Panasonic Super Dynamic III WV-CW974 User manual

WV-CW974
Dome Camera
Advanced Auto Track with template matching algorithm
IP66 Rated Weather Proof Structure
Super Dynamic III Camera with 160x Dynamic Range
30x Optical Zoom and 300x including Digital Zoom
400 deg/sec Panning Speed
Enhanced Processing of Natural Colour
New advances in Outdoor Surveillance from the Super Dynamic III dome camera with advanced au-
to track
General
Type Weather Proof Super Dynamic III Colour Dome Camera
Pick-up Device 1/4-type interline transfer CCD
Effective Pixels
Horizontal 752.0
Vertical 582.0
Scanning Area [mm]
Horizontal 3.65
Vertical 2.71
Signal PAL
Synchronization Internal (INT), Multiplexed Vertical Drive (VD2), Line-Lock (LL)
Scanning Mode 2:1 interlace
Scanning Frequency
Horizontal [KHz] 15.625
Vertical [Hz] 50.0
Resolution
Horizontal 480 TV lines minimum (Colour NORMAL mode), 540 TV lines typical.,
520 TV lines minimum (Colour HIGH mode) 570 TV lines minimum (B/
W)
null

Vertical 400 TV lines minimum (Centre)
Dynamic Range 160x
Signal-to-Noise Ratio 50 dB minimum (AGC: OFF)
Minimum Illumination (Colour) 0.5 lux
Minimum Illumination (B/W) 0.04 lux
Weather Protection IP66 protection from water jets from a nozzle (IEC60529/JIS C 0920)
Power Source
Voltage AC [V] 24
Frequency [Hz] 50.0
Power Consumption [W] 77.0
Ambient Operating Temperature [degrees C]
Minimum -40.0
Maximum 50.0
Ambient Operating Humidity [%]
Minimum 0.0
Maximum 90.0
Dimensions [mm]
Diameter 239.0
Height 395.5
Weight [kg] 4.7
Finish Camera: Die cast aluminium, baked on coating (Paint colour: Fine silver
(901)) Sun shield: ASA resin, coated (Paint colour: Fine silver(901)) Do-
me: Clear polycarbonate resin
Main Functions
Controller Interface Coaxial Multiplex System, RS-485
Control Functions Pan and tilt, zoom and focus, 256 preset positions, home position, pa-
trol
Auto Gain Control (AGC) ON (LOW), ON (MID), ON (HIGH), OFF
Zoom Speed approx. 6.0 seconds (TELE ~ WIDE) in manual mode
Focus Speed -
Iris / Light Control ALC (Adjustable OPEN/CLOSE output target level)/MANUAL
Shutter OFF (1/50), AUTO, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000,
1/10,000 s
Motion Detector OFF/MODE1/MODE2
Auto Mode OFF, SEQ, SORT, AUTO PAN, PATROL, AUTO TRACK
Auto Pan SEQ, SORT, AUTO PAN, PATROL, AUTO TRACK
Auto Focus MANUAL/AUTO (PAN, TILT, ZOOM linked)
Back Light Compensation (BLC) -
Sensitivity Enhancement 32x max. (AUTO or FIX)

White Balance -
Adaptive Black Stretch -
Camera Title ON, OFF (Preset ID, camera ID, area title: 16 alphanumeric characters
Image Hold ON/OFF
Digital Flip ON/OFF
Cleaning ON/OFF
Privacy Zone ON/OFF (8 zone settings)
Image Stabilizer ON/OFF
Detail / Aperture Level -
Colour/Mono Switching AUTO/ON/OFF
Patrol STOP/PLAY/LEARN
Scene Select Setting INDOOR (L)/INDOOR (H)/OUTDOOR (L)/OUTDOOR (H)
Password Lock All menus
Language Setting English, German, French, Italian, Spanish, Russian, Chinese, Japanese
Pan and Tilt
Pan Range [360 deg.] endless
Pan Modes Manual, auto, manual position, sequential position
Pan Speed Manual: approx. 0.065 ~ 120 deg/s 8 steps, 16 steps, 64 steps Preset:
approx. 400 deg/s
Tilt Range [-5 ~ 185 deg.] (horizontal - vertical - horizontal) (According to the TILT
ANGLE)
Tilt Modes Manual, manual position, sequential position
Tilt Speed Manual: approx. 0.065 ~ 120 deg/s 8 steps, 16 steps, 64 steps Preset:
approx. 400 deg./s
Lens
Type -
Zoom Ratio 30x (approx. 300x with digital zoom)
Focal Length [mm]
Minimum 3.4
Maximum 114.0
Iris Range / Aperture Ratio f1.4~ f22, Close
Angular Field of View
Horizontal 1.8 degrees (TELE) ~ 52 degrees (WIDE)
Vertical 1.4 degrees (TELE) ~ 40 degrees (WIDE)
Maximum Aperture Ratio 1:1.4 (WIDE) ~ 3.6 (TELE)
Object Distance [m] 1.5
Input/Output
Video Output VBS: 1.0V [p-p]/ 75 Ohms (BNC connector)
Alarm Input x4 (ALARM IN 1 ~ ALARM IN 4)

Alarm Output x2 (ALARM/AUX1, BW/AUX2)
