Panasonic Viera TH-65PF11 User manual

Product summary
Product specification (Design and specifications subject to change without notice)
• 65" 1080p High Definition Plasma Display for professional use.
• Equipped with three interchangeable slots-provide flexible and powerful system
solution by adding/exchanging wide variety of optional slot-in boards.
• Available with various unique professional features-Weekly Command Timer, Dual
picture mode, Digital zoom, Built-in video wall image enlarger, etc..
• Various Energy-saving functions-DPMS, Auto power off, Power save mode, etc..
TH-65PF11UK (1/3)
M080903
High Definition
Plasma Display TH-65PF11UK
DISPLAY
Screen Size (Diagonal)
Aspect ratio
Effective Display Area (W x H)
Resolution (H x V)
Pixel Pitch (H x V)
Brightness
Contrast Ratio (Bright room)
Dynamic contrast
Gradation
64.8-inch
16:9
56.4" x 31.7" (1,434 x 807 mm)
1,920 x 1,080 pixels (1pixel=3cells for R, G and B)
0.747 x 0.747 mm
1,200 cd/m
2
30,000:1 (400:1)
1,000,000:1
5,120 steps (equivalent)
APPLICABLE SIGNALS
Scanning format
PC Signal Compatibility
525(480)/60i•60p, 625(575)/50i•50p, 625(576)/50p, 750(720)/60p•50p,
1125(1080)/60i•60p•50i•50p•24p•25p•30p•24sF, 1250(1080)/50i
VGA, SVGA, XGA, WXGA, SXGA, SXGA
+
, UXGA (UXGA : compressed)
Horizontal scanning frequency 15-110 kHz
Vertical scanning frequency 48 -120 Hz
ELECTRICAL
Power Requirements
Operation distance
Weight
DC 3V (2 x AA Size batteries)
approx. 23ft (7m) in front of plasma display
approx. 4.6oz (130g) including batteries
SOUND
Audio Output 20 W [10 W + 10 W] (10% THD)
MECHANICAL
Dimensions (W x H x D)
Weight
Cabinet Color
61.2" x 36.5" x 3.9" (1,554 x 925 x 99 mm)
approx. 150.0 lbs (68.0 Kg)/with speakers 163.2 lbs (74.0 Kg)
Black
EMI REGULATIONS
FCC Part 15 Class-B, ICES-003 Class-B NOM approval
SAFETY STANDARDS
UL6500 Ver.2, NOM approval
IR REMOTE CONTROL
INCLUDED ACCESSORIES
• Fixing Band • AC power cord • Operating instruction book • Remote control • Batteries
OPTIONAL ACCESSORIES
• Wall-hanging bracket (vertical, angled) • Pedestal •Touch Panel • Speakers
• Anti-Glare Filter • Terminal boards
INPUT / OUTPUT
PC IN
AUDIO IN (L/R)
SERIAL
Fixed Terminal
Mini D-sub 15pin x 1 (Female) Analog RGB/Components
*Plug & Play (VESA DDC 2B)
M3 jack x 1
D-sub 9-pin x 1 (Male) External control, RS-232C compatible
ENVIRONMENTAL
Temperature
Humidity
Altitude
Operating environment
32 °F - 104 °F (0 °C - 40 °C)
20 % - 80 % (Non condensation)
0 - 9,100 feet (0 - 2,800 m)
Temperature
Humidity
Altitude
Storage environment
–4 °F - 140 °F (–20 °C - 60 °C)
20 % - 90 % (Non condensation)
0 - 10,800 feet (0 - 3,300 m)
Vacant
HDMI IN
COMPONENT IN
AUDIO IN (L/R)
Interchangeable Terminals
(Slot1)
(Slot2)
(Slot3)
TYPE A connector x 2
BNC x 3 Analog RGB/Components
RCA pin jack x 2
Power Requirements
Power Consumption
Power off condition
Stand-by condition
120 V AC, 50 Hz/60 Hz
755 W
0.2 W
Save OFF 1.0 W, Save ON 0.5 W
Note: Dual picture mode cannot handle the following combinations of two analog signals Component -
Component, Component - PC(RGB), PC(RGB) - Component, PC(RGB) - PC(RGB)

TH-65PF11UK (2/3)
M080903
Dimensions (Shown with optional Pedestal stand) Units : inches (mm)
<Connection terminals>
<Terminal dimension>
61.2 (1554) 3.9 (99)
1.7 (43)
36.5 (925)
15.7 (400)
39.7 (1008)
13.0 (330)10.4 (263) 31.8 (807)
56.5 (1434)
42.3 (1075)
6.7
(171)
16.5 (419)
4.0 (101)
42.3 (1075)
8.0
(205)
25.1 (638)16.2 (411)17.7 (449)
2.2 (56)
<Connection terminals>
With the option pedestal
TY-ST65P11 attached
AC cord connection
SLOT1 PC IN SERIAL
SLOT3
SLOT2
Multi-Function slots Fixed part

Component Video TY-42TM6A/Z PC Input TY-42TM6P Composite Video TY-42TM6B/V BNC Dual Video TY-FB9BD DVI-D TY-42TM6D DVI-D TY-FB11DD HD-SDI with Audio TY-FB10HD HDMI TY-FB8HM Dual HDMI TY-FB10HMD
Pin Assignment and Signal Name
NTSC 15.73 59.94 YY Pin No. Signal name
PAL 15.63 50.00 YY 1CD
PAL60 15.73 59.94 YY 2 RXD
SECAM 15.63 50.00 YY 3 TXD
Modified NTSC 15.73 59.94 YY 4 DTR
525(480)/60i 15.73 59.94 YY Y Y 5 GND
525(480)/60p 31.47 59.94 YY YY YYY 6 DSR
625(575)/50i 15.63 50.00 YY Y Y 7 RTS
625(575)/50p 31.25 50.00 YY Y 8 CTS
625(576)/50p 31.25 50.00 YY YY 9RI
750(720)/60p 45.00 60.00 YY YYYYYY
750(720)/50p 37.50 50.00 YY YYYYYY Transmitting Conditions
1125(1080)/60i 33.75 60.00 YY YYYYYY
1125(1080)/60p 67.50 60.00 YY Y YY
1125(1080)/50i 28.13 50.00 YY YYYYYY
1125(1080)/50p 56.25 50.00 YY Y YY
1125(1080)/30p 33.75 30.00 YY YY Y
1125(1080)/25p 28.13 25.00 YY YY Y
1125(1080)/24p 27.00 24.00 YY YY YY
1125(1080)/24sF 27.00 48.00 YY Y Y
1250(1080)/50i 31.25 50.00 YY Y
2048(1080)/24䌰27.00 24.00
2048(1080)/24䌳F 27.00 48.00
640×400@70Hz 31.46 70.07 YY Y
640×480@60Hz 31.47 59.94 YY YY YYY
640×480@72Hz 37.86 72.81 YY Y
640×480@75Hz 37.50 75.00 YY Y
640×480@85Hz 43.27 85.01 YY Y
800×600@56Hz 35.16 56.25 YY Y
800×600@60Hz 37.88 60.32 YY YY Y
800×600@72Hz 48.08 72.19 YY Y
800×600@75Hz 46.88 75.00 YY Y Signal Name
800×600@85Hz 53.67 85.06 YY Y Pin No.
852×480@60Hz 31.47 59.94 YY YY Y 1
1024×768@50Hz 39.55 50.00 Y2
1024×768@60Hz 48.36 60.00 YY YY Y 3
1024×768@70Hz 56.48 70.07 YY Y 4
1024×768@75Hz 60.02 75.03 YY Y 5
1024×768@85Hz 68.68 85.00 YY Y 6
1066×600@60Hz 37.64 59.94 YY YY Y 7
1152×864@60Hz 53.70 60.00 Y8
1152×864@75Hz 67.50 75.00 YY Y 9
1280×768@60Hz 47.70 60.00 YY Y 10
1280×960@60Hz 60.00 60.00 YY Y 11
1280×960@85Hz 85.94 85.00 YY Y 12
1280×1024@60Hz 63.98 60.02 YYYY
13
1280×1024@75Hz 79.98 75.03 YY Y 14
1280×1024@85Hz 91.15 85.02 YY Y 15
1366×768@50Hz 39.55 50.00 Y
1366×768@60Hz 48.36 60.00 YY YY Y
1400×1050@60Hz 65.22 60.00 Y
1600×1200@60Hz 75.00 60.00 YYYY
1600×1200@65Hz 81.25 65.00 YY Y
1920x1080@60Hz 67.50 60.00 YY YY Y
1920×1200@60Hz 74.04 59.95 YY
Mac13”䋨640×480䋩35.00 66.67 YY Y
Mac16”䋨832×624䋩49.72 74.54 YY Y
Mac21”䋨1152×870䋩68.68 75.06 YY Y
TH-32LR11 series(3/3)
GSMG0903
vertical frequency
(Hz)
Composite
Not used
Ground
Optional Terminal Board
RGB Component / RGB
Signal name
horizontal frequency
(kHz)
Not used
PC IN(D-sub 15-pin) Fixed Terminal
Descriptions
NC
Receive Data
Transmit Data
Serial RS232C : D-sub 9-Pin (Male)
NC (Not connected)
GND (Ground)
NC
ޓޓShort Circuit
Signal name
R (PR/CR)
G (Y)
B (PB/CB)
PC Input : D-Sub 15-Pin (Female)
Signal Level
GND (Ground)
GND (Ground)
GND (Ground)
+5V DC
Preset Input Signals
Synchronization
VD
SCL
Character Length 8 bits
Stop Bit 1 bit
Flow control -
GND (Ground)
NC (Not connected)
SDA
HD/SYNC
Parity None
Complied with
RS232C
Asynchronous
method
Baud Rate 9600 bps
