Panasonic CV-CFW103L User manual

HD Analog Camera
User's Manual
Model No. CV-CFW103L
CV-CFW103LN
Version 1.0.0

i
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Functions .......................................................................................................................1
1.4 Specifications................................................................................................................2
2Framework and Dimensions.....................................................................................................3
3Installation....................................................................................................................................5

ii
Welcome
Thank you for purchasing our HD analog camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

iii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC in the IEC60950-1.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
If this product is installed in the ceiling, please make sure the installation position can sustain the min
50N.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series HD analog camera should be installed in a cool, dry place away from direct sunlight or
strong light, inflammable, explosive substances and etc.
This series camera shall work on the specified working temperature. Please keep it away from the
electromagnetic radiation object and environment.
Please make sure the CMOS component is out of the radiation of the laser beam device. Otherwise it
may result in CMOS optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
6．Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.

iv
7．Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
Use the dry soft cloth to clean the device.
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
Please put the dustproof cap to protect the CMOS component when you do not use the camera.

1
1General Introduction
1.1 Overview
This series HD analog camera conforms to the HDCVI standard. It supports video signal high-
speed long distance transmission without any delay. It can be controlled by the DVR conforming
to the HDCVI.
1.2 Features
High-performance CMOS image sensor, megapixel definition.
Support 720p@25fps(PAL) /30fps (NTSC)
Support HDCVI video output.
Support 75-3 coaxial cable transmission over 800m.
High speed, long distance real-time transmission.
Support ICR switch to realize surveillance both in the daytime and at night.
Support auto exposure, auto white balance, auto electronic shutter and auto gain function.
High image color rendition, vivid image.
Support DC12V power supplying.
Support IP66 compliance.
Support intelligent IR function. max IR distance 30m.
1.3 Functions
HDCVI Specification
HDCVI（High Definition Composite Video Interface）is an over-coaxial –cable HD video
transmission standard. The technology renders two HD video formats by progressive scanning.
ICR
The IR cut removal is to filter the IR light in the daytime and then auto switch to the general fitter
at night. This function allows the camera to output the high sensitivity and clear video.
Smart IR technology
The sensor controls the IR light on/off via the combination work of the hardware and software,
which realizes the automatically IR light compensation according to the environment illumination.
Auto gain function
To output the standard video signal in the different illumination environments, the amplifier needs
to adjust in a wide range. The system can enhance the camera sensitivity in low illumination and
enhance the video signal output to get the clear and high definition video.
Auto white balance
The white balance refers to the camera to restore the white object color. It allows the camera to
automatically adjust the color temperature in indoor and outdoor environment, just like our human
eyes does.

2
Auto exposure
System can automatically set shutter speed and iris value according to the snapshot video
exposure condition.
Auto electronic shutter
The system can automatically adjust the electronic shutter when the environment light changes.
1.4 Specifications
Parameter
CV-CFW103L
CV-CFW103LN
Camera
Image Sensor
1/2.9" 1.0 Mega Pixels CMOS
Effective Pixels
1280 (H) × 720 (V)
Min Illumination
0.05Lux/ F1.6, 0Lux IR on
Electronic Shutter
1/50s~1/100,000s
1/60s~1/100,000s
Video Frame Rate
25fps
30fps
Synchronization
Internal
Day & Night
Auto (ICR)/ Color/ B/W
Max IR Distance
30m
Digital Noise Reduction
2D
White Balance
Auto
AGC
Auto
BLC
Auto
Lens
Focal Length
3.6 mm
Angular Field of View
H: 88 V: 46
Lens Type
M12
Input / Output
Video Output
1 CH BNC HD-CVI video output
General
Power
DC 12V±25%
Power Consumption
2.5W MAX
Working Temperature
-30℃~+60℃.
Less than 95% RH (no condensation)
Dimensions
Φ93.4 mm × 79.7 mm
Weight (approx.)
350g
Installation Mode
Wall mount/ In-ceiling mount
External Case
Metal

3
2Framework and Dimensions
Please refer to the following figures for dimension information. The unit is mm. See Figure 2-1
and Figure 2-2.
Figure 2-1
Figure 2-2
Please refer to the following sheet for detailed information.

4
SN
Name
Function
1
Power input port
Connect to the DC 12V power to input the power.
2
Video output port
BNC port is to output HDCVI video signal.
You can connect to the devices such as the DVR or the NVS conforming to the
HDCVI specifications.
3
Installation base
Device installation base
4
Rotate base
Adjust the rotate base to adjust the monitor angle.
5
Panel cover
Adjust the panel cover to adjust the monitor angle.
6
Dome Body
Adjust the dome body to adjust monitor angle.
7
IR light
It is to send out the IR compensation light to enhance the night vision.
8
Lens
It is to receive the optical signal from the environments.

5
3Installation
Important
Please make sure the installation surface can min support the 3X weight of the camera and
the bracket.
The dome camera usually uses the ceiling installation. It can be installed on the ceiling or the wall.
Step1 Device Installation
Take the hex key from the accessories bag and use it to loosen the three set screws on the side
of the camera body. See Figure 3-1.
Figure 3-1
Step 2 Pedestal Installation
Turn the pedestal of the device and then pull the cable through it. Use four screws to secure the
pedestal to the proper position. See Figure 3-2.
Figure 3-2

6
Step 3 Adjust Monitor Angle
Turn the pan base to the pedestal and secure firmly. Adjust rotate base and the dome body to get
the lens to the proper monitor angle. See Figure 3-3.
Figure 3-3
Step 4 Fix Monitor Angle
To prevent the dome from moving, use hex key to secure the three set screws to secure the
monitor angle position.
Note
This manual is for reference only. Slight difference may be found in the user
interface.
All the designs and software here are subject to change without prior written notice.
All trademarks and registered trademarks mentioned are the properties of their
respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of us.
Please visit our website or contact your local service engineer for more information.
