Display panel
Aspect Ratio 16:9
Visible screen size 80 cm (diagonal)
698 mm (W) ×393 mm (H)
Number of pixels 1,049,088 (1,366 (W) ×768 (H))
Sound
Speaker 160 mm ×40 mm ×2 pcs, 8 Ω
Audio Output 30 W (15 W + 15 W), 10% THD
PC signals VGA, SVGA, WVGA, XGA
SXGA, WXGA ...... (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems / Band name 17 SYSTEMS FUNCTIONS
1PAL B, G, H
Reception of broadcast transmission and
playback from video cassette tape recorders.
2PAL I
3PAL D, K
4SECAM B, G
5SECAM D, K
6SECAM K1
7NTSC M (NTSC 3.58 / 4.5MHz)
8NTSC 4.43 / 5.5 MHz
Playback from special VCR’s or DVD.
9NTSC 4.43 / 6.0 MHz
10 NTSC 4.43 / 6.5 MHz
11 NTSC 3.58 / 5.5 MHz
12 NTSC 3.58 / 6.0 MHz
13 NTSC 3.58 / 6.5 MHz
14 SECAM I
15 PAL 60 Hz / 5.5 MHz Playback from Special Disc Players and
Special VCR’s or DVD.
16 PAL 60 Hz / 6.0 MHz
17 PAL 60 Hz / 6.5 MHz
Receiving Channels (Regular TV)
PAL B/G 2 - 12 (PAL / SECAM B, K1)
0 - 12 (PAL B AUST.)
1 - 9 (PAL B N.Z.)
1 - 12 (PAL / SECAM D)
1 - 12 (NTSC M JAPAN)
2 - 13 (NTSC M USA)
UHF BAND 21 - 69 (PAL G, H, I / SECAM G, K, K1)
28 - 69 (PAL B AUST.)
13 - 57 (PAL D, K)
13 - 62 (NTSC M JAPAN)
14 - 69 (NTSC M USA)
CATV S1 - S20 (OSCAR)
1 - 125 (USA CATV)
C13 - C49 (JAPAN)
S21 - S41 (HYPER)
Z1 - Z37 (CHINA)
5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating Conditions Temperature : 0°C - 40°C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 Input AUDIO L-R RCA PIN Type ×2 0.5 V [rms]
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
COMPONENT Y 1.0 V [p-p] (including synchronization)
PB/CB, PR/CR± 0.35 V [p-p]
AV2 Input AUDIO L-R RCA PIN Type ×2 0.5 V [rms]
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
Audio Output AUDIO L-R RCA PIN Type ×2 0.5 V [rms] (high impedance)

TH-L32C22T
9
Note
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
Others HDMI Input TYPE A Connectors • This TV supports ‘HDAVI Control 5’ function.
PC Input HIGH-DENSITY D-SUB 15 PIN R, G, B / 0.7 V[p-p] (75 Ω)
HD, VD / TTL LEVEL 2.0-5.0 V [p-p] (high impedance)
Dimension (W x H x D) 920 mm ×556.5 mm ×204 mm (With Pedestal)
920 mm ×525 mm ×149 mm (TV only)
Mass 10.0 kg Net (With Pedestal)
9.5 kg Net (TV only)

TH-L32C22T
10
5 Service Mode
5.1. How to enter into Service Mode
While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds.
5.1.1. Contents of adjustment mode
• Value is shown as a hexadecimal number.
• Preset value differs depending on models.
• After entering the adjustment mode, take note of the value in each item before starting adjustment.
5.1.2. How to exit
Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.
Main item Sub item Sample Data Remark
ADJUST CONTRAST 000
COLOR 4C
TINT 00
SUB-BRT 808
BACKLGT 22E
B-Y-G 34
R-Y-A 00
WB-ADJ R-GAIN F7
G-GAIN FB
B-GAIN DB
R-CENT 82
G-CENT 80
B-CENT 86
OPTION Boot ROM Factory Preset.
STBY-SET 00
EMERGENCY ON
CLK MODE 00
CLOCK 0E4
RM-SET 00 Fixed.
SRV-TOOL 00 See next.

TH-L32C22T
11
5.2. SRV-TOOL
5.2.1. How to access
1. Select [SRV-TOOL] in Service Mode.
2. Press [OK] button on the remote control.
5.2.2. Display of SOS History
SOS History (Number of LED blinking ) indication.
From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment.
This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory
shipment setting].
5.2.3. POWER ON TIME/COUNT
Note : To display TIME/COUNT menu, highlight position, then press MUTE for 3sec.
Time : Cumulative power on time, indicated hour : minute by decimal
Count : Number of ON times by decimal
Note : This indication will not be cleared by either of the self-checks or any other command.
5.2.4. Exit
1. Disconnect the AC cord from wall outlet.

TH-L32C22T
12
5.3. Service Mode Adjustment
1. Press the ‘RECALL’ button on the remote control and press ‘-’ vol button on the LCD panel.
2. Press button number 1 on the remote control to select for Adjustment.
3. Self Check to Exit.
5.3.1. Self Check Mode
1. Press the ‘MENU’ button (on the remote control) and the ‘DOWN’ button on the LCD panel.
2. Press ON/OFF button on the panel to Exit.
5.3.2. Hotel Mode Adjustment
1. Press the ‘VOLUME DOWN’ button on the TV panel and simultaneously press the AV button on the remote control 3 times to
enter Hotel Mode.
2. Set Hotel mode ‘on’, then press ‘EXIT’ to come out.
5.3.3. Hotel Mode
1. Purpose
Restrict a function for hotels.
2. Access command to the Hotel mode setup menu.
In order to display the Hotel mode setup menu, please
enter the following command (within 2 second).
[TV] : Hold Vol [Down] + [Remote] : Press AV button 3
times.
Then, the Hotel mode setup menu is displayed.
Item Functions
Hotel Mode Valid/invalid of Hotel Mode function is set. Off ←→
On
Initial INPUT Off ←→ Analogue TV ←→ Digital TV ←→ AV1
←→ AV2 ←→ AV3 ←→ PC ←→ HDMI 1 ←→
HDMI 2 ←→ HDMI 3
Adjust the input signal when the unit is turned on.
Initial POS Select channel position when the unit is turned on.
When ‘Initial INPUT’ is set to RF (TV/Analogue/
Digital). In other settings of ‘Initial INPUT’ it is not
possible to select it.
Initial VOL level Press Volume button to adjust the volume when
the unit is turned on.
Off ←→ On
Off: Sets normal volume.
On: Sets your preferred volume.
• When ‘Maximum VOL level’ is ‘On’, the volume
can only be adjusted between 0 and your
maximum range.
Maximum VOL
level
Press Volume button to adjust the maximum
volume.
Off ←→ On
Off: Sets auto maximum volume.
On: Sets your preferred maximum volume.
• If the ‘Maximum VOL level’ is set lower than the
‘Initial VOL level’, the ‘Initial VOL level’
automatically becomes the same as the
“Maximum VOL level”
Button lock Select Panel key lock setting Off ←→ SETUP ←→
MENU ←→ All
Off: no key is locked SETUP.
Remote lock Select Remote key lock setting Off ←→ SETUP
←→ MENU.
Off: no key is locked
SETUP: only ‘SETUP’ menu is invalid.
MENU: ‘Main Menu’ is invalid
Welcome Image See another documents

TH-L32C22T
13
6 Troubleshooting Guide
Use the self-check function to test the unit.
1. Checking the IIC bus lines
2. Power LED Blinking timing
6.1. Check of the IIC bus lines
6.1.1. How to access
Self-check indication only:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control
for more than 3 seconds.
Self-check indication and forced to factory shipment setting:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote
control for more than 3 seconds.
6.1.2. Exit
Disconnect the AC cord from wall outlet.
6.1.3. Screen display
6.1.4. Check Point
Confirm the following parts if NG was displayed.

TH-L32C22T
14
6.2. Power LED Blinking timing chart
1. Subject
Information of LED Flashing timing chart.
2. Contents
When an abnormality occurs, the protection circuit will operate and reset the unit to stand by mode. During this time, the
defective block can be identified by the number of blinking times of the Power LED on the front panel of the unit as follow:
6.3. No Power
First check point
There are following 2 states of No Power indication by power LED.
1. No lit
2. Red is lit then turns red blinking a few seconds later. (See 6.2.)
Blinking times Contents BOARD
1 Inverter_SOS IP BOARD
2 SUB 1.8V_SOS A BOARD
3 SUB 1.2V_SOS A BOARD
4 POWER_SOS IP/A BOARD
5 SUB 5V_SOS A BOARD
9 TCON_SOS A BOARD
10 SUB 3.3V_SENSE A BOARD
11 DCDC_SOS A BOARD
12 SOS A BOARD

TH-L32C22T
15
7 Disassembly and Assembly Instructions
7.1. AC Cord Dressing
DRESSING AC CORD.

TH-L32C22T
16
7.2. Backcover Screw and Long Metal Frame
1. After fix I-CELL to CABINET COMPLETE ASSY, fix them by screw.
2. Before that, make sure LVDS wire, sp. Wire and lamp wire (L & R) not hit between I-CELL and CABINET COMPLETE ASSY.

TH-L32C22T
17
7.3. Speaker Assembly Fixing
Fix SPEAKER together RUBBER BUSH to cabinet.

TH-L32C22T
18
7.4. Speaker Assembly & Small Part Installation
Fix LED PANEL and CONTROL BUTTON to CABINET with screw.

TH-L32C22T
19
7.5. Dressing Sp. Wire to Cabinet Ribs
Sp wire dressing must slot-in at location No 1 ~ No 20

TH-L32C22T
20
7.6. Pedestal Assembly 1
1. Fix the STAND MTG SPACER at bottom PEDESTAL COVER with screw.
2. Stick the RUBBER FOOT at bottom PEDESTAL COVER.
