Digital Projection LIGHTNING 30isx+ Operating manual

LIGHTNING 30isx, 40iSX, 30-1080p, 40-1080p,
Reference 1080-30, Reference 1080-40
106-266B
3 Super High Brightness Digital Video Projector
Important Information
10 Super High Brightness Digitaler Videoprojektor
Wichtige Informationen
17 Vidéo projecteur numérique à forte luminosité
Informations importantes
24 Vídeo-proyector digital de alta luminosidad
Información importante
31 Proiettore video digitale ad alta luminosità
Informazioni importanti
38 Digital videoprojektor Super High Brightness
Viktig information

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Digital Projection
Digital Projection Limited,
Greenside Way, Middleton, Manchester M24 1XX, UK.
Registered in England No. 2207264, Registered Office: as above
Tel [phone]
Fax [phone]
Email [email protected], [email protected]
Web Site www.digitalprojection.co.uk
Digital Projection Inc.
55 Chastain Road, Suite 115, Kennesaw, GA 30144. USA
Tel (USA) 770 420 1350
Fax (USA) 770 420 1360
Email [email protected]
Web Site www.digitalprojection.com

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Rev B. April 2008 Page 3
English
Super High Brightness Digital Video Projector
Important Information
This information booklet contains the following extracts from the User Manual:
Full information about operating, connecting and setting up the projector can be found in the
User Manual, located on the CD.
Symbols used in the User Manual
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock
unless the instructions are closely followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself
and/or damage to the equipment unless the instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Contents
Symbols used in the User Manual................................................................................................3
Declaration of Conformity...............................................................................................................4
General precautions .........................................................................................................................5
Installation precautions...................................................................................................................6
Operation and configuration precautions..................................................................................7
Compliance with international standards ..................................................................................7
Noise ................................................................................................................................................7
RF Interference................................................................................................................................7
European Waste Electrical and Electronic Equipment (WEEE) Directive .................................7
Specifications.....................................................................................................................................8
Part numbers...................................................................................................................................8
Optical..............................................................................................................................................8
Electrical ..........................................................................................................................................9
Physical............................................................................................................................................9

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Page 4 Rev B. April 2008
Declaration of Conformity
Directives covered by this Declaration
2004/108/EC Electromagnetic Compatibility Directive.
2006/95/EC Low Voltage Equipment Directive.
Products covered by this Declaration
Large screen video projector type The CE mark was first applied in:
LIGHTNING 30isx+ February 2007
LIGHTNING 40isx+ February 2007
LIGHTNING 30-1080p July 2007
LIGHTNING 40-1080p July 2007
LIGHTNING Reference 1080p-30 July 2007
LIGHTNING Reference 1080p-40 July 2007
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU directives, and
the manufacturer has applied the following standards.
EN 55022:1998 - Limits and Methods of Measurement of Radio Disturbance Characteristics of
Information Technology Equipment.
EN 55024:1998 - Limits and Methods of Measurement of Immunity Characteristics of Information
Technology Equipment.
EN 55103:1997 - Product family Standard for Audio, Video, Audio-Visual and Entertainment
Lighting Control apparatus for Professional Use.
EN 60950-1:2001- Specification for Safety of Information Technology Equipment, including
Electrical Business equipment.
The technical documentation required to demonstrate that the products meet the requirements of the
Low Voltage directive has been compiled by the signatory below and is available for inspection by the
relevant enforcement authorities.
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 23 July 2007
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and limitations
to use which must be observed when these products are taken into service to maintain compliance
with the above directives. Details of these special measures are available on request, and are also
contained in the product manuals.
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Rev B. April 2008 Page 5
General precautions
Do not open the cabinet. There are no user serviceable parts inside.
Use only the power cable provided.
Ensure that the power outlet includes a Ground connection, as this equipment MUST be
earthed.
Take care to prevent small objects such as paper or wire from falling into the projector.
If this does happen, switch off immediately, and have the objects removed by
authorised service personnel.
Do not expose the projector to rain or moisture, and do not place any liquids on top of
the projector.
Unplug before cleaning, and use a damp, not wet, cloth.
Do not touch the power plug with wet hands.
Do not touch the power plug during a thunder storm.
Handle the power cable carefully and avoid sharp bends. Do not use a damaged power
cable.
There are no user-serviceable parts inside the lamp module. The whole module should
be replaced and returned to Digital Projection for re-furbishment.
Take care when removing the lamp module, as it is heavy (>10kg).
Take care not to touch the glass surface of the lamp module. If you do accidentally
touch the glass, it should be cleaned before use.
Do not use the lamp for more than 750 hours, as this may cause serious lamp failure,
damage the lamp module and cause extra cost on replacement.
Xenon lamps produce high intensity light. Do not look directly at the light coming from
the lamp housing, or the lens, or allow items such as magnifying lenses to be placed in
the light path. This could result in serious eye damage.
Do not touch the ventilation outlets, as they will become hot in use.
Do not cover the ventilation outlets or inlets.
Do not cover the lens whilst the projector is switched on. This could cause a fire
Always allow the projector to cool for 5 minutes before switching off the power, moving
the projector or changing the lamp.
Never use strong detergents or solvents such as alcohol or thinners to clean the
projector and lens.
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Page 6 Rev B. April 2008
Installation precautions
Connect the LAN cable only to a computer LAN connection. Other similar connectors
may have a dangerously high voltage source.
The projector must be installed only by suitably qualified personnel, in accordance with
local building codes.
The projector should be installed as close to the power outlet as possible.
The power connection should be easily accessible, so that it can be disconnected in an
emergency.
Ensure that there is at least 30cm (12in) of space between the ventilation outlets and
any wall, and 10cm (4in) on all other sides.
Do not install the projector close to anything that might be affected by its operational
heat, for instance, polystyrene ceiling tiles, curtains etc.
The projector weighs over 100kg (200lbs). Use safe handling techniques when lifting
the projector.
Do not stack more than four projectors.
When stacking projectors, the stack MUST be vertical, to ensure that the stresses are
distributed to all for frame couplings.
Before installation, make sure that the surface, ceiling or rigging that is to support the
projector is capable of supporting the combined weight of the projector and lens (see
specification for exact weights).
Separate backup safety chains or wires should always be used for each projector.
Do not place heavy objects on top of the projector chassis. Only the rigging frame is
capable of withstanding the weight of another projector.
Do not drop or jarr the projector.
The lens release lever should always be set to the locked position to prevent the lens
from falling out.
Place the projector in a dry area away from sources of dust, moisture, steam, smoke,
sunlight or heat.
Do not tilt the projector more than ±12° from side to side when in use, as this may
cause serious lamp failure, damage the lamp module and cause extra cost on
replacement. The projector my be tilted
forwards and backwards as necessary.
±12°
360°
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Rev B. April 2008 Page 7
Operation and configuration precautions
Do not make changes to the networking configuration unless you understand what you
are doing, or have taken advice from your Network Manager. If you make a mistake,
it is possible that you will lose contact with the projector. Always double-check your
settings before pressing the APPLY button. Always keep a written note of the original
settings, and any changes you have made.
Software update should NOT be carried out except by, or with the supervision of, Digital
Projection Service personnel.
Compliance with international standards
Noise
GSGV Acoustic Noise Information Ordinance
The sound pressure level is less than 70 dB (A) according to ISO 3744 or ISO 7779.
RF Interference
FCC
The Federal Communications Commission does not allow any modifications or changes to the unit
EXCEPT those specified by Digital Projection in this manual. Failure to comply with this government
regulation could void your right to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in which case the
user will be responsible for correcting any interference.
This equipment contains an FCC approved RF transmitter module with FCC ID:
R68WIPORT.
European Waste Electrical and Electronic Equipment (WEEE) Directive
Digital Projection Ltd is fully committed to minimising Waste Electrical and Electronic
Equipment. Our products are designed with reuse, recycling and recovery of all components
in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or
its agent so that the environmental impact can be minimised.
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Page 8 Rev B. April 2008
Specifications
Part numbers
Projector: USA 30isx+: 106-262 30-1080p: 107-686
40isx+: 106-387 40-1080p: 106-688
Projector: Rest of World 30isx+: 106-263 30-1080p: 107-687
40isx+: 106-388 40-1080p: 107-689
Reference 1080-30: 107-967
Reference 1080-40: 107-968
Power cable: USA LA00098
Power cable: Rest of World LA00097
Remote control 105-023
4x AAA batteries 105-922
Remote cable 5m 102-162
User manual (CD) 106-267
Important Information 106-266
Lenses
30/40isx+ 30/40-1080p
0.73 : 1 fixed lens 0.67 : 1 fixed lens 105-607
1.2 : 1 fixed lens (3 - 15m) 1.12 : 1 fixed lens (3 - 15m) 105-608
1.2 : 1 zoom lens (1.2 - 2m) 1.12 : 1 fixed lens (1.2 - 2m) 105-609
1.5 - 2.02 : 1 zoom lens 1.39 - 1.87 : 1 zoom lens 105-610
2.02 - 2.77 : 1 zoom lens 1.87 - 2.56 : 1 zoom lens 105-611
2.77 - 4.51 : 1 zoom lens 2.56 - 4.16 : 1 zoom lens 105-612
4.51 - 7.53 : 1 zoom lens 4.16 - 6.96 : 1 zoom lens 105-613
Reference 1080p-30/40
0.67 : 1 fixed lens 107-195
1.12 : 1 fixed lens (3 - 15m) 105-608
1.12 : 1 fixed lens (1.2 - 2m) 105-609
1.39 - 1.87 : 1 zoom lens 107-196
1.87 - 2.56 : 1 zoom lens 107-197
2.56 - 4.16 : 1 zoom lens 107-198
4.16 - 6.96 : 1 zoom lens 107-199
Replacement parts
Lamp module 30: 103-238
40: 104-578
Air filter, complete replacement 104-154
Air filter, replacement filling only 105-222
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Rev B. April 2008 Page 9
Optical
Digital Light Processor isx+: 3 x 0.94” Texas Instruments DMD™,
resolution 1400 x 1050 pixels
1080p: 3 x 0.95” Texas Instruments DMD™,
resolution 1920 x 1080 pixels
Contrast Ratio isx+: 1800:1 full field (±10%)
1080p: 2000:1 full field (±10%)
Reference 1080p: 5000:1 full field (±10%)
Pixel fill factor 87%
Lamp power 30: 3.0kW
40: 3.6kW
Lamp life (typical) 30: 750 hours
40: 500 hours
Brightness 30isx+: 18,000 Center lumens, 16,000 ANSI lumens (±10%)
40isx+: 22,000 Center lumens, 21,000 ANSI lumens (±10%)
30-1080p: 15,000 ANSI lumens (±10%)
40-1080p: 20,000 ANSI lumens (±10%)
Reference 1080p-30: 10,000 ANSI lumens (±10%)
Reference 1080p-30: 14,000 ANSI lumens (±10%)
Colour temperature 3000-9300°K
Electrical
Input RGB1, RGB2, SDI, DVI, Composite Video, S-Video,
Component
Pixel clock up to 165MHz
Control inputs 1 x LAN
1 x wifiLAN
1 x RS232 serial: 19200 baud, 8 bits, 1 stop bit, no parity
1 x remote control
Indicators Input, Power, Shutter, Error, IR, Lamp (Lamp 1 only)
Mains voltage 200-240 VAC, 50/60Hz (single phase)
Power consumption 30: 4000W
40: 4600W
International Regulations Meets FCC Class A requirements
Meets EMC Directives (EN 55022, EN 55024, EN 55103)
Meets Low Voltage Directive (EN 60950)
Physical
Operating Temperature 10 to 35°C
Storage Temperature -10 to 50°C
Thermal Dissipation 30: 13640 BTU/hr
40: 15695 BTU/hr
Operating Humidity up to 80% non-condensing
Weight 114kg (249lbs)
FCC WIFI ID, R68WIPORT
English

Digital Projection LIGHTNING i sx+, 1080p, Reference 1080p
Page 10 Rev B. April 2008
Super High Brightness Digitaler Videoprojektor
Wichtige Informationen
Dieses Informationsheft enthält die folgenden Auszüge aus dem Benutzerhandbuch:
Vollständige Informationen über den Betrieb, den Anschluss und die Einstellungen des
Projektors finden Sie im Benutzerhandbuch auf der CD.
Symbol in diesem Leitfaden
ELEKTRISCHE WARNUNG: Dieses Symbol weist darauf hin, dass Stromschlaggefahr
besteht, wenn die Anweisungen nicht strikt befolgt werden.
WARNUNG: Dieses Symbol weist darauf hin, dass die Gefahr von Körper- und
Sachschäden besteht, wenn die Anweisungen nicht strikt befolgt werden.
HINWEIS: Dieses Symbol weist auf wichtige Informationen hin, die Sie lesen sollten.
Deutsche
Inhalt
Symbol in diesem Leitfaden.........................................................................................................10
Konformitätserklärung................................................................................................................... 11
Allgemeine Vorsichtsmaßnahmen..............................................................................................12
Vorsichtsmaßnahmen bei der Installation................................................................................13
Vorsichtsmaßnahmen bei Betrieb und Konfiguration ..........................................................14
Übereinstimmung mit internationalen Normen ......................................................................14
Lärm ...............................................................................................................................................14
Funkstörung ..................................................................................................................................14
Europäische Richtlinie über Elektro- und Elektronik-Altgeräte (WEEE) .................................14
Technische Daten ............................................................................................................................15
Teilenummern................................................................................................................................15
Optisch...........................................................................................................................................15
Elektrisch.......................................................................................................................................16
Physisch ........................................................................................................................................16
