MITSUBISHI HOME THEATER PROJECTOR
The Finest in Black Levels Inspired
by Mitsubishi Innovation

1
Mitsubishi HC6000 boasts an innovative black reproduction
that is a pure expression of excellence.
Show off breathtakingly vivid images with stunning color saturation and depth.
Heighten the excitement of your visual sense with high contrast pictures
brought on by a ratio of 13,000:1.
With automatic contrast control of the HC6000,
deep blacks harmonize with peak whites easily such that a quick shift
from a bright scene to a low-light or even night scene comes
with instant dynamic richness in each display.
Mitsubishi HC6000 is a visual stimulation realized
with our newly perfected auto iris and lens aperture algorithms.
Bring one home today and enjoy a new dimension of excellence in high definition.
Auto Iris and Lens
Aperture Algorithm
at Work
Every point, every detail, shown with optimal clarity…
Clearly a superior reproduction of black levels,
white levels and all other colors
2
The visual comparisons for the auto-iris and lens aperture are conceptual images.
Auto Iris and Lens
Aperture Algorithm
not at Work

13
Mitsubishi HC6000 boasts an innovative black reproduction
that is a pure expression of excellence.
Show off breathtakingly vivid images with stunning color saturation and depth.
Heighten the excitement of your visual sense with high contrast pictures
brought on by a ratio of 13,000:1.
With automatic contrast control of the HC6000,
deep blacks harmonize with peak whites easily such that a quick shift
from a bright scene to a low-light or even night scene comes
with instant dynamic richness in each display.
Mitsubishi HC6000 is a visual stimulation realized
with our newly perfected auto iris and lens aperture algorithms.
Bring one home today and enjoy a new dimension of excellence in high definition.
Auto Iris and Lens
Aperture Algorithm
at Work
Every point, every detail, shown with optimal clarity…
Clearly a superior reproduction of black levels,
white levels and all other colors

A Statement of Innovation in Visual Expression
With Mitsubishi HC6000 Auto-Iris and Lens Aperture Control
4
Mitsubishi HC6000 offers a swift auto-iris control algorithm
that is often found in higher priced models… It automatically controls
the light intensity on the pixel level of each screen displayed in
high precision and speed for swift transitions from scene to scene.
With this breakthrough, the Mitsubishi HC6000 gives instant tracking
capacity that tones down dark scenes to black levels even when
the scene sequence is set against a backdrop of continuous bright-dark
scene changes, faithfully reproducing every scene detail with vivid clarity.
The auto-iris coupled with the original contrast control featured
in Mitsubishi HC6000, you are sure to have the richest blacks,
the brightest whites, and the vivid richness of all the colors in between.
Featuring our newly developed auto-iris algorithm
that enables control in increments as swift as 1/60™ of a second…
The Mitsubishi HC6000 is built for the demanding optical standards
incorporating a lens system designed for the 14-group/17 lens system.
By incorporating an extra-low dispersion glass lens,
superior performance is achieved over conventional lenses.
Chromatic aberration is also eliminated, resulting in resolution
improvement across the whole picture, all the way to the peripheral
sections of the displayed image. Finally, the addition of a fixed
aperture to lens of the Mitsubishi HC6000 further enhances
the full depth of black levels on screen.
Designed with Extra-Low Dispersion Glass Lens,
Mitsubishi HC6000 is 1080p High Definitionin its Full Glory.
ED (extra-low dispersion) glass lens
New auto-iris (HC6000)
Former auto-iris
Lens aperture OFF Lens aperture ON

The HC6000 is pushing image quality to the next level
6
5
Lens shift right-left motor drive
Lens shift up-down motor drive
Focus motor
Zoom motor
HC6000 Sirocco fan
A B C D
1 frame 1 frame 1 frame 1 frame
A A B B B C C D D D
1 frame 1 frame 1 frame 1 frame
A B C D
A A B B C C D D
24 frame/second
movie film signal
2-3 pulldown for
30 frame/second
output
The HC6000 is compatible with direct Blu-ray's 24P next generation optical disk.With output of 48P (liquid crystal panel 96Hz drive) at twice
the integer of movie film (24 frames/second), duplication of speed, smoothness, as well as detailed textures mirrors the original.
Compatible with 24P Blu-ray direct input for reproduction of original images movements
Our 14-bit gamma correction processing function expands gradation expression power 16-fold over the conventional 10-bit version.
This dramatically raises the capacity to express the subtleties of dark images.
Equipped with 14-bit digital gamma correction (liquid crystal panel driver)
Impressive big-screen images can be enjoyed even in a small room with the 1.6x powered zoom and focus lens. In addition,
the motorized lens shift simplifies vertical and horizontal adjustments, providing maximum flexibility wherever you place the HC6000.
Motorized zoom and focus adjustments with lens shift function greatly enhances ease of set-up
The HC6000 is designed with a newly structured cooling duct to improve liquid crystal panel cooling efficiency. It is also equipped with
a low-noise fan (large-size Sirocco fan) mobilizing a downsized motor that secures an ample air inlet for improved air intake efficiency,
all while slashing the overall noise level to only 19dBA.
Hushed 19dBA low mode noise level
Unparallel HQV next generation performance
The HC6000 is equipped with dual HDMI v1.3 inputs supporting transmission speeds up to 225MHz for pure high definition enjoyment.
Dual HDMI v1.3
The HC6000 is equipped with a new generation inorganic LCD panel. This new LCD panel generates high definition images that
produce rich blacks and vivid colors. Rated to last approximately 10 times longer than conventional organic film panels, this panel
translates to years of viewing enjoyment with high definition colors that stay vibrant and come alive every time you play your movies.
High Definition (1920x1080) Equipped with a New Generation Liquid Crystal Panel
Vertical
blowup
Incident
polarizing
plate group
Liquid crystal panel
Optical path
Cooling
fan
When screening images at 60 frames/second, lining up in 2-frame or
3-frame sequences caused a surplus in the third B-frame, detracting
from movement smoothness.
2-3 pulldown
With the integer multiple of 24 frames/second moved up to 48 frames/second,
a sequence is created with groups of two frames lined up. The bottom
line is a smooth and fluid reproduction of the original image.
24P direct output
24 frame/second
movie film signal
24P
(46Hz reproduction)
Conventional cooling structure New cooling structure
Output polarizing
plate group
Cooling
fan
Cooling
fan
Original new cooling structure for hushed running performance.
Reon-VX next-generation high-performance processor
This high-performance chip carries on the legacy of the REALTA made popular by Silicon Optics,
whose known for visual performance using the name HQV™(Hollywood Quality Video). It excels
behind the scenes as the genuine core of fine visual expression in our HC6000 HD projector.
High-precision I/P conversion, serving all sources
With 10-bit image processing, I/P (interlace/progressive) conversion in the HC6000 is rendered extremely accurate. Even with video-film
mixed sources, specific materials are detected and processed with top speed and precision. This ensures progressive reproduction of
higher picture quality. For terrestrial or satellite digital movies broadcasts, 2-3 pull-down zaps out most jaggies, making the image
look perfect. High-precision 3D processing and 24P new generation discs are also supported.
High-performance video scaler
In addition to I/P conversion, the Reon-VX in the Mitsubishi HC6000 packs high-precision image scaling (pixel conversion) capabilities
into a single chip. The result is impressive up-conversion of 720 X 480 display to 1920 X 1080 images.
Reduced chroma up-sampling errors
With the Reon-VX chip, HC6000 properly compensates for color data compressed at the production level of most DVD titles. This results
in a more faithful reproduction of high-definition images without color blur or loss, including subtle contours.
Conventional Sirocco fan

Screen
25%
Maximum shift
Maximum shift
Left shift
Screen (W)
Right shift
5% 5%
25%
50%
50%
Screen (H)
8
7
Replacement lamp
VLT-HC5000LP
Color domain expansion filter
CF6000
Projection system
Panel size
Number of pixels
Drive system
Array
Zoom/focus operation
Lens shift
f(mm)
Light source lamp
Optical system
Iris
Brightness (lm)
Contrast ratio
Resolution
Video
PC
Video
Serial / RS-232C standard
Trigger terminal
Fan noise
Power source voltage
Power consumption (W)
Weight (kg / lbs)
Main unit dimensions
PC input
Horizontal (kHz)
Vertical (kHz)
Panel specs
Optical specs
Projection screen size (inches)
Images
HC6000
Transmissive liquid crystal system
0.74 type
x 3 Aspect ratio 16:9
1920
x 1080
3 primary color liquid crystal shutter system
Stripe pattern
1.6-power zoom/motorized
Motorized up-down 75% / right-left 5%
23.5-37.6
160W
Mirror color separation / prism synthesis system
Auto-iris
50-300
1000
13,000:1 (auto-iris)
VGA* 640 x 480 - UXGA* 1600 x 1200
15-100
50-120
NTSC, NTSC4.43, PAL (including PAL-M and N), SECAM, PAL-60 Video input: 480i/p, 576i/p, 1080i 60/50, 1080p 60/50/24, 720p 60/50
PC/AT compatibles, Mac
1 terminal
2 terminals
1 terminal
1 terminal
1 terminal (component can be also input to Mini D-Sub 15 pin)
1 terminal (D-Sub 9 pin)
1 terminal
19dBA (at low mode)
AC100V 50/60Hz
250 (at waiting 7W)
5.6 / 12.3
334 x 352 x 125 (excluding height adjustment)
Mode
*: VGA is a registered trademark of IBM Corporation of the United States
Input signal
system
Input
Output
Mini D-Sub 15 pin
HDMI terminal
RCA terminal
S-Video terminal
RCA terminal
Analog RGB
Digital RGB
Composites
S
Components
Functions
Other
Width (mm) x depth (mm) x height (mm)
Side-Loading, Long Life Lamp, Up to 5,000 Hours
Illuminated Remote Control Unit
The Mitsubishi HC6000 is built for the most sophisticated
home theaters or for integration with the simplest home
entertainment systems. A trigger connector commonly used to
control motorized screen retraction is part of the projector,
enabling a quick-start and a faster approach to your total
home theater enjoyment.
Trigger Terminal
3D Micro Surface Structure Air Filter
Ease of User Interface Heightens Your Home Theater Enjoyment
Scan Frequency
Options
Specifications
Projection distance
Vertical direction Horizontal direction
50
60
70
80
90
100
110
120
130
