Panasonic NE-SCV2BPQ User manual

© Panasonic Corporation 2017 Unauthorized copy-
ing and distribution is a violation of law.
Order No.MOD1712487CE
Commercial Microwave Convection Oven
Model No. NE-SCV2BPQ
Product Colour : Silver
Destination : United Kingdom
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3 Technical Descriptions ----------------------------------------- 4
4 Location of Controls and Components ------------------12
5 Installation Instructions---------------------------------------14
6 Instruction for Stacking ---------------------------------------14
7 Important Safety Instructions -------------------------------15
8 Types of Container to Use------------------------------------20
9 Operating Instructions-----------------------------------------22
10 Service Mode -----------------------------------------------------52
11 Troubleshooting Guide----------------------------------------57
12 Disassembly and Assembly Instructions ---------------62
13 Measurements and Adjustments---------------------------74
14 Dimensions ------------------------------------------------------- 75
15 Block Diagram --------------------------------------------------- 76
16 Wiring Connection Diagram--------------------------------- 77
17 Exploded View and Replacement Parts List----------- 78

2
NE-SCV2BPQ
1 Safety Precautions

3
NE-SCV2BPQ
2 Specifications
*1 : The power consumption during grilling, etc. indicates a value measured with the oven pre-heated.
• The power consumption indicates a value measured after the rotation of the cooling fan.
• The power consumption of the oven with the power plug plugged into an outlet and its display turned off is approx. 2.5 W.
(Approx. 4 W when the oven has the initial screen displayed on its display)
Outside Dimensions (W x D x H) 474 mm x 565 mm x 412 mm
Cavity Effective Dimensions (W x D x H) 270 mm x 330 mm x 110 mm
Cavity Capacity 10 L (approx.)
Net Weight 38.3 kg (approx.)
Shipping Dimensions (W x D x H) 584 mm x 712 mm x 579 mm
Gross Weight 46 kg (approx.)
Length of Power Cord 1500 mm (approx.)
Rated Voltage 230-240 V, Single phase
Rated Frequency 50 Hz
Rated Power Consumption 3.6 kW
Rated High-Frequency Output 1050 W
Rated Oscillation Frequency 2450 MHz
Microwave Power Consumption 2.24 kW
High-Frequency Output 1050 W / 900 W / 800 W / 700 W / 600 W / 500 W / 300 W / 200 W / 0 W
Convection Power Consumption 1.465 kW (100% Fan Speed)
Heater Output 1.35 kW
Grill (High) *1 Power Consumption 1.915 kW (100% Fan Speed)
Heater Output 1.80 kW
Grill (Low) *1 Power Consumption 1.265 kW (100% Fan Speed)
Heater Output 1.15 kW
Covection + Grill (High) *1 Power Consumption 3.265 kW (100% Fan Speed)
Heater Output Grill : 1.80 kW / Convection : 1.35 kW
Convection + Grill (Low) *1 Power Consumption 2.615 kW (100% Fan Speed)
Heater Output Grill : 1.15 kW / Convection : 1.35 kW
Convection + Microwave Power Consumption 3.18 kW (100% Fan Speed)
Heater Output 1.35 kW
High-Frequency Output 800 W
Grill (High) + Microwave *1 Power Consumption 3.60 kW (100% Fan Speed)
Heater Output 1.80 kW
High-Frequency Output 800 W
Grill (Low) + Microwave *1 Power Consumption 3.48 kW (100% Fan Speed)
Heater Output 1.15 kW
High-Frequency Output 1050 W
Menu Function Maximum cooking time
Preheating Heating (180 ~ 280 °C)
Convection Heating (180 ~ 280 °C)
• Fan Speed (30 ~ 100%)
30 min
Grill (High / Low) Heating
• Fan Speed(30 ~ 100%)
30 min
Convection + Grill (High / Low) Heating (180 ~ 280 °C)
• Fan Speed (30 ~ 100%)
30 min
Convection + Microwave Heating (180 ~ 280 °C) + Microwave (~ Max800 W)
• Fan Speed (30 ~ 100%)
2 min
Grill (High) + Microwave Heating + Microwave (~ Max800 W)
• Fan Speed (30 ~ 100%)
2 min
Grill (Low) + Microwave Heating + Microwave (~ Max1050 W)
• Fan Speed (30 ~ 100%)
2 min
Cooking in Steps Maximum Microwave Power Consumption & Maximum Cooking Time by Each Step
(Convection & Microwave / Grill & Microwave)
Step1 : Max 800 W (In case Grill (Low), Max 1050 W) 2 min
Step2 : Max 600 W 2 min
Step3 : Max 300 W 30 min
Memory Cooking Heating with a Saved Cooking Programme.
Cooling The inside of the oven can be cooled after convection cooking or grilling. 45 min

4
NE-SCV2BPQ
3 Technical Descriptions
3.1. Operation description
3.1.1. Manual cooking operation
3.1.1.1. Preheating

5
NE-SCV2BPQ
3.1.1.2. Convection Cooking

6
NE-SCV2BPQ
3.1.1.3. Grill Cooking

7
NE-SCV2BPQ
3.1.1.4. Convection-and-Grill Cooking

8
NE-SCV2BPQ
3.1.1.5. Microwave Cooking

9
NE-SCV2BPQ
3.1.1.6. Convection-and-Microwave Cooking

10
NE-SCV2BPQ
3.1.1.7. Grill-and-Microwave Cooking

11
NE-SCV2BPQ
3.1.1.8. Cooling

12
NE-SCV2BPQ
4 Location of Controls and Components

13
NE-SCV2BPQ

14
NE-SCV2BPQ
5 Installation Instructions
Keep the following proper distances between the outer surfaces of the oven and walls.
• Otherwise, overheating can cause damage to the walls, etc., such as burn, deformation or ignition.
To ensure the safe use of the oven, keep distances greater than the ones indicated in the table below between its outer surfaces
and the walls.
6 Instruction for Stacking
Top Left-side Right-side Front Rear Hight
Separation distance (cm) 20 10
(Leave either the right-side or left-side surface open)
Open 3 Less than
150

15
NE-SCV2BPQ
7 Important Safety Instructions

16
NE-SCV2BPQ

17
NE-SCV2BPQ

18
NE-SCV2BPQ

19
NE-SCV2BPQ

20
NE-SCV2BPQ
8 Types of Container to Use
