Panasonic CT-1030M User manual

O
perating
vrtructors
= Color Video Monitor
Model No. CT-1030M
Panasonic.
Please read these instructions completely, before operating this set.

Dear Panasonic Customer;
Welcome to our Panasonic family of customers. It is our desire that you have many years of enjoyment
from your new Color Video Monitor. .
C
aac
eC
Customer’s
Record
The serial number of this product may be found on its back cover. You should note the serial number of
this unit in the space provided and retain this book as a permanent record of your purchase to aid in
identification in the event of theft or loss.
Model number: CT-1030M Serial number:
Note: This Color Video Monitor is designed to operate in the U.S.A. and Canada, and in other countries
where the broadcasting system and AC power are exactly the same as those in the U.S.A. and
Canada.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
The following cautions are attached to this color video monitor:
The lightning flash with arrowhead within
CAUTION a triangle is intended to tell the user that
parts inside the product present a risk of
DO NOT OPEN A
= electric shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, The exclamation point within a triangle is
DO
NOT
REMOVE
COVER
(OR
BACK).
intended
to
tell
the
user
that
important
NO USER-SERVICEABLE PARTS INSIDE . PE A A
, Operating and servicing instructions are
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL i à
contained in the paper work accompany-
ing the video monitor.
PrOCaUitiONS ... cick ek dma vw ce wwle ee oe 44 wd Ree aee L rA a a 2
Features. ........... cece eee eee TPS OOO’. . aug SUT SRE Petey es a es 2
Control LOCATIONS sesa eae e cw ew awd Pee 3. re ncaa ewes 3
QDGrAtIONS s <a s asvccece ok 0 op oe 4-4 leh tag E a a a +, CR ee cei awevs 4
Video/Audio: Terminals.. soso <n «wc ew vin 0 ood eraennw eels aes @ a Uae 5
Connections................- be ek Blt Pe obit aw wos 6
Specifications nisn wee onan caw ds owe Poked Peg he ee, na aaa 6

@ Do not attempt to disassemble the Color Video Monitor.
To prevent electric shock, do not remove screws or cover. There are no user-serviceable parts inside.
Refer servicing to qualified service personnel.
© Location
Adequate ventilation is essential to prevent failure of the electrical components. Avoid direct sunlight
on the set. Do not mount above heat generating equipment or near high magnetic fields.
O) Do not use this Color Video Monitor beyond its temperature and humidity range.
(a) This unit is designed for indoor use. Ambient temperature must not exceed the range of
32°F~104°F (0°C~+40°C).
(b) Avoid using this unit when the humidity is either above 80% or less than 20%.
(c) Do not block the ventilation slits on the bottom, sides and rear panels. If rack mounted, allow
ventilation space or force cool the unit.
O The input power source must be 120V 50Hz/60Hz AC Line.
® Do not remove the grounding pin on the AC power plug.
This Color Video Monitor is equipped with a three wire grounding-type power plug. This plug will
only fit a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug
into the outlet, contact an electrician. Do not defeat the purpose of the grounding plug.
Use a grounding-type
power outlet only.
Do not remove
@ NTSC-M System (American TV Standard 525 Line/60 Field)
Q) Two selectable input signals (LINE/VTR)
@ Front panel controls with easy to use “push-lock” switch
© Video In/Out terminals with automatic impedance change switch (75ohm or high)
© COMB/TRAP Switch (Comb, trap selectable)
© A compact designed attractive metal cabinet
@ Capable of rack-mounting with optional brackets
@ Virtually no magnetic/electrical interference
© Controls
e Front:
POWER/VOLUME CONTRAST
LINE/VTR Switch BRIGHT
COMB/TRAP Switch TINT
V-HOLD COLOR
e Behind Access Panel:
Vertical Size (Front) Horizontal Hold (Rear)
Screen (Rear) Focus (Rear)
Service Switch (Rear)
10) Input/Output
VTR | } 8-Pin EIA Type
VIDEO IN/OUT BNC Type
AUDIO IN/OUT. ž : RCA Phono Type
HEADPHONES Jack: 1/4" Phone RTS Type (Monaural Sound)
a

FRONT
V-SIZE Control
(5) V-HOLD Control
(6) CONTRAST Control
(7) BRIGHT Control
ia ipa |
ID)
l-
icH
(8)
TINT
Control
ae RA ae | (9) COLOR Control
(4) COMB/TRAP Switch
(3) LINE/VTR Switch
(1) POWER/VOL Control
(2) Power Indicator
HEADPHONES Jack
REAR
o
©
000000000000000000000000000000000000
AUDIO IN i 00000000000000000000000000
VIDEO IN
VTR Model Number
VIDEO OUT
AUDIO OUT
00000
co | mrs a
FOCUS
Serial Number
SCREEN
H-HOLD
SERVICE Switch
Note: 1. The circled numbers indicate the control description item on the following page.
2. Screw driver adjustments are for serviceman only.

Note: V-HOLD, CONTRAST, BRIGHT, TINT and COLOR controls are equipped with “push-lock” switches. In
the locked position, the controls are protected from being moved, and in the projected position, they
can be easily touched up.
(1) POWER/VOL Control
(2) Power Indicator
(3) LINE/VTR Switch
(4) COMB/TRAP Switch
(5) V-HOLD Control
(6) CONTRAST Control
(7) BRIGHT Control
TINT Control
(9) COLOR Control
HEADPHONES Jack
1. Turn clockwise to turn the monitor on.
Turn counterclockwise to turn the monitor off.
2. Adjust this control for the appropriate audio level.
The Power Indicator will light when the monitor is
turned on.
LINE: Receives video and audio signal from the VIDEO
IN and AUDIO IN terminals.
VTR: Receives video and audio signal from the VTR
terminal.
Push the COMB/TRAP Switch for trap filter function.
Push again for comb filter function.
Adjust the V-Hold control if the picture rolls up or down.
Adjust the contrast level for proper overall contrast.
There is a click position for normal level.
Adjust brightness level for proper overall picture
brightness.
There is a click position for normal level.
Adjust the Tint control for proper chroma phase of flesh
tones.
Adjust the Color control to set the chroma (saturation)
level.
Audio may be monitored by the headphones using this
jack (monaural sound).

Terminal Board on Rear Cover
Signal Level and Terminal Impedance
ie
ce
Hi
VTR
Note: The video input/output terminals are equipped with “Automatic Termination Switch”. If only input signal
is applied, they are terminated by 75ohm, and if both ea signals applied, they are opened to
high impedance.
VIDEO AUDIO
C) n
AUTO 750/HIGH
OUT
Video signal
includes
sync signal.
1Vrms=0dB
at 400Hz
Video and
audio signal
AUDIO/VIDEO AUDIO VIDEO
LINE IN Terminals Receive video and audio signals from outside source.
This signal is available at the LINE OUT (Throughout)
terminals.
LINE OUT Terminals LINE IN signals are available at this terminal —
(Throughout).
VTR (8-Pin) Terminal Receives video and audio signals from VTR, VCR or
Video Disc which has 8-Pin Connector.
Note:
It
is
possible
to
connect
up
to
10
monitors
in
series
by
looping
through
the
LINE
IN
and
LINE
OUT
terminals.
There may be a possibility of a brightness reduction or interference if more than 10 units are
connected. Please carefully confirm that these problems do not exist with the units before
connection. |

Video Camera
Video Disc
Power Source:
Power Consumption:
Television System:
Dimensions (H x W x D):
Weight:
Picture Tube:
Speaker Output Level:
Operation Temperature Range:
Operation Humidity Range:
Video Disc
120V, 50/60Hz AC
43W (average)
NTSC-M System (American TV Standard 525 Line/60 Field)
1013/16" x 113/16" x 1211/16”
(275 mm) x (284 mm) x (322 mm)
191/4 Ibs. (8.7 kg) |
10 inches, 90° deflection
1.0W (at 10% distortion)
32°F~104°F (0°C~+40°C)
20%~80%
Contents subject to change without notice.
