Panasonic WV-SP105 User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Operating Instructions
Network Camera
Model No. WV-SP105, WV-SP102
WV-SP105E, WV-SP102E
WV-SP105
WV-SP102
WV-SP102WV-SP105

2
23
CONTENTS
Preface ........................................................................ 3
About the user manuals .......................................... 3
About notations....................................................... 3
Trademarks and registered trademarks .................. 3
Abbreviations .......................................................... 3
Viewer software....................................................... 4
Monitor images on a PC.............................................. 5
Monitor images from a single camera..................... 5
About the "Live" page ............................................. 7
Monitor images from multiple cameras................... 9
Action at an alarm occurrence .................................. 10
Alarm type ............................................................. 10
Action at an alarm occurrence .............................. 10
Transmit images onto an FTP server......................... 11
Transmit an alarm image at an alarm occurrence
(Alarm image transmission) ................................... 11
Transmit images at a designated interval or
period (FTP periodic image transmission)............. 11
About the network security ....................................... 12
Equipped security functions.................................. 12
Display the setup menu from a PC ........................... 13
How to display the setup menu ............................ 13
How to operate the setup menu ........................... 14
About the setup menu window ............................. 15
Configure the basic settings of the camera [Basic]... 17
Configure the basic settings [Basic]...................... 17
Configure the settings relating to images [Image]..... 19
Configure the settings relating to the aspect ratio
[JPEG/H.264]......................................................... 19
Configure the settings relating to JPEG images
[JPEG/H.264]......................................................... 19
Configure the settings relating to H.264 images
[JPEG/H.264]......................................................... 20
Configure the settings relating to image quality,
extra zoom and the privacy zone
[Image/Privacy]...................................................... 23
Configure the settings relating to image quality
("Image adjust" setup menu).............................. 24
Set mask areas................................................... 27
Extra zoom setting (Extra zoom setup menu) .... 28
Configure the settings relating to the privacy
zone (Privacy zone setup menu) ........................ 29
Configure the multi-screen settings [Multi-screen] ... 30
Configure the alarm settings [Alarm] ......................... 31
Configure the settings relating to the alarm action
[Alarm] ................................................................... 31
Configure the settings relating to the alarm image
[Alarm] ................................................................... 32
Configure the VMD settings [VMD area]................ 33
Set the VMD areas [VMD area].............................. 35
Configuration of the settings relating to the mail
notification [Notification]........................................ 36
Configure the settings relating to Panasonic
alarm protocol [Notification] .................................. 37
Configure the settings relating to the authentication
[User mng.] ................................................................ 38
Configure the settings relating to the user
authentication [User auth.] .................................... 38
Configure the settings relating to the host
authentication [Host auth.] .................................... 39
Configure the settings relating to the priority
stream [System]..................................................... 40
Configure the settings of the servers [Server] ........... 41
Configure the settings relating to the mail server
[Mail]...................................................................... 41
Configure the settings relating to the FTP server
[FTP] ...................................................................... 42
Configure the settings relating to the NTP server
[NTP]...................................................................... 43
Configure the network settings [Network]................. 44
Configure the network settings [Network]............. 44
Configure the settings relating to DDNS
[DDNS]................................................................... 47
Configure the settings relating to SNMP
[SNMP] .................................................................. 48
Configure the settings relating to the FTP periodic
image transmission [FTP img. trans.].................... 49
Configure the schedule settings of the FTP
periodic image transmission [FTP img. trans.] ...... 50
Configure the settings relating to the schedules
[Schedule].................................................................. 52
Maintenance of the camera [Maintenance] ............... 53
Check the system log [System log]....................... 53
Upgrade the firmware [Upgrade]........................... 54
Reset the settings/Reboot the camera
[Default reset] ........................................................ 55
Viewing Help.............................................................. 56
Displaying the Help screen.................................... 56
About the displayed system log................................ 57
Troubleshooting......................................................... 59

2
23
Preface
About the user manuals
There are 2 sets of operating instructions for the WV-SP105, WV-SP102 (NTSC model), WV-SP105E, WV-SP102E
(PAL model) as follows.
 • InstallationGuide:Explainshowtoinstallandconnectdevices.
 • OperatingInstructions(PDF):Explainshowtoperformthesettingsandhowtooperatethiscamera.
Adobe®Reader®isrequiredtoreadtheseoperatinginstructions(PDF)ontheprovidedCD-ROM.
When the Adobe®Reader®is not installed on the PC, download the latest Adobe®Reader®from the Adobe web
site and install it.
The model number is abbreviated in some descriptions in this manual.
The screens used in these operating instructions show the case of WV-SP105 (NTSC model).
About notations
The following notations are used when describing the functions limited for specified models.
The functions without the notations are supported by all models.
SP105
:ThefunctionswiththisnotationareavailablewhenusingthemodelWV-SP105.
SP102
:ThefunctionswiththisnotationareavailablewhenusingthemodelWV-SP102.
Trademarks and registered trademarks
 • Microsoft,Windows,WindowsVista,WindowsMedia,InternetExplorer,ActiveX,andDirectXareeitherregis-
tered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
 • Microsoftproductscreenshot(s)reprintedwithpermissionfromMicrosoftCorporation.
 • Adobe,theAdobelogo,andReaderareeitherregisteredtrademarksortrademarksofAdobeSystems
Incorporated in the United States and/or other countries.
 • Allothertrademarksidentifiedhereinarethepropertyoftheirrespectiveowners.
Abbreviations
The following abbreviations are used in these operating instructions.
Microsoft®Windows®7 Professional (64-bit) and Microsoft®Windows®7 Professional (32-bit) are described as
Windows 7.
Microsoft®Windows Vista®Business SP1 (32-bit) is described as Windows Vista.
Microsoft®Windows®XPProfessionalSP3isdescribedasWindowsXP.
Windows®Internet Explorer®8.0, Windows®Internet Explorer®7.0 and Microsoft®Internet Explorer®6.0 are
described as Internet Explorer.

4
45
Viewer software
 • Itisnecessarytoinstalltheviewersoftware"NetworkCameraView4S"todisplayimagesonaPC.Thissoft-
warecanbeinstalleddirectlyfromthecameraorbydoubleclicking"nwcv4Ssetup.exe"ontheCD-ROMpro-
vided, and then following the on-screen instructions.
Important:
 • Thedefaultsettingof"AutomaticinstallationofViewersoftware"is
"On".Followtheinstructionsonpage63whenthemessageisdis-
played on the information bar of the browser.
 • Whenthe"Live"pageisdisplayedforthefirsttime,theinstallwiz-
ardoftheActiveXcontrolrequiredtodisplayimagesfromthecam-
era will be displayed. Follow the instructions of the wizard.
 • Whentheinstallwizardisdisplayedagainevenaftercompletingthe
installationoftheActiveX,restartthePC.
 • TheviewersoftwareusedoneachPCshouldbelicensedindividu-
ally. The number of installations of the viewer software from the
camera can be checked on the [Upgrade] tab of the "Maintenance"
page (☞page 54). Refer to your dealer for the software licensing.

4
45
Monitor images on a PC
The following are descriptions of how to monitor images from the camera on a PC.
Monitor images from a single camera
Important:
 • WhentheHTTPportnumberischangedfrom"80",
enter"http://IPaddressofthecamera+:(colon)+
port number" in the address box of the browser.
Example:Iftheportnumberissetto"8080":
http://192.168.0.11:8080
 • WhenthePCisinalocalnetwork,configurethe
proxy server setting of the web browser (under
"InternetOptions…"under"Tools"ofthemenubar)
to bypass the proxy server for the local address.
Step 3
Press the [Enter] key on the keyboard.
→The "Live" page will be displayed. Refer to page 7
for further information about the "Live" page.
When"On"isselectedfor"Userauth.",theauthentica-
tion window will be displayed before displaying live
images for the user name and password entries. The
default user name and password are as follows.
Username:admin
Password:12345
Step 1
Start up the web browser.
Step 2
Enter the IP address designated using the Panasonic IP
setup software in the address box of the browser.
ExamplewhenenteringanIPv4address:
http://URLregisteredusingIPv4address
http://192.168.0.10/
ExamplewhenenteringanIPv6address:
http://URLregisteredusingIPv6address
http://[2001:db8::10]/
<Example of IPv4 access>
<Example of IPv6 access>

6
67
Important:
 • Toenhancethesecurity,changethepasswordfortheusername"admin".Itisrecommendedtochangethis
password periodically.
 • WhendisplayingmultipleH.264imagesonaPC,imagesmaynotbedisplayeddependingontheperformance
of the PC.
Note:
 • Themaximumnumberofconcurrentaccessuseris14includinguserswhoisreceivingH.264imagesandusers
who are receiving JPEG images. Depending on the set values for "Bandwidth control(bit rate)" and "Max bit rate
(per client)*", the maximum concurrent access number may be less than 14 users. When 14 users are concur-
rently accessing, the access limit message will be displayed for users who subsequently attempt to access.
When "Multicast" is selected for "Transmission type" of "H.264", only the first user who accessed to monitor
H.264 images will be included in the maximum number.
 • When"On"isselectedfor"H.264transmission"(☞page20),H.264imageswillbedisplayed.When"Off"is
selected,aJPEGimagewillbedisplayed.ItispossibletodisplayaJPEGimageevenwhen"On"isselectedfor
"H.264 transmission". In this case, the refresh interval of JPEG images will be limited to 5 fps.
 • Therefreshintervalmaybecomelongerdependingonanetworkenvironment,PCperformance,photographic
subject, access traffic, etc.
<Refresh interval of JPEG images>
  When"On"isselectedfor"H.264transmission":Max.5fps
  When"Off"isselectedfor"H.264transmission":Max.30fps

6
67
About the "Live" page
q[Setup] button*1
Displays the setup menu. The button will turn green
and the setup menu will be displayed.
w[Live] button
Display the "Live" page. The button will turn green
and the "Live" page will be displayed.
e[Multi-screen] button
Images from multiple cameras can be displayed on
a multi-screen by registering cameras on the setup
menu. (☞Page 9)
r[Compression] buttons
[H.264] button: The letters "H.264" on the button
will turn green and H.264 image will be dis-
played.When"On"isselectedfor"H.264trans-
mission", the [H.264] button will be displayed.
(☞Page 20)
[JPEG] button: The letters "JPEG" on the button
will turn green and JPEG image will be dis-
played.
t[Image capture size] buttons
These buttons will be displayed only when a JPEG
image is displayed.
[VGA] button: The letters "VGA" will turn green and
images in the main area will be displayed in VGA
size.
[QVGA] button: The letters "QVGA" will turn green
and images in the main area will be displayed in
QVGA size.
[1280x960] button:
SP105
The letters "1280x960" will turn green and
images in the main area will be displayed in
1280 x 960 (pixels).
[640x360] button: The letters "640x360" will turn
green and images in the main area will be dis-
played in 640 x 360 (pixels).
[320x180] button: The letters "320x180" will turn
green and images in the main area will be dis-
played in 320 x 180 (pixels).
[1280x720] button:
SP105
The letters "1280x720" will turn green and
images in the main area will be displayed in
1280 x 720 (pixels).
q
w
e
r
t
y
u
io !0 !1
!2

8
89
Note:
 • Thebuttons[VGA]and[QVGA]aredisplayedonly
when"4:3"isselectedfor"Aspectratio".
 • Thebuttons[640x360]and[320x180]aredisplayed
onlywhen"16:9"isselectedfor"Aspectratio".
 • When"1280x960"or"1280x720"isselectedforthe
image capture size, it may become smaller than the
actual size depending on the window size of the
web browser.
y[Zoom] buttons
[x1] button: The letter "x1" will turn green and
images in the main area will be displayed at x1.
[x2] button: The letter "x2" will turn green and
images in the main area will be displayed at x2.
[x4] button: The letter "x4" will turn green and
images in the main area will be displayed at x4.
u[Brightness] buttons*2
[–] (darker) button: The displayed image will be
darker.
[Normal] button: The adjusted brightness will
return to the default brightness.
[+] (brighter) button: Image will be brighter.
iCamera title
The camera title entered for "Camera title" on the
[Basic] tab will be displayed. (☞Page 17)
oAlarm occurrence indication button*2
This button will be displayed and will blink when an
alarm has occurred. When this button is clicked, the
button will disappear. (☞Page 10)
!0 Full screen button
Images will be displayed on a full screen. (The
aspect ratio of displayed images will be adjusted in
accordance with the monitor.) To return to the "Live"
page, press the [Esc] key.
!1 One shot button
Click this button to take a picture (a still picture).
The picture will be displayed on a newly opened
window. When right-clicking on the displayed
image, the pop-up menu will be displayed. It is pos-
sible to save the image on the PC by selecting
"Save" from the displayed pop-up menu.
When "Print" is selected, printer output is enabled.
!2 Main area
Images from the camera will be displayed in this
area.
The current time and date will be displayed accord-
ing to the settings configured for "Time display for-
mat" and "Date/time display format". (☞Page 17)
When clicking a desired point while displaying live
images at x2 or x4 in the main area, the camera will
move to locate the clicked point at the center of the
main area.
*1 Onlyoperablebyuserswhoseaccesslevelis"1.
Administrator".
*2 Onlyoperablebyuserswhoseaccesslevelis"1.
Administrator"or"2.Cameracontrol"when"On"is
selected for "User auth." (☞page 38).
Note:
 • Whenoperatedbyaloweraccessleveluser,images
displayed on the screen may be changed temporar-
ily. This does not affect operation of the camera.
 • Azoomoperationcanbeperformedusingthe
mouse wheel.
 • DependingonthePCinuse,thetopandbottomof
the images may be displayed out of alignment.

8
89
Step 1
Click the desired [Multi-screen] button.
→Images from the registered cameras will be dis-
played on a selected multi-screen (screen can be
split up to 16 areas). The following are instructions
when displaying on a 4-split screen.
qTo display images on a single screen, click the [Live]
button.
wClick a camera title. Live images from the camera
corresponding to the clicked camera title will be dis-
played on the "Live" page of the newly opened win-
dow.
qw
Monitor images from multiple cameras
Images from multiple cameras can be displayed on a multi-screen. Images from 4 cameras (up to 16 cameras) can
be displayed simultaneously. To display images on a multi-screen, it is necessary to register cameras in advance. 4
cameras can be registered as a group and up to 4 groups (16 cameras) can be registered. (☞Page 30)
Important:
 • Whendisplayingimagesona16-screen,panning,tiltingandzoomingoperationsbecomeunavailablefor
images from the Panasonic PTZ cameras.
 • Whendisplayingimagesona4-screen,panning,tiltingandzoomingoperationsbecomeavailableonlyfor
imagesfromthePanasonicPTZcameras.Refertothe"Readme"fileontheprovidedCD-ROMforfurtherinfor-
mation about the compatible PTZ cameras and their versions.
 • OnlyJPEGimagescanbedisplayedonamulti-screen.Audiowillnotbeheard.
 • WhenthepoweristurnedoffortheLANcableisdisconnectedwhiledisplayingimages,displayingimagesona
multi-screen from the "Live" page will become unavailable.
 • Whendisplayingtheimageonamulti-screenand"16:9"isselectedfor"Aspectratio",theimagewillbedis-
playedalteredverticallytotheaspectratioof"4:3".

10
10 11
Action at an alarm occurrence
The alarm action (camera action at an alarm occurrence) will be performed when the following alarms occur.
Alarm type
VMDalarm: WhenmotionisdetectedinthesetVMDarea,thealarmactionwillbeperformed.
* VMD stands for "Video Motion Detection".
Commandalarm: WhenaPanasonicalarmprotocolisreceivedfromtheconnecteddeviceviaanetwork,the
alarm action will be performed.
Action at an alarm occurrence
Display the alarm occurrence indication button on the "Live" page. (☞Page 8)
The alarm occurrence indication button will be displayed on the "Live" page at an alarm occurrence.
Important:
 • When"Polling(30sec)"isselectedfor"Alarmstatusupdatemode"(☞page 18), the alarm occurrence indication
button will be refreshed in 30 second intervals. For this reason, it may take a maximum of 30 seconds until the
alarm occurrence indication button is displayed on the "Live" page at an alarm occurrence.
Transmit an image onto a server automatically
An alarm image can be transmitted at an alarm occurrence to the server designated in advance. The settings
required to transmit an alarm image to a server can be configured in the "Alarm image" section on the [Alarm] tab of
the "Alarm" page (☞page 32) and the [FTP] tab of the "Server" page (☞page 41).
Notify of alarm occurrences by e-mail
Alarm mail (alarm occurrence notification) can be sent at an alarm occurrence to the e-mail addresses registered in
advance. Up to 4 addresses can be registered as recipients of the alarm mail. An alarm image (still picture) can be
sent with the alarm mail as an attached file. The settings for alarm mail can be configured in the "Mail notification"
section on the [Notification] tab of the "Alarm" page (☞page 36) and the [Mail] tab of the "Server" page (☞page
41).
Notify of alarm occurrences to the designated IP addresses (Panasonic alarm protocol notification)
This function is available only when a Panasonic device, such as the network disk recorder, is connected to the
system.When"On"isselectedfor"Panasonicalarmprotocolnotification",theconnectedPanasonicdevicewillbe
notified that the camera is in the alarm state. The settings for Panasonic alarm protocol can be configured in the
Panasonic alarm protocol section of the [Notification] tab of the "Alarm" page. (☞Page 37)

10
10 11
Transmit images onto an FTP server
Images can be transmitted to an FTP server. By configuring the following settings, transmission of images captured
at an alarm occurrence or captured at a designated interval to an FTP server will become available.
Important:
 • Whenusingthisfunction,settheusernameandthepasswordtoaccesstheFTPservertorestrictuserswho
can log into the FTP server.
Transmit an alarm image at an alarm occurrence (Alarm image
transmission)
An alarm image can be transmitted at an alarm occurrence to the FTP server. To transmit alarm images to an FTP
server, it is necessary to configure the settings in advance.
The settings for the FTP server can be configured on the [FTP] tab of the "Server" page. (☞Page 42)
The alarm image transmission function can be turned on/off in the "Alarm image" section of the [Alarm] tab of the
"Alarm" page. (☞Page 32)
Note:
 • Dependingonthenetworktraffic,thenumberofthetransmittedimagesmaynotreachthesetnumberof
images to be transmitted.
Transmit images at a designated interval or period (FTP peri-
odic image transmission)
Images can be transmitted at a designated interval or period. To transmit images at a designated interval or period,
it is necessary to configure the settings in advance.
The settings for the FTP server can be configured on the [FTP] tab of the "Server" page. (☞Page 42)
It is possible to determine whether or not to use the FTP periodic image transmission function and to configure the
settings relating to alarm images and the schedule on the "FTP img. trans." tab of the "Network" page.
(☞Page 50)
Note:
 • Dependingonthelinespeedorthetraffic,imagesmaynotbetransmittedatthedesignatedinterval.
 • When"On"isselectedforboththealarmimagetransmissionfunctionandtheFTPperiodicimagetransmission
function, the alarm image transmission function will be given priority over the FTP periodic image transmission
function. Therefore, images may not be transmitted at the interval designated on the "FTP periodic image trans-
mission" setting.

12
12 13
About the network security
Equipped security functions
The following security functions are featured in this camera.
qAccess restrictions by the host authentication and the user authentication
It is possible to restrict users from accessing the camera by setting the host authentication and/or the user
authenticationto"On".(☞Pages 38 and 39)
wAccess restrictions by changing the HTTP port
It is possible to prevent illegal access such as port scanning, etc. by changing the HTTP port number.
(☞Page 45)
Important:
 • Designandenhancesecuritycountermeasurestopreventleakageofinformationsuchasimagedata,authenti-
cation information (user name and password), alarm mail information, FTP server information, DDNS server
information, etc. Perform the countermeasure such as the access restriction using the user authentication.
 • Afterthecameraisaccessedbytheadministrator,makesuretoclosethebrowserforaddedsecurity.
 • Changetheadministratorpasswordperiodicallyforaddedsecurity.
Note:
 • Whenuserauthentication(authenticationerror)hasfailedtopass8timeswithin30secondsusingthesameIP
address (PC), access to the camera will be denied for a while.

12
12 13
Display the setup menu from a PC
The settings of the camera can be configured on the setup menu.
Important:
 • Thesetupmenuisonlyoperablebyuserswhoseaccesslevelis"1.Administrator".Refertopage38forhowto
configure the access level.
How to display the setup menu
Step 1
Display the "Live" page. (☞Page 5)
Step 2
Click the [Setup] button on the "Live" page.
→ The window with the user name and password entry
fields will be displayed.
Step 3
Clickthe[OK]buttonafterenteringtheusernameand
the password.
→ The setup menu will be displayed. Refer to page 15
for further information about this menu.

14
14 15
Step 1
Click the desired button in the frame on the left of the
window to display the respective setup menu.
When there are tabs at the top of the setup page dis-
played in the frame on the right of the window, click the
desired tab to display and configure the setting items
relating to the name of the tab.
Step 2
Complete each setting item displayed in the frame on
the right of the window.
Step 3
After completing each setting item, click the [Set] but-
ton to apply them.
Menu buttons Setup page
How to operate the setup menu
Important:
 • Whentherearetwoormore[Set]and[Execute]buttonsonthepage,clicktherespectivebuttontotheedited
setting item.
<Example>
When completing the setting items in field A, click the [Set] button (A-1) below field (A). The edited settings in
field A will not be applied unless the [Set] button (A-1) below field (A) is clicked. In the same manner as above,
click the [Set] button (B-1) below field B when completing the setting items in field B.
B
A
B-1
A-1

14
14 15
About the setup menu window
q[Setup] button
Displays the setup menu.
w[Live] button
Display the "Live" page.
e[Basic] button
Displays the "Basic" page. The basic settings such
as time and date and camera title can be configured
on the "Basic" page. (☞Page 17)
r[Image] button
Displays the "Image" page. The settings relating to
image capture size and image quality of JPEG/H.264
camera images can be configured on the "Image"
page. (☞Page 19)
t[Multi-screen] button
Displays the "Multi-screen" page. The cameras from
which images are to be displayed on a multi-screen
can be registered on the "Multi-screen" page.
(☞Page 30)
y[Alarm] button
Displays the "Alarm" page. The settings relating to
alarm occurrences such as settings for the alarm
action at an alarm occurrence, the alarm occurrence
notification, and the VMD area settings can be con-
figured on the "Alarm" page. (☞Page 31)
u[User mng.] button
Displays the "User mng." page. The settings relating
to the authentication such as users and PCs restric-
tions for accessing the camera can be configured
on the "User mng." page. (☞Page 38)
i[Server] button
Displays the "Server" page. The settings relating to
the mail server, the FTP server and the NTP server
to which the camera accesses can be configured on
the "Serve" page. (☞Page 41)
o[Network] button
Displays the "Network" page. The network settings
and the settings relating to DDNS (Dynamic DNS),
SNMP (Simple Network Management Protocol) and
the FTP (File Transfer Protocol) periodic transmis-
sion can be configured on the "Network" page.
(☞Page 44)
!4 Setup page
!3 Camera title
w[Live] button
q[Setup] button
e[Basic] button
r[Image] button
t[Multi-screen] button
y[Alarm] button
u[User mng.] button
i[Server] button
o[Network] button
!0 [Schedule] button
!1 [Maintenance] button
!2 [Help] button

16
16 17
!0 [Schedule] button
  Displaysthe"Schedule"page.Onthe"Schedule"
page, it is possible to designate time zones to allow
to activate the VMD detection function or allow to
access the cameras. (☞Page 52)
!1 [Maintenance] button
Displays the "Maintenance" page. System log
check, firmware upgrade and initialization of the
setup menu can be carried out on the
"Maintenance" page. (☞Page 53)
!2 [Help] button
Displays the "Help" page. (☞Page 56)
!3 Camera title
The title of the camera whose settings are currently
being configured will be displayed.
!4 Setup page
Pages of each setup menu will be displayed. There
are tabs for some setup menus. When the under-
lined item is clicked, the corresponding help page
will be displayed.

16
16 17
Configure the basic settings of the camera [Basic]
The basic settings such as camera title and time and date can be configured on the "Basic" page.
Configure the basic settings [Basic]
Click the [Basic] tab on the "Basic" page. (☞Pages13and14:Howtodisplay/operatethesetupmenu)
The settings such as the camera title, time and date, etc. can be configured on this page.
[Camera title]
Enter the title of the camera. Click the [Set] button after
entering the title of the camera. The entered title will be
displayed in the camera title field.
Available number of characters: 0 - 20 characters
Default: Varies as follows depending on the model in
use.
WV-SP105
WV-SP102
[Date/time]
Enter the current time and date. When "12h" is selected
for "Time display format", "AM" or "PM" can be
selected.
Available range:01/01/201000:00:00-31/12/2035
23:59:59
Important:
 • UseanNTPserverwhenthemoreaccuratetime&
date setting is required for the system operation. ☞
Page 43)
[Time display format]
Select the time display format from "24h", "12h" and
"Off".Enterthecurrenthourreflectingthissettingwhen
entering the current time and date for "Date/time". To
hidetimeanddate,select"Off".
Default: 24h
[Date/time display format]
Select a date/time display format. When "2010/04/01
13:10:00"issetfor"Date/time"afterselecting"24h"for
"Date/timedisplayformat",time&datewillberespec-
tively displayed as follows.
DD/MM/YYYY:01/04/201013:10:00
MM/DD/YYYY:04/01/201013:10:00
DD/Mmm/YYYY: 01/Apr/201013:10:00
YYYY/MM/DD:2010/04/0113:10:00
Mmm/DD/YYYY:Apr/01/201013:10:00
Default: DD/MM/YYYY (PAL model)
Mmm/DD/YYYY (NTSC model)
[Summer time(daylight saving)]
Select"In"or"Out"todeterminewhetherornotto
apply daylight saving time. Configure this setting if the
summer time (daylight saving time) is applied in the
location where the camera is in use.
In: Applies summer time. An asterisk (*) will be dis-
played on the left side of the displayed time and
date.
Out: Does not apply summer time.
Default:Out
[Camera title on screen]
Select"On"or"Off"todeterminewhetherornottodis-
play the camera title on the screen.
When"On"isselected,thecharacterstringenteredfor
"Camera title on screen(0 - 9,A - Z)" will be displayed at
thepositionselectedfor"OSDposition".
Default:Off
[Camera title on screen(0 - 9,A - Z)]
Enter a character string to be displayed on the image.
Available number of characters: 0 - 16 characters
Available characters: 0-9, A-Z and the following
marks.
!"#$%&'()*+,-./:;=?
Default: None (blank)

18
18 19
[OSD position]
Select the position where the time and date and a char-
acter string to be displayed on the image of the "Live"
page.
Upper left: The above information will be displayed at
the upper left corner of the main area on the "Live"
page.
Lower left: The above information will be displayed at
the lower left corner of the main area on the "Live"
page.
Upper right: The above information will be displayed at
the upper right corner of the main area on the "Live"
page.
Lower right: The above information will be displayed at
the lower right corner of the main area on the "Live"
page.
Default: Upper left
[Brightness status display]
Select"On"or"Off"todeterminewhetherornottodis-
play the status of brightness on images displayed on
the "Live" page when adjusting brightness.
Default:On
[Link/Access indicator]
Determine whether or not to use the following indica-
tors.Select"On"tousethefollowingindicatorsto
check the operational status by lighting them.
Select"Off"toturnofftheindicatorsatalltimes.
 • Powerindicator
 • Linkindicator
 • Accessindicator
Default:On
Note:
 • Power indicator (green):
This indicator will light when the power is on.
 • Link indicator (orange):
This indicator will light when communication with
the connected device is available.
 • Access indicator (Green):
This indicator will light when accessing a network.
[Alarm status update mode]
Select an interval of the camera status notification from
the following.
When the status of the camera changes, the alarm
occurrence indication button will be displayed to notify
of the camera status.
Polling(30sec): Updates the status each 30 seconds
and provide notification of the camera status.
Real time: Provide notification of the camera status
when the status has changed.
Default: Real time
Note:
 • Dependingonthenetworkenvironment,notification
may not be provided in real time.
[Alarm status reception port]
When selecting "Real time" for "Alarm status update
mode", designate a port number to which the status
change notification is to be sent.
Refer to the help window to infomation about the
unavailable port number.
Available port number: 1 - 65535
Default: 31004
[Automatic installation of viewer software]
Determine whether or not to install the viewer software
from this camera.
On: Installs the viewer software from the camera auto-
matically.
Off: The viewer software cannot be installed from the
camera.
Default:On
Important:
 • Itisimpossibletodisplayimageswhentheviewer
software "Network Camera View 4S" is not installed
on the PC.
 • Thenumberoftheviewersoftwareinstallationscan
be checked on the [Upgrade] tab of the
"Maintenance" page.

18
18 19
Configure the settings relating to images [Image]
The settings relating to JPEG and H.264 images such as the settings of image quality, etc. can be configured on
this page.
The"Image"pagehas2tabs;the[JPEG/H.264]tabandthe[Image/Privacy]tab.
Configure the settings relating to the aspect ratio [JPEG/H.264]
Click the [JPEG/H.24] tab on the "Image" page. (☞Pages13and14:Howtodisplay/operatethesetupmenu)
[Aspect ratio]
Select"4:3"or"16:9"fortheaspectratio.
Default:4:3
Configure the settings relating to JPEG images [JPEG/H.264]
Click the [JPEG/H.24] tab on the "Image" page. (☞Pages13and14:Howtodisplay/operatethesetupmenu)
■JPEG
Configure the settings such as "Refresh interval
(JPEG)*", "Image capture size" and "Image quality" on
this section. Refer to page 20 for further information
about the settings relating to H.264 images.
[Refresh interval (JPEG)*]
Select an interval to refresh the displayed JPEG image
from the following.
0.1fps/ 0.2fps/ 0.33fps/ 0.5fps/ 1fps/ 2fps/ 3fps/ 5fps/
6fps*/ 10fps*/ 12fps* (PAL model)/ 15fps*/ 30fps*
Default: 5fps
Note:
 • When"On"isselectedfor"H.264transmission",the
refresh interval may be longer than the set value
when any value with an asterisk (*) on the right is
selected.
[Image capture size (Initial display)]
Select the image capture size to display the JPEG
image on the "Live" page for the first time.
 • When"4:3"isselectedfor"Aspectratio"
QVGA/ VGA/ 1280 x 960*1
 • When"16:9"isselectedfor"Aspectratio"
320×180/ 640×360/ 1280 ×720*1
Default: 1280x960*1
VGA*2
*1
SP105
*2
SP102
Note:
 • i-PROSeriesdoesnotsupportaspectratioof
"16:9",ifnotspecified(asofOctober2010).
 • Imageadjustmentfunctionsareactivatedforthe
angleofviewintheaspectratioof4:3evenwhile
"16:9"isbeingselectedfor"Aspectratio".Area
masking under the backlight compensation (BLC)
function can be set only when the aspect ratio is
"4:3".
  Iftheaspectratioischangedto"16:9"aftersetting
of the backlight compensation function, the setting
of area masking is maintained.

20
20 21
[Image quality]
Specify the image quality of JPEG images.
0 Super fine/ 1 Fine/ 2/ 3/ 4/ 5 Normal/ 6/ 7/ 8/ 9 Low
Default: 5 Normal
Configure the settings relating to H.264 images [JPEG/H.264]
Click the [JPEG/H.24] tab on the "Image" page. (☞Pages13and14:Howtodisplay/operatethesetupmenu)
Configure the settings relating to H.264 image such as "Max bit rate (per client)*", "Image capture size", "Image
quality", etc. in this section.
Refer to page 19 for further information about the settings relating to JPEG images.
■H.264 (1) · H.264 (2)
[H.264 transmission]
Select"On"or"Off"todeterminewhetherornotto
transmit H.264 images.
On: Transmits H.264 images.
Off: Does not transmit H.264 images.
Default:On
Note:
 • When"On"isselectedfor"H.264transmission"in
"H.264(1)", displaying of H.264 images or JPEG
images on the "Live" page will be available.
 • When"On"isselectedfor"H.264transmission"in
"H.264(1)" and "H.264(2)", H.264 images are view-
able using other devices with each setting.
 • When"On"isselectedfor"H.264transmission"in
"H.264(1)" or "H.264(2)", the transmission interval of
JPEG images may sometimes become longer.
[Internet mode (over HTTP)]
Select"On"whentransmittingH.264imagesviathe
Internet. It is possible to transmit H.264 images without
changing the broadband router settings configured for
JPEG image transmission.
On: H.264 images will be transmitted using the HTTP
port. Refer to page 45 for further information about
the HTTP port number settings.
Off: H.264 images will be transmitted using the UDP
port.
Default:Off
