Panasonic PT-RS11K Operating instructions

Thank you for purchasing this Panasonic product.
■The Operating Instructions correspond to the rmware’s main version 2.00 and higher.
■This manual is common to all the models regardless of sufxes of the Model No.
zfor India
PT-RZ12KD / PT-RS11KD
zfor other countries or regions
PT-RZ12K / PT-RS11K
■Before operating this product, please read the instructions carefully and save this manual
for future use.
■Before using this product, be sure to read “Read this rst!” (xpages 5 to 16).
TQBJ0904-4
DLP™ Projector Commercial Use
Operating Instructions
Functional Manual
ENGLISH
Model No. PT-RZ12K
 PT-RS11K
The projection lens is sold separately.

2 - ENGLISH
Contents
Contents
Read this rst! 5
Chapter 1 Preparation
Precautions for use 20
Cautions when transporting
20
Cautions when installing
20
Security
23
DIGITAL LINK
23
Art-Net
24
Early Warning Software
24
Disposal
24
Cautions on use
24
Accessories
26
Optional accessories
27
About your projector
28
Remote control
28
Projector body
30
Preparing the remote control
33
Inserting and removing the batteries
33
When using the multiple projectors
33
Connecting the remote control to the projector
with a cable
34
Chapter 2 Getting Started
Setting up 36
Installation mode
36
Parts for ceiling mount (optional)
37
Projected image and throw distance
37
Adjusting adjustable feet
47
Attaching/removing the projection lens
(optional)
48
Attaching the projection lens
48
Removing the projection lens
49
Connecting
50
Before connecting
50
Connecting example: AV equipment
51
Connecting example: Computers
52
Connecting example using DIGITAL LINK
53
Connecting example when using the
contrast synchronization function/shutter
synchronization function
54
Chapter 3 Basic Operations
Switching on/off the projector 57
Connecting the power cord 57
Power indicator 57
Switching on the projector 58
When the initial setting screen is displayed
59
Making adjustments and selections
65
Switching off the projector 66
Projecting 67
Selecting the input signal 67
How to adjust focus, zoom, and shift
67
Adjusting the lens position and focus when the
Fixed-focus Lens (Model No.: ET-D75LE90)
is used 68
Setting the lens position 69
Adjustment range by the lens position shift
(optical shift) 69
Adjusting the lens mounter when the focus is
unbalanced 70
Operating with the remote control
73
Switching the input 73
Using the shutter function 74
Using the on-screen display function
75
Using the automatic setup function
75
Switching the image aspect ratio
75
Using the function button 76
Displaying internal test pattern 76
Using the status function 76
Using the AC voltage monitor function
77
Setting ID number of the remote control
77
Chapter 4 Settings
Menu navigation 79
Navigating through the menu 79
Main menu 80
Sub-menu 81

ENGLISH - 3
Contents
[PICTURE] menu
85
[PICTURE MODE]
85
[CONTRAST]
85
[BRIGHTNESS]
86
[COLOR]
86
[TINT]
86
[COLOR TEMPERATURE]
86
[GAMMA]
88
[SYSTEM DAYLIGHT VIEW]
89
[SHARPNESS]
89
[NOISE REDUCTION]
90
[DYNAMIC CONTRAST]
90
[SYSTEM SELECTOR]
91
sRGB-compliant video
92
[POSITION] menu
93
[SHIFT]
93
[ASPECT]
93
[ZOOM]
94
[CLOCK PHASE]
95
[GEOMETRY]
95
[ADVANCED MENU] menu
98
[DIGITAL CINEMA REALITY]
98
[BLANKING]
98
[INPUT RESOLUTION]
99
[CLAMP POSITION]
99
[EDGE BLENDING]
100
[FRAME RESPONSE]
101
[FRAME CREATION]
102
[FRAME LOCK]
102
[RASTER POSITION]
103
[DISPLAY LANGUAGE] menu
104
Changing the display language
104
[3D SETTINGS] menu
105
[3D SYSTEM SETTING]
105
[3D SYNC SETTING]
105
[3D INPUT FORMAT]
106
[LEFT/RIGHT SWAP]
106
[3D COLOR MATCHING]
107
[3D PICTURE BALANCE]
107
[DARK TIME SETTING]
107
[3D FRAME DELAY]
108
[3D TEST MODE]
108
[3D TEST PATTERN]
108
[SAFETY PRECAUTIONS MESSAGE]
109
[3D SAFETY PRECAUTIONS]
109
[DISPLAY OPTION] menu 110
[COLOR MATCHING] 110
[LARGE SCREEN CORRECTION]
111
[SCREEN SETTING] 111
[AUTO SIGNAL] 112
[AUTO SETUP] 112
[BACKUP INPUT SETTING] 113
[SIMUL INPUT SETTING] 114
[RGB IN] 115
[DVI-D IN] 116
[HDMI IN] 117
[DIGITAL LINK IN] 118
[SDI IN] 120
[ON-SCREEN DISPLAY] 121
[IMAGE ROTATION] 123
[BACK COLOR] 123
[STARTUP LOGO] 123
[UNIFORMITY] 124
[SHUTTER SETTING] 124
[FREEZE] 127
[WAVEFORM MONITOR] 127
[CUT OFF] 128
[PROJECTOR SETUP] menu 129
[PROJECTOR ID] 129
[PROJECTION METHOD] 129
[OPERATION SETTING] 129
[LIGHT OUTPUT] 133
[BRIGHTNESS CONTROL] 134
[STANDBY MODE] 138
[NO SIGNAL SHUT-OFF] 138
[NO SIGNAL LIGHTS-OUT] 138
[INITIAL STARTUP] 139
[STARTUP INPUT SELECT]
139
[DATE AND TIME] 139
[SCHEDULE] 140
[MULTI PROJECTOR SYNC]
142
[RS-232C] 144
[REMOTE2 MODE] 146
[FUNCTION BUTTON] 146
[LENS CALIBRATION] 146
[LENS MEMORY] 147
[STATUS] 148
[AC VOLTAGE MONITOR] 149
[SAVE ALL USER DATA] 150
[LOAD ALL USER DATA] 150
[INITIALIZE] 150
[SERVICE PASSWORD] 151
[P IN P] menu 152
Using P IN P function 152
[TEST PATTERN] menu 154
[TEST PATTERN] 154

4 - ENGLISH
Contents
[SIGNAL LIST] menu 155
Registering new signals
155
Renaming the registered signal
155
Deleting the registered signal
155
Protecting the registered signal
156
Expanding signal lock-in range
156
Sub memory
157
[SECURITY] menu
158
[SECURITY PASSWORD]
158
[SECURITY PASSWORD CHANGE]
158
[DISPLAY SETTING]
158
[TEXT CHANGE]
159
[CONTROL DEVICE SETUP]
159
[CONTROL DEVICE PASSWORD CHANGE]
160
[NETWORK] menu
162
[DIGITAL LINK MODE]
162
[DIGITAL LINK SETUP]
162
[DIGITAL LINK STATUS]
163
[NETWORK SETUP]
163
[NETWORK CONTROL]
164
[NETWORK STATUS]
164
[DIGITAL LINK MENU]
165
[Art-Net SETUP]
165
[Art-Net CHANNEL SETTING]
165
[Art-Net STATUS]
166
Network connection
166
Connecting to a twisted-pair-cable transmitter
167
Accessing from the web browser
168
Chapter 5 Maintenance
Light source/temperature/lter indicators 188
When an indicator lights up
188
Maintenance/replacement
190
Before performing maintenance/replacement 190
Maintenance
190
Replacing the unit
192
Troubleshooting
193
Self-diagnosis display
195
Chapter 6 Appendix
Technical information 198
PJLink protocol
198
Using Art-Net function
199
Control commands via LAN
202
<SERIAL IN>/<SERIAL OUT> terminal
205
<REMOTE 2 IN> terminal
209
Two-window display combination list
210
Control device password
211
Upgrade Kit
211
List of compatible signals
212
Specications 218
Dimensions 222
Precautions for attaching the Ceiling Mount
Bracket 223
Index 224

ENGLISH - 5
Read this rst!
Read this rst!
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
or moisture.
This device is not intended for use in the direct eld of view at visual display workplaces. To avoid
incommoding reexions at visual display workplaces this device must not be placed in the direct
eld of view.
The equipment is not intended for used at a video workstation in compliance BildscharbV.
The sound pressure level at the operator position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualied
service personnel.
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong earthing-
type mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you are
unable to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the
earthing plug.
WARNING:
This equipment is compliant with Class A of CISPR32.
In a residential environment this equipment may cause radio interference.
CAUTION: To assure continued compliance, follow the attached installation instructions. This includes using
the provided power cord and shielded interface cables when connecting to computer or peripheral
devices. Also, any unauthorized changes or modications to this equipment could void the user’s
authority to operate this device.
This is a device to project images onto a screen, etc., and is not intended for use as indoor lighting in a
domestic environment.
Directive 2009/125/EC
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
WARNING: RISK OF ELECTRIC SHOCK. DON’T OPEN
or
Indicated on the projector
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.

6 - ENGLISH
Read this rst!
WARNING: Do not look at the light emitted from the lens while the projector is being used.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
Indicated on the projector
Notice on laser
(for USA and Canada)
This projector is the Class 3R laser product that complies with IEC 60825-1:2007.
TQFX609
For North America
“Complies with 21 CFR Parts 1040.10 and 140.11
except for deviations pursuant to Laser Notice
No.50 dated june 24.2007”
IEC 60825-1:2007
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
WAVE LENGTH:448-462nm
MAXIMUM OUTPUT:333mW
IEC 60825-1:2007
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL ÀLASER DE CLASSE 3R
LONGUEURS D'ONDES:448-462nm
MAXIMALE DU RAYONNEMENT:248mW
DURÉE DE L'IMPULSION:1.1ms
TQFX608
DANGER- CLASS 4 LASER RADIATION WHEN OPEN AVOID EYE OR
SKIN EXPOSURE TO DIRECT OR SCATTERED RADIATION
DANGER- RAYONNEMENT LASER DE CLASSE 4 - EN CAS D'OUVERTURE
EXPOSITION DANGEREUSE AU RAYONNEMENT DIRECT OU
DIFFUS DES YEUX OU DE LA PEAU
(Inside of product)
(for Taiwan)
This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.
DPQT1242ZA
此產品可能含有危險的光學輻射。
危險等級 3
(for India)
This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.
TQFX340

ENGLISH - 7
Read this rst!
(for other countries or regions)
This projector is the Class 1 laser product that complies with IEC/EN 60825-1:2014.
TQFX340
CAUTION (North/Middle/South America/Taiwan)
Power Supply: This Projector is designed to operate on 100 V - 240 V, 50 Hz/60 Hz AC, house current only.
CAUTION: The AC power cord which is supplied with the projector as an accessory can only be used for
power supplies up to 125 V. If you need to use higher voltages than this, you will need to obtain a
separate 250 V power cord. If you use the accessory cord in such situations, re may result.
CAUTION (North/Middle/South America/Taiwan)
This equipment is equipped with a three-pin grounding-type power plug. Do not
remove the grounding pin on the power plug. This plug will only t a grounding-type
power outlet. This is a safety feature. If you are unable to insert the plug into the
outlet, contact an electrician. Do not defeat the purpose of the grounding plug.
Do not remove
WARNING (USA and Canada)
fNot for use in a computer room as dened in the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75.
fFor permanently connected equipment, a readily accessible disconnect device shall be incorporated in the
building installation wiring.
fFor pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily
accessible.
NOTIFICATION (Canada)
This class A digital apparatus complies with Canadian ICES-003.
For USA-California Only
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material – special handling
may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate

8 - ENGLISH
Read this rst!
FCC NOTICE (USA)
Verication
Model Number: PT-RZ12K / PT-RS11K
Trade Name: Panasonic
Responsible Party: Panasonic Corporation of North America
Address: Two Riverfront Plaza, Newark, NJ 07102-5490
General Contact: http://www.panasonic.com/support
Projector Contact: https://panasonic.net/cns/projector/
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution:
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
FCC Warning:
To assure continued compliance, follow the attached installation instructions. This includes using the provided
power cord and shielded interface cables when connecting to computer or peripheral devices. Also, any
unauthorized changes or modications to this equipment could void the user’s authority to operate this device.

ENGLISH - 9
Read this rst!
IMPORTANT: THE MOLDED PLUG (U.K. only)
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a molded three pin mains plug for your safety and convenience. A 13 amp fuse
is tted in this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating
of 13 amps and that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you
lose the fuse cover, the plug must not be used until a replacement cover is obtained. A replacement fuse cover
can be purchased from an Authorized Service Center.
If the tted molded plug is unsuitable for the mains socket in your home, then the fuse should be
removed and the plug cut off and disposed of safely. There is a danger of severe electrical shock if the
cut off plug is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are colored in accordance with the following code:
Green - and - Yellow: Earth
Blue: Neutral
Brown: Live
As the colors of the wire in the mains lead of this appliance may not correspond with the colored markings
identifying the terminals in your plug, proceed as follows.
The wire which is colored GREEN - AND - YELLOW must be connected to the terminal in the plug
which is marked with the letter E or by the Earth symbol or colored GREEN or GREEN - AND -
YELLOW.
The wire which is colored BLUE must be connected to the terminal in the plug which is marked
with the letter N or colored BLACK.
The wire which is colored BROWN must be connected to the terminal in the plug which is marked
with the letter L or colored RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
Importer’s name and address within the European Union
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany

10 - ENGLISH
Read this rst!
rHazard distance (IEC 62471-5:2015)
The distance from the projection lens surface, at which the level of exposure has reached the level of the
applicable Exposure Limit Value, is known as the hazard distance (HD) or safety distance.
Do not look into the projected light from inside the hazard distance (within RG3 range). The eyes may be damaged
by the direct irradiation. It is considered to be safe to look into the projected light from outside the hazard distance
(within RG2 range).
RG2
HD
D3
D4
RG3
RG2
HD
D1
D2
RG3
Except ET-D75LE90
rRisk group
The combination of the projector and the projection lens is categorized as the risk group 2 when the hazard
distance is less than 1 m (39-3/8"). It is categorized as the risk group 3 when the hazard distance exceeds 1 m
(39-3/8"), and it will be for professional use instead of consumer use.
In case of risk group 3, there is a possibility of damaging the eyes by direct irradiation when looking into the
projection light from inside the hazard distance (within RG3 range).
In case of risk group 2, it can be used safely without damaging the eyes in any condition.
The combination of the projector and the projection lens which the hazard distance exceeds 1 m (39-3/8") and is
categorized as risk group 3 is as follows.
Projection lens Model No. Risk group
ET-D75LE30
Risk group 3*1
ET-D75LE40
ET-D75LE8
*1 When the projector is used with the optional Zoom Lens (Model No.: ET-D75LE30, ET-D75LE40, ET-D75LE8) attached, the
hazard distance exceeds 1 m (39-3/8"), and regardless of the use condition, the throw ratio is larger than 2.4:1. In this case, it is
categorized as the risk group 3.
THISPROJECTORMAYBECOMERG3FORPROFESSIONALUSE
ONLYANDISNOTINTENDEDFORCONSUMERUSEWHENAN
INTERCHANGEABLEPROJECTIONLENSISUSEDUNDERTHE
CONDITIONTHATTHROWRATIOISGREATERTHAN2.4.
REFERTOTHEOPERATINGINSTRUCTIONSORLEAFLET
FORHAZARDDISTANCEBEFOREOPERATION.
CEPROJECTEURPEUTDEVENIRRG3POURUNEUTILISATION
PROJECTIONINTERCHANGEABLEESTUTILISÉÀCONDITIONQUE
LERAPPORTDEPROJECTIONSOITSUPÉRIEURÀ2,4.
PRENEZCONNAISSANCEDELADISTANCEDURISQUEAVANTDE
DIESERPROJEKTORKANNALSRG3NURFÜRDIEPROFESSIONELLE
VERWENDUNGEINGESTUFTWERDENUNDISTNICHTFÜRDIE
VERWENDUNGDURCHVERBRAUCHERKONZIPIERT,WENNEIN
AUSTAUSCHPROJEKTIONSOBJEKTIVVERWENDETWIRD,UNTER
DERVORAUSSETZUNG,DASSDASPROJEKTIONSVERHÄLTNIS
ÜBER2,4LIEGT.
BEACHTENSIEVORDERBEDIENUNGDIEBEDIENUNGSANLEITUNG
UNDDASFALTBLATTINBEZUGAUFDENGEFÄHRDUNGSABSTAND.
ДАННЫЙ ПРОЕКТОР МОЖЕТ ВХОДИТЬ В ГРУППУ РИСКА RG3 —
ТОЛЬКО ДЛЯ ПРОФЕССИОНАЛЬНОГО ИСПОЛЬЗОВАНИЯ, И ОН
НЕ ПРЕДНАЗНАЧЕН ДЛЯ ИСПОЛЬЗОВАНИЯ ПОТРЕБИТЕЛЯМИ
ПРИ ИСПОЛЬЗОВАНИИ СМЕННЫХ ПРОЕКЦИОННЫХ
ОБЪЕКТИВОВ ПРИ УСЛОВИИ, ЧТО ПРОЕКЦИОННОЕ
ОТНОШЕНИЕ (THROW RATIO) БОЛЬШЕ ЧЕМ 2,4.
ПЕРЕД НАЧАЛОМ РАБОТЫ ОБРАТИТЕСЬ К ИНСТРУКЦИЯМ ПО
ЭКСПЛУАТАЦИИ ИЛИ БРОШЮРЕ, ЧТОБЫ УЗНАТЬ ПРО
ОПАСНОЕ РАССТОЯНИЕ.
이 프로젝터는 투사 비율이 2.4보다 큰 교체식 투사 렌즈를 사용한 경우,
전문가 전용인 RG3 등급이 될 수 있으며, 일반 소비자용이 아닙니다.
작동하기 전에 위험 거리에 대해서는 사용 설명서 또는 안내책자를
참조하십시오.
スローレシオが2.4以上の条件では
RG3になり、民生用ではなく業務用に
なります。
障害距離：取扱説明書または
リーフレットをご覧ください。
DPQT1424ZA

ENGLISH - 11
Read this rst!
Each dimension inside the hazard distance (within RG3 range) for combination with projection lens which the
hazard distance exceeds 1 m (39-3/8") is as follows.
(Unit: m)
Projection lens
Model No. HD*1 D1*2 D2*2 D3*2 D4*2
ET-D75LE30 2.1 0.6 0.6 0.68 0.68
ET-D75LE40 2.5 0.38 0.38 0.43 0.43
ET-D75LE8 4.9 0.46 0.46 0.53 0.53
*1 HD: Hazard Distance
*2 The values of D1 to D4 will change in accordance with the lens shift amount. Each value in the table is the maximum value.
Note
fThe value in the table is based on IEC 62471-5:2015.

12 - ENGLISH
Read this rst!
WARNING:
rPOWER
The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily accessible
when problems occur. If the following problems occur, cut off the power supply immediately.
Continued use of the projector in these conditions will result in re or electric shock.
fIf foreign objects or water get inside the projector, cut off the power supply.
fIf the projector is dropped or the cabinet is broken, cut off the power supply.
fIf you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
fDo not damage the power cord, make any modications to it, place it near any hot objects, bend it
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Do not use anything other than the provided power cord.
Failure to observe this will result in electric shocks or re. Please note that if you do not use the provided power
cord to ground the device on the side of the outlet, this may result in electric shocks.
Completely insert the power plug into the wall outlet and the power connector into the projector terminal.
If the plug is not inserted correctly, electric shocks or overheating will result.
fDo not use plugs which are damaged or wall outlets which are coming loose from the wall.
Do not handle the power plug and power connector with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
fIf dust builds up on the power plug, the resulting humidity can damage the insulation.
fIf not using the projector for an extended period of time, pull the power plug out from the wall outlet.
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
rON USE/INSTALLATION
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam.
Using the projector under such conditions will result in re, electric shocks or deterioration of components.
Deterioration of components (such as ceiling mount brackets) may cause the projector which is mounted on the
ceiling to fall down.
Do not install this projector in a place which is not strong enough to take the full weight of the projector
or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.
Do not cover the air intake/exhaust ports or place anything within 500 mm (19-11/16") of them.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
fDo not place the projector in narrow, badly ventilated places.
fDo not place the projector on cloth or papers, as these materials could be drawn into the air intake port.

ENGLISH - 13
Read this rst!
WARNING:
Do not look at or place your skin into the light emitted from the lens while the projector is being used.
Doing so can cause burns or loss of sight.
fStrong light is emitted from the projector’s lens. Do not look at or place your hands directly into this light.
fBe especially careful not to let young children look into the lens. In addition, turn off the power and switch
off the main power when you are away from the projector.
Do not project an image with the lens cover of the projection lens (optional) attached.
Doing so can cause re.
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
fFor any inspection, adjustment and repair work, please contact an Authorized Service Center.
Doing so may cause exposure to dangerous laser radiation.
fThe laser module is built in this projector. Follow procedures specied in the Operating Instructions to make
operations and adjustments.
Do not allow metal objects, ammable objects, or liquids to enter inside of the projector. Do not allow
the projector to get wet.
Doing so may cause short circuits or overheating, and result in re, electric shock, or malfunction of the
projector.
fDo not place containers of liquid or metal objects near the projector.
fIf liquid enters inside of the projector, consult your dealer.
fParticular attention must be paid to children.
Use the ceiling mount bracket specied by Panasonic.
Using the ceiling mount bracket other than the specied one will result in falling accidents.
fAttach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
Installation work (such as ceiling mount bracket) should only be carried out by a qualied technician.
If installation is not carried out and secured correctly, it can cause injury or accidents, such as electric shocks.
fBe sure to use the wire provided with the ceiling mount bracket as an extra safety measure to prevent the
projector from falling down. (Install in a different location to the ceiling mount bracket.)
rACCESSORIES
Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
fDo not use unspecied batteries.
fDo not charge dry cell batteries.
fDo not disassemble dry cell batteries.
fDo not heat the batteries or place them into water or re.
fDo not allow the + and – terminals of the batteries to come into contact with metallic objects such as
necklaces or hairpins.
fDo not store or carry batteries together with metallic objects.
fStore the batteries in a plastic bag and keep them away from metallic objects.
fMake sure the polarities (+ and –) are correct when inserting the batteries.
fDo not use a new battery together with an old battery or mix different types of batteries.
fDo not use batteries with the outer cover peeling away or removed.
If the battery uid leaks, do not touch it with bare hands, and take the following measures if necessary.
fBattery uid on your skin or clothing could result in skin inammation or injury.
Rinse with clean water and seek medical advice immediately.
fBattery uid coming in contact with your eyes could result in loss of sight.
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.
Do not allow children to reach the lens xing screw.
Accidentally swallowing them can cause physical harm.
fIf swallowed, seek medical advice immediately.
Remove the depleted batteries from the remote control promptly.
fLeaving them in the unit may result in uid leakage, overheating, or explosion of the batteries.

14 - ENGLISH
Read this rst!
CAUTION:
rPOWER
When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric shocks
will result.
When not using the projector for an extended period of time, disconnect the power plug from the wall
outlet.
Failure to do so may result in re or electric shock.
Before replacing the projection lens, be sure to turn off the power and disconnect the power plug from
the wall outlet.
fUnexpected projection of light may cause injury to eyes.
fReplacing the projection lens without removing the power plug may result in electric shock.
Disconnect the power plug from the wall outlet before carrying out any cleaning and replacing the unit.
Failure to do so may result in electric shock.
rON USE/INSTALLATION
Do not place heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
fBe especially careful not to let young children stand or sit on the projector.
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
fTake particular care in locations exposed to direct sunlight or near heaters.
Do not install the projector in a location where salt pollution or corrosive gas may occur.
Doing so may result in falling due to corrosion. Also, it may result in malfunctions.
Do not place your hands or other objects close to the air exhaust port.
Doing so will cause burns or damage your hands or other objects.
fHeated air comes out of the air exhaust port. Do not place your hands or face, or objects which cannot
withstand heat close to this port.
Do not place your hands in the openings beside the optical lens, while shifting the lens.
Failure to observe this could cause injury.
Do not stand in front of the lens while the projector is being used.
Doing so can cause damage and burns to clothing.
fStrong light is emitted from the projector’s lens.
Do not place objects in front of the lens while the projector is being used.
Doing so can cause re, damage to an object, or malfunction of the projector.
fStrong light is emitted from the projector’s lens.
The projector must be carried or installed by two or more people.
Failure to do so may cause falling accidents.
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks to
occur.
When mounting the projector on the ceiling, keep mounting screws and power cord from contact with
metal parts inside the ceiling.
Contact with metal parts inside the ceiling can cause electric shocks.

ENGLISH - 15
Read this rst!
CAUTION:
rACCESSORIES
When not using the projector for an extended period of time, remove the batteries from the remote
control.
Failure to observe this will cause the batteries to leak, overheat, catch re or explode, which may result in re
or contamination of surrounding area.
rMAINTENANCE
Do not attach the air lter unit while it is wet.
Doing so may result in electric shock or malfunctions.
fAfter you clean the air lter units, dry them thoroughly before reattaching them.
Ask your dealer about cleaning inside the projector every 20 000 hours of usage as an estimated
duration.
Continuous use while dust is accumulated inside the projector may result in re.
fFor cleaning fee, ask your dealer.
rVIEWING 3D VIDEO
Those with a medical history of oversensitivity to light, heart problems, or poor physical health should
not view 3D images.
This may lead to a worsening of medical conditions.
If you feel tiredness or discomfort, or other abnormality while viewing with 3D Eyewear, discontinue
viewing.
Continuing use may cause health problems. Take a break as necessary.
When viewing 3D movies, aim to view one movie at a time and take a break as necessary.
When viewing 3D images, for example when playing 3D games or using a PC where two way interaction
is possible, take an appropriate break every 30 to 60 minutes.
Watching for long periods of time may cause eye fatigue.
When preparing contents, use contents properly created to be used for 3D.
This may cause eye fatigue or health problems.
When viewing 3D images, pay attention to people and objects in the vicinity.
3D video may be mistaken for actual objects, and the related bodily movements can cause damage to objects
and lead to injury.
Use 3D Eyewear when viewing 3D videos.
Do not tilt your head when viewing with 3D Eyewear.
Those who are near or far sighted, those with weaker eyesight in one eye, or those with astigmatism
should use corrective glasses etc. when using 3D Eyewear.
If the image appears distinctly double when viewing 3D video, discontinue viewing.
Watching for long periods of time may cause eye fatigue.
View at a distance of at least three times the effective height of the screen.
Viewing at distance closer than the recommended distance may cause eye fatigue. As with movies, if there are
black bands at the top and bottom of the video, view at a distance of 3 times or more of the height of the video
section.
Children younger than 5 or 6 years old should not use 3D Eyewear.
As it is difcult to gauge the reactions of children to fatigue and discomfort their condition may worsen suddenly.
If a child uses the 3D Eyewear, guardians should beware of the child’s eyes becoming tired.

16 - ENGLISH
Read this rst!
To remove the battery
Remote Control Battery
1. Press the guide and lift the cover.
(i)
(ii)
2. Remove the batteries.
Brazil Only
Brasil Apenas
rManuseio de baterias usadas
BRASIL
Após o uso, as pilhas e/ou baterias deverão
ser entregues ao estabelecimento comercial
ou rede de assistência técnica autorizada.
Cobrir os terminais positivo (+) e negativo (-) com uma ta isolante adesiva, antes de depositar numa caixa
destinada para o recolhimento. O contato entre partes metálicas pode causar vazamentos, gerar calor, romper
a blindagem e produzir fogo. (Fig. 1)
Fig. 1
Como isolar os terminais
Não desmonte, não remova o invólucro, nem amasse a bateria. O gás liberado pela bateria pode irritar a
garganta, danicar o lacre do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo
devido ao curto circuito dos terminais. Não incinere nem aqueça as baterias, elas não podem car expostas a
temperaturas superiores a 100 °C (212 °F). O gás liberado pela bateria pode irritar a garganta, danicar o lacre
do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo devido ao curto circuito dos
terminais provocado internamente.
Evite o contato com o liquido que vazar das baterias. Caso isto ocorra, lave bem a parte afetada com bastante
água. Caso haja irritação, consulte um médico.
rRemoção das baterias
1. Pressione a guia e levante a tampa.
(i)
(ii)
2. Remova as baterias.
Fita Isolante
Fita Isolante

ENGLISH - 17
rTrademarks
fSOLID SHINE is a trademark of Panasonic Corporation.
fWindows and Internet Explorer are registered trademarks or trademarks of Microsoft Corporation in the United
States and other countries.
fMac, macOS, and Safari are trademarks of Apple Inc., registered in the United States and other countries.
fTrademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and other
countries and areas.
fThe terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
fCrestron Connected, the Crestron Connected logo, Crestron Fusion, Crestron RoomView, and RoomView
are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other
countries.
fHDBaseTTM is a trademark of HDBaseT Alliance.
fArt-NetTM Designed by and Copyright Artistic Licence Holdings Ltd
fDisplayPort is a trademark or registered trademark of the Video Electronics Standards Association.
fAdobe, Acrobat, Flash Player, and Reader are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
fRealD 3D is a trademark of RealD Inc.
fSome of the fonts used in the on-screen menu are Ricoh bitmap fonts, which are manufactured and sold by
Ricoh Company, Ltd.
fAll other names, company names, and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Please note that the ®and TM symbols are not specied in this manual.
rIllustrations in this manual
fIllustrations of the projector, screen, and other parts may vary from the actual product.
fIllustrations of the projector with the power cord attached are only examples. The shape of the supplied power
cords varies depending on the country where you purchased the product.
rReference pages
fReference pages in this manual are indicated as (x page 00).
rTerm
fIn this manual, the “Wireless/wired remote control unit” accessory is referred to as “Remote control”.

18 - ENGLISH
Features of the Projector
High luminance and high contrast
▶With the high efcient optical system that
maximizes the output of the solid-state
light source, and unique drive system, high
luminance of 12 000 lm and high contrast
of 20 000:1 are realized in addition to the
high color reproduction.
Easy and highly exible setup
▶In addition to the DIGITAL LINK support,
Art-Net support, and abundant lineup
of the optional lens, application to wide
range of usage is possible with support of
all 360° direction projection utilizing the
characteristics of solid-state light source.
Long life and high reliability
▶The maintenance cost for long-term
operation is reduced by the unique light
source cooling control technology and
improvement of the dust resistance. Also,
it will contribute to the stable operation by
implementation of the backup function that
will continue the projection by switching to
the backup input signal immediately even
when the input signal is discontinued, in
addition to adopting solid-state light source
which has long life.
Quick Steps
For details, refer to the corresponding pages.
1. Set up the projector.
(xpage 36)
2. Attach the projection lens
(optional).
(xpage 48)
3. Connect with external devices.
(xpage 50)
4. Connect the power cord.
(xpage 57)
5. Switch on the projector.
(xpage 58)
6. Make initial settings.
(xpage 59)
fTake this step when you switch on the
power for the rst time after purchasing the
projector.
7. Select the input signal.
(xpage 67)
8. Adjust the image.
(xpage 67)

ENGLISH - 19
Chapter 1 Preparation
This chapter describes things you need to know or check before using the projector.

Chapter 1 Preparation — Precautions for use
20 - ENGLISH
Precautions for use
Cautions when transporting
fBefore using the projector, remove the dust sponge from the mounting portion of the projection lens and store it
for the future use. When transporting the projector, remove the projection lens before attaching the dust sponge.
Otherwise dust will accumulate inside and may cause malfunctions.
fTransport the projector with 2 or more people. Failure to do so may drop the projector, which may result in
damage or deformation of the projector, or injury.
fWhen transporting the projector, hold it securely by its bottom and avoid excessive vibration and impacts. They
may damage the internal components and result in malfunctions.
fDo not transport the projector with the adjustable feet extended. Doing so may damage the adjustable feet.
Cautions when installing
rDo not set up the projector outdoors.
The projector is designed for indoor use only.
rDo not set up the projector in the following locations.
fPlaces where vibration and impacts occur such as in a car or vehicle: Doing so may cause damage to internal
components or malfunction.
fLocation close to sea or where corrosive gas may occur: The projector may fall due to corrosion. Also, failure to
do so may shorten the life of the components and result in malfunctions.
fNear the exhaust of an air conditioner: Depending on the conditions of use, the screen may uctuate in rare
cases due to the heated air from the air exhaust port or the hot or cooled air. Make sure that the exhaust
from the projector or other equipment, or the air from the air conditioner does not blow toward the front of the
projector.
fPlaces with sharp temperature uctuations such as near lights (studio lamps): Doing so may shorten the life of
the light source, or result in deformation of the projector due to heat, which may cause malfunctions.
Follow the operating environment temperature of the projector.
fNear high-voltage power lines or near motors: Doing so may interfere with the operation of the projector.
fPlaces where there is high-power laser equipment: Directing a laser beam onto the projection lens surface
causes damage to the DLP chips.
rBe sure to ask a specialized technician or your dealer when installing the projector on
a ceiling.
The optional Ceiling Mount Bracket is required.
Model No.: ET-PKD520H (for High Ceilings), ET-PKD520S (for Low Ceilings), ET-PKD520B (Projector Mount
Bracket)
rAsk a qualied technician or your dealer to install the cable wiring for DIGITAL LINK
connection.
Image and sound may be disrupted if cable transmission characteristics cannot be obtained due to inadequate
installation.
rThe projector may not work properly due to strong radio wave from the broadcast
station or the radio.
If there is any facility or equipment which outputs strong radio waves near the installation location, install the
projector at a location sufciently far from the source of the radio waves. Or, wrap the LAN cable connected to the
<DIGITAL LINK/LAN> terminal using a piece of metal foil or a metal pipe which is grounded at both ends.
rFocus adjustment
The high clarity projection lens is thermally affected by the light from the light source, making the focus unstable in
the period just after switching on the power. It is recommended that images be projected continuously for at least
30 minutes before the focus is adjusted.
