Panasonic OneHome KX-HCM110A User manual

ORDERNO.KMS0504060CE
F5
NetworkCamera
KX-HCM110A
(forU.S.A.)
 2005PanasonicCommunicationsCo.,Ltd.Allrightsreserved.
Unauthorizedcopyinganddistributionisaviolationoflaw.
IMPORTANTINFORMATIONABOUTLEADFREE,(PbF),SOLDERING
Ifleadfreesolderwasusedinthemanufactureofthisproducttheprintedcircuitboardswillbemarked
PbF.
Standardleaded,(Pb),soldercanbeusedasusualonboardswithoutthePbFmark.
Whenthismarkdoesappearpleasereadandfollowthespecialinstructionsdescribedinthismanual
1

ontheuseofPbFandhowitmightbepermissibletousePbsolderduringserviceandrepairwork.
1.ABOUTLEADFREESOLDER(PbF:Pbfree)
Note:
Intheinformationbelow,Pb,thesymbolforleadintheperiodictableofelements,willrefertostandard
solderorsolderthatcontainslead.
WewillusePbFsolderwhendiscussingtheleadfreesolderusedinourmanufacturingprocesswhich
ismadefromTin,(Sn),Silver,(Ag),andCopper,(Cu).
Thismodel,andotherslikeit,manufacturedusingleadfreesolderwillhavePbFstampedonthePCB.
Forserviceandrepairworkwesuggestusingthesametypeofsolderalthough,withsomeprecautions,
standardPbsoldercanalsobeused.
Caution
-PbFsolderhasameltingpointthatis50°~70°F,(30°~40°C)higher
thanPbsolder.Pleaseuseasolderingironwithtemperaturecontrol
andadjustitto700°±20°F,(370°±10°C).Incaseofusinghigh
temperaturesolderingiron,pleasebecarefulnottoheattoolong.
-PbFsolderwilltendtosplashifitisheatedmuchhigherthanitsmelting
point,approximately1100°F,(600°C).
-IfyoumustusePbsolderonaPCBmanufacturedusingPbFsolder,
removeasmuchoftheoriginalPbFsolderaspossibleandbesurethat
anyremainingismeltedpriortoapplyingthePbsolder.
-WhenapplyingPbFsoldertodoublelayeredboards,pleasecheckthe
componentsideforexcesswhichmayflowontotheoppositeside(See
figure,below).
1.1.SUGGESTEDPbFSOLDER
ThereareseveraltypesofPbFsolderavailablecommercially.Whilethisproductismanufacturedusing
Tin,Silver,andCopper,(Sn+Ag+Cu),youcanalsouseTinandCopper,(Sn+Cu),orTin,Zinc,and
Bismuth,(Sn+Zn+Bi).Pleasecheckthemanufacturer’sspecificinstructionsforthemeltingpointsof
theirproductsandanyprecautionsforusingtheirproductwithothermaterials.Thefollowingleadfree
(PbF)solderwiregaugearerecommendedforserviceofthisproduct:0.3mm,0.6mmand1.0mm.
2

1.2.HOWTORECOGNIZETHATPbFREESOLDERISUSED
MAINBOARD
I/OBOARD
3

CAMERABOARD
4

2.FORSERVICETECHNICIANS
ICsandLSIsarevulnerabletostaticelectricity.
Whenreplacing,thefollowingprecautionswillhelptopreventrecurringmalfunctions.
1.Covertheplasticpartswithaluminumfoil.
2.Groundthesolderingirons.
3.Useaconductivematonthework-table.
4.DonotgraspICorLSIpinswithbarefingers.
3.CAUTION
3.1.SAFETYPRECAUTIONS
1.Beforeservicing,unplugthepowercordtopreventanelectricalshock.
2.Whenreplacingparts,useonlymanufacturer’srecommended
componentsforsafety.
3.Checktheconditionofpowercord.Replaceifwearordamageis
evident.
4.Afterservicing,besuretorestoretheleaddress,insulationbarriers,
insulationpapers,shields,etc.
5.Beforereturningtheservicedequipmenttothecustomer,makethe
followinginsulationresistancetesttopreventashockhazard.
3.2.BATTERYCAUTION
Dangerofexplosionifthebatteryisreplacedincorrectly.Replaceonlywiththesameorequivalenttype
recommendedbythemanufacturer.Discardusedbatteriesaccordingtofollowingcaution:
Disposalortransportationoflithiumbatteriesshouldbeperformedbypermitted,inaccordancewith
federal,stateandlocalguidelines.
Abatterycontinuestohavenotransportationlimitationsaslongasitisseparatedtopreventshort
circuitsandpackedinstrongpackaging.
Commercialfirmsthatdisposeofanyquantityoflithiumcellsshouldhaveamechanisminplaceto
accountfortheirultimatedisposition.Thisisagoodpracticeforalltypesofcommercialorindustrial
waste.
Whenthelithiumbatteryisexchanged,theclocksettingsarecleared.Inthiscase,makeclocksettings
again.
RecommendTypeNumber:
CR2032/1VC1(BAT401)ManufacturedbyMATSUSHITA
5

3.3.TRADEMARKS
-Adobe,AcrobatandReaderareeitherregisteredtrademarksor
trademarksofAdobeSystemsIncorporatedintheUnitedStatesand/or
othercountries.
-Microsoft,Windows,HotmailandActiveXareeitherregistered
trademarksortrademarksofMicrosoftCorporationintheUnitedStates
and/orothercountries.
-PentiumisatrademarkorregisteredtrademarkofIntelCorporationor
itssubsidiariesintheUnitedStatesandothercountries.
-ScreenshotsreprintedwithpermissionfromMicrosoftCorporation.
-Allothertrademarksidentifiedhereinarethepropertyoftheirrespective
owners.
-ThissoftwareisbasedinpartontheworkoftheIndependentJPEG
Group.
3.4.INSULATIONRESISTANCETEST
1.UnplugtheACpowercordandshortthetwoprongsoftheplugwitha
jumperwire.
2.MeasuretheresistancevaluewithohmmeterbetweenthejumperedAC
plugandeachexposedmetalcabinetpart,suchasscrewthreads,etc.
Note:
Someexposedpartsmaybeisolatedfromthechassisbydesign.Thesewillreadinfinity.
3.Ifthemeasurementisoutsidethespecifiedlimits,thereisapossibility
ofshockhazard.Theequipmentshouldberepairedandrechecked
beforeitisreturnedtothecustomer.
6

3.5.POWERCAUTION
Thepowersocketwalloutletshouldbelocatednearthisequipmentandbeeasilyaccessible.
3.6.CLEANING
AfterthecameraisturnedoffbydisconnectingtheACplug,cleanthecamera.
3.6.1.CleaningtheMainUnit
Ifthelenscoverhasthesandorthedust,imagequalitymaydecrease.Aftertakingawaythesandor
thedustonit,wipeitwithadrycloth.
7

Note:
-Donotusealcohol,polishingpowder,cleanser,benzine,thinner,wax,
petroleumproductsorhotwatertowipethecamera.Alsoavoid
pesticide,glasscleanerorhairspray.Theymaycausechangeinthe
shapeorcolor.
-Donotdirectlytouchthelenscover.Yourfingerprintscancausethe
imagetobeoutoffocus.
4.SPECIFICATIONS
NetworkCamera
Items Specifications
Zoom 10xdigitalzoom
Pan/TiltAngle Pan:-60°to+60°,Tilt:-45°to+20°
NumberofPixels 1/4-inchCMOSSensor320,000pixels
Illuminance 5-10,000lx(1-10,000lxincolornightviewmode)
WhiteBalance Auto/Manual/Hold
Focus Fixed0.5m(20inches)-Infinity
CaliberRatio(FNo.) F2.8
HorizontalViewingAngle 43°
Exposure Auto
OtherSpecifications
8

Items Specifications
VideoCompression JPEG(3Levels)
VideoResolution 640x480,320x240(default),160x120
BufferedImage*1 About125frames(320x240)withtimedisplay
AudioCommunication 2-wayHalfDuplex
AudioBandwidth 300Hz-3.4KHz
AudioPlayMethod PlaywithActiveX
InputEncodingMethod EncodingwithActiveX
AudioInput Built-inMicrophoneorExternalMicrophoneInputTerminal
AudioOutput*2 AudioLineOutputTerminalforExternalSpeaker
Framerate*3 Max.12frames/second(640x480)
Max.30frames/second(320x240or160x120)
SupportedProtocols IPv4/IPv6Dual-Stack
-IPv4:
TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3,NTP,IPsec,UPnP 
-IPv6:
TCP,UDP,IP,HTTP,FTP,SMTP,DNS,ICMPv6,POP3,NDP,NTP,IPsec
IPsecFeature ESPEncryption,ESPAuthentication
Transportmode/Tnnelmode
IKE(InternetKeyExchange)
IKE(InternetKey
Exchange)
Pre-SharedKey
CipherAlgorithm DES-CBC,3DES-CBC,AES-CBC
Message-Digest
Algorithm
HMAC-MD5,HMAC-SHA-1
MessageTransfer
Condition
Alarm,TimerorMotionDetection
ImageTransferMethod SMTP,FTP
Interface 10Base-T/100Base-TXEthernetRJ-45connectorx1
IndicatorDisplay Power/NetworkCommunication/Cameraoperation/Ethernetlink
ExternalMicrophone
Input
3.5mmMiniJack
AudioOutput 3.5mmStereoMiniJack(Butoutptismono.)
ExternalI/O ExternalSensorInputx2
ExternalSensorOutputx1
SDMemoryCardSlot FullSize
Dimension(HWD) About100mm(3.94inches)xAbout100mm(3.94inches)xAbout73.5mm
(2.89inches)
Weight 275g(0.61lb.)(Onlytheunit)
PowerSupply ACadaptor:Input120VAC,60Hz
Output12VDC,750mA
Consumption:About2.5W(5.5Wduringpan/tiltscan)
Temperature Operation:0°C(+32°F)to+40°C(+104°F)
Storage:+0°C(+32°F)to+50°C(+122°F)
Humidity Operation:20%-80%(NoCondensation)
Storage:20%-90%(NoCondensation)
9

*1)Themaximumnumberofframeschangesdependingontheimagequalityandwhatobjectyou
buffer.
*2)Connectittoanamplifieroranexternalspeakerwithabuilt-inamplifier.
*3)Frameratemayslowdowndependingonthenetworkenvironment,thePCperformance,theimage
quality,enablingIPsecorwhatobjectyouview.
5.MAINFEATURES
IPv6*1NetworkCamera
YourPanasonicNetworkCamerasupportsIPv6(InternetProtocolVersion6),IPv6wascreatedto
addresstheadditionalIPaddressesthatwillbeneededastheInternetcontinuestoexpand.Sincethe
cameraalsosupportsIPv4that'scurrentlyused,itis"dualstack"designwillseamlesslyoperatewhile
IPv6isphasedin.FormoreinformationinIPv6youwishtovisithttp://www.ipv6.org/.
Audio2-wayCommunication*2(Walkie-talkieType)
YourPanasonicNetworkCameranowprovides2-wayaudio,betweenthecameraandyourPC.Youwill
beabletohearthepersononcameraandrespondusingamicrophoneconnectedtoyourPC'ssound
card(customer-provided.)Theywillhearyourresponsethroughtheamplifiedspeaker(customer-
provided)connectedtothecamera.
Forexample,thecameracanbeusedinthefollowingvariouslocations:
-Inthebaby'sroom,tohearifthebabyiscrying.
-Atthefrontdoor,toseeandhearwhoisatthedoor.
-Inthechildren'splayroom,toseeandheariftheyaresafe.
Note:
PLEASENOTEthatndercertaincircumstances,audio/videorecordingmaybePROHIBITEDbylaw.This
deviceshouldbeusedonlyincompliancewithallapplicablefederal,stateandlocalstatutes.
Digitalzoomfeature*3
Camerahasa10xdigitalzoomfeature.
ThisfeatureallowsyoutoincreaseordecreasethesizeoftheobjectontheSingleCamerascreen,the
MultiCamerascreen,andtheBufferedImagescreen.
Therefore,itwillbeeasytoviewtheobjectthatlocatedtoadistantplace.*4Amousewheeloperation
andclickingtherightmousebuttonincreaseordecreasethesizeoftheobjectontheSingleCamera
screen.
BetterImageQuality
TheCMOSsensorandthecolornightviewmodeprovidesbetterimagequalityandlowlight
performance.
-TheCMOSsensorgivesyouclearimage.
-Youcanmonitorlivevideo(MotionJPEG)thatrefreshesitsimage30
framespersecond.
10

-Colornightviewmodeallowsyoutomonitorthecamerainlow
illuminance.
VariousCameraControlFeatures
Thecamerapansortiltsfastinmaximum80°persecond.Youcancontrolthecameraathighspeed
fromyourPCorcellphone.Alarmpositionfeaturealsoallowsthecameratoautomaticallyturnthelens
tothealarmposition.Additionally,thefollowingcontrolfeaturesareavailabletoeasilyandquickly
monitorthecamera.
ClicktoCenter...Whenyoclickacertainpointonthecameraimage,thepointiscenteredontheimage.
PresetPosition...Youcanregister8presetpositions.Whenyoclickeachbutton,theimageswitchesto
itsposition.
OutputControl...Youcancontroltheexternaldevices(OpenorShorttoGND)(E.g.,turningthelighton
orringingabuzzer).
Multi-CameraSupport
Multi-Camerapagedisplaysupto4cameraswhilesupportingeachaudio2-waycommunication.The
previousmodeldisplaysonly4cameras,butthiscameracanswitch3setsof4cameras.Additionally,
thecameracandisplaysmaximum12camerasonapageinastaticimage.
Multi-LanguageDisplay
Toppage,SingleCameraandMulti-CamerapagecanbedisplayedinEnglish,French,German,Italian,
Spanish,Russian,SimplifiedChineseorJapanese.TheSetup,MaintenanceandSupportpagesare
displayedonlyinEnglishorJapanese.
MotionDetectionfeature
CamerahasaMotionDetectionfeaturethatdetectsmovement,suchaspeople,basedonthepreset
thresholdandsensitivityofCamera.
Youcanbufferthecameraimages,transfertoanFTPserverorsendE-mailsusingtheMotion
Detectionfunctionasatrigger.
*1ToconnectinIPv6,subscribetotheISP's"IPv4/IPv6Dual-Stack"or"IPv6overIPv4Tunneling"
service.ThecameradoesnotworkinIPv6-onlynetwork.
*2Audiofeaturedoesnotworkonmobilephones.TalkbuttonandListenbuttoncannotbeusedsim
ltaneously.InIPv6,theaudiofeaturedoesnotwork.Itwillbesupportedbythefirmwareupdateinthe
future.Inconsequenceoftrafficandnetworkenvironments,theaudiomaybedelayedormaybreakup.
*3Thisfeatureisnotavailablewhenviewingonacellphone.
*4Asthemagnificationincreases,theimagequalitydecreases.
6.PARTSLOCATIONS
6.1.FRONTVIEW
11

IndicatorDisplay
Poweron NotontheLAN Orange Orangeblinking
OntheLAN Orangeblinking Greenblinking
Green
NormalOperation*1 Green
Automatic
Setup
Setting Greenblinking
Finishedseting Greenblinking Green
Using
DHCP
GettingIPaddress*2 Greenblinking
GotIPaddress Green
UpdatingFirmware Orangeblinking
PressingFACTORYDEFAULT
RESETbutton
Orangeblinking Turningoff
(Thecamerarestartsafterthat.)
UPnP Failure Orangeblinking(Abouta2-second
interval)
InternalFailure Redblinking
*1)TheindicatorturnsorangeifthecameraisnotconnectedtotheLAN.
*2)TheindicatorblinksorangeifthecameraisnotconnectedtotheLAN.
6.2.SIDEVIEW
12

6.3.BOTTOMVIEW
6.4.REARVIEW
13

Note:
Tolistentoaudiofromthecamera,anexternalamplifiedspeaker(customer-provided)mustbe
connectedtothecamera.Theconnectorusedisastereotype,similartothatusedbyamplifiedPC
speakers.Thoughtheconnectorisstereo,theaudioisnot.
7.CONNECTINGYOURNETWORKCAMERA
7.1.PREPARATION
PreparethefollowingbeforeconnectingtheNetworkCamera.
-Setupsoftware(SetupCD-ROM)
-PCtofulfillthesystemrequirements.
-EthernetRouterforLANConnection.
-Ethernetcable(twopiecesofCategory5straightcable).
SystemRequirementsforyourPC
YourPC(PersonalComputer)andnetworkmustmeetthefollowingtechnicalspecificationsforthe
cameratoworkproperly.
ForIPv4Connection
14

Item Description
OperationSystem Microsoft Windows XP
Microsoft Windows 2000
Microsoft Windows Me
Microsoft Windows 98SE
CPU -Forviewingsinglecamera
Pentium III(800MHzorgreaterisrecommended.)
-Forviewingmultiplecameras
Pentium 4(1.8GHzorgreaterisrecommended.)
Protocol TCP/IPprotocol(HTTP,TCP,UDP,IP,DNS,ARP,ICMP)
Interface 10/100Mbpsnetworkcardinstalled
WebBrowser InternetExplorer6.0orlater(NotincludedontheSetupCD-ROM)
Audio Audioinput/outputfeature(Microphoneorspeaker)
ForIPv6Connection
Item Description
OperationSystem Microsoft Windows XPServicePack1orlater
CPU -Forviewingsinglecamera
Pentium III(800MHzorgreaterisrecommended.)
-Forviewingmultiplecameras
Pentium 4(1.8GHzorgreaterisrecommended.)
Protocol TCP/IPprotocol(HTTP,TCP,UDP,IP,DNS,ICMPPv6,NDP)
Interface 10/100Mbpsnetworkcardinstalled
WebBrowser InternetExplorer6.0orlater(NotincludedontheSetupCD-ROM)
Audio Audioinput/outputfeature(Microphoneorspeaker)
Note:
SeePanasonicNetworkCamerasupportwebsiteat
http://panasonic.co.jp/pcc/products/en/netwkcam/forthelatestinformationaboutwebbrowser.
7.2.CONNECTTHECAMERATOYOURROUTER
ConnectthecameratoyourrouterwithanEthernetcabletosetupthecamera.
-Beforeyoubegintheinstallation,theUPnP featureinyourrouter
needstobeenabled.Usually,thedefaultsettingdisablesthisfeature.
Formoreinfo,pleasevisit,http://panasonic.co.jp/pcc/products/en/
netwkcam/orcontactyourrouter'smanufacturer.
-TheseinstructionsassumeyourPCisalreadyconnectedtotheInternet
andyourhomenetworkincludesarouterthatisUPnP andPlay)
compliant.
15

-Thecamerawillbeconnectedtoyourrouterusinga"straight"Cat5
networkcable(customer-provided).
1.ConnecttheEthernetcable(customer-provided)tothecamera.
Note:
TheseinstructionsassumeyourPCisalreadyconnectedtotheInternetandyournetworkincludesa
router.
2.ConnecttheEthernetcabletoyourrouter.
7.3.TURNTHECAMERAON
InsertingtheACplugoftheACcordtotheoutletpowersupthecamera.
1.ConnectthepowercordoftheACadaptortotheDCInjack,andplug
theACcordintotheoutlet.
-TheACcordisusedasthemaindisconnectdevice,ensurethat
thesocket-outletislocated/installedneartheequipmentandis
easilyaccessible.
-UseonlyspecifiedPanasonicACadaptorPQLV202(OrderNo.
PQLV202Y).
16

-Iftheindicatordoesnotlightgreen,seepage3ofthe
TroubleshootingontheSetupCD-ROM.
-Anoisecanbeheardduringpan/tiltoperation.Thisisnormal.
2.HooktheACadaptorcordtotheHookforACadaptorcord.
7.4.SETUPTHECAMERA
Important
-Toavoidanypossibleproblems,temporarilydisableanyfirewallor
antivirussoftware.
-Thisprocedureexplainsinstallationofthecameraonthesamenetwork
thatyourPCispartof.
-Beforeproceeding,closeyourwebbrowser.
1.InserttheSetupCD-ROMintotheCD-ROMdriveofthePC.
(IftheNetworkCameraSetupwindowisnotdisplayedautomatically,double-click"Setup.exe"fileon
theSetupCD-ROM.)
17

2.Click[CameraSetup].
-IfWindowsSecurityAlertisdisplayed,click[Unblock].
3.Selectthecameratosetupandclick[Execute].
-Thisprogramsearchesforthecamerasthatareconnectedtotherouter
anddisplaystheMACAddresses,IPaddressesandPortNumbers.
-TheMACAddressontherearsideofthecamerashowswhichcamera
youselectontheCameraListwindow.
18

Note:
-Iftheindicatordoesnotlightgreen,checktheconnection.
-Ifmorethan20minuteshavepassedsincethecamerawasturnedon,
thecameracannotbesetupfromtheSetupProgram.Inthissituation,
disconnecttheACcordfromtheoutlet,andreconnectitagain.
-TheSetupProgrammaynotlistanycamerasduetoyourfirewallor
antivirussoftwaresettingsonyourPC.Ifyoucannotdisableyour
firewallorantivirussoftware,youcansetupthecameraenteringthe
cameraMACaddressonthefollowingwindow.Thecamera'sMAC
addresscanbefoundonthelabelaffixedtothebackofeachcamera.
4.Click[AutomaticSetup(LocalAccessOnly)].
-ForthefirsttimeinstallationorafterpressingtheFACTORYDEFAULT
RESETbutton,only[AutomaticSetup(LocalAccessOnly)]canbe
selected.TosetupthecamerawithStaticorDHCPsettings,after
performingthe[AutomaticSetup(LocalAccessOnly)],runtheSetup
Programagainandselect[ManualSetup].
19

5.Entertheusernameandpasswordyouwishtouse,andclick[Save].
6.TheEnterNetworkPasswordwindowisdisplayed.Entertheusernameandpasswordthatwereset,
andclick[OK].
7.WhentheSingleCamerapageisdisplayed,thesetupiscompleted.
-IfSecurityWarningwindowisdisplayedtoinstallActiveX Controls,
click[Yes].
-ToinstallActiveXControlsonMicrosoftWindowsXPServicePack2,
see"SecurityWarningwindowonMicrosoftWindowsXPServicePack
2".
20
